Mazda 3 (2022 year). Manual in english - page 4





Before Driving
Doors and Locks
After closing the doors and the
Door Locks
liftgate/trunk lid, always verify that
they are securely closed:
Door Locks
Doors and the liftgate/trunk lid not
securely closed are dangerous, if the
WARNING
vehicle is driven with a door and the
liftgate/trunk lid not securely closed,
Always take all children and pets with
the door and the liftgate/trunk lid
you or leave a responsible person
could open unexpectedly resulting in
with them:
an accident.
Leaving a child or a pet unattended in
a parked vehicle is dangerous. In hot
Always confirm the safety around the
weather, temperatures inside a vehicle
vehicle before opening a door and the
can become high enough to cause
liftgate/trunk lid:
brain damage or even death.
Suddenly opening a door and the
liftgate/trunk lid is dangerous. A
Do not leave the key in your vehicle
passing vehicle or a pedestrian could
with children and keep them in a
be hit and cause an accident.
place where your children will not
find or play with them:
CAUTION
Leaving children in a vehicle with the
key is dangerous. This could result in
¾ Always confirm the conditions
someone being badly injured or even
around the vehicle before opening/
killed.
closing the doors and the liftgate/
trunk lid and use caution during
Keep all doors locked when driving:
strong winds or when parked on an
Unlocked doors in a moving vehicle
incline. Not being aware of the
are dangerous. Passengers can fall out
conditions around the vehicle is
if a door is accidentally opened and
dangerous because fingers could get
can more easily be thrown out in an
caught in the door and the liftgate/
accident.
trunk lid or a passing pedestrian
could be hit, resulting in an
Always close all the windows and
unexpected accident or injury.
moonroof, lock the doors, fuel-filler
lid, and liftgate and take the key with
you when leaving your vehicle
unattended:
Leaving your vehicle unlocked is
dangerous as children could lock
themselves in a hot vehicle, which
could result in death. Also, a vehicle
left unlocked becomes an easy target
for thieves and intruders.
3-11
Before Driving
Doors and Locks
NOTE
(With the advanced keyless
function)
Always stop the engine and lock the
The beep sound is heard for about
doors. In addition, to prevent theft of
10 seconds to notify the driver that
valuables, do not leave them inside
the key has been left in the vehicle.
the cabin.
(Without the advanced keyless
If the key is left in the following areas
function)
and you leave the vehicle, the doors
The horn sound is heard twice to
may be locked depending on the
notify the driver that the key has
radio wave conditions even if the key
been left in the vehicle.
is left in the vehicle.
(Door unlock (control) system with
Around the dashboard
collision detection)
In the storage compartments such
This system automatically unlocks the
as the glove compartment or the
doors, fuel-filler lid, and liftgate in
center console
the event the vehicle is involved in an
On the rear parcel shelf (4-door)
accident to allow passengers to get
Next to a communication device
out of the vehicle immediately and
such as a mobile phone
prevent being trapped inside. While
When the ignition is switched to
the ignition is switched ON and in
ACC or ON, the vehicle lock-out
the event the vehicle receives an
prevention feature prevents you from
impact strong enough to inflate the
locking yourself out of the vehicle.
air bags, all the doors, fuel-filler lid,
All doors, fuel-filler lid, and liftgate
and liftgate are automatically
will automatically unlock if they are
unlocked after about 6 seconds have
locked using the power door locks
elapsed from the time of the
with any door or the liftgate open.
accident.
The vehicle lock-out prevention
The doors, fuel-filler lid, and liftgate
feature does not operate while the
may not unlock depending on how
ignition is switched off.
an impact is applied, the force of the
When all doors, fuel-filler lid, and
impact, and other conditions of the
liftgate are locked using the power
accident.
door lock with any door or the
If door-related systems or the battery
liftgate/trunk lid open, the closed
is malfunctioning, the doors,
doors, fuel-filler lid, and liftgate are
fuel-filler lid, and liftgate may not
locked. After that, when all doors
unlock depending on your vehicle
and the liftgate/trunk lid are closed,
type.
all doors and the liftgate/trunk lid
are locked. However, if the key is
inside the vehicle, all doors,
fuel-filler lid, and liftgate are
automatically unlocked.
3-12
Before Driving
Doors and Locks
Unlocking with Auxiliary Key
2. Sensing area of door release touch
sensor (Inner side of door handle)
Only the driver's door can be unlocked
using the auxiliary key.
NOTE
Refer to Keys on page 3-2.
When locking/unlocking with the
Insert the auxiliary key while the
transmitter carried, securely touch
driver's door handle is pulled and turn
the sensing area of the touch sensor
the key to the unlock side. Turn the
as follows.
auxiliary key back to its original
Locking
position before removing it.
Unlocking
NOTE
If you attempt to open the driver’s
door using an unauthorized auxiliary
key, the key cylinder will spin around
but the door will not unlock.
Locking, Unlocking with Touch
The system may not operate normally
Sensor, Door Handle (With the
under the following conditions.
advanced keyless function)
You touch the sensing area of the
By touching the sensing area of the
door lock touch sensor and the
touch sensor, various locking/
sensing area of the door release
unlocking operations can be done
touch sensor at the same time.
without taking the key out of a bag or
pocket.
There are two types of touch sensors
used for locking and unlocking, and
each sensor is built into the outer door
handle on the driver and front
passenger's doors.
You touch the sensing area of the
touch sensor while wearing gloves.
