NOTE

Some gate operators and garage
door openers may require you to
replace this Programming Step 3
with procedures noted in the “Gate
Operator/Canadian Programming”
section.

4. Press the HomeLink button again to

check if the programming has been
completed.

x

If the indicator light remains on in
green, the programming is
complete and the device
becomes operational.

x

If the indicator light flashes
rapidly in green, firmly press and
hold the Homelink button and
release it after two seconds have
passed. Repeat this process up to
three times to complete the
programming. The device
becomes operational and
programming is complete. If the
device does not operate, go to
the next step.

5. At the garage door opener receiver

(motor-head unit) in the garage,
locate the “learn” or “smart” button.
This can usually be found where the
hanging antenna wire is attached to
the motor-head unit.

6. Firmly press and release the “learn”

or “smart” button. (The name and
color of the button may vary by
manufacturer.)

NOTE
Complete the programming within
30 seconds.

7. Return to the vehicle and firmly

press

 and

hold

 the Homelink

button, and then

release

 it after

two seconds have passed. Repeat
the “

press/hold/release

” sequence

a second time, and, depending on
the brand of the garage door
opener (or other rolling code
equipped device), repeat this
sequence a third time to complete
the programming process.
Press the programmed HomeLink
button and make sure that the
HomeLink System operates.

8. If the status indicator arrows are

flashing, refer to Garage Door
Two-Way Communication.

1. Indicator light

NOTE

To program the remaining two
HomeLink buttons, go back to

Step 1

of Programming the HomeLink System
and repeat the procedure.

For questions or comments, please
contact

HomeLink at

www.homelink.com

 or

www.youtube.com/
HomeLinkGentex

, or the HomeLink

toll-free hotline at 1-800-355-3515
(for calls placed outside of the USA,
Canada, and Puerto Rico, international
rates will apply and may differ based
on landline or mobile phone).

When Driving

Switches and Controls

4-72

Gate operator/Canadian
Programming

Canadian radio-frequency laws require
transmitter signals to “time-out” (or
quit) after several seconds of
transmission

ʊ

 which may not be long

enough for HomeLink to pick up the
signal during programming. Similar to
this Canadian law, some U.S. gate
operators are designed to “time-out”
in the same manner.

If you live in Canada or are having
difficulties programming a gate
operator by using the programming
procedures (regardless of where you
live),

replace Step 3 of Programming

the HomeLink System

 with the

following:

NOTE

If programming a garage door opener
or gate operator, it is advised to unplug
the device during the “cycling” process
to prevent possible overheating.

While the indicator light is flashing in
amber, press the button on the
hand-held transmitter for 2 seconds
and release it repeatedly until the
indicator light changes from amber to
green.
Go back to Step 4 of Programming the
HomeLink System to complete the
procedure.

Operating the HomeLink System

Press the programmed HomeLink
button to operate a programmed
device.

Reprogramming the HomeLink
system

To program a device to HomeLink
using a HomeLink button previously
trained, follow these steps:
1. Press and hold the desired

HomeLink button.

DO NOT

 release

the button.

2. After 20 seconds, the indicator light

flashes in amber. After the indicator
light flashes, release the HomeLink
button.

3. Go back to Step 2 of Programming

the HomeLink System to complete
the procedure.

NOTE

If the programming has not been
completed, the system returns to the
previous programming.

Erasing Programmed HomeLink
Buttons

NOTE

x

All of the programmed HomeLink
buttons are reset. Individual buttons
cannot be reset, however, individual
buttons can be reprogrammed. For
individual button reprogramming,
refer to Reprogramming the
HomeLink System (page 4-73).

x

Verify that the programming has
been erased if you resell the vehicle.

When Driving

Switches and Controls

4-73

1. Press the two outer HomeLink

buttons continuously at the same
time until the indicator light flashes.

1. HomeLink button 3
2. HomeLink button 1

2. Stop pressing the HomeLink

buttons.

Garage Door Two-Way
Communication

The garage door two-way
communication is a function that
communicates with the garage door
opener and indicates whether the
garages door is open or closed using
the indicator lights in the rear view
mirror. It can indicate the status of the
garage door within a range up-to 250
m (820 ft).

NOTE

The communication range may shorten
depending on obstructions.

