FRONT SUSPENSION –

General

33A-1

GROUP 33A

FRONT SUSPENSION

GENERAL

OUTLINE OF CHANGE

The coil spring has been changed as follows <1800,1900>.

COIL SPRING

Items

1800-M/T

1800-A/T,1900

Wire dia.

×

 O.D.

×

 free length mm

13

×

 160

×

 374

13

×

 160

×

 384

NOTES

REAR SUSPENSION –

General/Stabilizer Bar

34-1

GROUP 34

REAR SUSPENSION

GENERAL

OUTLINE OF CHANGES



The coil spring specifications have been changed.



The removal and installation procedures have been established due to the change of the stabilizer
bar mounting clamp.

COIL SPRING

Items

Specifications

Wire dia.

×

 O.D.

×

 free length   mm

10

×

86

×

414

STABILIZER BAR

The number of stabilizer bar mounting bolts has been changed from1 to 2. The procedures other than
those shown below are the same as before.

1

2

4

3

2

3

5

5

25 Nm

25 Nm

35 Nm

35 Nm

45 Nm

45 Nm

Removal steps

1. Stabilizer link
2. Clamp
3. Bushing
4. Stabilizer bar



A



5. Stabilizer bracket

NOTE
Points to note for installation are the same procedures as
before.