Foreign matter such as snow or dirt
1. Sensing area of door lock touch
is stuck on the sensing area of the
sensor (Depression on outer side of
touch sensor.
door handle)
3-13
Before Driving
Doors and Locks
You pull the door handle just after
(Unlocking from the driver's door)
touching the sensing area of the
The following locations are unlocked
touch sensor.
by touching the sensing area of the
The system may operate if the outer
door release touch sensor of the
side door handle of a front door is
driver's door.
splashed with water by a car wash or
Driver’s door
rain while the transmitter is in the
Fuel-filler lid
operation range.
If the system does not operate even
NOTE
though you touch the sensing area of
the touch sensor correctly, release
The location to be unlocked can be
the touch sensor once, and then
changed.
touch the sensing area of the touch
Refer to the Settings section in the
sensor again after waiting about 3
Mazda Connect Owner's Manual.
seconds.
When unlocking, the hazard warning
Locking
lights and sound operate two times.
When locking, touch the sensing area
(Unlocking from the front passenger’s
of the door lock touch sensor with all
door)
of the following conditions met.
The following locations are unlocked
The ignition is switched OFF.
by touching the sensing area of the
All the doors are closed.
door release touch sensor of the front
You are carrying the transmitter.
passenger's door.
The following locations are locked by
All doors
touching the sensing area of the door
Fuel-filler lid
lock touch sensor.
Liftgate
All doors
When unlocking, the hazard warning
Fuel-filler lid
lights and sound operate two times.
Liftgate
NOTE
When locking, the hazard warning
Confirm that all the doors and
lights and sound operate one time.
liftgate/trunk lid are securely locked.
Unlocking
For the liftgate/trunk lid, move it
without pressing the electric liftgate/
When unlocking, touch the sensing
trunk lid opener to verify that the
area of the door release touch sensor
liftgate/trunk lid has not been left
with all of the following conditions
ajar.
met.
The ignition is switched OFF.
The driver’s door is locked.
Three seconds or longer have passed
since the doors were locked.
You are carrying the transmitter.
3-14
Before Driving
Doors and Locks
A beep sound is heard for
(Walk-away auto lock function)
confirmation when the doors,
A beep sound is heard when all
fuel-filler lid, and liftgate are locked/
doors and the liftgate/trunk lid are
unlocked using the touch sensor. If
closed while the transmitter is being
you prefer, the beep sound can be
carried. All the doors, fuel-filler lid,
turned off.
and liftgate are locked automatically
The volume of the beep sound can
when the transmitter is out of the
also be changed. Refer to the
operational range. Also, the hazard
Settings section in the Mazda
warning lights flash once. (Even if the
Connect Owner's Manual.
driver is in the operational range, all
(With theft-deterrent system)
the doors, fuel-filler lid, and liftgate
The hazard warning lights flash when
are locked automatically after about
the theft-deterrent system is armed
30 seconds.) If you are out of the
or turned off.
operational range before the doors
Refer to Theft-Deterrent System on
and the liftgate/trunk lid are
page 3-44.
completely closed or another
The setting can be changed so that
transmitter is left in the vehicle, the
the doors, fuel-filler lid, and liftgate
walk-away auto lock function will
are locked automatically without
not work. Always make sure that all
touching the sensing area of the
doors and the liftgate/trunk lid are
touch sensor.
closed and locked before leaving the
Refer to the Settings section in the
vehicle. The walk-away auto lock
Mazda Connect Owner's Manual.
function does not close the power
windows.
3-15
Before Driving
Doors and Locks
(Auto re-lock function)
Driver's door
After unlocking with the touch
sensor, all the doors , fuel-filler lid,
and liftgate will automatically lock if
any of the following operations are
not performed within about 60
seconds.
Opening a door or the liftgate/
trunk lid.
Switching the ignition to any
position other than off.
1. Unlock
If your vehicle has a theft-deterrent
2. Lock
system, the hazard warning lights will
Front passenger's door
flash for confirmation.
The time required for the doors to
lock automatically can be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Locking, Unlocking with
Transmitter
The following locations can be locked/
unlocked by operating the keyless
entry system transmitter. Refer to
Keyless Entry System (page 3-4).
1. Unlock
All doors
2. Lock
Fuel-filler lid
Liftgate
NOTE
To prevent the transmitter from being
Locking, Unlocking with
left in the vehicle, make sure that you
Door-Lock Switch
carry the transmitter before locking.
Door-lock switch on driver’s and front
After locking by pressing the
passenger's door
door-lock switch and when the
liftgate/trunk lid is closed last with
The following locations are locked/
the transmitter left in the vehicle,
unlocked by pressing the door-lock
only the liftgate/trunk lid is
switch.
unlocked.
All doors
Locking from the outside using the
Fuel-filler lid
Liftgate
door-lock switch
Doors can be locked from the outside
of the vehicle without using the
transmitter.
3-16
Before Driving
Doors and Locks
When locking from the outside using
NOTE
the door-lock switch, press the lock
To prevent the transmitter from being
side of the door-lock switch with all of
left in the vehicle, make sure that the
the following conditions met and then
driver carries the transmitter when
close all the doors.
locking the doors with any door
The ignition is switched OFF.
open.
Any door is open.
After locking by pressing the
door-lock switch and when all the
doors are closed with the transmitter
left in the vehicle, all the doors,
liftgate, and fuel-filler lid are
unlocked.
Door-lock switch on liftgate (With the
advanced keyless function)
All doors, fuel-filler lid, and the liftgate
can be locked by pressing the
door-lock switch.
When locking using the door-lock
switch, press the door-lock switch with
all of the following conditions met and
then close the liftgate.
