Mitsubishi Eclipse. Technical Information Manual (1994) - part 2

GENERAL - Technical Features

TECHNICAL FEATURES

BODY DIMENSIONS

External Dimensions

Internal Dimensions

N70ADO2AA

5, 6

00X0081

Items

No.

New model

mm (in.)

Difference between

previous and

new models

Overall Length

4,375 (172.2)

-15 (-59)

Overall Width

1,735 (68.3)

1,745 (68.7)*’

+40 (+1.57)

+50 (+1.97)“’

External

dimensions

Overall Height

Wheelbase

Tread (front)

Tread (rear)

Overhang (front)

Overhang (rear)

1,295 (51.0)

1,310 (51 .6)*2

-11 (-.43)

-4 (-. 15)*2

2,510 (98.8)

+40 (+1.57)

1,515 (59.6)

+50

(+1.97)

1,510 (59.4)

+60 (+2.36)

930 (36.6)

-45 (-1.77)

935 (38.8)

-10 (-.39)

NOTES
*l denotes a vehicles with side air dam.
*2 denotes AWD.

GENERAL - Technical Features

o-5

Items

No.

New model

Difference between

previous and

new models

Head Room 8 (front)

860 (33.9)

Head Room 8 (rear)

785 (30.1)

Internal

Brake Pedal Room

940 (37.0)

+15 (+.59)

dimensions

Hip Point Couple

635 (25.0)

Front Hat Room

1,080 (41.7)

Front Hip Point Couple

714 (28.1)

AERODYNAMIC CHARACTERISTICS

Many Cd reduction design features, including taper-
ing at body corners, has raised ECLIPSE’s aerody-

N70ADOUA

namic characteristics to the top level of the class
(Cd = 0.29).

18X0646

Tapered front side corners
Tapered rear pillar area
Tapered rear side corners

and rounded engine hood

Smaller rear window inclination

angle for smoother air flow

Venturi skirt
Smoother and more flush under-

floor surface

Raised rear floor plane

Greater contribution to fuel econo-

O-6

GENERAL - Technical Features

ENGINE

N70AEOOAA

Two basic DOHC engines are available.

420A Engine

On non-turbocharged models, the Chrysler-
manufactured 2.0 lit. DOHC 16-valve engine in-
creases domestic parts content. The engine and

transaxle unit, unlike the conventional MMC engine,

is arranged with the engine on the passenger side

and the transaxle on the driver’s side.

4G63 Engine

On turbocharged models, new techniques and im-
provements have been embodied in the 4G63 en-

N70AEOlAA

gine to provide better performance and lower fuel
consumption.

NEW TECHNIQUES AND IMPROVEMENTS

Aims

Items

Smaller size

Higher

Higher de-

Tighter ex-

performance Less noise

Resource

pendability

haust emis-

and lighter

and

and energy

and easier

sion control

weight

efficiency

saving

mainte-

and better

nance

driveability

Higher compression ratio

Better turbocharger performance

Small-size pressure type Karman air

flow sensor adopted

Higher intercooler efficiency

Cylinder head intake port is tumble-

type

2-spray injector adopted

Optimized injector direction and tim-
ing

Engine coolant temperature inlet

control system

48 Kbyte computer adopted

Resonance type knock sensor

adopted

Stainless steel exhaust manifold
adopted

Dual oxygen sensor system

adopted

Oxygen sensor mounted to front ex-
haust pipe

Piston top land height reduced

ECM-controlled EGR adopted

ECM-controlled fuel vapor control

system adopted

Generator control improved

NOTE:

x Applicable

GENERAL - Technical Features

Aims

Higher per-

formance

and

efficiency

Higher

Tighter

Resource

pendability haust

Less noise

and energy

and easier

sion control

saving

and better

driveability

Items

Smaller size

and lighter

weight

Cooling fan controlled by ECM
(Total Control System)

Integrated control of A/T

Higher accuracy coolant tempera-

ture sensor

Crank angle sensor using Hall
directly mounted to crankshaft

Cylinder block reinforced

Turbocharger piping revised

Small-size and light-weight air
cleaner made of resin which allows

the air to pass with less resistance

Dual mode damper

Air bypass valve position optimized

Power steering belt changed to V
ribbed style

Oil level gauge grip changed to

resin

Scan tool (MUT-II) compatible

VOTE:
x Applicable
