MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE> 13A-602 STEP 7. Test the OBD-II drive cycle. Diagnostic Function − OBD-II Drive Cycle − Procedure 3 − Catalytic Converter Monitor . (2) Check the diagnostic trouble code (DTC). YES : Retry the troubleshooting. DTC P0431: Warm Up Catalyst Efficiency Below Threshold (cylinder 2, 3) . TECHNICAL DESCRIPTION • The signal from the rear heated oxygen sensor differs from the front heated oxygen sensor. That • The PCM compares the output of the front and rear heated oxygen sensor signals. . DESCRIPTIONS OF MONITOR METHODS Front and rear heated oxygen sensor rich/lean switching frequencies are nearly equal. . MONITOR EXECUTION Continuous . MONITOR EXECUTION CONDITIONS Other Monitor (There is no temporary DTC stored in memory for the item monitored below) • Heated oxygen sensor (front) monitor • Heated oxygen sensor (rear) monitor • Heated oxygen sensor heater (front) monitor • Heated oxygen sensor heater (rear) monitor • Misfire monitor • Fuel system monitor • Air/fuel ratio feedback monitor Sensor (The sensor below is determined to be normal) • Mass airflow sensor • Engine coolant temperature sensor • Intake air temperature sensor • Barometric pressure sensor • Throttle position sensor • Accelerator pedal position sensor . |