You are carrying the transmitter.
The ignition is switched OFF.
All the doors are closed.
3-17
Before Driving
Doors and Locks
(With theft-deterrent system)
Locking, Unlocking with
When locking, a beep sound operates
Door-Lock Knob
1 time.
Operation from inside
When the liftgate closes, the hazard
warning lights operate 1 time.
To lock any door from the inside, press
the door-lock knob.
(Without theft-deterrent system)
To unlock, pull it outward.
When locking, the hazard warning
This does not operate the other door
lights and a beep sound operate 1
locks.
time.
NOTE
To prevent the transmitter from being
left in the vehicle, make sure that you
carry the transmitter before locking.
After locking by pressing the
door-lock switch and when the
liftgate is closed with the transmitter
left in the vehicle, the liftgate is
unlocked.
1.
Unlocked: Red indicator
Auto Lock/Unlock Function
2.
Lock
3.
Unlock
WARNING
Do not pull the inner handle on a
front door:
Pulling the inner handle on a front
door while the vehicle is moving is
dangerous. Passengers can fall out of
the vehicle if the door opens
accidentally, which could result in
death or serious injury.
When the vehicle speed exceeds 20
km/h (12 mph), all the doors,
fuel-filler lid, and liftgate lock
automatically.
When the ignition is switched off, all
the doors, fuel-filler lid, and liftgate
unlock automatically.
The auto lock/unlock function settings
can be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
3-18
Before Driving
Doors and Locks
Operation from outside
Rear Door Child Safety Locks
To lock any door using its door-lock
Rear doors that have been locked
knob from the outside, press the
using the child safety lock switched to
door-lock knob to the lock position
the lock side cannot be opened from
and close the door (holding the door
inside the vehicle.
handle in the open position is not
For child safety, switch the child safety
required).
lock on both rear doors to the lock
This does not operate the other door
side.
locks.
When opening a rear door with the
child safety lock switched to the lock
side, pull the outer door handle with
the lock knob inside the vehicle
switched to the unlock side.
1. Auxiliary key (page 3-2)
2. Lock
3. Unlock
NOTE
When locking the door this way:
Be careful not to leave the key inside
the vehicle.
The doors cannot be locked using
the driver's door lock knob if any
door or liftgate is open when the
ignition is switched to ACC or ON.
All the doors, fuel-filler lid , and
liftgate are unlocked when the lock
knob on all the doors is pressed
down to the lock side and all the
doors are closed with the transmitter
left in the vehicle.
3-19
Before Driving
Doors and Locks
Liftgate/Trunk Lid
CAUTION
Liftgate/Trunk Lid
¾ Before opening the liftgate/trunk lid,
remove any snow and ice
accumulation on it. Otherwise, the
WARNING
liftgate/trunk lid could close under
the weight of the snow and ice
Never allow a person to ride in the
resulting in injury.
luggage compartment/trunk:
¾ Be careful when opening/closing the
Allowing a person to ride in the
liftgate/trunk lid during strong
luggage compartment/trunk is
winds. If a strong gust blows against
dangerous. The person in the luggage
the liftgate/trunk lid, it could close
compartment/trunk could be seriously
suddenly resulting in injury.
injured or killed during sudden braking
¾ Fully open the liftgate/trunk lid and
or a collision.
make sure that it stays open. If the
liftgate/trunk lid is only opened
Do not drive with the liftgate/trunk
partially, it could slam shut by
lid open:
vibration or wind gusts resulting in
Exhaust gas in the cabin of a vehicle is
injury.
dangerous. An open liftgate/trunk lid
¾ When loading or unloading luggage
in a moving vehicle will cause exhaust
in the luggage compartment/trunk,
gas to be drawn into the cabin. This
turn off the engine. Otherwise, you
gas contains CO (carbon monoxide),
could get burned by the heat of the
which is colorless, odorless, and highly
exhaust gas.
poisonous, and it can cause loss of
¾ Be careful not to apply excessive
consciousness and death. Moreover,
force to the damper stay on the
an open liftgate/trunk lid could cause
liftgate such as by putting your hand
occupants to fall out in an accident.
on the stay. Otherwise, the damper
stay may bend and affect the liftgate
Do not stack or leave loaded luggage
operation.
unsecured in the luggage
compartment:
Otherwise, the luggage may move or
collapse, resulting in injury or an
accident. In addition, do not load
luggage higher than the seatbacks. It
may affect the side or rear field of view.
Additionally, if the air bags deploy, the
cargo may scatter which could result in
serious injury or death.
1. Damper stay
3-20
Before Driving
Doors and Locks
¾ Do not modify or replace the liftgate
The liftgate can be closed when the
damper stay. Consult an Authorized
doors are locked with the key left in
Mazda Dealer if a liftgate damper
the vehicle. However, to prevent
stay is deformed or damaged for
locking the key in the vehicle, the
reasons such as a collision or if there
liftgate can be opened by pressing
is some other problem.
the electric liftgate opener. If the
liftgate cannot be opened despite
Opening and Closing the Liftgate/
doing this procedure, first push the
Trunk Lid
liftgate completely closed, then press
the electric liftgate opener to fully
Opening the liftgate (5-door)
open the liftgate.
Using the electric liftgate opener
When the liftgate latch is released by
pressing the electric liftgate opener,
Unlock the doors and liftgate, then
the liftgate raises slightly. If the
press the electric liftgate opener on the
liftgate is not operated for a certain
liftgate and raise the liftgate when the
period of time, the liftgate cannot be
latch releases.
raised.
