ON-VEHICLE SERVICE
TSB Revision
MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>
13A-1118
ON-VEHICLE SERVICE
COMPONENT LOCATION
M1131002100860
NAME
SYMBOL
NAME
SYMBOL
Accelerator pedal position sensor S
Fuel pump relay
R
Camshaft position sensor
O
Fuel tank differential pressure
sensor
U
Crankshaft position sensor
I
Fuel tank temperature sensor)
V
Cylinder 1, 4 heated oxygen
sensor (front)
L
Ignition coil
K
Cylinder 1, 4 heated oxygen
sensor (rear)
L
Injector
N
Cylinder 2, 3 heated oxygen
sensor (front)
L
Knock sensor
M
Cylinder 2, 3 heated oxygen
sensor (rear)
L
Malfunction Indicator Lamp
(SERVICE ENGINE SOON or
Check Engine Lamp)
Q
Data link connector
T
Manifold absolute pressure
sensor
B
Engine coolant temperature
sensor
D
Mass airflow sensor (with built-in
intake air temperature sensor)
G
Engine oil control valve
F
Multiport fuel injection (MFI) relay H
Engine oil pressure switch
F
Powertrain control module (PCM) P
Evaporative emission purge
solenoid
A
Power steering pressure switch
J
Evaporative emission ventilation
solenoid
W
Throttle actuator control motor
E
Exhaust gas recirculation (EGR)
valve
C
Throttle actuator control motor
relay
H
Fuel level sensor (main)
V
Throttle position sensor
E
Fuel level sensor (sub)
U
