Before Driving
Doors and Locks
(Without theft-deterrent system)
Auto Lock/Unlock Function
When locking, the hazard warning
lights and a beep sound operate 1
WARNING
time.
In addition, before the liftgate closes,
Do not pull the inner handle on a
the hazard warning lights operate 2
front door:
times and a long beep sound is
Pulling the inner handle on a front
activated.
door while the vehicle is moving is
dangerous. Passengers can fall out of
For details on the power liftgate
the vehicle if the door opens
function, refer to Power Liftgate on
accidentally , which could result in
page 3-22.
death or serious injury.
When the vehicle speed exceeds 20
Without power liftgate
km/h (12 mph), all the doors,
When locking using the door-lock
fuel-filler lid, and liftgate lock
switch, press the door-lock switch with
automatically.
all of the following conditions met and
When the ignition is switched off, all
then close the liftgate.
the doors, fuel-filler lid, and liftgate
unlock automatically.
You are carrying the transmitter.
The ignition is switched OFF.
The auto lock/unlock function settings
All the doors are closed.
can be changed.
Refer to the Settings section in the
(With theft-deterrent system)
Mazda Connect Owner's Manual.
When locking, a beep sound operates
1 time.
Locking, Unlocking with
When the liftgate closes, the hazard
Door-Lock Knob
warning lights operate 1 time.
Operation from inside
(Without theft-deterrent system)
To lock any door from the inside, press
When locking, the hazard warning
the door-lock knob.
lights and a beep sound operate 1
To unlock, pull it outward.
time.
This does not operate the other door
NOTE
locks.
To prevent the transmitter from being
left in the vehicle, make sure that you
carry the transmitter before locking.
After locking by pressing the
door-lock switch and when the
liftgate is closed with the transmitter
left in the vehicle, the liftgate is
unlocked.
1. Unlocked: Red indicator
2. Lock
3-18
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
3. Unlock
All the doors, fuel-filler lid , and
liftgate are unlocked when the lock
knob on all the doors is pressed
Operation from outside
down to the lock side and all the
To lock any door using its door-lock
doors are closed with the transmitter
knob from the outside, press the
left in the vehicle.
door-lock knob to the lock position
Rear Door Child Safety Locks
and close the door (holding the door
handle in the open position is not
Rear doors that have been locked
required).
using the child safety lock switched to
This does not operate the other door
the lock side cannot be opened from
locks.
inside the vehicle.
For child safety, switch the child safety
lock on both rear doors to the lock
side.
When opening a rear door with the
child safety lock switched to the lock
side, pull the outer door handle with
the lock knob inside the vehicle
switched to the unlock side.
1. Auxiliary key (page 3-2)
2. Unlock
3. Lock
NOTE
When locking the door this way:
Be careful not to leave the key inside
the vehicle.
The doors cannot be locked using
the driver's door lock knob if any
door or liftgate is open when the
ignition is switched to ACC or ON.
3-19
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Liftgate
CAUTION
Liftgate
¾ Before opening the liftgate, remove
any snow and ice accumulation on it.
Otherwise, the liftgate could close
WARNING
under the weight of the snow and ice
resulting in injury.
Never allow a person to ride in the
¾ Be careful when opening/closing the
luggage compartment:
liftgate during strong winds. If a
Allowing a person to ride in the
strong gust blows against the liftgate,
luggage compartment is dangerous.
it could close suddenly resulting in
The person in the luggage
injury.
compartment could be seriously
¾ Fully open the liftgate and make sure
injured or killed during sudden braking
that it stays open. If the liftgate is
or a collision.
only opened partially, it could slam
shut by vibration or wind gusts
Do not drive with the liftgate open:
resulting in injury.
Exhaust gas in the cabin of a vehicle is
¾ When loading or unloading luggage
dangerous. An open liftgate in a
in the luggage compartment, turn off
moving vehicle will cause exhaust gas
the engine. Otherwise, you could get
to be drawn into the cabin. This gas
burned by the heat of the exhaust
contains CO (carbon monoxide),
gas.
which is colorless, odorless, and highly
¾ Be careful not to apply excessive
poisonous, and it can cause loss of
force to the damper stay on the
consciousness and death. Moreover,
liftgate such as by putting your hand
an open liftgate could cause occupants
on the stay. Otherwise, the damper
to fall out in an accident.
stay may bend and affect the liftgate
operation.