Programming two-way
communication

Within five seconds after programming
a new HomeLink button, both of the
garage door status indicator lights will
flash rapidly in green indicating that
the garage door two-way
communication has been established.
If the garage door status indicator
lights flash, the two-way
communication programming is
complete.

If the garage door status indicator
lights do not flash, the two-way
communication programming is not
completed. For additional HomeLink
information and programming videos,
refer to the following Websites:

x

www.HomeLink.com

x

www.youtube.com/
HomeLinkGentex

Operating the garage door two-way
communication

By pressing HomeLink buttons 1 and 2
at the same time for two seconds, the
status of the garage door is indicated
for about 3 seconds as follows:

1. HomeLink button 2
2. HomeLink button 1

Garage door

status

Indicator light

Closing

Amber flashes

Opening

Amber flashes

Closed

Green turns on

Opened

Green turns on

NOTE

The programming will not be erased
even if the battery is disconnected.

When Driving

Switches and Controls

4-74

Brake System

Foot Brake

This vehicle has power-assisted brakes
that adjust automatically through
normal use.

Should power-assist fail, you can stop
by applying greater force than normal
to the brake pedal. But the distance
required to stop will be greater than
usual.

WARNING

Do not coast with the engine stalled
or turned off, find a safe place to stop:

Coasting with the engine stalled or
turned off is dangerous. Braking will
require more effort, and the brake's
power-assist could be depleted if you
pump the brake. This will cause longer
stopping distances or even an
accident.

Shift to a lower gear when going
down steep hills:

Driving with your foot continuously on
the brake pedal or steadily applying
the brakes for long distances is
dangerous. This causes overheated
brakes, resulting in longer stopping
distances or even total brake failure.
This could cause loss of vehicle control
and a serious accident. Avoid
continuous application of the brakes.

Dry off brakes that have become wet
by driving slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the
brake performance returns to normal:

Driving with wet brakes is dangerous.
Increased stopping distance or the
vehicle pulling to one side when
braking could result in a serious
accident. Light braking will indicate
whether the brakes have been
affected.

CAUTION

¾

Do not drive with your foot held on
the clutch pedal or brake pedal, or
hold the clutch pedal depressed
halfway unnecessarily. Doing so
could result in the following:

¾

The clutch and brake parts will
wear out more quickly.

¾

The brakes can overheat and
adversely affect brake
performance.

¾

Always depress the brake pedal with
the right foot. Applying the brakes
with the unaccustomed left foot
could slow your reaction time to an
emergency situation resulting in
insufficient braking operation.

¾

Wear shoes appropriate for driving in
order to avoid your shoe contacting
the brake pedal when depressing the
accelerator pedal.

When Driving

Brake

4-75

Electric Parking Brake (EPB)

The EPB system applies the parking
brake using an electric motor. The
system can operate automatically and
manually.
The EPB switch indicator light turns on
when applying the parking brake and it
turns off when releasing the parking
brake.

1. Indicator light

WARNING

Do not drive the vehicle with the
parking brake applied:

If the vehicle is driven with the parking
brake applied, the brake parts may
generate heat and the brake system
may not operate, leading to an
accident.
Before driving the vehicle, release the
parking brake and make sure that the
EPB indicator light in the instrument
cluster turns off.

Apply the parking brake when leaving
the vehicle:

Not applying the parking brake when
parking the vehicle is dangerous as the
vehicle may move unexpectedly and
result in an accident. Before leaving the
vehicle, apply the parking brake and
make sure that the EPB indicator light
in the instrument cluster turns on.

NOTE

x

The parking brake cannot be applied
or released while the vehicle battery
is dead.
Refer to If a Jump-Starting on page
7-17.

x

When the charging system warning
light in the instrument cluster turns
on, the parking brake cannot be
applied after switching the ignition
OFF. Before switching the ignition
OFF, apply the parking brake
manually.

x

The sound of the parking brake being
applied or released can be heard,
however, this does not indicate a
problem.

x

If the EPB is not used for long
periods, an automatic inspection of
the system is performed while the
vehicle is parked. An operation
sound can be heard, however, this
does not indicate a problem.

x

When applying the parking brake
and switching OFF the ignition, an
operation sound can be heard,
however, this does not indicate a
problem.

x

The brake pedal may move while
applying or releasing the parking
brake, however, this does not
indicate a problem.

x

If the parking brake is applied with
the ignition switched OFF or in ACC,
the EPB indicator light in the
instrument cluster and the indicator
light in the switch may turn on for 15
seconds.

x

When using an automatic car wash
which moves the vehicle with the
front tires mounted, it is necessary to
cancel the parking brake auto
operation before the vehicle enters
the automatic car wash. For details,
refer to Canceling the parking brake
automatic operation.

