Mitsubishi Lancer Evolution IX. Manual - part 371
ACX00571
M.U.T.-II connected
Within 10 seconds
Hazard
warning
switch
ON
OFF
1
2
3
4
5
6
AB
KEYLESS ENTRY SYSTEM
BODY
42-45
4. Press the hazard warning switch six times within
10 seconds.
NOTE: Once the process is completed six times,
then it will operate with all doors lock and unlock
operations once and then go to the save mode.
NOTE: The hazard warning lamp switch is turned
on and off alternately whenever it is pushed.
5. Press the transmitter switch, and then press it two
times within 10 seconds of the first press. This will
register the code.
6. Once the program is saved, it will operate once
with the all doors lock and unlock operations.
7. If you are using two or more transmitters or have
added a second transmitter, the next transmitter
should be registered within one minute after
registering the code for the previous transmitter.
The registration procedure is common for all the
transmitters.
8. Registration mode will be cancelled under the
following conditions:
• When the secret code for four transmitters has
been registered;
• When passing one minute after finishing the reg-
istration of all transmitters;
• When the M.U.T.-II is disconnected from the diag-
nosis connector;
• When the key is removed from the key cylinder;
• When no secret codes have been registered for
more then one minute after the registration mode
is entered;
9. After the registration is completed, remove the
ignition key and close all the doors, and then
check that the keyless entry system operates
normally.
WHEN THE SPECIAL TOOL V.C.I.
(MB991824) IS USED
1. Check that the doors lock normally when the key
is used.
2. Insert the ignition key.
CAUTION
Before connecting or disconnecting the V.C.I.,
turn the ignition switch to the "LOCK" (OFF)
position.
AC309970
AC211686
AC
MB991911
MB991824
16-Pin
3. Connect the V.C.I. to the diagnosis connector.
ACX00571
Within 10 seconds
Hazard
warning
lamp
switch
ON
OFF
1
2
3
4
5
6
AQ
V.C.I. connected
4. Press the hazard warning lamp switch six times
within 10 seconds.
NOTE: Once the process is completed six times,
then it will operate with all doors lock and unlock
operations once and then go to the save mode.
NOTE: The hazard warning lamp switch is turned
on and off alternately whenever it is pushed.
5. Press the transmitter switch, and then press it two
times within 10 seconds of the first press. This will
register the code.
6. Once the program is saved, it will operate once
with the all doors lock and unlock operations.