Do not stack or leave loaded luggage
unsecured in the luggage
compartment:
Otherwise, the luggage may move or
collapse, resulting in injury or an
accident. In addition, do not load
luggage higher than the seatbacks. It
may affect the side or rear field of view.
Additionally, if the air bags deploy, the
cargo may scatter which could result in
serious injury or death.
1. Damper stay
3-20
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
¾ Do not modify or replace the liftgate
The liftgate can be closed when the
damper stay. Consult an Authorized
doors are locked with the key left in
Mazda Dealer if a liftgate damper
the vehicle. However, to prevent
stay is deformed or damaged for
locking the key in the vehicle, the
reasons such as a collision or if there
liftgate can be opened by pressing
is some other problem.
the electric liftgate opener. If the
liftgate cannot be opened despite
Opening and Closing the Liftgate
doing this procedure, first push the
Opening the liftgate
liftgate completely closed, then press
the electric liftgate opener to fully
Using the electric liftgate opener
open the liftgate.
When the liftgate latch is released by
Unlock the doors and liftgate, then
press the electric liftgate opener on the
pressing the electric liftgate opener,
the liftgate raises slightly. If the
liftgate and raise the liftgate when the
latch releases.
liftgate is not operated for a certain
period of time, the liftgate cannot be
For the power liftgate operation, refer
to Power Liftgate on page 3-22.
raised.
To open
Press the electric liftgate opener
again.
To close
To close the liftgate from its slightly
raised position, open it first by
pressing the electric liftgate opener,
then close it after waiting at least 1
second.
If the vehicle battery is dead or there
is a malfunction in the electrical
NOTE
system and the liftgate cannot be
unlocked, the liftgate can be opened
(With the advanced keyless function)
by performing the emergency
A locked liftgate can also be opened
procedure.
while the key is being carried.
Refer to When Liftgate Cannot be
When opening the liftgate with the
Opened on page 7-43.
doors and the liftgate locked, it may
require a few seconds for the liftgate
latch to release after the electric
liftgate opener is pressed.
3-21
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Closing the liftgate
Power Liftgate*
Lower the liftgate slowly using the
The power liftgate opens/closes
liftgate grip recess, then push the
electrically by operating the switches in
liftgate closed using both hands.
the vehicle or the buttons on the
Do not slam it. Pull up on the liftgate
keyless entry system transmitter.
to make sure it is secure.
For the power liftgate operation, refer
WARNING
to Power Liftgate on page 3-22.
Be sure to watch the power liftgate as
it opens or closes, and make sure that
it closes completely:
Opening or closing the power liftgate
while not watching it move is
dangerous. Because of unseen
obstacles and the jam-safe feature, a
liftgate may not close completely and,
if left unnoticed, could result in serious
injury or death if an occupant were to
fall out of the vehicle.
Always be sure that the area around
WARNING
the liftgate is clear before activating it.
Do not drive the vehicle with the
Always confirm the safety of the area
liftgate-ajar warning indication
around the power liftgate before
displayed :
operating it electrically.
Otherwise, the liftgate may open
Not checking the area around the
unexpectedly and result in an accident.
liftgate for people before operating it
using the power liftgate switch or the
NOTE
button on the keyless entry system is
Confirm that the liftgate is securely
dangerous. A person could become
closed.
caught between the liftgate and an
Move the liftgate without pressing the
obstruction while it is opening
electric liftgate opener to verify that the
electrically or between the liftgate and
liftgate has not been left ajar.
vehicle while it is closing electrically,
resulting in an accident and serious
injury.
