DASH PANEL

CONFIGURATION DIAGRAMS

80-16

37DB231A

STEERING COLUMN

Connector

symbol

C

CLOCK

SPRING

CLOCK SPRING

WIRING HARNESS

Y

INSTRUMENT PANEL

WIRING HARNESS

C-301

C-302

C-303

C-304

C-305

C-306

C-307

C-308

C-309

C-310

C-311

C-301 ->  C-311

C-301 (2-B)

REMOTE CONTROLLED RADIO
SWITCH (RH)

C-302 (3-Y)

AUTO-CRUISE CONTROL SWITCH

C-303 (5-GR)

CLOCK SPRING AND CLOCK
SPRING WIRING HARNESS
COMBINATION

C-304 (1)

HORN SWITCH

C-305 (2-Y)

AIR BAG MODULE (SQUIB)
(DRIVER’S SIDE)

C-306 (6)

CLOCK SPRING

C-307 (4-Y)

CLOCK SPRING

C-308 (6)

IGNITION SWITCH

C-309 (10)

COLUMN SWITCH

C-310 (7)

KEY REMINDER SWITCH

C-311 (2-B)

REMOTE CONTROLLED RADIO
SWITCH (LH)

FLOOR, SEAT AND ROOF

CONFIGURATION DIAGRAMS

80-17

FLOOR, SEAT AND ROOF

M1801000900930

37DB232A

CONNECTOR COLOR

CODE

B: BLACK

BR: BROWN

G: GREEN

GR: GRAY

L: BLUE

NONE: MILK WHITE

O: ORANGE

R: RED

V: VIOLET

Y: YELLOW

Connector

symbol

D

FLOOR

WIRING

HARNESS

4

Y

2

15

D-01

D-02

D-03

D-04

D-05

D-24

D-25

D-28

D-32

D-33

D-34

D-35

D-36

ROOF

WIRING

HARNESS

D-07

D-38

D-39

D-01  ->

D-26

D-27

D-13

D-15

D-14

D-01

(2)

VANITY MIRROR LIGHT (RH)

D-02

(4)

MAP LIGHT ASSEMBLY <WITHOUT
SUNROOF>

D-03

(7)

OVERHEAD CONSOLE ASSEMBLY
<WITH SUNROOF>

D-04

(10)

SUNROOF ASSEMBLY

D-05

(2)

VANITY MIRROR LIGHT (LH)

D-06

(3)

REAR DOOR SWITCH (RH)

D-07

(3)

REAR DOME LIGHT

D-09

(2)

REAR SPEAKER (RH)

D-10

(2)

TRUNK LAMP

D-11

(1)

DEFOGGER (CHOKE COIL)

D-12

(2)

REAR SPEAKER (LH)

D-13

(1-B)

PARKING BRAKE SWITCH

D-14

(6)

A/T SHIFT SWITCH AND SELECT
POSITION ILLUMINATION LIGHT

D-15

(2)

SUB WIRING HARNESS FOR
ACCESSORY SOCKET (2)

D-16

(3)

REAR DOOR SWITCH (LH)

D-17

(2)

FUEL LEVEL SENSOR (SUB)

D-18

(5-GR)

FUEL PUMP MODULE

D-19

(10)

FLOOR WIRING HARNESS AND
REAR DOOR WIRING HARNESS
(LH) COMBINATION

D-20

(2)

SIDE IMPACT SENSOR (LH)

D-21

(2-B)

SEAT BELT PRETENSIONER (LH)

D-22

(3)

FRONT DOOR SWITCH (LH)

D-24

(2-R)

SIDE AIR BAG MODULE (SQUIB)
(LH)

FLOOR, SEAT AND ROOF

CONFIGURATION DIAGRAMS

80-18

D-25-6 (10)

D-25-9

D-25-11

D-25-2

D-25-3

D-38

D-25-13

D-25

D-25-4

D-25-7

D-25-12

D-25-5

D-25-8

D-25-10

   M.S.C

D-25-1

Connector
symbol

D

 D-25  ->

37DB240A

RHS. DRIVER SEAT
       (MEMORY)

D-25-14 (8)
MEMORY

D-25

(2-B)

POWER SEAT ASSEMBLY

D-25-1

(5-W)

FRONT HEIGHT MOTOR

D-25-2

(5-B)

REAR HEIGHT MOTOR

D-25-3

(4)

SEAT SLIDE MOTOR

D-25-4

(5)

SEAT BACK RECLINING MOTOR

D-25-5

(2)

SEAT BACK LUMBAR MOTOR

D-25-6

(10)

SEAT ADJUST SWITCH (RH) <WITH
MEMORY> AND <NON MEMORY
WITH POWER RECLINER>

D-25-7

(7)

MEMORY BUTTON SWITCH

D-25-8

(4)

SEAT BACK LUMBAR
POTENTIOMETER

D-25-9

(20)

MEMORY SEAT MODULE

D-25-10

(16)

MEMORY SEAT MODULE

D-25-11

(12)

MEMORY SEAT MODULE (LUMBAR
AND RECLINER)

D-25-12

(12-W) MEMORY SEAT MODULE

D-25-13

(4)

LUMBAR ADJUST SWITCH

D-25-14

(8)

LUMBAR AND RECLINER PATCH
HARNESS AND SEAT CUSHION
PAD HARNESS COMBINATION
<WITH MEMORY>

D-25-15

(4)

LUMBAR AND RECLINER PATCH
HARNESS AND SEAT CUSHION
PAD HARNESS COMBINATION
<WITHOUT MEMORY>

D-25-16

(4)

SEAT ADJUST SWITCH <NON
MEMORY WITHOUT POWER
RECLINER>

FLOOR, SEAT AND ROOF

CONFIGURATION DIAGRAMS

80-19

D-25-6 (10)

D-25-2

D-25-3

D-38

D-25-4

D-25-1

Connector
symbol

D

37DB242A

RHS. DRIVER SEAT
          (8-WAY)

D-25-15 (4)
NON-MEMORY
RECLINER ONLY
