Fig. 602: Identifying Wiring Harness Repair Kit, Basic (000 589 13 99 00)

Fig. 603: Identifying Wiring Harness Repair Kit (220 589 02 99 00)

Fig. 604: Identifying Unlocking Device With RK 1.5 Ejector (220 589 01 99 20)

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis

Unpin contact pins from the plug (LKS 1.5)

1. Insert release tool, with RK 1.5

ejector, into the contact cavity of the plug (1) from the front end.

Applying high pressure could break the webs of the contact cavities.

In this step, the sleeve (3) of the release tool with RK 1.5 ejector

compresses the spring tabs on the

contact pin (2).

Fig. 605: Contact Pins From Plug (LKS 1.5)

2. Press the contact-pin (2) from its seat in the housing using the plunger (4) on the release tool with RK 1.5

ejector against the spring force of the tool.

3. Gently pull the respective line to remove the contact pin (2) from the plug (1).

REMOVE CONTACTS FROM SIEMENS ELO COUPLING - AR00.19-P-0120-23A

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis

Fig. 606: Identifying Wiring Harness Repair Kit, Supplement For Passenger Cars (220 589 04 99 00)

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis

Fig. 607: Identifying Wiring Harness Repair Kit, Basic (000 589 13 99 00)

Fig. 608: Identifying Wiring Harness Repair Kit (220 589 02 99 00)