When Driving

Brake

4-76

x

Release the parking brake and use
neutral hold mode (automatic car
wash mode) when it is necessary to
change the shift position to the N
position for an automatic car wash.
Refer to Selector Lever Operation on
page 4-41.

Manual operation

Applying the parking brake manually

When the brake pedal is firmly
depressed and the EPB switch is pulled
up, the parking brake is applied
regardless of the ignition position.
When the parking brake is applied, the
EPB indicator light in the instrument
cluster and the EPB switch indicator
light turn on.

Releasing the parking brake manually

When the brake pedal is firmly
depressed and the EPB switch is
pressed while the ignition is switched
ON or the engine is running, the
parking brake is released. When the
parking brake is released, the EPB
indicator light in the instrument cluster

and the EPB switch indicator light turn
off.

If the EPB switch is pressed without
depressing the brake pedal, a message
is displayed on the multi-information
display to notify the driver to depress
the brake pedal.
Refer to Message Indicated on
Multi-information Display on page
7-40.

Auto operation

Applying the parking brake
automatically

When the ignition is switched from ON
to ACC or OFF, the parking brake will
be applied automatically. When the
parking brake is applied, the EPB
indicator light in the instrument cluster
and the EPB switch indicator light turn
on.

NOTE

To release the parking brake when the
ignition is switched OFF, it is necessary
to cancel the parking brake auto
operation. For details, refer to
Canceling the parking brake automatic
operation.

When Driving

Brake

4-77

Releasing the parking brake
automatically

(Selector lever operation (Automatic
transmission vehicle))

If the selector lever is shifted from the
P position to a position other than P
with the parking brake applied and all
of the following conditions met, the
parking brake is released automatically.
When the parking brake is released,
the EPB indicator light in the
instrument cluster and the EPB switch
indicator light turn off.

x

The engine is running.

x

The driver's door is closed.

x

Shift interlock release is enabled.

x

The brake pedal is being depressed.

CAUTION

Firmly depress the brake pedal and
perform the shift operation.
Otherwise, the vehicle may move
unexpectedly.

When performing the following
operations, shift interlock release can
be enabled/disabled.
1. Switch the ignition ON.
2. Pull the EPB switch continuously for

4 seconds or longer.

3. Release the EPB switch once and

then pull it again continuously for 4
seconds or longer within 3 seconds.
(Switching from disable to enable
shift interlock release)
When shift interlock release is
enabled, a sound is activated 2
times and the EPB switch indicator
changes to fast flashing, and flashes
for 3 seconds.
(Switching from enable to disable
shift interlock release)
When shift interlock release is
disabled, a sound is activated 2
times and the EPB switch indicator

light changes to slow flashing, and
flashes for 4 seconds.

NOTE

When the ignition is switched OFF,
the system setting before it was
turned off is maintained.

(Accelerator pedal operation)

If the accelerator pedal is depressed
with the parking brake applied and all
of the following conditions met, the
parking brake is released automatically.
When the parking brake is released,
the EPB indicator light in the
instrument cluster and the EPB switch
indicator light turn off.

x

The engine is running.

x

The driver's door is closed.

x

The driver's seat belt is fastened.

x

(Manual transmission vehicle)

x

The shift lever is in a position other
than neutral.

x

The clutch pedal is depressed
halfway.

x

(Automatic transmission vehicle)

The selector lever is in the D, M, or R
position.

CAUTION

If something such as the driver’s foot
contacts the accelerator pedal with the
engine running and the parking brake
applied, the parking brake may be
released automatically and the vehicle
may move unexpectedly. If you do not
intend to start driving the vehicle
immediately, shift the shift lever to the
neutral position for a manual
transmission, or shift the selector lever
to the P or N position for an automatic
transmission.

When Driving

Brake

4-78

Canceling the parking brake
automatic operation

The parking brake automatic operation
can be canceled by doing any of the
following after switching the ignition
from ON to OFF.

Auto operation cancel method 1

1. Switch the ignition ON.
2. Release the parking brake manually.
3. Turn off the AUTOHOLD.
4. Press the EPB switch continuously

for 2 seconds or longer (until a
sound is activated).

