GROUP 16

ENGINE

ELECTRICAL

CONTENTS

STARTER MOTOR  . . . . . . . . . . . . . .

16-2

ALTERNATOR . . . . . . . . . . . . . . . . . .

16-3

IGNITION COIL . . . . . . . . . . . . . . . . . .

16-4

SPARK PLUG . . . . . . . . . . . . . . . . . . .

16-4

STARTER MOTOR

TSB Revision

ENGINE ELECTRICAL

16-2

STARTER MOTOR

M2161002000416

The starter motor is a reduction drive planetary gear type.

AK603841

ALTERNATOR

TSB Revision

ENGINE ELECTRICAL

16-3

ALTERNATOR

M2162001000342

The new generation alternator is used to reach the high output
and the high efficiency, also to reduce the noise.
The major characteristics are as follows:

• Circuit structure for new generation.

Reduction in magnetic noise and nipple.

• Higher performance of stator.

Higher output and higher efficiency.

• New generation of rectifier:

Improves the coolability by the larger heat sink and accepts
the higher output.

The pulley with one-way clutch is used.

AK703273

Rectifier

A

A

AC

A–A

Pulley

Stator

Stator

Pulley

Rectifier

Circuit diagram
