MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-1036 DIAGNOSIS Required Special Tools: • MB991958: Scan Tool (MUT-III Sub Assembly) • MB991824: V.C.I. • MB991827: USB Cable • MB991910: Main Harness A STEP 1. Measure the battery positive voltage. • The voltage is 8 volts or more. Q: Does the voltage remain greater than 8 volts while the engine is cranked? − Battery check STEP 2. Using scan tool MB991958, read the diagnostic CAUTION To prevent damage to scan tool MB991958, always turn the YES : Refer to Diagnostic Trouble Code Chart NO : Go to Step 3. AC305412 AB MB991910 DATA LINK CONNECTOR MB991824 MB991827 |
