Mitsubishi Lancer Evolution IX. Manual - part 26

REAR FOG LAMP

CIRCUIT DIAGRAMS

90-83

POWER

SOURCE

ETACS-ECU

ETACS-ECU

IGNITION
SWITCH (IG2)

IGNITION
SWITCH (IG1)

LIGHTING
SWITCH

COLUMN
SWITCH

COLUMN-ECU

·AUTOMATIC AIR
 CONDITIONER
·COOLING SYSTEM

·ACD AND AYC
·ANTI-SKID BRAKING
 SYSTEM (ABS)
·BRAKE WARNING
 LAMP, OIL PRESSURE
 WARNING LAMP
 AND FUEL
 WARNING LAMP
·CHARGING SYSTEM
·ENGINE CONTROL
 SYSTEM
·ENGINE OIL LEVEL
 WARNING LAMP
·METER AND GAUGE
·SUPPLEMENTAL
 RESTRAINT SYSTEM
 (SRS)
·WINDSHIELD WIPER
 AND WASHER

·AUTOMATIC AIR
 CONDITIONER

REAR FOG LAMP

CIRCUIT DIAGRAMS

90-84

REAR FOG LAMP <RH drive vehicles> (CONTINUED)

J/C (1)

FUSIBLE
LINK

1

J/B

ETACS-ECU

POWER
SOURCE

DIAGNOSIS
CONNECTOR

FRONT SIDE

J/B SIDE

2

(FUSE     )

REAR FOG LAMP

CIRCUIT DIAGRAMS

90-85

NOTES

ROOM LAMP, LUGGAGE COMPARTMENT LAMP, IGNITION KEY CYLINDER ILLUMINATION LAMP AND DOOR AJAR WARNING LAMP

CIRCUIT DIAGRAMS

90-86

ROOM LAMP, LUGGAGE COMPARTMENT LAMP, IGNITION KEY

CYLINDER ILLUMINATION LAMP AND DOOR AJAR WARNING LAMP

ROOM LAMP, LUGGAGE COMPARTMENT LAMP, IGNITION KEY CYLINDER ILLUMINATION LAMP

AND DOOR AJAR WARNING LAMP <LH drive vehicles>

M1901024000013

IGNITION
SWITCH (ACC)

RELAY
BOX

ETACS-ECU

COMBINATION
METER

KEY REMINDER
SWITCH

REAR
ROOM
LAMP

IGNITION KEY
CYLINDER
ILLUMINATION
LAMP

INTERIOR LAMP AUTOMATIC

SHUTDOWN BACK-UP CIRCUIT

·AUDIO SYSTEM
 SPARE CONNECTOR
·CLOCK

J/B SIDE