5. Release the EPB switch and switch

the ignition OFF within 5 seconds
after the sound was activated.
After the auto operation is
canceled, a sound is activated one
time, and the EPB switch indicator
light switches from illumination to
flashing, and then turns off after 3
seconds.

Auto operation cancel method 2

1. Switch the ignition ON.
2. Release the parking brake manually.
3. Turn off the AUTOHOLD.
4. Switch the ignition OFF with the

EPB switch pressed while the brake
pedal is not depressed.
When the auto operation is
canceled, a sound is activated one
time, and the EPB switch indicator
light goes from normal flashing to
faster flashing, and then turns off
after 3 seconds.

NOTE

x

When canceling the parking brake
auto operation and parking the
vehicle, shift the shift lever to the 1st
gear or the R position for a manual
transmission, or shift the selector
lever to the P position for an
automatic transmission, and then
use wheel blocks.

x

The auto operation may not cancel if
the vehicle is parked on a steep
slope.

When the ignition is switched ON, the
parking brake auto operation is
restored.

How to use Emergency Brake

If there is a problem with the brake
system (foot brake) while driving the
vehicle or in an emergency situation
where the driver cannot step on the
brake pedal, continually pulling up the
EPB switch will apply the brakes and
decelerate or stop the vehicle. The
parking brake on-reminder sound is
activated while the brake is applied. In
addition, when releasing the switch,
the brake is released and the sound
stops.

WARNING

Use Emergency Brake only in an
emergency situation:

Excessive use may cause the brake
parts to wear quickly or the brakes to
heat up and become less effective.

Warning Light

The warning light turns on when the
system has a malfunction.
Refer to Brake System Warning
Indication/Warning Light on page
7-27.

When Driving

Brake

4-79

Brake Pad Wear Indicator

When the disc brake pads become
worn, the built-in wear indicators
contact the disc plates. This causes a
screeching noise to warn that the pads
should be replaced.

When you hear this noise, consult an
Authorized Mazda Dealer as soon as
possible.

WARNING

Do not drive with worn disc pads:

Driving with worn disc pads is
dangerous. The brakes could fail and
cause a serious accident. As soon as
you hear a screeching noise consult an
Authorized Mazda Dealer.

NOTE

In high humidity weather conditions,
brake noises, such as brake squeak or
brake squeal can be heard. It does not
indicate a malfunction.

Brake Assist

During emergency braking situations
when it is necessary to depress the
brake pedal with greater force, the
brake assist system provides braking
assistance, thus enhancing braking
performance.

When the brake pedal is depressed
hard or depressed more quickly, the
brakes apply more firmly.

NOTE

x

When the brake pedal is depressed
hard or depressed more quickly, the
pedal will feel softer but the brakes
will apply more firmly. This is a
normal effect of the brake assist
operation and does not indicate a
malfunction.

x

When the brake pedal is depressed
hard or depressed more quickly, a
motor/pump operation noise may
be heard. This is a normal effect of
the brake assist and does not
indicate a malfunction.

x

The brake assist equipment does not
supersede the functionality of the
vehicle's main braking system.

When Driving

Brake

4-80

Brake Override System

The brake override system applies the
brake first for safety if the brake pedal
and accelerator pedal are depressed at
the same time.

NOTE

Operation of the brake override system
can be turned on or off.
Refer to the Settings section in the
Mazda Connect Owner's Manual.

When Driving

Brake

4-81

AUTOHOLD

AUTOHOLD

The AUTOHOLD function automatically holds the vehicle stopped, even if you take
your foot off the brake pedal. This function can be best used while stopped in traffic
or at a traffic light. The brakes are released when you start driving the vehicle.

WARNING

Do not rely completely on the AUTOHOLD function:

The AUTOHOLD function is only designed to assist the brake operation while the
vehicle is stopped. Neglecting to operate the brakes and relying only on the
AUTOHOLD system is dangerous and could result in an unexpected accident if the
vehicle were to suddenly move. Operate the brakes appropriately in accordance
with the road and surrounding conditions.
Note that the vehicle may move suddenly depending on the vehicle's load or if it is
towing something.

Do not release your foot from the brake pedal while the vehicle is stopped on a
steep grade:

Because there is a possibility of the vehicle not being held in the stopped position by
the AUTOHOLD function, the vehicle may move unexpectedly and result in an
accident.

