When Driving
M Hybrid
Charging the M Hybrid battery
¾ Touching an unattended or illegally
abandoned M Hybrid battery may
The M Hybrid battery is charged
cause electrocution.
automatically during engine operation
¾ If the M Hybrid battery is used on a
and by deceleration regeneration.
vehicle other than one equipped
Therefore, it is not necessary to charge
with M Hybrid (including modified
the battery from outside of the vehicle.
vehicles), accidents such as
electrocution, heat generation,
CAUTION
smoking, combustion, and
Drive the vehicle for about 30 minutes
explosions, or an electrolyte leakage
once every few months because
may occur.
self-discharge occurs gradually if the
Scrapping Your Vehicle and Disposing
vehicle is not driven for a long period
of the M Hybrid battery
of time. If the M Hybrid battery
becomes completely discharged and
The M Hybrid battery must be recycled
M Hybrid cannot be activated, contact
to prevent accidents involving it. When
an Authorized Mazda Dealer.
scrapping your vehicle, replacing the M
Hybrid battery, or disposing of the M
M Hybrid Precautions
Hybrid battery, consult an Authorized
For vehicle maintenance or repairs, or
Mazda Dealer. Please cooperate in
when scrapping the vehicle, consult an
ensuring that the vehicle's M Hybrid
Authorized Mazda Dealer.
battery is recycled.
Handling the M Hybrid battery
WARNING
Technical knowledge and skill are
necessary in handling the M Hybrid
Dispose of the M Hybrid battery
battery.
appropriately:
If the M Hybrid battery is not recycled
WARNING
appropriately, such as by leaving it
unattended or illegally abandoning it,
some other person may touch it which
To ensure safe and correct handling of
could cause electrocution leading to
the M Hybrid battery, always heed the
serious injury.
following precautions:
¾ Do not remove the M Hybrid battery.
If an Accident Occurs
¾ Do not resell, transfer, or modify the
If the vehicle is involved in a collision,
M Hybrid battery.
M Hybrid may stop operating. In this
¾ Do not use the battery on vehicles
case, the charging system warning light
other than those equipped with the
turns on and M Hybrid cannot activate.
M Hybrid battery.
Park the vehicle in a safe place
immediately and contact an
If the M Hybrid battery is not handled
Authorized Mazda Dealer.
properly, the following may occur and
cause serious injury:
4-54
When Driving
M Hybrid
If the vehicle catches fire, extinguish
WARNING
the fire using an ABC fire
extinguisher:
Never touch the areas where high
Only extinguish a fire with water when
current is flowing:
a high volume of water is available
Never touch a M Hybrid related part.
such as from a fire hydrant.
Otherwise, it could lead to an
electrical shock or burns causing
M Hybrid Control Status Display
serious injury.
The driver is notified of the M Hybrid
operation status by the control status
Never touch electrical wiring that may
display.
be protruding into or outside of the
cabin:
Control status display (vehicles with
Otherwise, it could lead to an
type B audio)
electrical shock or burns causing
The M Hybrid operation status is
serious injury.
displayed in the center display.
Refer to the Information section in the
Never touch any area where
Mazda Connect Owner's Manual.
electrolyte is visible or electrolyte is
leaking from the area:
If any electrolyte from the M Hybrid
battery gets in the eyes or on the skin,
it could cause loss of vision or skin
reactions. In the unlikely event that
electrolyte comes into contact with the
eyes or skin, flush with large quantities
of water immediately and seek
immediate medical attention.
Do not come near the vehicle if
electrolyte is leaking from the M
Hybrid battery:
Even if the M Hybrid battery is
damaged, large quantities of
electrolyte will not flow out due to the
internal structure of the battery,
however, in the unlikely event that it
does, it will produce steam. The steam
contains properties that can irritate the
eyes and skin, and could cause acute
poisoning if absorbed.
Never approach objects that are on
fire or extremely hot:
Electrolyte in the M Hybrid battery may
cause a fire.
4-55
When Driving
Switches and Controls
Lighting Control
Headlights
Turn the headlight switch to turn the headlights and other exterior lights on or off.
When the taillights, parking lights, license plate lights, and the side-marker lights are
turned on, the lights-on indicator light in the instrument cluster turns on.
NOTE
If the light switch is left on, the lights will automatically switch off approximately
30 seconds after switching the ignition off.
The time setting can be changed.
Refer to the Settings section in the Mazda Connect Owner's Manual.
To prevent discharging the battery, do not leave the lights on while the engine is
off unless safety requires them.
Without auto-light control
Switch Position
OFF
Headlights
Off
Off
On*1
Daytime running lights
On*2
On*2
Off
Taillights
Parking lights
Off
On*3
On*1
License plate lights
Side-marker lights
*1
When the ignition is switched from ON to ACC or OFF, the headlights turn off if the auto headlight
off function has been canceled. If the auto headlight off function is enabled, the lights turn on for the
set period using the auto headlight off function, and then they turn off.
4-56
When Driving
Switches and Controls
2
When the light switch is switched to a different position from the OFF,
position while the
vehicle is stopped, the daytime running lights turn off. When starting to drive the vehicle, the daytime
running lights turn on again.
*3
When the ignition is switched from ON to ACC or OFF, the headlights remain on if the auto headlight
off function has been canceled. If the auto headlight off function is enabled, the lights turn on for the
set period using the auto headlight off function, and then they turn off.
With auto-light control
AUTO
Surround-
Surround-
Surround-
Surround-
Switch Position
OFF*1
ings are
ings are
ings are
ings are
bright*2
dark*3
bright*2
dark*3
Headlights
Off
Off
On
Off
On*4*5
On*6
Daytime running lights
Off
On*7
Off
On*8
Off
Off
Taillights
Parking lights
Off
Off
On
On*9
On*9
On*6
License plate lights
Side-marker lights
*1
When the light switch is switched to OFF while the vehicle is stopped, the lights turn off. The light
switch returns automatically to the AUTO position and the headlights change to AUTO operation
when you start driving the vehicle.