3-22
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Never allow children to operate the
NOTE
power liftgate system:
Do not apply unnecessary force to
Allowing children to operate the
the power liftgate when it is
power liftgate switch and the keyless
opening/closing electrically.
entry system is dangerous. Children are
Unnecessary force on the liftgate
not aware of the dangers of people
may cause it to reverse direction of
getting fingers and hands caught in a
movement automatically. Also, it
moving liftgate. If someone's neck,
could result in a malfunction.
head or hands get caught in a closing
The power liftgate may not open/
door, it could result in death or serious
close electrically if the vehicle is
injury.
parked on an incline, or there is
strong wind, or the liftgate is laden
CAUTION
with snow.
If a power liftgate system fuse has
¾ When closing the power liftgate,
blown, the liftgate cannot be opened
make sure there are no foreign
using the power liftgate switch or the
objects around the striker. If foreign
electric liftgate opener. Use the
objects are obstructing the striker,
emergency lever to open the liftgate.
the liftgate may not close properly.
Fully close the power liftgate before
disconnecting the vehicle battery. If
the battery is disconnected with the
liftgate open, it cannot be opened or
closed automatically after the battery
is reconnected. If this happens, fully
close the liftgate manually to restore
the auto full open/close function.
If the liftgate is snow-laden, remove
the snow before operating the power
liftgate. Operating the power liftgate
1. Striker
with excessive force applied to the
liftgate may damage the liftgate.
¾ Do not install accessories to the
power liftgate other than specified
Operation using the transmitter
accessories. Otherwise, it cannot be
When the power liftgate button on the
opened/closed automatically and
transmitter is pressed and held for
could result in a malfunction.
about 1 second or longer with all of
¾ Be careful when switching the power
the following conditions met, the
liftgate from electrical to manual
hazard warning lights flash 2 times, a
operation. The power liftgate may
beep sound is activated, and the
open/close unexpectedly depending
liftgate automatically opens/closes
on its position which could result in
fully.
injury.
The ignition is switched OFF.
The vehicle is stopped.
Refer to Transmitter on page 3-5.
3-23
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
NOTE
Closing the liftgate
When opening the liftgate by
The vehicle is stopped.
pressing the power liftgate button on
(Manual transmission)
the transmitter, the liftgate can be
The ignition is switched to a position
opened even when it is locked.
other than ON, or when the parking
If the power liftgate button on the
brake is applied with the shift lever in
transmitter is pressed while the
N and the ignition switched ON.
liftgate is opening/closing
(Automatic transmission)
electrically, the beep is activated and
The ignition is switched to a position
the liftgate stops. When pressing the
other than ON, or the selector lever
power liftgate button again, the
is in P with the ignition switched ON.
liftgate moves in the reverse
direction.
NOTE
If the shift lever/selector lever is shifted
Operation using switch only for
to another position and the vehicle is
power liftgate
moved while the liftgate is opening/
Operation conditions
closing automatically, the liftgate
operates as follows:
Opening the liftgate
If the vehicle has satisfied all the
When the liftgate is opening
following operation conditions, the
A beep sound is activated, and the
power liftgate can be opened using the
liftgate moves in the reverse
power function.
direction automatically and closes.
When the liftgate is closing
All doors and the liftgate are
A beep sound is activated, but the
unlocked.
liftgate continues to close.
The vehicle is stopped.
(Manual transmission)
The ignition is switched to a position
other than ON, or when the parking
brake is applied with the shift lever in
N and the ignition switched ON.
(Automatic transmission)
The ignition is switched to a position
other than ON, or the selector lever
is in P with the ignition switched ON.
3-24
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Operation from the driver's seat (To
Operation from outside (To close)
open/close)
Press the power liftgate close switch
Press the power liftgate switch for
while the liftgate is fully opened. The
about 1 second or longer while the
hazard warning lights flash twice and
liftgate is in the fully closed/open
the liftgate closes automatically after
position. The hazard warning lights
the beep sound is heard.
flash twice and the liftgate opens/
(With the advanced keyless function)
closes fully after a sound is activated.
Operation from outside (To open)
(Without the advanced keyless
Press the electric liftgate opener on the
function)
liftgate. The hazard warning lights flash
twice and the liftgate opens
automatically after the beep sound is
heard.
(With the advanced keyless function)
A locked liftgate can also be opened
while the key is being carried.