To open
Press the electric liftgate opener
again.
To close
To close the liftgate from its slightly
raised position, open it first by
pressing the electric liftgate opener,
then close it after waiting at least 1
second.
If the vehicle battery is dead or there
is a malfunction in the electrical
NOTE
system and the liftgate cannot be
(With the advanced keyless function)
unlocked, the liftgate can be opened
A locked liftgate can also be opened
by performing the emergency
while the key is being carried.
procedure.
When opening the liftgate with the
Refer to When Liftgate/Trunk Lid
doors and the liftgate locked, it may
Cannot be Opened on page 7-49.
require a few seconds for the liftgate
latch to release after the electric
liftgate opener is pressed.
3-21
Before Driving
Doors and Locks
Opening the trunk lid (4-door)
The trunk lid can be closed when the
doors are locked with the key left in
Using the trunk lid release button
the vehicle. However, to prevent
Push the trunk lid release button.
locking the key in the vehicle, the
trunk lid can be opened by pressing
the electric trunk lid opener. If the
trunk lid cannot be opened despite
doing this procedure, press the
electric trunk lid opener to fully open
the trunk lid after pushing the trunk
lid completely closed.
If the vehicle battery is dead or there
is a malfunction in the electrical
system and the trunk lid cannot be
unlocked, the trunk lid can be
opened by performing the
emergency procedure.
Using the electric trunk lid opener
Refer to When Liftgate/Trunk Lid
(With the advanced keyless function)
Cannot be Opened on page 7-49.
A trunk lid can also be opened while
Closing the liftgate/trunk lid
the key is being carried.
Lower the liftgate/trunk lid slowly
Press the electric trunk lid opener on
using the liftgate/trunk lid grip recess,
the trunk lid, then raise the trunk lid
then push the liftgate/trunk lid closed
when the latch releases.
using both hands.
Do not slam it. Pull up on the liftgate/
trunk lid to make sure it is secure.
(5-door)
NOTE
When opening the trunk lid with the
doors locked, it may require a few
seconds for the trunk lid latch to
release after the electric trunk lid
opener is pressed.
3-22
Before Driving
Doors and Locks
(4-door)
Make sure luggage and cargo are
secured before driving:
Not securing cargo while driving is
dangerous as it could move or be
crushed during sudden braking or a
collision and cause injury.
CAUTION
¾ Make sure the luggage compartment
cover is firmly secured. If it is not
firmly secured, it could unexpectedly
disengage resulting in injury.
WARNING
The luggage compartment can be
accessed by opening the liftgate when
Do not drive the vehicle with the
the straps are attached to the sides of
liftgate-ajar warning indication
the liftgate.
displayed :
Otherwise, the liftgate/trunk lid may
open unexpectedly and result in an
accident.
NOTE
Confirm that the liftgate/trunk lid is
securely closed.
Move the liftgate/trunk lid without
pressing the electric liftgate/trunk lid
opener to verify that the liftgate/trunk
lid has not been left ajar.
Luggage Compartment
Luggage compartment cover (5-door)
WARNING
Do not place anything on top of the
cover:
Placing luggage or other cargo on top
of the luggage compartment cover is
dangerous. During sudden braking or a
collision, the cargo could become a
projectile that could hit and injure
someone.
3-23
Before Driving
Doors and Locks
Removing the luggage compartment
Inside Trunk Release
cover
Lever (4-door)*
This cover can be removed for more
room.
Inside Trunk Release Lever
1.
Remove the straps from the hooks.
2.
Press the luggage compartment
Your vehicle is equipped with an inside
cover upward from near the pins
trunk release lever that provides a
and remove the luggage
means of escape for children and
compartment cover from the pins.
adults in the event they become locked
inside the trunk.
No matter how careful adults might be
with keys and locking their cars,
parents should be aware that children
may be tempted to play around
vehicles and use the trunk as a hiding
place.
Adults are advised to familiarize
themselves with the operation and
location of the inside trunk release
1. Pin
lever so that all children can be told
about it in an appropriate way, keeping
3.
Lift the front end of the luggage
in mind that most vehicles do not have
compartment cover and remove it.
such levers.
WARNING
Close the trunk lid, be sure the seat
backs are latched and do not allow
children to play inside the vehicle:
Leaving the trunk lid open or leaving
children in the vehicle with the keys is
dangerous. Children could open the
trunk lid and climb inside resulting in
possible injury or death from heat
exposure.
3-24
*Some models.
Before Driving
Doors and Locks
Always keep the car from being a
tempting place to play by latching the
rear seats, doors and the trunk, and
keeping the keys where children can
not play with them:
Leaving children or animals unattended
in a parked vehicle is dangerous.
Babies left sleeping and children who
lock themselves in cars or trunks can
die very quickly from heat prostration.
Do not leave your children or pets
alone in a car at any time. Do not leave
the car, the rear folding seats or the
trunk unlocked.
Opening the Trunk Lid from the
Inside
Slide the inside trunk release lever in
the direction of the arrow. The lever is
made of material that will glow for
hours in the darkness of the trunk
following a brief exposure to ambient
light.
The inside trunk release lever is located
on the inside of the trunk lid.
3-25
Before Driving
Fuel and Emission
Fuel and Engine Exhaust Precautions
Fuel Requirements
Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED
FUEL, which will reduce exhaust emissions and keep spark plug fouling to a
minimum.
To achieve maximum engine performance, use the specified fuel.
