HEADLAMP LEVELLING SYSTEM
CIRCUIT DIAGRAMS
90-95
TAIL LAMP
RELAY
RELAY
BOX
IGNITION
SWITCH (IG2)
BATTERY
HEADLAMP
LEVELLING
SWITCH
TAIL LAMP,
POSITION LAMP,
LICENCE PLATE LAMP
AND LIGHTING
MONITOR BUZZER
POWER
SOURCE
·ACD AND AYC
·AUDIO SYSTEM SPARE CONNECTOR
·AUTOMATIC AIR CONDITIONER
·BRAKE WARNING LAMP,
OIL PRESSURE WARNING LAMP
AND FUEL WARNING LAMP
·CENTRAL DOOR LOCKING SYSTEM
·CLOCK
·HEADLAMP
·METER AND GAUGE
·POWER WINDOWS
·REAR FOG LAMP
·ROOM LAMP, LUGGAGE
COMPARTMENT LAMP, IGNITION KEY
CYLINDERILLUMINATION LAMP AND
DOOR AJAR WARNING LAMP
·TAIL LAMP, POSITION LAMP,
LICENCE PLATE LAMP AND
LIGHTING MONITOR BUZZER
·TURN-SIGNAL LAMP AND
HAZARD WARNING LAMP
·WINDSHIELD WIPER AND WASHER
·AUTOMATIC AIR
CONDITIONER
·COOLING SYSTEM
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet PU : Purple
RELAY
BOX