Operation using door-lock switch
(With the advanced keyless function)
When the door-lock switch on the
liftgate is pressed, the liftgate fully
closes automatically after all the doors,
fuel-filler lid, and the liftgate are
locked.
For details such as the operation
conditions, refer to Locking, Unlocking
with Door-Lock Switch on page 3-16.
3-25
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Automatic open/close stop function
(With the advanced keyless function)
When the door-lock switch on the
The liftgate can be stopped at a
liftgate is pressed, the liftgate
desired position while it is opening/
automatically closes.
closing automatically.
Changing the power liftgate fully
Stopping the liftgate
open position
If any of the following operations is
The power liftgate fully-open position
done while the liftgate is opening/
can be changed according to the
closing automatically, the liftgate is
height of a garage.
stopped.
When changing the position
The power liftgate button on the
transmitter is pressed.
1. Stop the liftgate at the desired
The power liftgate switch is pressed.
position.
The electric liftgate opener on the
2. Press the power liftgate close switch
liftgate is pressed.
for about three seconds.
The power liftgate close switch is
A beep sound is activated two
pressed.
times to indicate that the position
(With the advanced keyless
change has been completed.
function)
NOTE
The door-lock switch on the liftgate
Set the desired fully-open position of
is pressed.
the liftgate at the position where it is
open more than halfway. The position
NOTE
where it is less than halfway open
The liftgate cannot be stopped in the
cannot be set.
area about 20 cm (7.9 in) away from
the fully-closed position. It moves in
To reset
the close direction by the load weight
1. Open the liftgate.
of the liftgate itself.
2. Press the power liftgate close switch
Moving the liftgate again
for about seven seconds.
A beep sound is activated three
If any of the following operations is
times to indicated that the reset has
done, the liftgate moves in the
been completed.
direction opposite to the direction it
was moving before it stopped.
NOTE
After about 3 seconds have elapsed
The power liftgate button on the
since the switch was pressed, a beep
transmitter is pressed for about 1
sound is activated 2 times to indicate
second or longer.
that the liftgate fully-open position has
The power liftgate switch is pressed
changed. Continuously press the
for about 1 second or longer.
switch for about 7 seconds to
The electric liftgate opener on the
complete the reset.
liftgate is pressed.
The power liftgate close switch is
pressed.
3-26
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Jam-safe equipment
CAUTION
While the power liftgate is opening/
Sensors are installed on both ends of
closing electrically and the system
the power liftgate. Be careful not to
detects a person or an object in the
allow the sensors to be scratched or
liftgate's path, the liftgate will move in
damaged by sharp objects, otherwise
the reverse direction automatically and
the liftgate may no longer open/close
stops.
automatically. In addition, if the sensor
is damaged while the liftgate is closing
WARNING
automatically, the system will stop.
Always check the area around the
power liftgate before opening/closing
it:
Not checking for occupants and
objects around the power liftgate
before opening/closing it is
dangerous. The jam-safe equipment is
designed to prevent jamming in the
event an obstruction is in the liftgate's
path. The system may not detect
certain objects obstructing the liftgate
depending on the way they are
1. Sensor
positioned and their shape. However,
if the jam-safe function detects an
NOTE
obstruction and moves the liftgate in
The jam-safe equipment does not
the reverse direction, an occupant in
activate during easy closure operation
the liftgate's path could be seriously
when the power liftgate is between the
injured.
near-shut position and fully closed
position.
When the power liftgate is moving in
the open/close direction and an
obstruction is detected, the beep
sound will be heard and the liftgate
moves in the reverse direction and
stops.
Liftgate easy closure
The Easy Closure system automatically
closes the liftgate completely from the
near-shut position.
This system also operates when the
liftgate is closed manually.
3-27
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
WARNING
CAUTION
¾ Make sure the luggage compartment
When closing a liftgate, always keep
cover is firmly secured. If it is not
hands and fingers away from the
firmly secured, it could unexpectedly
liftgate:
disengage resulting in injury.
Placing hands or fingers around a
liftgate is dangerous because the
The luggage compartment can be
liftgate closes automatically from the
accessed by opening the liftgate when
near-shut position, which could cause
the straps are attached to the sides of
hands and fingers to be pinched and
the liftgate.
injured.
