MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-704 STEP 2. Check harness connector F-08 at the evaporative YES : Go to Step 3. . Then go to Step 12. STEP 3. Check the evaporative emission ventilation connector F-08. (2) Measure the resistance between evaporative emission ventilation solenoid side connector terminal No. 1 and No. Standard value: 17 − 21 ohms [at 20°C (68°F)] Q: Is the measured resistance between 17 and 21 ohms [at 20 °C (68°F)]? YES : Go to Step 4. 1 2 AK303150 CONNECTOR: F-08 AB EVAPORATIVE EVAPORATIVE F-08 (B) HARNESS 1 2 AK303150 CONNECTOR: F-08 AB EVAPORATIVE EVAPORATIVE F-08 (B) HARNESS 1 2 AK202969 EVAPORATIVE EMISSION AB |
