DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-41 STEP 9. Check the wiring harness between joint connector CAUTION A digital multimeter should be used. For details refer to CAUTION The test wiring harness should be used. For details refer to (1) Disconnect joint connector (CAN4), and check that there is continuity at the harness side of joint connector (CAN4). (2) Check that there is continuity between joint connector (CAN4) terminals 6 and 19. OK: No continuity Q: Is the check result normal? YES : Go to Step 10. STEP 10. Check the wiring harness between joint CAUTION A digital multimeter should be used. For details refer to CAUTION The test wiring harness should be used. For details refer to Disconnect joint connector (CAN3) and Disconnect joint con- (CAN3) terminals 5 and 16. OK: No continuity Q: Is the check result normal? YES : Check intermediate connector A-13, and repair if necessary. If the intermediate connector is in good NO : Check intermediate connector C-131, and repair if necessary. If the intermediate connector is in good AC709707 Harness side: A-14 AN TEST TEST AC709707 Harness side: C-127 AO TEST TEST |