*2
The level of brightness around the vehicle is of a sufficient level.
*3
The level of brightness around the vehicle is of an insufficient level.
*4
The daytime running lights can be disabled using the personalization features (page 4-61). If the
daytime running lights are disabled, the headlights turn off directly after starting the engine. The
headlights turn on when you begin driving the vehicle.
*5
When the light switch is switched from the OFF, AUTO, or
position to the
position while
the vehicle is stopped, the headlights turn off. When starting to drive the vehicle, the headlights turn
on again.
*6
When the ignition is switched from ON to ACC or OFF, the headlights turn off if the auto headlight
off function has been canceled. If the auto headlight off function is enabled, the lights turn on for the
set period using the auto headlight off function, and then they turn off.
4-57
When Driving
Switches and Controls
7
When the light switch is switched to a different position from the AUTO position while the vehicle is
stopped, the daytime running lights turn off. When starting to drive the vehicle, the daytime running
lights turn on again.
*8
If one of the following operations is done from the
position while the vehicle is stopped, the
daytime running lights turn off.
Switch the light switch to the OFF position.
Switch the light switch to the AUTO position, and then to the
position again.
Switch the light switch to the
position.
When starting to drive the vehicle, the daytime running lights turn on again.
*9
When the ignition is switched from ON to ACC or OFF, the headlights remain on if the auto headlight
off function has been canceled. If the auto headlight off function is enabled, the lights turn on for the
set period using the auto headlight off function, and then they turn off.
Auto-light control
When the headlight switch is in the AUTO position and the ignition is switched ON,
the light sensor senses the surrounding lightness or darkness and automatically turns
the headlights and other exterior lights on or off.
CAUTION
¾ Do not shade the light sensor by adhering a sticker or a label on the windshield.
Otherwise the light sensor will not operate correctly.
¾ The light sensor also works as a rain sensor for the auto-wiper control. Keep hands
and scrapers clear of the windshield when the wiper lever is in the AUTO position
and the ignition is switched ON as fingers could be pinched or the wipers and
wiper blades could be damaged when the wipers activate automatically. If you are
going to clean the windshield, be sure the wipers are turned off completely when
it is particularly tempting to leave the engine running. This is particularly important
when clearing ice and snow.
4-58
When Driving
Switches and Controls
NOTE
The headlights and other exterior lights may not turn off immediately even if the
surrounding area becomes well-lit because the light sensor determines that it is
night time if the surrounding area is continuously dark for several minutes such as
inside long tunnels, traffic jams inside tunnels, or in indoor parking lots.
If the headlight switch and the windshield wiper switch are in AUTO, and the
wipers are operated at low or high speed by the auto wiper control for several
seconds, bad weather conditions are determined and the headlights may be
turned on.
The sensitivity of the auto-light control may be changed.
Refer to the Settings section in the Mazda Connect Owner's Manual.
Headlight High-Low Beam
Flashing the Headlights
The headlights switch between high
When the ignition is switched ON, and
and low beams by moving the lever
regardless of the headlight position,
forward or backward.
the headlights switch to high beams
while the lever is being pulled.
1. High beam
2. Low beam
1. OFF
2. Headlight flashing
When the headlight high-beams are
on, the headlight high-beam indicator
The headlight high-beam indicator
light is turned on.
light in the instrument cluster
illuminates simultaneously. The lever
will return to the normal position when
released.
4-59
When Driving
Switches and Controls
Coming Home Light
To turn on the lights
The coming home light turns on the
When the ignition switch and the
headlights (low beams) when the lever
headlight switch are in the following
is operated.
conditions, the headlights will
illuminate when the transmitter unlock
To turn on the lights
button is pressed and the vehicle
When the lever is pulled with the
receives the transmitter signal. The
ignition switched to ACC or OFF, the
headlights turn off after a certain
low beam headlights turn on.
period of time has elapsed (30
The headlights turn off after a certain
seconds).
period of time has elapsed after all of
Ignition switch: off
the doors are closed.
Headlight switch: AUTO,
, or
NOTE
The time until the headlights turn off
after all of the doors are closed can
be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
1. Lock button
If no operations are done for 3
2. Unlock button
minutes after the lever is pulled, the
headlights turn off.
NOTE
The headlights turn off if the lever is
Operation of the leaving home light
pulled again while the headlights are
can be turned on or off.
illuminated.
Refer to the Settings section in the
Leaving Home Light
Mazda Connect Owner's Manual.
When the transmitter lock button is
The leaving home light turns on the
pressed and the vehicle receives the
lights when the transmitter unlock
transmitter signal, the headlights turn
button is pressed while away from the
off.
vehicle.
When the headlight switch is turned
The following lights turn on when the
to the OFF position, the headlights
leaving home light is operated.
turn off.
Low beams, Parking lights, Taillights,
License plate lights.
4-60
When Driving
Switches and Controls
Headlight Leveling
Daytime Running Lights
The number of passengers and weight
Some countries require moving
of cargo in the luggage compartment
vehicles to have their lights on
change the angle of the headlights.
(daytime running lights) during the
daytime.
Auto type
The daytime running lights turn on
The angle of the headlights will be
automatically.
automatically adjusted when turning
NOTE
on the headlights.
(Except Canada)
The daytime running lights can be
A system malfunction or operation
deactivated.
conditions are indicated by a warning.
Refer to the Settings section in the
Refer to Exterior Light Warning
Mazda Connect Owner's Manual.
Indication/Warning Light on page
7-35.
Manual type
When adjusting the illumination angle
of the headlights, refer to the Settings
section in the Mazda Connect
Owner's Manual.
Select the proper headlight angle from
the following chart.