Do not use the AUTOHOLD function on slippery roads such as icy or
snow-covered roads, or unpaved roads:

Even if the vehicle is held in the stopped position by the AUTOHOLD function, the
vehicle may move unexpectedly and result in an accident. Operate the accelerator
pedal, brakes, or steering wheel appropriately as necessary.

Immediately depress the brake pedal in the following cases:

Because the AUTOHOLD function is canceled forcibly, the vehicle may move
unexpectedly and result in an accident.

¾

“Depress Brake Pedal. Brake Hold Disabled” is displayed in the multi-information
display and the warning sound is activated at the same time.

Always apply the parking brake when parking the vehicle:

Not applying the parking brake when parking the vehicle is dangerous as the vehicle
may move unexpectedly and result in an accident. When parking the vehicle, shift
the selector lever to the P position (automatic transmission vehicle) and apply the
parking brake.

When Driving

Brake

4-82

CAUTION

If you stop operating the accelerator pedal before the vehicle starts moving, the
force holding the vehicle in the stopped position may weaken. Firmly depress the
brake pedal or depress the accelerator pedal to accelerate the vehicle.

NOTE

x

Under the following conditions, a problem with the AUTOHOLD is occurring.
Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible.

x

A message is indicated on the multi-information display and a warning sound is
activated for about 5 seconds while the AUTOHOLD is operating or when you
press the AUTOHOLD switch.

x

If you switch the ignition OFF while the AUTOHOLD is operating, the parking
brake is applied automatically to assist you with parking the vehicle.

x

The AUTOHOLD is canceled when the selector lever/shift lever is shifted to R
position while the vehicle is on level ground, or facing up a hill or grade (as shown
below).

Vehicle posture and road surface gradient

AUTOHOLD operation status

Vehicle tilts forward

Operates

Level ground

Does not operate, canceled

Vehicle tilts rearward

Does not operate, canceled

 : Reverse driving (selector lever/shift lever in the reverse (R) position)

When Driving

Brake

4-83

x

The brake pedal response may change, sound may occur from the brakes, or the
brake pedal could vibrate from the operation of the AUTOHOLD function.
However, this does not indicate a malfunction.

To Turn On AUTOHOLD System

Press the AUTOHOLD switch and
when the AUTOHOLD standby
indicator light turns on, the
AUTOHOLD function turns on.

1. AUTOHOLD standby indicator light

NOTE

When all of the following conditions
are met, the AUTOHOLD standby
indicator light turns on when the
AUTOHOLD switch is pressed and the
AUTOHOLD function turns on.

x

The ignition is switched ON (engine
is running or stopped by i-stop).

x

The driver's seat belt is fastened.

x

The driver's door is closed.

x

There is no problem with the
AUTOHOLD function.

To operate AUTOHOLD and hold the
brakes

1. Depress the brake pedal and bring

the vehicle to a complete stop.

2. The AUTOHOLD active indicator

light in the instrument cluster turns
on and the brakes are held.

When Driving

Brake

4-84

3. The vehicle is held in its stopped

position even with the brake pedal
released.

NOTE

When all of the following conditions
are met, the AUTOHOLD operates and
the brakes are held.

x

The ignition is switched ON (engine
is running or stopped by i-stop).

x

The vehicle is stopped.

x

The brake pedal is being depressed.

x

The AUTOHOLD active indicator
light turns on.

x

The accelerator pedal is not
depressed.

x

The driver's seat belt is fastened.

x

The driver's door is closed.

x

There is no problem with the
AUTOHOLD function.

x

The parking brake is released.

x

There is no problem with the Electric
Parking Brake (EPB) function.

x

(Automatic transmission vehicle)

The selector lever is in a position
other than R position or the vehicle
tilts forward with the selector lever in
the R position.

To release AUTOHOLD and start
driving the vehicle

If you try to resume driving the vehicle,
the brakes will be released
automatically and the AUTOHOLD
active indicator light turns off.

