SPLICE NUMBER

LOCATION

FIG.

S210

Near Radio

21

S211

Near Heater Timer-Auxiliary

21

S212

Near Security System Module

50

S213

Instrument Panel

18, 50

S214

Near Security System Module

18

S215

Instrument Panel

18

S216

Instrument Panel

18

S217

Near Engine Control Module

18

S218

Instrument Panel

21

S219

Instrument Panel

18

S220

Near Central Timer Module

18

S221

Instrument Panel

18

S222

Near Security System Module

18

S223

Instrument Panel

18

S224

Instrument Panel

18

S225

Instrument Panel

18

S226

Near Turn Signal/Anti-Theft Alarm Relay-Left

18

S227

Near Sentry Key Remote Entry Module

18

S228

Instrument Panel

18

S229

Near C202

9

S230

Center Instrument Panel

23, 25

S231

Left Plenum

27

S232

Left Plenum

27

S250

Near Turn Signal/Anti-Theft Alarm Relay-Left

18

S251

Near Trailer Tow Control Module

9

S252

Near Trailer Tow Control Module

21

S253

Instrument Panel

21, 22

S254

Near Interior Lamp No.5

9

S255

Near Control Timer Module

27

S256

Near A/C Roof-Switch

18, 21

S257

Near Data Link Connector

18

S258

Near Transmission Control Module

18

S259

Under Drivers Seat

18

S260

Under Drivers Seat

18

S261

Near Data Link Connector

18

S262

Under Drivers Seat

18

S299

Instrument Panel

N/S

S300

Near Heated Seat Switch-Driver

21

S301

Near Heated Seat Switch-Passenger

21

S302

Under Drivers Seat

18

S303

Near Power Window Switch-Driver

21

S304

Near Power Window Motor-Driver

21

S305

Near Power Window Motor-Driver

21

VA

8W-91 CONNECTOR/GROUND/SPLICE LOCATION

8W - 91 - 11

SPLICE NUMBER

LOCATION

FIG.

S306

Near Locker Switch No.2

18

S307

Near Fuse/Relay Block

18

S308

Near Interior Lamp No.3

50

S309

Near Interior Lamp-Right

50

S310

Near Fuse Block No.2

18, 21

S311

Under Drivers Seat

18

S312

Near Wheel Speed Sensor-Left Rear

47

S313

Near Wheel Speed Sensor-Left Rear

47

S314

Near Wheel Speed Sensor-Right Rear

47

S315

Near Wheel Speed Sensor-Right Rear

47

S316

Near Headlamp Assembly-Left

18

S317

Under Drivers Seat

18

S318

Near Marker Lamp-Left Rear

7

S319

Near Tail Lamp Assembly-Left

7

S320

Under Body-Rear Center

7

S321

Near Power Window Switch-Passenger

23, 25

S322

Instrument Panel

18

S323

Near Brake Wear Sensor-Left Rear

47

S324

Near Interior Lamp No.3

N/S

S325

Near Map/Reading Lamp Switch

21

S326

Top Body- Front Center

42

S327

Near Security System Module

18

S328

Near Central Timer Module

18

S329

Near Central Timer Module

18

S330

Near Security System Module

18

S331

Near Security System Module

18

S332

Near Brake Wear Sensor-Left Rear

47

S333

Instrument Panel

18

S350

Near Trailer Tow Connector

18

S351

Near Trailer Tow Control Module

18

S352

Near Trailer Tow Control Module

18

S353

Near Dome Lamp

21

S354

Body-Upper Right Center

42, 50

S355

Near Window Defogger Module-Rear

18, 23

S356

Near Headlamp Assembly-Left

18

S357

Near Central Timer Module

23

S358

Near Trailer Tow Control Module

18

S359

Near Interior Light Switch-Passenger

9

S360

Near Interior Light Switch-Rear

9

S361

Near Time Delay Relay

18

S362

Near Circulation Pump Diode

18

S363

Near Heated Seat Module-Passenger

47

S364

Near CTEL Connector

21

8W - 91 - 12

8W-91 CONNECTOR/GROUND/SPLICE LOCATION

VA

SPLICE NUMBER

LOCATION

FIG.

S365

Near A/C Fan Switch

21

S366

Near Heated Seat Module-Driver

18

S375

Under Driver Seat

23

S376

Above pedals

24

S377

Front Center Headliner

24

S378

Left Plenum

27

VA

8W-91 CONNECTOR/GROUND/SPLICE LOCATION

8W - 91 - 13

Fig.

1

ENGINE

COMP

AR

TMENT

-

LEFT

FRONT