Front seat
Illumi-
nation
Rear
Load
angle
Driver
Passenger
seat
(num-
ber)
×
0
×
×
0
×
×
×
1
×
×
×
×
2
×
×
2.5
×: Yes
: No
4-61
When Driving
Switches and Controls
The turn signal indicators in the
Turn and Lane-Change
instrument cluster flash according to
Signals
the operation of the turn signal lever to
show which signal is working.
Turn and Lane-Change Signals
The ignition must be switched ON to
use the turn and lane-change signals.
Turn Signals
Move the signal lever down (for a left
NOTE
turn) or up (for a right turn) to the stop
position. The signal will self-cancel
There may be a problem with the
after the turn is completed.
turn signal lights if they do not flash
but remain turned on, or they flash
If the indicator light continues to flash
abnormally. Have your vehicle
after a turn, manually return the lever
inspected by an Authorized Mazda
to its original position.
Dealer.
A personalized function is available
to change the turn indicator sound
volume.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Lane-Change Signals
Move the lever halfway toward the
direction of the lane changeuntil the
indicator flashes and hold it there. It
will return to the off position when
1.
Right turn
released.
2.
Right lane change
3.
OFF
Three-Flash Turn Signal
4.
Left lane change
After releasing the turn signal lever
5.
Left turn
from the halfway point, the turn signal
indicator flashes 3 times. The
operation can be canceled by moving
the lever in the direction opposite to
which it was operated.
NOTE
The three-flash turn signal function can
be switched to on/off using the
personalization function.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
4-62
When Driving
Switches and Controls
¾ If the amount of washer fluid spray is
Windshield Wipers and
insufficient, do not use the washer
Washer
switch. If the washer switch
continues to be operated with no
Windshield Wipers and Washer
washer fluid being sprayed, it could
lead to pump damage.
The ignition must be switched ON to
use the wipers.
NOTE
WARNING
If the windshield wipers are operated
under cold weather conditions or
during snowfall, they could stop due to
Use only windshield washer fluid or
accumulated snow on the windshield.
plain water in the reservoir:
If the windshield wipers stop due to
Using radiator antifreeze as washer
accumulated snow on the windshield,
fluid is dangerous. If sprayed on the
park the vehicle in a safe place, turn
windshield, it will dirty the windshield,
the wiper switch off, and then remove
affect your visibility, and could result in
the accumulated snow. If the wiper
an accident.
switch is turned to another position
other than OFF, the wipers will
Only use windshield washer fluid
operate. If the wipers do not operate
mixed with anti-freeze protection in
even though the wiper switch is turned
freezing weather conditions:
to a position other than OFF, consult
Using windshield washer fluid without
an Authorized Mazda Dealer as soon
anti-freeze protection in freezing
as possible.
weather conditions is dangerous as it
could freeze on the windshield and
Windshield Wipers
block your vision which could cause an
accident. In addition, make sure the
Turn the wipers on by pressing the
windshield is sufficiently warmed using
lever up or down.
the defroster before spraying the
With intermittent wiper
washer fluid.
CAUTION
¾ When the wipers are not used during
freezing temperatures or for a long
time, the wiper rubber may adhere
to the glass. If the wipers are
operated while adhered to the glass,
it could damage the wiper rubber
and motor.
¾ If the wipers are operated while the
glass is dry, the glass could be
scratched and the wiper rubber
damaged. When the glass is dry,
spray washer fluid before operating
the wipers.
4-63
When Driving
Switches and Controls
Switch Posi-
Switch Posi-
Wiper operation
Wiper operation
tion
tion
Operation while pulling up lev-
Operation while pulling up lev-
MIST
MIST
er
er
OFF
Stop
OFF
Stop
INT
Intermittent
AUTO*1
Auto control
LO
Low speed
LO
Low speed
HI
High speed
HI
High speed
Variable-speed intermittent wipers
*1
When the wiper lever is switched to the
AUTO position, the indicator light turns on.
Set the lever to the intermittent
position and choose the interval timing
Auto-wiper control*
by rotating the switch.
Rotate the switch upward (FAST
When the wiper lever is in the AUTO
position, the rain sensor senses the
direction) to shorten the interval time
of the wiper operation, and rotate the
amount of rainfall on the windshield
and turns the wipers on or off
switch downward (SLOW direction) to
lengthen it.
automatically (offintermittentlow
speedhigh speed).
The sensitivity of the rain sensor can be
adjusted by turning the switch on the
wiper lever.
From the center position (normal),
rotate the switch upward (+ direction)
for higher sensitivity (faster response)
or rotate it downward (- direction) for
less sensitivity (slower response).
1. Switch
With auto-wiper control
1. Switch
2. Higher sensitivity
3. Center position
4. Less sensitivity
1. Indicator light
4-64
*Some models.
When Driving
Switches and Controls
NOTE
CAUTION
Switching the auto-wiper lever from
¾ Do not shade the rain sensor by
the OFF to the AUTO position while
adhering a sticker or a label on the
driving activates the windshield
windshield. Otherwise the rain
wipers once, after which they
sensor will not operate correctly.
operate according to the rainfall
amount.
The auto-wiper control may not
operate when the rain sensor
temperature is about 10 °C (14 °F)
or lower, or about 85 °C (185 °F) or
higher.
If the windshield is coated with
water repellent, the rain sensor may
not be able to sense the amount of
rainfall correctly and the auto-wiper
¾ When the ignition is switched ON
control may not operate properly.
and the wiper lever is in the AUTO
If dirt or foreign matter (such as ice
position, the windshield wipers may
or matter containing salt water)
operate automatically in the
adheres to the windshield above the
following cases:
rain sensor, or if the windshield is
¾ The area of the windshield above
iced, it could cause the wipers to
the rain sensor is touched or wiped
move automatically. However, if the
with a cloth.
wipers cannot remove this ice, dirt or
¾ The windshield or the rain sensor
foreign matter, the auto-wiper
area in the cabin is hit.
control will stop operation. In this
case, set the wiper lever to the low
When the ignition is switched ON
speed position or high speed
and the wiper lever is in the AUTO
position for manual operation, or
position, do not touch the
remove the ice, dirt or foreign matter
windshield or the windshield wipers
by hand to restore the auto-wiper
Otherwise, the windshield wipers
operation.
will operate automatically which
If the auto-wiper lever is left in the
could catch your fingers or damage
AUTO position, the wipers could
the windshield wipers.
operate automatically from the effect
When removing ice or snow, or
of strong light sources,
cleaning the windshield, always
electromagnetic waves, or infrared
make sure the wiper lever is in the
light because the rain sensor uses an
OFF position.
optical sensor. It is recommended
that the auto-wiper lever be
switched to the OFF position other
than when driving the vehicle under
rainy conditions.
