DIAGNOSIS CONTROLLER AREA NETWORK (CAN) 54D-322 disconnected. (4) Resistance between A-16 intermediate connector terminal Nos. 6 and 12 OK: 120 ± 20 Ω Q: Is the check result normal? YES : <Within 120 ± 20 Ω> Go to Step 33 . NO : <Not within 120 ± 20 Ω> Go to Step 30 . STEP 30. Connector check: C-112 engine-ECU CAUTION The strand end of the twist wire should be within Q: Is the check result normal? YES : Go to Step 31. NO : Repair the defective connector. STEP 31. Resistance measurement at the A-16 CAUTION A digital multimeter should be used. For details . CAUTION The test wiring harness should be used. For (1) Disconnect the engine-ECU <M/T> or engine-A/T-ECU <A/T> connector and the (2) Ignition switch: OFF (LOCK) CAUTION When measuring the resistance, disconnect the (3) Ensure that the negative battery terminal is AC204740 AC204740 AC204740 AC204740DM Male side: A-16 Test Test AC310615 AS Harness side Connector: C-112 <LHD> C-112 (GR) 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 AC310403 AC Connector: A-16 <LHD> A-16 (B) AC310615 AS Harness side Connector: C-112 <LHD> C-112 (GR) 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 |
