TIMING BELT TSB Revision ENGINE OVERHAUL <3.8L ENGINE> 11D-14 3. Align the timing mark on the left bank camshaft sprocket with the timing mark on the rocker cover. 4. Align the timing mark on the right bank camshaft sprocket with the timing mark on the rocker cover. 5. Align the timing mark on the crankshaft sprocket with the timing mark on the oil pump case. 6. Install the timing belt on each sprocket and pulley in the following sequence. Do not leave the belt slack between (1) Crankshaft sprocket 7. Install special tool MD998767 to the tensioner pulley. While pushing the pulley lightly against the belt using the special Tightening torque: 48 ± 6 N⋅m (35 ± 4 ft-lb) AKX00640 TIMING MARKS LEFT RIGHT CAMSHAFT SPROCKET AB AKX00681AB TIMING MARK CRANKSHAFT MD998769 AKX00654AB MD998767 |
