Mercedes-Benz ML320. Manual - part 512

In areas exposed to particularly high stresses (dampness, scouring), additional safety precautions may however
be required.

The following measures are recommended depending on the application.

Protect repair area using:



Heat-shrinkable tube



Corrugated tube



Wrapping with fabric tape



Spaghetti insulation

BASIC KNOWLEDGE

MODEL SURVEY - GF00.10-P-0025-01I

MAJOR ASSEMBLY OVERVIEW - GF00.10-P-0025-02I

COMPLETE VEHICLE, MODEL/COMPONENT INSTALLATION SURVEY, BUILD CONDITION - GF00.10-P-0801I

MODEL 163

163.1

163.11

163.113

ML 270 CDI

163.12

163.128

ML 400 CDI

163.13

163.136

ML 230

163.15

163.154

ML 320

163.157

ML 350

163.17

163.172

ML 430

163.174

ML 55 AMG

163.175

ML 500

Sales
designation

Model

Engine

Manual
transmission

Automatic
transmission

Steering gear

ML 270 CDI

163.113

612.963

716.644

722.661

-

ML400CDI

163.128

628.963

-

722.666
722.673

-

ML 230

163.136

111.977

717.461

722.660

-

ML 320

163.154

112.942

-

722.662

-

ML 350

163.157

112.970

-

722.674

-

ML 430

163.172

113.942

-

722.663

-

ML 55 AMG

163.174

113.981

-

722.666

-

ML 500

163.175

113.965

-

722.666

-



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 18: Identifying Complete Vehicle

FEMALE CONTACTS AND CONTACT PINS, INSTALLATION SURVEY, AS-BUILT CONFIGURATION - GF00.19-P-7000A

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463

Fig. 19: Identifying Junior Power Timer (JPT) Pin



Component survey

Model 163

GF00.10-P-0025-02I



Model survey

Model 163

GF00.10-P-0025-01I



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 20: Identifying Junior Power Timer (JPT) Bushing

Fig. 21: Identifying Standard Power Timer (SPT) Pin



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 22: Identifying Standard Power Timer (SPT) Bushing



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
