GENERAL DESCRIPTION

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-22

FRONT IMPACT SENSOR
INTERFACE CIRCUIT

FRONT
IMPACT
SENSOR
(LH)

FRONT
IMPACT
SENSOR
(RH)

SRS-ECU

GENERAL DESCRIPTION

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-23

SEAT BELT
SWITCH (DRIVER'S SIDE)
DETECTION CIRCUIT

SEAT BELT
SWITCH (PASSENGER'S SIDE)
DETECTION CIRCUIT

SEAT BELT
SWITCH
(DRIVER'S SIDE)

SEAT BELT
SWITCH
(PASSENGER'S SIDE)

SEAT
SLIDE
SENSOR

HALL IC

SEAT SLIDE SENSOR
DETECTION CIRCUIT

SRS-ECU

GENERAL DESCRIPTION

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-24

COMPONENT LOCATION

AC306289

AC307338

AC306418

AC305250

AC305035

OCCUPANT CLASSIFICATION SENSOR AND ECU

SIDE IMPACT SENSOR

FRONT IMPACT SENSOR

SEAT SLIDE SENSOR

FRONT IMPACT
SENSOR

CONDENCER
TANK

CENTER
PILLER

SIDE IMPACT
SENSOR

OCCUPANT
CLASSIFICATION-ECU

OCCUPANT
CLASSIFICATION SENSOR

AB

GENERAL DESCRIPTION

TSB Revision

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-25

NOTE: The illustration above shows the front impact sensor (LH) and the side impact sensor (LH). The posi-
tion of the front impact sensor (RH) and the side impact sensor (RH) is symmetrical to this.

AC306318

AC307339

AC305362

AC305028

DATA LINK CONNECTOR

SRS-ECU

SRS-ECU
