PRECAUTIONS BEFORE SERVICE

TSB Revision

GENERAL

00-47

4. Select "From 2006 MY" under "Model Year". Check that

"Vehicle Information" contents are correct.

5. Select "ETACS" from "System List", and then press

"OK" button.
NOTE: If "Loading Option Setup" list is shown, click
appropriate box.

6. Select "Coding."
7. Select "Option Coding."
8. Change to correct option coding data.

LIST

BOLTS AND NUTS WITH STABILIZER FOR
COEFFICIENT OF FRICTION

M1001014800082

The bolts and nuts with stabilizer for coefficient of friction have
been used for the connections such as the suspension arm and
crossmember in order to stabilize the axial force and to ensure
the high axial force at bolt/nut connections, resulting in
improved reliability.
NOTE: The bolts and nuts with stabilizer for coefficient of fric-
tion mean that the bolts and nuts with surface treatment to sta-
bilize and reduce the coefficient of friction, allowing to achieve
the stable axial force and to secure the high axial force with low
tightening torque.

Item name

Number of speaker

Seat material

Auto light control

AUDIO (CAN)

AND

HFM (hands free-ECU)

Rain Light Sensor

Front fog light

Rear fog light

Horn type

Manner switch

Remote engine starter

Wiper washer check bulb

Compressor type

Satellite Radio

DRL function

Keyless

TOWING AND HOISTING

TSB Revision

GENERAL

00-48

TOWING AND HOISTING

M1001000800755

WRECKER TOWING RECOMMENDATION

.

FRONT TOWING PICKUP

CAUTION

• The vehicle must not be towed by placing only its front

wheels on a rolling dolly, because to do so will result in
deterioration of the viscous coupling and in the vis-
cous coupling causing the vehicle to jump forward sud-
denly.

• If this vehicle is towed, use flat bed equipment

.

REAR TOWING PICKUP

CAUTION

• The vehicle must not be towed by placing only the rear

wheels on a rolling dolly, because to do so will result in
deterioration of the viscous coupling causing the vehi-
cle to jump forward suddenly.

• If this vehicle is towed, use flat bed equipment.

.

AC000070

SLING TYPE

WHEEL LIFT TYPE

FLAT BED TYPE

AI

NO

OK

NO

AC611522

SLING TYPE

WHEEL LIFT TYPE

FLAT BED TYPE

AC

OK

NO

NO

TOWING AND HOISTING

TSB Revision

GENERAL

00-49

TOWING WHEN KEYS ARE NOT AVAILABLE

When a locked vehicle must be towed and keys are not avail-
able, the vehicle may be lifted and towed from the front, pro-
vided the parking brake is released. If not released, the rear
wheels should be placed on a tow dolly.

.

SAFETY PRECAUTIONS

The following precautions should be taken when towing the
vehicle:

1. Do not lift or tow the vehicle by attaching to or wrapping

around the bumper.

2. Any loose, protruding, or damaged parts such as hoods,

doors, fenders, trim, etc. should be secured or removed
prior to moving the vehicle.

3. Refrain from going under a vehicle when it is lifted by the

towing equipment, unless the vehicle is adequately sup-
ported by safety stands.

4. Never allow passengers to ride in a towed vehicle.
5. State and local rules and regulations must be followed when

towing a vehicle.

TOWING AND HOISTING

TSB Revision

GENERAL

00-50

LIFTING, JACKING SUPPORT LOCATION

.

FLOOR JACK AND RIGID RACK

CAUTION

• Never place a support at any point other than the speci-

fied one, or that point will be deformed.

• For lifting, put rubber or similar material between the

side sill and rigid rack, otherwise the side sill area will
be damaged.

.

AC709513

FLOOR JACK

RIGID RACK

AB

<FRONT>

<REAR>

Center member

Differential carrier
assembly

Notch

Notch

Rubber

Rubber

<FRONT>

<REAR>