4-65
When Driving
Switches and Controls
If the headlight switch and the
If the washer does not work, inspect
windshield wiper switch are in
the fluid level (page 6-21). If the fluid
AUTO, and the wipers are operated
level is normal, consult an Authorized
at low or high speed by the auto
Mazda Dealer.
wiper control for several seconds,
bad weather conditions are
determined and the headlights may
be turned on.
The auto-wiper control functions can
be turned off.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Windshield Washer
Pull the wiper lever toward you to
spray washer fluid and operate the
windshield wipers several times. The
washer fluid is sprayed only while the
windshield wipers move out of their
stowed positions to the point where
they start reversing back.
1. OFF
2. Washer
NOTE
If the windshield washer is turned on
when the windshield wipers are not
operating, the windshield wipers
operate a few times.
If you pull the wiper lever while the
windshield wipers are reversing back
to their stowed positions, the next
time the washer fluid is sprayed is
during the next cycle.
4-66
When Driving
Switches and Controls
Rear Window Washer
Rear Window Wiper and
To spray washer fluid, turn the rear
Washer*
wiper/washer switch to either of the
Rear Window Wiper and Washer
position. After the switch is
released, the washer will stop.
The ignition must be switched ON to
use the wiper.
NOTE
While the windshield washers are
Rear Window Wiper
operating (from the time the wiper
lever is pulled until the washer fluid
stops spraying), the rear window
washer does not spray washer fluid
even if you operate the switch.
If the washer does not work, inspect
the fluid level (page 6-21). If the fluid
level is normal and the washer still
does not work, consult an Authorized
Mazda Dealer.
Turn the wiper on by turning the rear
wiper/washer switch.
Switch Posi-
Wiper operation
tion
Spray washer fluid and operate
the rear wiper
ON
Normal
INT
Intermittent
OFF
Stop
Spray washer fluid and operate
the rear wiper
*Some models.
4-67
When Driving
Switches and Controls
NOTE
Rear Window Defogger
This defogger is not designed for
Rear Window Defogger
melting snow. If there is an
accumulation of snow on the rear
The rear window defogger clears fog
window, remove it before using the
from the rear window.
defogger.
The rear window defogger operation
The ignition must be switched ON to
time can be changed from 15
use the defogger.
minutes to continuous operation.
When the operation time has been
Press the switch to turn on the rear
switched to continuous operation,
window defogger. The rear window
by pressing the switch, the rear
defogger operates for about 15
window defogger will continue to
minutes and then turns off
operate until the ignition is switched
automatically.
OFF.
The indicator light illuminates when
Refer to the Settings section in the
the defogger is operating.
Mazda Connect Owner's Manual.
To turn off the rear window defogger
Windshield Wiper De-icer*
before the 15 minutes has elapsed,
press the switch again.
The thermal filaments at the following
positions heat up and facilitate the
removal of snow accumulated on the
windshield.
1. Indicator light
The windshield wiper de-icer operates
in conjunction with the rear window
CAUTION
defogger.
¾ Do not use sharp instruments or
window cleaners with abrasives to
clean the inside of the rear window
surface. They may damage the
defogger grid inside the window.
4-68
*Some models.
When Driving
Switches and Controls
To turn on the windshield wiper
Horn
de-icer, switch the ignition ON and
press the rear window defogger switch
Horn
(page 4-68).
To sound the horn, press the
mark on the steering wheel.
1. Indicator light
Mirror Defogger*
The mirror defoggers defrost the
outside mirrors.
The mirror defoggers operate in
conjunction with the rear window
defogger.
To turn on the mirror defoggers, switch
the ignition ON and press the rear
window defogger switch (page 4-68).
1. Indicator light
*Some models.
4-69
When Driving
Switches and Controls
Hazard Warning Flasher
HomeLink Wireless
Hazard Warning Flasher
Control System*
The hazard warning lights should
HomeLink Wireless Control
always be used when you stop on or
System
near a roadway in an emergency.
NOTE
HomeLink and HomeLink house are
registered trademarks of Gentex
Corporation.
The HomeLink system replaces up to 3
hand-held transmitters with a single
built-in component in the
auto-dimming mirror. Pressing the
HomeLink button on the
auto-dimming mirror activates garage
doors, gates and other devices
surrounding your home.
The hazard warning lights warn other
drivers that your vehicle is a traffic
hazard and that they must take
extreme caution when near it.
1. Indicator light
2. HomeLink button
Depress the hazard warning flasher
and all the turn signals will flash. The
WARNING
hazard warning indicator lights in the
instrument cluster flash simultaneously.
Do not use the HomeLink system with
NOTE
any garage door opener that lacks the
The turn signals do not work when
safety stop and reverse feature:
Using the HomeLink system with any
the hazard warning lights are on.
Check local regulations about the
garage door opener that lacks the
safety stop and reverse feature as
use of hazard warning lights while
the vehicle is being towed to verify
required by federal safety standards is
dangerous. (This includes garage doors
that it is not in violation of the law.
manufactured before April 1, 1982.)
4-70
*Some models.
When Driving
Switches and Controls
Using these garage door openers can
Programming the HomeLink
increase the risk of serious injury or
System
death. For further information, contact
The HomeLink system provides 3
HomeLink at www.homelink.com or
buttons which can be individually
selected and programmed using the
or an Authorized Mazda Dealer.
transmitters for current, on-market
devices as follows:
Always check the areas surrounding
1.
