AUTO-CRUISE CONTROL ENGINE AND EMISSION CONTROL 17-33 STEP 6. Measure the voltage at stop lamp switch (1) Disconnect stop lamp switch connector C-127. (2) Measure the voltage between stop lamp switch connector C-127 terminal No.2 and earth. OK: System voltage (3) Connect stop lamp switch connector C-127. Q: Is the check result normal? YES : Go to Step 10. NO : Go to Step 7. STEP 7. Connectors check: C-127 stop lamp Q: Is the check result normal? YES : Go to Step 8. NO : Repair or replace the damaged AC311916 Connector: C-127 AB C-127 AC305712AE C-127 harness AC311916 Connector: C-127 AB C-127 AC311915AB Connector: C-125 C-125 |