Fuel
Octane Rating*1 (Anti-knock index)
Regular unleaded fuel
87 [(R+M)/2 method] or above (91 RON or above)
*1
U.S. federal law requires that octane ratings be posted on gas station pumps.
Fuel with a rating lower than 87 octane (91 RON) will negatively affect the emission
control system performance and could also cause engine knocking and serious
engine damage.
CAUTION
¾ USE ONLY UNLEADED FUEL.
Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead
to deterioration of the emission control system and or failures.
¾ This vehicle can only use oxygenated fuels containing no more than 10 % ethanol
by volume. Damage to the vehicle may occur when ethanol exceeds this
recommendation, or if the gasoline contains any methanol. Stop using gasohol of
any kind if your vehicle engine is performing poorly.
¾ Never add fuel system additives other than a Mazda genuine product, otherwise
the emission control system could be damaged. Consult an Authorized Mazda
Dealer for details.
Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with
your vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol,
such as ethanol or methanol, may be marketed under the name "Gasohol".
Vehicle damage and drivability problems resulting from the use of the following may
not be covered by the warranty.
Gasohol containing more than 10 % ethanol.
Gasoline or gasohol containing methanol.
Leaded fuel or leaded gasohol.
3-26
Before Driving
Fuel and Emission
Emission Control System
NOTE
This vehicle is equipped with an
Under U.S. federal law, any
emission control system (the catalytic
modification to the
converter is part of this system) that
original-equipment emission control
enables the vehicle to comply with
system before the first sale and
existing exhaust emissions
registration of a vehicle is subject to
requirements.
penalties. In some states, such
modification made on a used vehicle
WARNING
is also subject to penalties.
While the engine is off, the sound of
Never park over or near anything
a valve opening and closing can be
flammable:
heard at the rear of the vehicle,
Parking over or near anything
however this does not indicate an
flammable, such as dry grass, is
abnormality. The vehicle has a
dangerous. Even with the engine
self-checking device and it operates
turned off, the exhaust system remains
while the engine is off.
very hot after normal use and could
Engine Exhaust (Carbon
ignite anything flammable. A resulting
monoxide)
fire could cause serious injury or death.
WARNING
CAUTION
Ignoring the following precautions
Do not drive your vehicle if you smell
could cause lead to accumulate on the
exhaust gas inside the vehicle:
catalyst inside the converter or cause
Engine exhaust gas is dangerous. This
the converter to get very hot. Either
gas contains carbon monoxide (CO),
condition will damage the converter
which is colorless, odorless, and
and cause poor performance.
poisonous. When inhaled, it can cause
loss of consciousness and death. If you
¾ USE ONLY UNLEADED FUEL.
smell exhaust gas inside the vehicle,
¾ Do not drive your Mazda with any
keep all windows fully open and
sign of engine malfunction.
contact an Authorized Mazda Dealer
¾ Do not coast with the ignition
immediately.
switched off.
¾ Do not descend steep grades in gear
with the ignition switched off.
¾ Do not operate the engine at high
idle for more than 2 minutes.
¾ Do not tamper with the emission
control system. All inspections and
adjustments must be made by a
qualified technician.
¾ Do not push-start or pull-start this
vehicle.
3-27
Before Driving
Fuel and Emission
Do not run the engine when inside an
Fuel-Filler Lid and Cap
enclosed area:
Running the engine inside an enclosed
Fuel-Filler Lid and Cap
area, such as a garage, is dangerous.
Exhaust gas, which contains poisonous
carbon monoxide, could easily enter
WARNING
the cabin. Loss of consciousness or
even death could occur.
When removing the fuel-filler cap,
loosen the cap slightly and wait for
Open the windows or adjust the
any hissing to stop, then remove it:
heating or cooling system to draw
Fuel spray is dangerous. Fuel can burn
fresh air when idling the engine:
skin and eyes and cause illness if
Exhaust gas is dangerous. When the
ingested. Fuel spray is released when
vehicle is stopped with the windows
there is pressure in the fuel tank and
closed and the engine running for a
the fuel-filler cap is removed too
long time even in an open area,
quickly.
exhaust gas, which contains poisonous
carbon monoxide, could enter the
Before refueling, stop the engine, and
cabin. Loss of consciousness or even
always keep sparks and flames away
death could occur.
from the filler neck:
Fuel vapor is dangerous. It could be
Clear snow from underneath and
ignited by sparks or flames causing
around your vehicle, particularly the
serious burns and injuries.
tail pipe, before starting the engine:
Additionally, use of the incorrect
Running the engine when a vehicle is
fuel-filler cap or not using a fuel-filler
stopped in deep snow is dangerous.
cap may result in a fuel leak, which
The exhaust pipe could be blocked by
could result in serious burns or death
the snow, allowing exhaust gas to
in an accident.
enter the cabin. Because exhaust gas
contains poisonous carbon monoxide,
Do not continue refueling after the
it could cause loss of consciousness or
fuel pump nozzle shuts off
even death to occupants in the cabin.
automatically:
Continuing to add fuel after the fuel
pump nozzle has shut off automatically
is dangerous because overfilling the
fuel tank may cause fuel overflow or
leakage. Fuel overflow and leakage
could damage the vehicle and if the
fuel ignites it could cause a fire and
explosion resulting in serious injury or
death.
3-28
Before Driving
Fuel and Emission
However, when the driver's door
CAUTION
is locked using the following
¾ Always use only a genuine Mazda
functions, the fuel lid is also
fuel-filler cap or an approved
locked at the same time.
equivalent, available at an
Auto lock/unlock function
Authorized Mazda Dealer. The
(page 3-18)
wrong cap can result in a serious
Auto re-lock function (page
malfunction of the fuel and emission
3-5) and (page 3-13)
control systems.