Press and release the HomeLink
garage doors and gates for people or
button you would like to program.
obstructions before programming or
The indicator light flashes slowly in
during operation of the HomeLink
amber when the button is pressed.
system:
Programming or operating the
HomeLink system without verifying the
safety of areas surrounding garage
doors and gates is dangerous and
could result in an unexpected accident
and serious injury if someone were to
be hit.
1. Indicator light
NOTE
2. HomeLink button
The programming will not be erased
even if the battery is disconnected.
2.
Hold the hand-held transmitter 2.5
to 7.5 cm (1 to 3 in) away from the
Pre-programming the HomeLink
HomeLink button you would like to
System
program while keeping the
indicator light in view.
NOTE
It is recommended that a new battery
NOTE
Depending on the hand-held
be placed in the hand-held transmitter
of the device being programmed to
transmitter, it may be easier to do
the programming by holding it 15
HomeLink for quicker training and
accurate transmission of the
to 20 cm (6 to 7.8 in) away from
the HomeLink button.
radio-frequency signal.
3.
Press the hand-held transmitter
Verify that there is a remote control
button continuously until the
transmitter available for the device
indicator light changes from amber
you would like to program.
(flashing) to green (on/flashing).
4-71
When Driving
Switches and Controls
NOTE
7.
Return to the vehicle and firmly
Some gate operators and garage
press and hold the Homelink
door openers may require you to
button, and then release it after
replace this Programming Step 3
two seconds have passed. Repeat
with procedures noted in the “Gate
the “press/hold/release” sequence
Operator/Canadian Programming”
a second time, and, depending on
section.
the brand of the garage door
4.
Press the HomeLink button again to
opener (or other rolling code
check if the programming has been
equipped device), repeat this
completed.
sequence a third time to complete
the programming process.
If the indicator light remains on in
Press the programmed HomeLink
green, the programming is
button and make sure that the
complete and the device
HomeLink System operates.
becomes operational.
8.
If the status indicator arrows are
If the indicator light flashes
flashing, refer to Garage Door
rapidly in green, firmly press and
Two-Way Communication.
hold the Homelink button and
release it after two seconds have
passed. Repeat this process up to
three times to complete the
programming. The device
becomes operational and
programming is complete. If the
device does not operate, go to
1. Indicator light
the next step.
5.
At the garage door opener receiver
NOTE
(motor-head unit) in the garage,
To program the remaining two
locate the “learn” or “smart” button.
HomeLink buttons, go back to Step 1
This can usually be found where the
of Programming the HomeLink System
hanging antenna wire is attached to
and repeat the procedure.
the motor-head unit.
For questions or comments, please
6.
Firmly press and release the “learn”
contact HomeLink at
or “smart” button. (The name and
color of the button may vary by
manufacturer.)
HomeLinkGentex, or the HomeLink
NOTE
toll-free hotline at 1-800-355-3515
Complete the programming within
(for calls placed outside of the USA,
30 seconds.
Canada, and Puerto Rico, international
rates will apply and may differ based
on landline or mobile phone).
4-72
When Driving
Switches and Controls
Gate operator/Canadian
Reprogramming the HomeLink
Programming
system
Canadian radio-frequency laws require
To program a device to HomeLink
transmitter signals to “time-out” (or
using a HomeLink button previously
quit) after several seconds of
trained, follow these steps:
transmission which may not be long
1. Press and hold the desired
enough for HomeLink to pick up the
HomeLink button. DO NOT release
signal during programming. Similar to
the button.
this Canadian law, some U.S. gate
2. After 20 seconds, the indicator light
operators are designed to “time-out”
flashes in amber. After the indicator
in the same manner.
light flashes, release the HomeLink
button.
If you live in Canada or are having
3. Go back to Step 2 of Programming
difficulties programming a gate
the HomeLink System to complete
operator by using the programming
the procedure.
procedures (regardless of where you
NOTE
live), replace Step 3 of Programming
If the programming has not been
the HomeLink System with the
completed, the system returns to the
following:
previous programming.
NOTE
Erasing Programmed HomeLink
If programming a garage door opener
Buttons
or gate operator, it is advised to unplug
the device during the “cycling” process
to prevent possible overheating.
NOTE
All of the programmed HomeLink
While the indicator light is flashing in
buttons are reset. Individual buttons
amber, press the button on the
cannot be reset, however, individual
hand-held transmitter for 2 seconds
buttons can be reprogrammed. For
and release it repeatedly until the
individual button reprogramming,
indicator light changes from amber to
refer to Reprogramming the
green.
HomeLink System (page 4-73).
Go back to Step 4 of Programming the
Verify that the programming has
HomeLink System to complete the
been erased if you resell the vehicle.
procedure.
Operating the HomeLink System
Press the programmed HomeLink
button to operate a programmed
device.
4-73
When Driving
Switches and Controls
1. Press the two outer HomeLink
If the garage door status indicator
buttons continuously at the same
lights do not flash, the two-way
time until the indicator light flashes.
communication programming is not
completed. For additional HomeLink
information and programming videos,
refer to the following Websites:
HomeLinkGentex
Operating the garage door two-way
1. HomeLink button 3
communication
2. HomeLink button 1
By pressing HomeLink buttons 1 and 2
at the same time for two seconds, the
2. Stop pressing the HomeLink
status of the garage door is indicated
buttons.
for about 3 seconds as follows:
Garage Door Two-Way
Communication
The garage door two-way
communication is a function that
communicates with the garage door
opener and indicates whether the
garages door is open or closed using
1. HomeLink button 2
the indicator lights in the rear view
2. HomeLink button 1
mirror. It can indicate the status of the
garage door within a range up-to 250
Garage door
Indicator light
m (820 ft).
status
Amber flashes
NOTE
Closing
The communication range may shorten
depending on obstructions.
