MULTIPORT FUEL INJECTION (MPI) DIAG
MULTIPORT FUEL INJECTION (MPI)
13A-460
STEP 7. Using diagnostic tool , read the diagnostic trouble
code (DTC).
CAUTION
To prevent damage to diagnostic tool , always turn the
ignition switch to the "LOCK"(OFF) position before con-
necting or disconnecting diagnostic tool .
(1) Connect diagnostic tool to the data link connector.
(2) Turn the ignition switch to the "ON" position.
(3) After the DTC has been deleted, read the DTC again.
(4) Turn the ignition switch to the "LOCK"(OFF) position.
Q: Is DTC P2100 set?
YES : Then go to Step 8.
NO : It can be assumed that this malfunction is intermittent.
Refer to GROUP 00, How to Use
Troubleshooting/Inspection Service Points
− How to
Cope with Intermittent Malfunctions
P.00-14
.
STEP 8. Using diagnostic tool , read the diagnostic trouble
code (DTC).
(1) Connect diagnostic tool to the data link connector.
(2) Turn the ignition switch to the "ON" position.
(3) After the DTC has been deleted, read the DTC again.
(4) Turn the ignition switch to the "LOCK"(OFF) position.
Q: Is DTC P2100 set?
YES : Retry the troubleshooting.
NO : The inspection is complete.
00DB076A
MB991910
DATA LINK
CONNECTOR
MB991824
MB991827
00DB076A
MB991910
DATA LINK
CONNECTOR
MB991824
MB991827