2.
Press the location shown in the
(U.S.A. and Canada)
illustration and open the fuel lid.
It may also cause the check engine
light in the instrument cluster to
illuminate.
¾ When using an automatic car wash
or a high water pressure car washer,
lock the vehicle. Otherwise, the
fuel-filler lid may open unexpectedly
and could be damaged.
Refueling
3.
To remove the fuel-filler cap, turn it
Before refueling, close all the doors,
counterclockwise.
windows, and liftgate/trunk lid, and
4.
Attach the removed cap to the
switch the ignition OFF.
inner side of the fuel-filler lid.
1.
Using the following, unlock the
driver’s door.
4-door
Transmitter (page 3-16)
Touch sensor (page 3-13)
Door-lock switch (page 3-16)
Auto lock/unlock function (page
3-18)
NOTE
When unlocking the driver's
door, the fuel lid is also unlocked
at the same time.
1. Fuel-filler lid
When locking the driver's door,
2. Fuel-filler cap
the fuel lid is locked after 90
seconds.
The time until the fuel lid is
locked after locking the driver's
door can be changed.
Refer to the Settings section in
the Mazda Connect Owner's
Manual.
3-29
Before Driving
Fuel and Emission
5-door
NOTE
Lock the doors after closing the
fuel-filler lid.
If the fuel-filler lid is closed after
locking the doors, the fuel-filler lid
cannot be locked.
CAUTION
(U.S.A. and Canada)
If the check fuel cap warning light
illuminates, the fuel-filler cap may not
1. Fuel-filler lid
be properly installed. If the warning
2. Fuel-filler cap
light illuminates, park your vehicle
safely off the right-of-way, remove the
5.
Insert the refueling nozzle all the
fuel-filler cap and reinstall it correctly.
way and begin refueling. Pull out
After the cap has been correctly
the refueling nozzle after the
installed, the fuel cap warning light
refueling stops automatically.
may continue to illuminate until a
6.
To close the fuel-filler cap, turn it
number of driving cycles have been
clockwise until a click is heard.
completed. A drive cycle consists of
7.
To close, press the fuel-filler lid
starting the engine (after four or more
until a click sound is heard.
hours with the engine off) and driving
the vehicle on city and highway roads.
4-door
Continuing to drive with the check fuel
cap warning light illuminated could
cause the check engine light to
illuminate as well.
5-door
8. Make sure to lock all the doors
when leaving the vehicle.
3-30
Before Driving
Mirrors
2.
Press the adjustment switch to
Mirrors
adjust the angle of the outside
mirror.
Mirrors
Before driving, adjust the inside and
outside mirrors.
Outside Mirrors
WARNING
Be sure to look over your shoulder
before changing lanes:
Changing lanes without taking into
account the actual distance of the
vehicle in the convex mirror is
dangerous. You could have a serious
accident. What you see in the convex
mirror is closer than it appears.
Mirror type
Flat type (driver's side)
1.
Indicator light
Flat surface mirror.
2.
Select switch
Convex type (front passenger side)
3.
Adjustment switch
The mirror has single curvature on its
surface.
After adjusting the angle of the outside
mirror, press the select switch for the
Power mirror adjustment
outside mirror to be adjusted to turn
The ignition must be switched to ACC
off the indicator light.
or ON position.
NOTE
To adjust:
(With driving position memory
1. Press the select switch for the
function)
outside mirror to be adjusted to
The on-road outside mirror position
turn on the indicator light.
can be programmed in conjunction
with the driving position memory
function.
Refer to Driving Position Memory on
page 2-11.
3-31
Before Driving
Mirrors
Power mirrors with reverse tilt down
Folding outside mirror
function*
The outside mirrors tilt downward to
WARNING
facilitate the view of the lower area on
each side of the vehicle.
Always return the outside mirrors to
1. Switch the ignition ON.
the driving position before you start
2. Press the select switch for the
driving:
outside mirror to be tilted
Driving with the outside mirrors folded
downward to turn on the indicator
in is dangerous. Your rear view will be
light of the select switch.
restricted, and you could have an
3. Shift the shift lever/selector lever to
accident.
the R position to tilt the outer
Manually fold the outside mirror
mirror on the side where the select
rearward until it is flush with the
button was pressed downward.
vehicle.
NOTE
When any of the following condition is
met, the outer mirrors return to their
normal positions.
The ignition is switched to a position
other than ON.
The shift lever/selector lever is
shifted to a position other than R.
The select switch is pressed again.
Engine-off outside mirror operation
The outside mirrors can be operated
for about 40 seconds after the ignition
is switched from ON to off.
Driver's side auto-dimming outside
mirror*
The movement of the auto-dimming
outside mirror is interlocked with the
auto-dimming rearview mirror in the
interior to automatically reduce glare
from rear on-coming vehicles.
Refer to Rearview Mirror on page
3-33.
NOTE
The front passenger-side outside
mirror does not have the
auto-dimming feature.
3-32
*Some models.
Before Driving
Mirrors
Rearview Mirror
Reducing glare from headlights
Manual day/night mirror
WARNING
Push the day/night lever forward for
day driving. Pull it back to reduce glare
Do not stack cargo or objects higher
of headlights from vehicles at the rear.
than the seatbacks:
Cargo stacked higher than the
seatbacks is dangerous. It can block
your view in the rearview mirror, which
might cause you to hit another car
when changing lanes.