Amber flashes
Programming two-way
Opening
communication
Within five seconds after programming
Green turns on
a new HomeLink button, both of the
Closed
garage door status indicator lights will
flash rapidly in green indicating that
the garage door two-way
Green turns on
communication has been established.
Opened
If the garage door status indicator
lights flash, the two-way
communication programming is
NOTE
complete.
The programming will not be erased
even if the battery is disconnected.
4-74
When Driving
Brake
Dry off brakes that have become wet
Brake System
by driving slowly, releasing the
accelerator pedal and lightly applying
Foot Brake
the brakes several times until the
This vehicle has power-assisted brakes
brake performance returns to normal:
that adjust automatically through
Driving with wet brakes is dangerous.
normal use.
Increased stopping distance or the
vehicle pulling to one side when
Should power-assist fail, you can stop
braking could result in a serious
by applying greater force than normal
accident. Light braking will indicate
to the brake pedal. But the distance
whether the brakes have been
required to stop will be greater than
affected.
usual.
WARNING
CAUTION
¾ Do not drive with your foot held on
Do not coast with the engine stalled
the clutch pedal or brake pedal, or
or turned off, find a safe place to stop:
hold the clutch pedal depressed
Coasting with the engine stalled or
halfway unnecessarily. Doing so
turned off is dangerous. Braking will
could result in the following:
require more effort, and the brake's
power-assist could be depleted if you
¾ The clutch and brake parts will
pump the brake. This will cause longer
wear out more quickly.
stopping distances or even an
¾ The brakes can overheat and
accident.
adversely affect brake
performance.
Shift to a lower gear when going
¾ Always depress the brake pedal with
down steep hills:
the right foot. Applying the brakes
Driving with your foot continuously on
with the unaccustomed left foot
the brake pedal or steadily applying
could slow your reaction time to an
the brakes for long distances is
emergency situation resulting in
dangerous. This causes overheated
insufficient braking operation.
brakes, resulting in longer stopping
distances or even total brake failure.
This could cause loss of vehicle control
and a serious accident. Avoid
continuous application of the brakes.
¾ Wear shoes appropriate for driving in
order to avoid your shoe contacting
the brake pedal when depressing the
accelerator pedal.
4-75
When Driving
Brake
Electric Parking Brake (EPB)
NOTE
The EPB system applies the parking
The parking brake cannot be applied
brake using an electric motor. The
or released while the vehicle battery
system can operate automatically and
is dead.
manually.
Refer to If a Jump-Starting on page
The EPB switch indicator light turns on
7-17.
when applying the parking brake and it
When the charging system warning
turns off when releasing the parking
light in the instrument cluster turns
brake.
on, the parking brake cannot be
applied after switching the ignition
OFF. Before switching the ignition
OFF, apply the parking brake
manually.
The sound of the parking brake being
applied or released can be heard,
however, this does not indicate a
problem.
If the EPB is not used for long
periods, an automatic inspection of
the system is performed while the
vehicle is parked. An operation
1. Indicator light
sound can be heard, however, this
does not indicate a problem.
WARNING
When applying the parking brake
and switching OFF the ignition, an
Do not drive the vehicle with the
operation sound can be heard,
parking brake applied:
however, this does not indicate a
If the vehicle is driven with the parking
problem.
brake applied, the brake parts may
The brake pedal may move while
generate heat and the brake system
applying or releasing the parking
may not operate, leading to an
brake, however, this does not
accident.
indicate a problem.
Before driving the vehicle, release the
If the parking brake is applied with
parking brake and make sure that the
the ignition switched OFF or in ACC,
EPB indicator light in the instrument
the EPB indicator light in the
cluster turns off.
instrument cluster and the indicator
light in the switch may turn on for 15
Apply the parking brake when leaving
seconds.
the vehicle:
When using an automatic car wash
Not applying the parking brake when
which moves the vehicle with the
parking the vehicle is dangerous as the
front tires mounted, it is necessary to
vehicle may move unexpectedly and
cancel the parking brake auto
result in an accident. Before leaving the
operation before the vehicle enters
vehicle, apply the parking brake and
the automatic car wash. For details,
make sure that the EPB indicator light
refer to Canceling the parking brake
in the instrument cluster turns on.
automatic operation.
4-76
When Driving
Brake
Release the parking brake and use
and the EPB switch indicator light turn
neutral hold mode (automatic car
off.
wash mode) when it is necessary to
change the shift position to the N
position for an automatic car wash.
Refer to Selector Lever Operation on
page 4-41.
Manual operation
Applying the parking brake manually
When the brake pedal is firmly
depressed and the EPB switch is pulled
up, the parking brake is applied
regardless of the ignition position.
If the EPB switch is pressed without
When the parking brake is applied, the
depressing the brake pedal, a message
EPB indicator light in the instrument
is displayed on the multi-information
cluster and the EPB switch indicator
display to notify the driver to depress
light turn on.
the brake pedal.
Refer to Message Indicated on
Multi-information Display on page
7-40.
Auto operation
Applying the parking brake
automatically
When the ignition is switched from ON
to ACC or OFF, the parking brake will
be applied automatically. When the
parking brake is applied, the EPB
indicator light in the instrument cluster
Releasing the parking brake manually
and the EPB switch indicator light turn
When the brake pedal is firmly
on.
depressed and the EPB switch is
NOTE
pressed while the ignition is switched
To release the parking brake when the
ON or the engine is running, the
ignition is switched OFF, it is necessary
parking brake is released. When the
to cancel the parking brake auto
parking brake is released, the EPB
operation. For details, refer to
indicator light in the instrument cluster
Canceling the parking brake automatic
operation.
4-77
When Driving
Brake
Releasing the parking brake
light changes to slow flashing, and
automatically
flashes for 4 seconds.
