TWIN CLUTCH SPORT SHIFT TRANSAXLE (TC-SST)

TSB Revision

CIRCUIT DIAGRAMS

90-89

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

FRONT SIDE

ETACS-ECU

(FUSE     )

5

ETACS-ECU

JOINT
CONNECTOR
(CAN3)

JOINT
CONNECTOR
(CAN2)

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU

HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-90

HEADLIGHT <HALOGEN TYPE>

M1901001503823

FUSIBLE
LINK

36

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
ASSEMBLY
(RH)

HEADLIGHT
RELAY
(LOW)

HEADLIGHT
RELAY
(HIGH)

FEELD EFFECT
TRANSISTOR

NOTE

:

RELAY BOX

ENGINE
COMPARTMENT

VEHICLES WITH
AUTOMATIC LIGHT

HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-91

(HEAD)

(TAIL)

(AUTO)

COLUMN SWITCH

JOINT
CONNECTOR
(2)

COLUMN-ECU

LIGHTING
SWITCH

DIMMER
SWITCH

(DIMMER)

(PASSING)

PASSING
SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

12

(FUSE     )

ETACS-ECU

ETACS-ECU

(FUSE     )

8

ETACS-ECU

LIN DRIVE
CIRCUIT

·ABS, ASC, ACD,
 AYC AND S-AWC
·AIR CONDITIONING
 SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·DOME LIGHT,
 LUGGAGE
 COMPARTMENT
 LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEATED SEAT
·IGNITION KEY
 REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
 SYSTEM (KOS)
·REAR WINDOW
 DEFOGGER
·SEAT BELT WARNING
 TONE ALARM
·SHIFT LOCK
 MECHANISM
·SUNROOF
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)
·TC-SST
·THEFT-ALARM
 SYSTEM
·TIRE PRESSURE
 MONITORING
 SYSTEM (TPMS)
·TRUNK LID OPENER

·AIR CONDITIONING
 SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT
 AND OIL PRESSURE
 WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·DOME LIGHT,
 LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·IGNITION KEY REMINDER
 TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATION
 SYSTEM (KOS)
·METER AND GAUGE
·SEAT BELT WARNING
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM
 (TPMS)
·TRUNK LID OPENER

HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-92

HEADLIGHT <HALOGEN TYPE> (CONTINUED)

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

34

FUSIBLE
LINK

ETACS-ECU

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)

FRONT SIDE

<VEHICLES WITH AUTOMATIC LIGHT>
