AUTO-CRUISE CONTROL SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-289

NOTES

TIRE PRESSURE MONITORING SYSTEM (TPMS) <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-290

TIRE PRESSURE MONITORING SYSTEM (TPMS) <M/T>

M1901003900419

·ABS, ASC, ACD,
 AYC AND S-AWC
·AIR CONDITIONING
 SYSTEM
·DAYTIME RUNNING LIGHT
 (DRL)
·FOG LIGHT
·HEADLIGHT
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM
·KEYLESS OPERATING
 SYSTEM (KOS)
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING
 TONE ALARM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD
 WIPER AND WASHER

HEATED
SEAT

IG1
RELAY

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

36

RELAY BOX

ENGINE
COMPARTMENT

FUSIBLE
LINK

34

ETACS-
ECU

·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND OIL
 PRESSURE WARNING LIGHT
·DAYTIME RUNNING LIGHT (DRL)
·FOG LIGHT
·HEADLIGHT
·IMMOBILIZER SYSTEM
·KEYLESS OPERATION
 SYSTEM (KOS)
·METER AND GAUGE
·SEAT BELT WARNING
 TONE ALARM
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD
 WIPER AND WASHER

TIRE PRESSURE MONITORING SYSTEM (TPMS) <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-291

ANTENNA

TPMS
TRANSMITTER

TPMS
TRANSMITTER

FRONT TIRE (LH)

CONTROL CIRCUIT

·PRESSURE SENSOR
·ROLL SWITCH

·PRESSURE SENSOR
·ROLL SWITCH

·PRESSURE SENSOR
·ROLL SWITCH

·PRESSURE SENSOR
·ROLL SWITCH

ANTENNA

FRONT TIRE (RH)

CONTROL CIRCUIT

ANTENNA

REAR TIRE (LH)

TPMS
TRANSMITTER

TPMS
TRANSMITTER

ANTENNA

REAR TIRE (RH)

CONTROL CIRCUIT

CONTROL CIRCUIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

TIRE PRESSURE MONITORING SYSTEM (TPMS) <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-292

TIRE PRESSURE MONITORING (TPMS) <M/T> (CONTINUED)

<VEHICLES WITHOUT KOS>

JOINT
CONNECTOR
(6)

WIRELESS CONTROL
MODULE

CAN DRIVE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

(FUSE     )

12

(FUSE     )

8

ETACS-ECU

RECEIVER
ANTENNA
ASSEMBLY

RECEIVER