(Selector lever operation (Automatic
NOTE
transmission vehicle))
When the ignition is switched OFF,
If the selector lever is shifted from the
the system setting before it was
P position to a position other than P
turned off is maintained.
with the parking brake applied and all
(Accelerator pedal operation)
of the following conditions met, the
If the accelerator pedal is depressed
parking brake is released automatically.
with the parking brake applied and all
When the parking brake is released,
of the following conditions met, the
the EPB indicator light in the
parking brake is released automatically.
instrument cluster and the EPB switch
When the parking brake is released,
indicator light turn off.
the EPB indicator light in the
instrument cluster and the EPB switch
The engine is running.
indicator light turn off.
The driver's door is closed.
Shift interlock release is enabled.
The engine is running.
The brake pedal is being depressed.
The driver's door is closed.
The driver's seat belt is fastened.
(Manual transmission vehicle)
CAUTION
The shift lever is in a position other
Firmly depress the brake pedal and
than neutral.
perform the shift operation.
The clutch pedal is depressed
Otherwise, the vehicle may move
halfway.
unexpectedly.
(Automatic transmission vehicle)
When performing the following
The selector lever is in the D, M, or R
operations, shift interlock release can
position.
be enabled/disabled.
1. Switch the ignition ON.
CAUTION
2. Pull the EPB switch continuously for
4 seconds or longer.
If something such as the driver’s foot
3. Release the EPB switch once and
contacts the accelerator pedal with the
then pull it again continuously for 4
engine running and the parking brake
seconds or longer within 3 seconds.
applied, the parking brake may be
(Switching from disable to enable
released automatically and the vehicle
shift interlock release)
may move unexpectedly. If you do not
When shift interlock release is
intend to start driving the vehicle
enabled, a sound is activated 2
immediately, shift the shift lever to the
times and the EPB switch indicator
neutral position for a manual
changes to fast flashing, and flashes
transmission, or shift the selector lever
for 3 seconds.
to the P or N position for an automatic
(Switching from enable to disable
transmission.
shift interlock release)
When shift interlock release is
disabled, a sound is activated 2
times and the EPB switch indicator
4-78
When Driving
Brake
Canceling the parking brake
NOTE
automatic operation
When canceling the parking brake
The parking brake automatic operation
auto operation and parking the
can be canceled by doing any of the
vehicle, shift the shift lever to the 1st
following after switching the ignition
gear or the R position for a manual
from ON to OFF.
transmission, or shift the selector
lever to the P position for an
Auto operation cancel method 1
automatic transmission, and then
1. Switch the ignition ON.
use wheel blocks.
2. Release the parking brake manually.
The auto operation may not cancel if
3. Turn off the AUTOHOLD.
the vehicle is parked on a steep
4. Press the EPB switch continuously
slope.
for 2 seconds or longer (until a
When the ignition is switched ON, the
sound is activated).
parking brake auto operation is
5. Release the EPB switch and switch
restored.
the ignition OFF within 5 seconds
after the sound was activated.
How to use Emergency Brake
After the auto operation is
If there is a problem with the brake
canceled, a sound is activated one
system (foot brake) while driving the
time, and the EPB switch indicator
vehicle or in an emergency situation
light switches from illumination to
where the driver cannot step on the
flashing, and then turns off after 3
brake pedal, continually pulling up the
seconds.
EPB switch will apply the brakes and
Auto operation cancel method 2
decelerate or stop the vehicle. The
parking brake on-reminder sound is
1. Switch the ignition ON.
activated while the brake is applied. In
2. Release the parking brake manually.
addition, when releasing the switch,
3. Turn off the AUTOHOLD.
the brake is released and the sound
4. Switch the ignition OFF with the
stops.
EPB switch pressed while the brake
pedal is not depressed.
WARNING
When the auto operation is
canceled, a sound is activated one
Use Emergency Brake only in an
time, and the EPB switch indicator
emergency situation:
light goes from normal flashing to
Excessive use may cause the brake
faster flashing, and then turns off
parts to wear quickly or the brakes to
after 3 seconds.
heat up and become less effective.
Warning Light
The warning light turns on when the
system has a malfunction.
Refer to Brake System Warning
Indication/Warning Light on page
7-27.
4-79
When Driving
Brake
Brake Pad Wear Indicator
WARNING
When the disc brake pads become
worn, the built-in wear indicators
Do not drive with worn disc pads:
contact the disc plates. This causes a
Driving with worn disc pads is
screeching noise to warn that the pads
dangerous. The brakes could fail and
should be replaced.
cause a serious accident. As soon as
you hear a screeching noise consult an
Authorized Mazda Dealer.
NOTE
In high humidity weather conditions,
brake noises, such as brake squeak or
brake squeal can be heard. It does not
indicate a malfunction.
Brake Assist
When you hear this noise, consult an
During emergency braking situations
Authorized Mazda Dealer as soon as
when it is necessary to depress the
possible.
brake pedal with greater force, the
brake assist system provides braking
assistance, thus enhancing braking
performance.
When the brake pedal is depressed
hard or depressed more quickly, the
brakes apply more firmly.
NOTE
When the brake pedal is depressed
hard or depressed more quickly, the
pedal will feel softer but the brakes
will apply more firmly. This is a
normal effect of the brake assist
operation and does not indicate a
malfunction.
When the brake pedal is depressed
hard or depressed more quickly, a
motor/pump operation noise may
be heard. This is a normal effect of
the brake assist and does not
indicate a malfunction.
The brake assist equipment does not
supersede the functionality of the
vehicle's main braking system.
4-80
When Driving
Brake
Brake Override System
The brake override system applies the
brake first for safety if the brake pedal
and accelerator pedal are depressed at
the same time.
NOTE
Operation of the brake override system
can be turned on or off.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
4-81
When Driving
Brake
AUTOHOLD
AUTOHOLD
The AUTOHOLD function automatically holds the vehicle stopped, even if you take
your foot off the brake pedal. This function can be best used while stopped in traffic
or at a traffic light. The brakes are released when you start driving the vehicle.