NOTE
If the electric liftgate opener is
pressed while the easy closure
function is operating, the liftgate can
be opened.
If the liftgate is opened/closed
repeatedly in a short period of time,
the easy closure function may not
operate. Wait for about 2 seconds
and then try again.
Luggage Compartment
Luggage compartment cover*
WARNING
Do not place anything on top of the
cover:
Placing luggage or other cargo on top
of the luggage compartment cover is
dangerous. During sudden braking or a
collision, the cargo could become a
projectile that could hit and injure
someone.
Make sure luggage and cargo are
secured before driving:
Not securing cargo while driving is
dangerous as it could move or be
crushed during sudden braking or a
collision and cause injury.
3-28
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Doors and Locks
Removing the luggage compartment
cover
This cover can be removed for more
room.
1. Remove the straps from the hooks.
2. Press the luggage compartment
cover upward from near the pins
and remove the luggage
compartment cover from the pins.
1. Pin
3. Lift the front end of the luggage
compartment cover and remove it.
3-29
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Fuel and Emission
Fuel and Engine Exhaust Precautions
Fuel Requirements
Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED
FUEL, which will reduce exhaust emissions and keep spark plug fouling to a
minimum.
To achieve maximum engine performance, use the specified fuel.
Fuel
Octane Rating*1 (Anti-knock index)
Regular unleaded fuel
87 [(R+M)/2 method] or above (91 RON or above)
*1
U.S. federal law requires that octane ratings be posted on gas station pumps.
Fuel with a rating lower than 87 octane (91 RON) will negatively affect the emission
control system performance and could also cause engine knocking and serious
engine damage.
CAUTION
¾ USE ONLY UNLEADED FUEL.
Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead
to deterioration of the emission control system and or failures.
¾ This vehicle can only use oxygenated fuels containing no more than 10 % ethanol
by volume. Damage to the vehicle may occur when ethanol exceeds this
recommendation, or if the gasoline contains any methanol. Stop using gasohol of
any kind if your vehicle engine is performing poorly.
¾ Never add fuel system additives other than a Mazda genuine product, otherwise
the emission control system could be damaged. Consult an Authorized Mazda
Dealer for details.
Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with
your vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol,
such as ethanol or methanol, may be marketed under the name "Gasohol".
Vehicle damage and drivability problems resulting from the use of the following may
not be covered by the warranty.
Gasohol containing more than 10 % ethanol.
Gasoline or gasohol containing methanol.
Leaded fuel or leaded gasohol.
3-30
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Fuel and Emission
Emission Control System
NOTE
This vehicle is equipped with an
Under U.S. federal law, any
emission control system (the catalytic
modification to the
converter is part of this system) that
original-equipment emission control
enables the vehicle to comply with
system before the first sale and
existing exhaust emissions
registration of a vehicle is subject to
requirements.
penalties. In some states, such
modification made on a used vehicle
WARNING
is also subject to penalties.
While the engine is off, the sound of
Never park over or near anything
a valve opening and closing can be
flammable:
heard at the rear of the vehicle,
Parking over or near anything
however this does not indicate an
flammable, such as dry grass, is
abnormality. The vehicle has a
dangerous. Even with the engine
self-checking device and it operates
turned off, the exhaust system remains
while the engine is off.
very hot after normal use and could
Engine Exhaust (Carbon
ignite anything flammable. A resulting
monoxide)
fire could cause serious injury or death.
WARNING
CAUTION
Ignoring the following precautions
Do not drive your vehicle if you smell
could cause lead to accumulate on the
exhaust gas inside the vehicle:
catalyst inside the converter or cause
Engine exhaust gas is dangerous. This
the converter to get very hot. Either
gas contains carbon monoxide (CO),
condition will damage the converter
which is colorless, odorless, and
and cause poor performance.
poisonous. When inhaled, it can cause
loss of consciousness and death. If you
¾ USE ONLY UNLEADED FUEL.
smell exhaust gas inside the vehicle,
¾ Do not drive your Mazda with any
keep all windows fully open and
sign of engine malfunction.
contact an Authorized Mazda Dealer
¾ Do not coast with the ignition
immediately.
switched off.
