CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-146

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

IGNITION
SWITCH (ACC)

WINDSHIELD WIPER
AND WASHER

ETACS-
ECU

JUNCTION
BLOCK

·AUDIO SYSTEM
·AUTOMATIC AIR
 CONDITIONING SYSTEM
·CONTROLLER
 AREA NETWORK(CAN)
·MANUAL AIR
 CONDITIONING SYSTEM
·MULTI-CENTER DISPLAY

RELAY
BOX

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-147

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

1

DATA LINK
CONNECTOR

JUNCTION BLOCK SIDE

KEEP
RELAY

CURRENT
DETECTION

POWER
SUPPLY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

(FUSE     )

22

JOINT
CONNECTOR (1)

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-148

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

BATTERY

IGNITION
SWITCH (IG1)

JUNCTION
BLOCK

JOINT
CONNECTOR (2)

JOINT
CONNECTOR (1)

RELAY
BOX

·FOG LIGHT
·HEADLIGHT
·TAILLIGHT, POSITION LIGHT,
 FRONT SIDE MARKER LIGHT
 AND LICENSE PLATE LIGHT
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER
 AND WASHER

·AUDIO SYSTEM
·AUTOMATIC AIR
 CONDITIONING
 SYSTEM
·CONTROLLER ARE
 NETWORK (CAN)
·FOG LIGHT
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEADLIGHT
·MANUAL AIR
 CONDITIONING SYSTEM
·MULTI-CENTER DISPLAY
·TAILLIGHT, POSITION LIGHT,
 FRONT SIDE MARKER LIGHT
 AND LICENSE PLATE LIGHT
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·VANITY MIRROR LIGHT
·WINDSHIELD WIPER
 AND WASHER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-149

JOINT
CONNECTOR (1)

(FUSE     )

22

COMBINATION
METER

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

ETACS-
ECU

JOINT
CONNECTOR (2)

(FUSE     )

23