WARNING
Do not rely completely on the AUTOHOLD function:
The AUTOHOLD function is only designed to assist the brake operation while the
vehicle is stopped. Neglecting to operate the brakes and relying only on the
AUTOHOLD system is dangerous and could result in an unexpected accident if the
vehicle were to suddenly move. Operate the brakes appropriately in accordance
with the road and surrounding conditions.
Note that the vehicle may move suddenly depending on the vehicle's load or if it is
towing something.
Do not release your foot from the brake pedal while the vehicle is stopped on a
steep grade:
Because there is a possibility of the vehicle not being held in the stopped position by
the AUTOHOLD function, the vehicle may move unexpectedly and result in an
accident.
Do not use the AUTOHOLD function on slippery roads such as icy or
snow-covered roads, or unpaved roads:
Even if the vehicle is held in the stopped position by the AUTOHOLD function, the
vehicle may move unexpectedly and result in an accident. Operate the accelerator
pedal, brakes, or steering wheel appropriately as necessary.
Immediately depress the brake pedal in the following cases:
Because the AUTOHOLD function is canceled forcibly, the vehicle may move
unexpectedly and result in an accident.
¾ “Depress Brake Pedal. Brake Hold Disabled” is displayed in the multi-information
display and the warning sound is activated at the same time.
Always apply the parking brake when parking the vehicle:
Not applying the parking brake when parking the vehicle is dangerous as the vehicle
may move unexpectedly and result in an accident. When parking the vehicle, shift
the selector lever to the P position (automatic transmission vehicle) and apply the
parking brake.
4-82
When Driving
Brake
CAUTION
If you stop operating the accelerator pedal before the vehicle starts moving, the
force holding the vehicle in the stopped position may weaken. Firmly depress the
brake pedal or depress the accelerator pedal to accelerate the vehicle.
NOTE
Under the following conditions, a problem with the AUTOHOLD is occurring.
Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible.
A message is indicated on the multi-information display and a warning sound is
activated for about 5 seconds while the AUTOHOLD is operating or when you
press the AUTOHOLD switch.
If you switch the ignition OFF while the AUTOHOLD is operating, the parking
brake is applied automatically to assist you with parking the vehicle.
The AUTOHOLD is canceled when the selector lever/shift lever is shifted to R
position while the vehicle is on level ground, or facing up a hill or grade (as shown
below).
Vehicle posture and road surface gradient
AUTOHOLD operation status
Vehicle tilts forward
Operates
Level ground
Does not operate, canceled
Vehicle tilts rearward
Does not operate, canceled
: Reverse driving (selector lever/shift lever in the reverse (R) position)
4-83
When Driving
Brake
The brake pedal response may change, sound may occur from the brakes, or the
brake pedal could vibrate from the operation of the AUTOHOLD function.
However, this does not indicate a malfunction.
To Turn On AUTOHOLD System
2. The AUTOHOLD active indicator
light in the instrument cluster turns
Press the AUTOHOLD switch and
on and the brakes are held.
when the AUTOHOLD standby
indicator light turns on, the
AUTOHOLD function turns on.
1. AUTOHOLD standby indicator light
NOTE
When all of the following conditions
are met, the AUTOHOLD standby
indicator light turns on when the
AUTOHOLD switch is pressed and the
AUTOHOLD function turns on.
The ignition is switched ON (engine
is running or stopped by i-stop).
The driver's seat belt is fastened.
The driver's door is closed.
There is no problem with the
AUTOHOLD function.
To operate AUTOHOLD and hold the
brakes
1. Depress the brake pedal and bring
the vehicle to a complete stop.
4-84
When Driving
Brake
3. The vehicle is held in its stopped
NOTE
position even with the brake pedal
If the Electric Parking Brake (EPB)
released.
switch is pulled while the
NOTE
AUTOHOLD is operating, the
When all of the following conditions
parking brake is applied and the
are met, the AUTOHOLD operates and
AUTOHOLD is released. In addition,
the brakes are held.
if the parking brake is released under
this condition, the AUTOHOLD
The ignition is switched ON (engine
operates to hold the brakes.
is running or stopped by i-stop).
Under the following conditions, the
The vehicle is stopped.
parking brake is automatically
The brake pedal is being depressed.
applied and the AUTOHOLD is
The AUTOHOLD active indicator
released. The AUTOHOLD is
light turns on.
re-enabled when the conditions
The accelerator pedal is not
before the AUTOHOLD is released
depressed.
are restored.
The driver's seat belt is fastened.
The driver's door is closed.
The driver’s seat belt is unfastened.
There is no problem with the
The driver’s door is opened.
AUTOHOLD function.
When about 10 minutes or longer
The parking brake is released.
have passed since the AUTOHOLD
There is no problem with the Electric
operation started, the parking brake
Parking Brake (EPB) function.
is automatically applied. Because the
(Automatic transmission vehicle)
AUTOHOLD is restored when
The selector lever is in a position
releasing the parking brake, the hold
other than R position or the vehicle
on the brakes by AUTOHOLD
tilts forward with the selector lever in
function resumes.
the R position.
(Manual transmission vehicle)
When starting to drive the vehicle
To release AUTOHOLD and start
forward or in reverse on a down
driving the vehicle
slope, depress the clutch pedal and
If you try to resume driving the vehicle,
shift the shift lever to the appropriate
the brakes will be released
position for driving in the desired
automatically and the AUTOHOLD
direction, and then depress the
active indicator light turns off.
accelerator pedal to release the
AUTOHOLD.
The AUTOHOLD can be canceled
forcibly by fully depressing the
accelerator pedal for 1 second or
longer while the AUTOHOLD is
operating. Forcibly cancel the
AUTOHOLD only when the
AUTOHOLD cannot be canceled due
to a system malfunction or it is
necessary to cancel the AUTOHOLD
in an emergency.
4-85















Content      ..     5      6      7      8     ..
