CHARGING SYSTEM <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-45

DATA LINK
CONNECTOR

FRONT
SIDE

JOINT
CONNECTOR
(CAN3)

JOINT
CONNECTOR
(CAN2)

(FUSE     )

5

ETACS-ECU

ETACS-ECU

(CAN DRIVE CIRCUIT)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CHARGING SYSTEM <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-46

CHARGING SYSTEM <M/T> (CONTINUED)

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

COMBINATION
METER

LED DRIVE
CIRCUIT

CAN
TRANSCEIVER
CIRCUIT

CPU

LCD (GENERATOR MALFUNCTION LIGHT)

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

HEATED
SEAT

GENERATOR
MALFUNCTION
LIGHT

JOINT
CONNECTOR
(CAN1)

JOINT
CONNECTOR
(CAN2)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

ETACS-
ECU

NOTE

:·ABS, ASC, ACD, AYC AND S-AWC

·AIR CONDITIONING SYSTEM
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·HEADLIGHT
·HEATED SEAT
·IGNITION KEY REMINDER TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING SYSTEM (KOS)
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT, LICENSE
 PLATE LIGHT AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM (TPMS)
·TRUNK LID OPENER
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

CHARGING SYSTEM <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-47

NOTES

CHARGING SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-48

CHARGING SYSTEM <TC-SST>

M1901000703501

FUSIBLE
LINK

33

FUSIBLE
LINK

36

STATOR
COIL

STATOR
COIL

FIELD
COIL

IC VOLTAGE REGULATOR

ENGINE CONTROL
MODULE

ENGINE
COMPARTMENT

RELAY BOX

GENERATOR