NOTE

x

If the Electric Parking Brake (EPB)
switch is pulled while the
AUTOHOLD is operating, the
parking brake is applied and the
AUTOHOLD is released. In addition,
if the parking brake is released under
this condition, the AUTOHOLD
operates to hold the brakes.

x

Under the following conditions, the
parking brake is automatically
applied and the AUTOHOLD is
released. The AUTOHOLD is
re-enabled when the conditions
before the AUTOHOLD is released
are restored.

x

The driver’s seat belt is unfastened.

x

The driver’s door is opened.

x

When about 10 minutes or longer
have passed since the AUTOHOLD
operation started, the parking brake
is automatically applied. Because the
AUTOHOLD is restored when
releasing the parking brake, the hold
on the brakes by AUTOHOLD
function resumes.

x

(Manual transmission vehicle)

When starting to drive the vehicle
forward or in reverse on a down
slope, depress the clutch pedal and
shift the shift lever to the appropriate
position for driving in the desired
direction, and then depress the
accelerator pedal to release the
AUTOHOLD.

x

The AUTOHOLD can be canceled
forcibly by fully depressing the
accelerator pedal for 1 second or
longer while the AUTOHOLD is
operating. Forcibly cancel the
AUTOHOLD only when the
AUTOHOLD cannot be canceled due
to a system malfunction or it is
necessary to cancel the AUTOHOLD
in an emergency.

When Driving

Brake

4-85

To Turn Off AUTOHOLD System

Depress the brake pedal and press the
AUTOHOLD switch. The AUTOHOLD
is turned off and the AUTOHOLD
standby indicator light turns off.

1. AUTOHOLD standby indicator light

NOTE

x

When the brakes are not held such
as while driving the vehicle, the
AUTOHOLD can be turned off only
by pressing the AUTOHOLD switch.

x

If the AUTOHOLD switch is pressed
without depressing the brake pedal
while AUTOHOLD is operating
(AUTOHOLD active indicator light in
instrument cluster is turned on), the
message “Depress Brake Pedal and
Operate Switch to Release” is
indicated on the multi-information
display to notify the driver to depress
the brake pedal.

x

If any of the following conditions
occurs while the AUTOHOLD
function is operating (AUTOHOLD
active indicator light is turned on),
the parking brake is applied
automatically and the AUTOHOLD
function turns off. For the Electric
Parking Brake (EPB) operation, refer
to the Electric Parking Brake (EPB) on
page 4-76.

x

The ignition is switched OFF.

x

There is a problem with the
AUTOHOLD function.

When Driving

Brake

4-86

Hill Launch Assist (HLA)

Hill Launch Assist (HLA)

The HLA functions to assist in
accelerating the vehicle from a stop on
slopes. When releasing the brake pedal
and depressing the accelerator pedal
to accelerate the vehicle from a stop
while on a slope, the function prevents
the vehicle from rolling. The HLA also
operates when reversing on a slope.
The braking force is maintained
automatically after releasing the brake
pedal on a steep slope.
For manual transmission vehicles, the
HLA operates when the vehicle is tilted
rearward with the shift lever in a
forward gear, and operates when the
vehicle is tilted forward with the shift
lever in the R position.
For automatic transmission vehicles,
the HLA operates when the vehicle is
tilted rearward with the selector lever
in a forward gear, and operates when
the vehicle is tilted forward with the
selector lever in the R position.

WARNING

Do not rely completely on HLA:

HLA is an auxiliary device for
accelerating from a stop on a slope.
The system only operates for about 2
seconds and therefore, relying only on
the system, when accelerating from a
stop is dangerous because the vehicle
may move (roll) unexpectedly and
cause an accident.
The vehicle could roll depending on
the vehicle's load or if it is towing
something. In addition, for vehicles
with a manual transmission, the
vehicle could still roll depending on
how the clutch pedal or the accelerator
pedal is operated.

Always confirm the safety around the
vehicle before starting to drive the
vehicle.

NOTE

x

HLA does not operate on a gentle
slope. In addition, the gradient of
the slope on which the system will
operate changes depending on the
vehicle's load.

x

HLA does not operate if the parking
brake is applied, the vehicle has not
stopped completely, or the clutch
pedal is released.

x

While HLA is operating, the brake
pedal may feel stiff and vibrate,
however, this does not indicate a
malfunction.

x

HLA does not operate while the
TCS/DSC indicator light is
illuminated.
Refer to TCS/DSC Indication/
Indicator Light (Turns on) on page
7-33.

x

HLA does not turn off even if the
DSC OFF switch is pressed to turn off
the TCS/DSC.

When Driving

Brake

4-87















Content      ..     12      13      14      15     ..
