STABILIZER BAR FRONT SUSPENSION 33-18 STABILIZER BAR REMOVAL AND INSTALLATION M1332004000297 CAUTION • Before removing the steering wheel and air bag module assembly, refer to GROUP 52B − Service Precautions ( ) and Air Bag Module and Clock Spring ( ). Also, put the front wheels in straight-ahead position. Failure to do so may damage the SRS clock spring and render • * : Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. Stabilizer Bar Pre-removal Operation On-Vehicle Service − Fluid Replacement ). • Front Under Cover Removal. • Centermember Removal (Refer to GROUP 32, Engine Roll Stopper, Centermember ). • Lower Arm Assembly Removal (Refer to • Air Bag Module Assembly, Steering Damper and Steering Wheel Assembly Removal (Refer to GROUP 37, Steering • Floor Console Assembly Removal (Refer to GROUP 52A, Floor Console Assembly • Front Scuff Plate and Cowl Side Trim Removal (Refer to GROUP 52A, Trims ). • Trunk Lid Opener Cover Removal • Accelerator Pedal Stopper Removal Stabilizer Bar Post-installation Operation with your finger. • Floor Carpet Installation • Trunk Lid Opener Cover Installation • Accelerator Pedal Stopper Installation GROUP 52A, Trims ). • Floor Console Assembly Installation (Refer to GROUP 52A, Floor Console Assembly ). • Steering Wheel Assembly, Steering Damper and Air Bag Module Assembly Installation (Refer to GROUP 37, Steer- ). • Checking Steering Wheel Position with Wheels Straight Ahead • Lower Arm Assembly Installation (Refer to ). • Centremember Installation (Refer to GROUP 32, Engine ). • Front Wheel Alignment Check and Adjustment (Refer to ). • Front Under Cover Installation. • Power Steering Fluid Supplying (Refer to GROUP 37, On-Vehicle Service − Fluid Replacement ). • Power Steering Fluid Line Bleeding (Refer to GROUP 37, On-Vehicle Service − Power Steering System Air Bleeding |
