INPUT SIGNAL PROCEDURES SMART WIRING SYSTEM (SWS) USING SWS MONITOR 54C-542 Step 8. Check the wiring harness from D-26 seat NOTE: Prior to the wiring harness inspection, check • Check the input line for open circuit. Q: Is the check result normal? YES : Go to Step 9. NO : Repair the wiring harness. Step 9. ETACS switch data by using the SWS Check the input signal from the driver's seat belt • Ignition switch: ON • Driver's seat belt switch: ON (Unfastened) → OFF (Fastened) OK: Normal condition is displayed. Q: Is the check result normal? YES : The trouble can be an intermittent malfunction (Refer to GROUP 00 − How to Cope with Intermittent Malfunction NO : Go to Step 10. Step 10. Retest the system. After the ETACS-ECU is replaced, check that the received. Q: Is the check result normal? YES : The trouble can be an intermittent malfunction (Refer to GROUP 00 − How to Cope with Intermittent Malfunction NO : Replace the combination meter. AC312031 Connector: C-02 <LHD> AK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 23 24 25 26 27 28 29 30 31 32 33 34 35 36 2221 AC312058 Harness side AC Connector: D-26 <RHD> AC312043 Connector: C-16 <RHD> AH 9 21 33 35 24 12 3 4 7 8 5 6 39 28 41 30 18 4243 31 1920 32 40 29 1617 38 27 15 37 36 26 14 13 25 2 1 34 23 11 10 22 Item No. Item name Normal Item 12 SEAT BELT SW from ON |
