Specifications
Identification Numbers
Engine Number
Forward
9-3
Specifications
Specifications
Specifications
Engine
Gasoline engine
Specification
Item
SKYACTIV-G 2.5
SKYACTIV-G 2.5T
Type
DOHC-16V in-line, 4-cylinder
Bore × Stroke
89.0 × 100.0 mm (3.50 × 3.94 in)
Displacement
2,488.5 ml (2,488.5 cc)
Compression ratio
13.0
10.5
Electrical System
Battery*1
Classification
Specification
SKYACTIV-G 2.5,
12V-60Ah/20HR or 12V-65Ah/20HR
SKYACTIV-G 2.5T
Spark-plug
Classification
Specification
SKYACTIV-G 2.5
PE5R-18-110-A or PE5S-18-110
Mazda Genuine spark plug*2
SKYACTIV-G 2.5T
PY8V-18-110
*1
Check the battery installed on the vehicle and use a battery with an equal or higher performance. However, the
performance of the battery may vary even among the same battery types, consult an Authorized Mazda Dealer
for replacement.
*2
The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
Lubricant Quality
Lubricant
Classification
Engine oil
Refer to Recommended Oil on page 6-20.
Coolant
FL-22 type
Automatic transaxle fluid*1
Mazda Genuine ATF-FZ
Transfer case oil*2
Mazda Long Life Hypoid Gear Oil SG1
9-4
Specifications
Specifications
Lubricant
Classification
Rear differential oil*2
Mazda Long Life Hypoid Gear Oil SG1
Brake fluid
SAE J1703 or FMVSS116 DOT-3
*1
Periodic replacement is unnecessary.
*2
Replacement is necessary when the component is submerged in water.
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
Capacities
(Approximate Quantities)
Item
Capacity
Engine oil
With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
SKYACTIV-G
Without oil filter replace-
2.5
4.3 L (4.5 US qt, 3.8 Imp qt)
ment
With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
SKYACTIV-G
Without oil filter replace-
2.5T
4.6 L (4.9 US qt, 4.0 Imp qt)
ment
Coolant
U.S.A. and Can-
SKYACTIV-G 2.5
7.5 L (7.9 US qt, 6.6 Imp qt)
ada
SKYACTIV-G 2.5T
8.5 L (9.0 US qt, 7.5 Imp qt)
Mexico
SKYACTIV-G 2.5
7.7 L (8.1 US qt, 6.8 Imp qt)
SKYACTIV-G 2.5T
8.5 L (9.0 US qt, 7.5 Imp qt)
Automatic transaxle
7.8 L (8.2 US qt, 6.9 Imp qt)/
SKYACTIV-G 2.5
fluid
8.0 L (8.5 US qt, 7.0 Imp qt)
SKYACTIV-G 2.5T
8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil
0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil
0.35 L (0.37 US qt, 0.31 Imp qt)
FWD
56.0 L (14.8 US gal, 12.3 Imp gal)
Fuel tank
AWD
58.0 L (15.3 US gal, 12.8 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
Dimensions
Item
Vehicle specification
Overall length
4,575 mm (180.1 in)
Overall width
1,845 mm (72.6 in)
Overall height
1,675 mm (65.9 in)
Front tread
1,596 mm (62.8 in)
Rear tread
1,596 mm (62.8 in)
Wheelbase
2,698 mm (106.2 in)
9-5
Specifications
Specifications
Weights
U.S.A. and Canada
SKYACTIV-G 2.5
Weight
Item
AWD
GVWR (Gross Vehicle Weight Rating)
2,143 kg (4,724 lbs)
Front
1,100 kg (2,425 lbs)
GAWR (Gross Axle Weight Rating)
Rear
1,043 kg (2,299 lbs)
SKYACTIV-G 2.5T
Weight
Item
AWD
GVWR (Gross Vehicle Weight Rating)
2,190 kg (4,828 lbs)
Front
1,145 kg (2,524 lbs)
GAWR (Gross Axle Weight Rating)
Rear
1045 kg (2,304 lbs)
Mexico
SKYACTIV-G 2.5
Weight
Item
Without moonroof
With moonroof
Total
2,060 kg (4,542 lbs)
2,110 kg (4,652 lbs)
GVW (Gross Vehicle Weight)
Front
1,035 kg (2,282 lbs)
1,045 kg (2,304 lbs)
Rear
1,025 kg (2,260 lbs)
1,065 kg (2,348 lbs)
Front
1,055 kg (2,326 lbs)
1,065 kg (2,348 lbs)
GAW (Permissible axle load)
Rear
1,105 kg (2,436 lbs)
1,145 kg (2,524 lbs)
SKYACTIV-G 2.5T
Item
Weight
Total
2,115 kg (4,663 lbs)
GVW (Gross Vehicle Weight)
Front
1,100 kg (2,425 lbs)
Rear
1,015 kg (2,238 lbs)
Front
1,125 kg (2,480 lbs)
GAW (Permissible axle load)
Rear
1,090 kg (2,403 lbs)
9-6
Specifications
Specifications
Light Bulbs
Exterior light
All the light bulbs are the LED type.
The LED bulb cannot be replaced. Consult an Authorized Mazda Dealer when the
replacement is necessary.
Interior light
Category
Light bulb
Wattage
UN-R*1
LED type
LED
Overhead light (Front)/Map lights
Bulb type
8
LED type
LED
Rear map lights
Bulb type
8
LED type
LED
Vanity mirror lights*
Bulb type
2
Ambient lights*
LED
LED type
LED
Luggage compartment light
Bulb type
8
*1
UN-R stands for United Nations Regulation.
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-35.
Standard tire
(U.S.A. and Canada)
Inflation pressure
Tire size
Front
Rear
P225/65R17 100H
230 kPa (34 psi)
230 kPa (34 psi)
P225/55R19 99V
240 kPa (35 psi)
240 kPa (35 psi)
*Some models.
9-7
Specifications
Specifications
(Mexico)
Inflation pressure
Tire size
Up to 3 persons
ʊFull load
Front
230 kPa (2.3 bar, 33 psi)
260 kPa (2.6 bar, 38 psi)
225/65R17 102V
Rear
230 kPa (2.3 bar, 33 psi)
280 kPa (2.8 bar, 41 psi)
Front
250 kPa (2.5 bar, 36 psi)
260 kPa (2.6 bar, 38 psi)
225/55R19 99V
Rear
250 kPa (2.5 bar, 36 psi)
290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
Temporary spare tire
(U.S.A. and Canada)
Tire size
Inflation pressure
T145/90D16 106M*
420 kPa (60 psi)
T155/90D17 101M*2
420 kPa (60 psi)
*1
SKYACTIV-G 2.5
*2
SKYACTIV-G 2.5T
(Mexico)
Tire size
Inflation pressure
T155/80R17 100M
420 kPa (4.2 bar, 60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 Nꞏm (12―14 kgfꞏm, 80―108 ftꞏlbf)
Fuses
Refer to Fuses on page 6-43.
9-8