Rearview mirror adjustment
Before driving, adjust the rearview
mirror to center on the scene through
the rear window.
1. Day/Night lever
2. Night
3. Day
Auto-dimming mirror
The auto-dimming mirror
automatically reduces the glare of
headlights from vehicles at the rear
when the ignition is switched ON.
NOTE
For the manual day/night mirror,
perform the adjustment with the day/
night lever in the day position.
3-33
Before Driving
Mirrors
(With ON/OFF button)
(With Homelink wireless control
Press the ON/OFF button ( ) to cancel
system)
the auto-dimming function. The
For information regarding the 3
indicator light will turn off.
buttons ( ,
,
) on the
To reactivate the auto-dimming
auto-dimming mirror.
function, press the ON/OFF button
Refer to HomeLink Wireless Control
(
). The indicator light will illuminate.
System on page 4-70.
The auto-dimming function is
canceled when the ignition is
switched ON and the shift lever/
selector lever is in the R position.
1. ON/OFF button
2. Indicator light
NOTE
Do not use glass cleaner or suspend
objects on or around the light
sensor. Otherwise, light sensor
sensitivity will be affected and may
not operate normally.
1. Light sensor
3-34
Before Driving
Windows
Do not let a child put a hand or head
Power Windows
out of the window while driving the
vehicle:
Power Windows
If the person's hand or head hits
The windows can be opened/closed
something outside the vehicle, or
by operating the power window
sudden braking is applied, it could
switches.
result in serious injury or death.
WARNING
NOTE
When driving with only 1 of the rear
Make sure the opening is clear before
windows open, your ears might
closing a window:
experience a resonating sound.
Closing a power window is dangerous.
However, this does not indicate a
A person's hands, head, or even neck
problem. The sound can be reduced
could be caught by the window and
by slightly opening a front window or
result in serious injury or even death.
by changing the size of the rear
This warning applies especially to
window opening.
children.
Opening/Closing Windows
Never allow children to play with
The window opens while the switch is
power window switches:
pressed and it closes while the switch
Power window switches that are not
is pulled up with the ignition switched
locked with the power window lock
ON. Do not open or close 3 or more
switch would allow children to operate
windows at the same time.
power windows unintentionally, which
The front passenger's window and rear
could result in serious injury if a child's
windows can be opened/closed when
hands, head or neck becomes caught
the power window lock switch on the
by the window.
driver's door is in the unlocked
position. Keep this switch in the locked
Make sure nothing blocks the window
position while children are in the
just before it reaches the fully closed
vehicle.
position or while fully holding up the
power window switch:
Blocking the power window just before
it reaches the fully closed position or
while fully holding up the power
window switch is dangerous.
In this case, the jam-safe function may
not prevent the window from closing
all the way. If fingers are caught,
serious injuries could occur.
3-35
Before Driving
Windows
Master control switches
Front passenger's window switch/
Rear window switches
1. Close
2. Open
NOTE
A power window may no longer
open/close if you continue to press
the switch for a long time. If the
power window does not open/
close, wait for a while and then
operate the switch again.
The passenger windows may be
opened or closed using the master
control switches on the driver's door.
1.
Close
The power window can be operated
2.
Open
for about 40 seconds after the
3.
Front passenger's window
ignition is switched from ON to ACC
4.
Right rear window
or off with all doors closed. If any
5.
Power window lock switch
door is opened, the power window
6.
Left rear window
will stop operating.
7.
Driver's window
8.
Locked position
9.
Unlocked position
3-36
Before Driving
Windows
Auto-opening/Closing
Jam-safe Window
To fully open the window
When the window is closing and a
automatically, press the switch
foreign object is detected between the
completely down, then release. The
window and the window frame, the
window will fully open automatically.
window stops closing and
To fully close the window
automatically opens partway.
automatically, pull the switch
NOTE
completely up, then release. The
window will fully close automatically.
The jam-safe function may operate
under the following conditions:
To stop the window partway, pull or
A strong impact is detected while
press the switch in the opposite
the window is closing.
direction and then release it.
The window is closing in very low
NOTE
temperatures.
Power window system initialization
(A window cannot be closed)
procedure
If the jam-safe function has operated
If you operate the switch any number
and the window cannot be closed,
of times with the power window not
check around the window frame for
fully closed, the window may no longer
a foreign object.
fully open/close automatically.
If there is no foreign object around
The power window auto function will
the window frame, forcibly close a
only resume on a power window that
window using the following
has been reset.
procedure.
1. Switch the ignition ON.
1. After switching the ignition OFF,
2. Make sure that the power window
wait for 45 seconds or longer.
lock switch located on the driver's
2. Switch the ignition ON.
door is not depressed.
3. Operate the switch in the
3. Press the switch and fully open the
direction to close the window
window.
until the jam-safe function
4. Pull up the switch to fully close the
operates and the window stops.
window and continue holding the
Repeat this operation a total of 5
switch for about 2 seconds after the
times.
window fully closed.
4. Continue pulling up the switch to
5. Make sure that the power windows
fully close the window.
operate correctly using the door
Remote Power Window Operation
switches.
All power windows can be opened
from outside the vehicle after the
doors are closed.
The power windows can be operated
remotely when the power window lock
switch on the driver's door is in the
lock or unlocked position.
3-37
Before Driving
Windows
Remote power window operation is
Moonroof
activated under the following
conditions.
Moonroof
All the doors and liftgate are closed.
The moonroof can be opened or
The ignition is switched OFF.
closed when operating the overhead
tilt/slide switch at the front seats.
