INSPECTION TERMINAL

TSB Revision

COMPONENT LOCATIONS

70-3

IN SPEC TIO N  TER M INA L

M1701000200097

NAME

SYMBOL NAME

SYMBOL

Data link connectorB

Inspection connector

A

AC003120AC

A

B

ACX02446AB

INSPECTION
CONNECTOR

BATTERY

A

ACX02447AE

ACCELERATOR
PEDAL

DATA LINK
CONNECTOR(2)

DATA LINK
CONNECTOR(1)

B

GROUNDING

TSB Revision

COMPONENT LOCATIONS

70-4

G R O U N D IN G

M1701000300083

NOTE: 1 to 17 numbers correspond to the body ground point numbers in CIRCUIT DIAGRAMS.

AC003121

AB

1

2

4

5

6

7

8

9

10

11

12

13

14

15

16

17

3

1

2

4

5

6

7

3

17

10

11

12

13

14

15

16

<ECLIPSE>

<ECLIPSE SPYDER>

GROUNDING

TSB Revision

COMPONENT LOCATIONS

70-5

AC003111

1

AB

HEADLIGHT (RH)

ACX02449AB

FRONT
DECK

2

ACX02450

3

AB

BLOWER
ASSEMBLY

ACX02451AB

4

<2.4L ENGINE>

ACX02452

4

AB

<3.0L ENGINE>

ACX02453AB

ENGINE CONTROL
MODULE OR
POWERTRAIN
CONTROL MODULE

5

ACX02454 AC

FRONT SEAT BELT
RETRACTOR (RH)

6

<ECLIPSE>

AC003104

6

AB

FRONT SEAT BELT
RETRACTOR (RH)

<ECLIPSE SPYDER>

GROUNDING

TSB Revision

COMPONENT LOCATIONS

70-6

ACX02455

7

AD

<ECLIPSE>

INSIDE
REAR VIEW
MIRROR

AC003103

7

AB

INSIDE
REAR VIEW
MIRROR

<ECLIPSE SPYDER>

AC003108 AB

8

FRONT
SEAT BELT (LH)

AC003107

9

AB

LIFTGATE

ACX02456

10

AD

AC003109AB

HEADLIGHT (LH)

11

ACX02458

12,13

12

13

AD

BATTERY

ACX02459AC

14

CENTER
REINFORCEMENT
