Mercedes-Benz ML320. Manual - part 107

255

Practical hints

What to do if …

Problem

Possible cause

Suggested solution

1

The red SRS indicator lamp lights
up while driving.

There is a malfunction in the restraint sys-
tems. The airbags or emergency tensioning
device (ETDs) could deploy unexpectedly or
fail to activate in an accident.

왘

Drive with added caution to the near-
est authorized Mercedes-Benz Light
Truck Center.

Warning!

G

In the event a malfunction of the SRS is indi-
cated as outlined above, the SRS may not be
operational. For your safety, we strongly
recommend that you visit an authorized
Mercedes-Benz Light Truck Center immedi-
ately to have the system checked, otherwise
the SRS may not be activated when needed
in an accident, which could result in serious
or fatal injury, or it might deploy unexpect-
edly and unnecessarily which could result in
an accident/or injury to you or to others.

256

Practical hints

What to do if …

Additional indicators in the speedome-
ter display

Display

Possible cause

Suggested solution

9

Perform minor service (A) (

컄

page 232).

왘

Visit an authorized Mercedes-Benz
Light Truck Center to perform service.

´

Perform major service (B) (

컄

page 232).

왘

Visit an authorized Mercedes-Benz
Light Truck Center to perform service.

Á
î

The

StArt

 message comes on in

addition to the

Error

 message.

The immobilizer is not operational.

왘

Contact an authorized
Mercedes-Benz Light Truck Center or
call 1-800-FOR-MERCedes (in the
USA), or 1-800-387-0100 (in Cana-
da).

257

Practical hints

Where will I find ...?

왔

Where will I find ...?

First aid kit

The first aid kit is stored in the liftgate.

왘

Open and fold down panel 1.

The first aid kit can be removed.

Vehicle tool kit

The vehicle tool kit is stored in the cargo
area behind the right trim panel.

1 Handles
2 Panel

왘

Turn handles 1 90° in direction of
arrows.

왘

Fold down the panel 2.

3 Screw
4 Vehicle jack with tool kit

왘

Turn screw 3 counterclockwise.

왘

Remove vehicle jack.

Vehicles with CD-changer*
(

컄

page 258).

The jack is exclusively designed for lifting
the vehicle during a wheel change. Always
lower the vehicle on sufficient capacity
jackstands before working under the vehi-
cle.

i

Check expiration dates and contents
for completeness at least once a year
and replace missing /expired items.

258

Practical hints

Where will I find ...?

1 Vehicle jack
2 Wheel bolt wrench
3 Screwdriver
4 Interchangeable slot

Screwdriver 3 is placed inside the wheel-
bolt wrench handle.

Vehicle jack

Please also observe the safety guidelines
in the “Flat tire” section (

컄

page 274)

when using the jack.

Vehicle with CD-changer*

To access the vehicle tool kit, swing the
CD-changer out of the panel.

1 Screw
2 CD-changer

왘

Turn screw 1 counterclockwise.

왘

Swing the CD-changer 2 out of the
panel.

Warning!

G

The jack is designed exclusively for jacking
up the vehicle at the jack take-up brackets
built into both sides of the vehicle. To help
avoid personal injury, use the jack only to lift
the vehicle during a wheel change. Never
get beneath the vehicle while it is supported
by the jack. Keep hands and feet away from
the area under the lifted vehicle. Always
firmly set parking brake and block wheels
before raising vehicle with jack.

Do not disengage parking brake while the
vehicle is raised. Be certain that the jack is
always vertical (plumb line) when in use, es-
pecially on hills. Always try to use the jack
on level surface.

Make sure that the jack arm is fully seated
in the jack take-up bracket. Always lower
the vehicle onto sufficient capacity jack-
stands before working under the vehicle.