NOTE
The power windows cannot be
WARNING
opened from the outside of the vehicle
if the power window initialization has
Do not let passengers stand up or
not been completed.
extend part of the body through the
Opening
open moonroof while the vehicle is
moving:
The windows can be opened for
Extending the head, arms, or other
ventilating the cabin before getting in
parts of the body through the
the vehicle.
moonroof is dangerous. The head or
Press the unlock button on the key
arms could hit something while the
quickly and briefly 3 times and then
vehicle is moving. This could cause
immediately afterwards, press and
serious injury or death.
hold the unlock button to open the
windows.
Never allow children to play with the
tilt/slide switch:
The tilt/slide switch would allow
children to operate the moonroof
To stop the windows from opening,
unintentionally, which could result in
release the button. If the operation is
serious injury if a child's hands, head
performed from the beginning again,
or neck becomes caught by the
the windows open.
moonroof.
Make sure the opening is clear before
closing the moonroof:
A closing moonroof is dangerous. The
hands, head, or even neck of a person,
especially a child, could be caught in it
as it closes, causing serious injury or
even death.
3-38
*Some models.
Before Driving
Windows
Make sure nothing blocks the
Tilt/Slide Operation
moonroof just before it reaches the
The moonroof can be opened or
fully closed position:
closed electrically only when the
Blocking the moonroof just before it
ignition is switched ON.
reaches the closed position is
dangerous.
Before leaving the vehicle or washing
In this case, the jam-safe function
your Mazda, make sure the
cannot prevent the moonroof from
moonroof is completely closed so
closing. If fingers are caught, serious
that water does not get inside the
injuries could occur.
cabin area.
After washing your Mazda or after it
rains, wipe the water off the
CAUTION
moonroof before operating it to
¾ Do not sit on or put heavy items on
avoid water penetration which could
the area where the moonroof opens
cause rust and water damage to your
and closes. Otherwise, the
headliner.
moonroof could be damaged.
¾ Do not open or close the moonroof
forcefully during freezing
temperatures or snowfall. Otherwise,
the moonroof could be damaged.
¾ The sunshade does not tilt. To avoid
damaging the sunshade, do not push
it up.
¾ Do not close the sunshade while the
moonroof is opening. Trying to force
1. Tilt/Slide switch
the sunshade closed could damage
it.
Tilt Operation
The rear of the moonroof can be tilted
open to provide more ventilation.
To fully tilt automatically, momentarily
press the tilt/slide switch.
To fully close automatically,
momentarily press the tilt/slide switch
in the forward direction.
To stop tilting partway, press the tilt/
slide switch.
3-39
Before Driving
Windows
When the moonroof is already slid
NOTE
open and you want to tilt it open, first
If the moonroof does not operate
close the moonroof and then do a tilt
normally, do the following procedure:
operation.
1. Switch the ignition ON.
2. Press the tilt switch, to partially tilt
open the rear of the moonroof.
3. Repeat Step 2. The rear of the
moonroof tilts open to the fully
open position, then closes a little.
If the reset procedure is performed
while the moonroof is in the slide
position (partially open) it will close
1. Tilt up
before the rear tilt opens.
2. Close (Tilt down)
Jam-safe Moonroof
If a person's hands, head or an object
Slide Operation
blocks the moonroof while it is closing,
To fully open automatically,
the moonroof will stop and move in
momentarily press the tilt/slide switch
the open direction.
in the backward direction.
NOTE
To fully close automatically,
momentarily press the tilt/slide switch
The jam-safe function may operate
in the forward direction.
under the following conditions:
To stop sliding partway, press the tilt/
A strong impact is detected while
slide switch.
the moonroof is closing
When the moonroof is already tilted
automatically.
open and you want to slide it open,
The moonroof is closing
first close the moonroof and then do a
automatically during very low
slide operation.
temperatures.
In the event the jam-safe function
activates and the moonroof cannot
be closed automatically, press the
tilt/slide switch and the moonroof
will close.
The jam-safe moonroof function
does not operate until the system has
been reset.
1. Open
2. Close
3-40
Before Driving
Windows
Sunshade
The sunshade can be opened and
closed by hand.
The sunshade opens at the same time
as the moonroof slides open, but it
must be closed by hand.
1. Sunshade
3-41
Before Driving
Security System
Modification and
Immobilizer System
Add-On Equipment
Immobilizer System
Modification and Add-On
The immobilizer system allows the
Equipment
engine to start only with a key the
system recognizes.
Mazda cannot guarantee the
immobilizer and the theft-deterrent
If someone attempts to start the
system's operation if the system has
engine with an unrecognized key, the
been modified or if any add-on
engine will not start, thereby helping to
equipment has been installed.
prevent vehicle theft.
If you have a problem with the
CAUTION
immobilizer system or the key, consult
To avoid damage to the vehicle, do not
an Authorized Mazda Dealer.
modify the system or install any add-on
equipment to the immobilizer and the
CAUTION
theft-deterrent systems or the vehicle.
¾ Radio equipment like this is
governed by laws in the United
States.
Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user's authority to operate
the equipment.
¾ To avoid damage to the key, do not:
¾ Drop the key.
¾ Get the key wet.
¾ Expose the key to any kind of
magnetic field.
¾ Expose the key to high
temperatures on places such as the
dashboard, under direct sunlight.
¾ If the engine does not start with the
correct key, and the security indicator
light keeps illuminating or flashing,
the system may have a malfunction.
Consult an Authorized Mazda
Dealer.
3-42















Content      ..     2      3      4      5     ..
