DIAGNOSIS <TC-SST> TSB Revision TWIN CLUTCH- SPORTRONIC SHIFT TRANSMISSION (TC-SST) 22C-277 LOGIC FLOW CHARTS (Monitor Sequence) . DTC SET CONDITIONS Check Conditions • Voltage of battery: 8 V or more. • Voltage of battery: 16.5 V or less. JUDGMENT CRITERIA • FET (Field Effect Transistor) output: 1 V or more. (400 millisecond) . OBD-II DRIVE CYCLE PATTERN The FET channel output remains 1 V or less for 400 . PROBABLE CAUSES • Malfunction of TC-SST-ECU DIAGNOSTIC PROCEDURE STEP 1. Scan tool CAN bus diagnostics YES : Go to Step 2. − Troubleshooting .) After repairing the CAN bus line, go to Step 2. STEP 2. Check whether the DTC is reset. YES : Replace the TC-SST assembly. (Refer to NO : Intermittent malfunction. (Refer to GROUP 00 − How to Cope with Intermittent Malfunction .) AC710661 START No Good Malfunction END Monitoring condition met Continuous failure No Yes Yes Yes FET* output > 1 V No *FET : Field Effect Transistor |