¾ Do not descend steep grades in gear
Do not run the engine when inside an
with the ignition switched off.
enclosed area:
¾ Do not operate the engine at high
Running the engine inside an enclosed
idle for more than 2 minutes.
area, such as a garage, is dangerous.
¾ Do not tamper with the emission
Exhaust gas, which contains poisonous
control system. All inspections and
carbon monoxide, could easily enter
adjustments must be made by a
the cabin. Loss of consciousness or
qualified technician.
even death could occur.
¾ Do not push-start or pull-start this
vehicle.
3-31
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Fuel and Emission
Open the windows or adjust the
Fuel-Filler Lid and Cap
heating or cooling system to draw
fresh air when idling the engine:
Fuel-Filler Lid and Cap
Exhaust gas is dangerous. When the
vehicle is stopped with the windows
closed and the engine running for a
WARNING
long time even in an open area,
exhaust gas, which contains poisonous
When removing the fuel-filler cap,
carbon monoxide, could enter the
loosen the cap slightly and wait for
cabin. Loss of consciousness or even
any hissing to stop, then remove it:
death could occur.
Fuel spray is dangerous. Fuel can burn
skin and eyes and cause illness if
Clear snow from underneath and
ingested. Fuel spray is released when
around your vehicle, particularly the
there is pressure in the fuel tank and
tail pipe, before starting the engine:
the fuel-filler cap is removed too
Running the engine when a vehicle is
quickly.
stopped in deep snow is dangerous.
The exhaust pipe could be blocked by
Before refueling, stop the engine, and
the snow, allowing exhaust gas to
always keep sparks and flames away
enter the cabin. Because exhaust gas
from the filler neck:
contains poisonous carbon monoxide,
Fuel vapor is dangerous. It could be
it could cause loss of consciousness or
ignited by sparks or flames causing
even death to occupants in the cabin.
serious burns and injuries.
Additionally, use of the incorrect
fuel-filler cap or not using a fuel-filler
cap may result in a fuel leak, which
could result in serious burns or death
in an accident.
Do not continue refueling after the
fuel pump nozzle shuts off
automatically:
Continuing to add fuel after the fuel
pump nozzle has shut off automatically
is dangerous because overfilling the
fuel tank may cause fuel overflow or
leakage. Fuel overflow and leakage
could damage the vehicle and if the
fuel ignites it could cause a fire and
explosion resulting in serious injury or
death.
3-32
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Fuel and Emission
However, when the driver's door
CAUTION
is locked using the following
¾ Always use only a genuine Mazda
functions, the fuel lid is also
fuel-filler cap or an approved
locked at the same time.
equivalent, available at an
Auto lock/unlock function
Authorized Mazda Dealer. The
(page 3-18)
wrong cap can result in a serious
Auto re-lock function (page
malfunction of the fuel and emission
3-5) and (page 3-13)
control systems.
2.
Press the location shown in the
(U.S.A. and Canada)
illustration and open the fuel lid.
It may also cause the check engine
light in the instrument cluster to
illuminate.
¾ When using an automatic car wash
or a high water pressure car washer,
lock the driver's door. Otherwise,
the fuel-filler lid may open
unexpectedly and could be
damaged.
Refueling
3.
To remove the fuel-filler cap, turn it
counterclockwise.
Before refueling, close all the doors,
4.
Attach the removed cap to the
windows, and liftgate, and switch the
inner side of the fuel-filler lid.
ignition OFF.
1. Using the following, unlock the
driver’s door.
Transmitter (page 3-16)
Touch sensor (page 3-13)
Door-lock switch (page 3-16)
Auto lock/unlock function (page
3-18)
NOTE
When unlocking the driver's
door, the fuel lid is also unlocked
1. Fuel-filler lid
at the same time.
2. Fuel-filler cap
When locking the driver's door,
the fuel lid is locked after 90
5.
Insert the refueling nozzle all the
seconds.
way and begin refueling. Pull out
The time until the fuel lid is
the refueling nozzle after the
locked after locking the driver's
refueling stops automatically.
door can be changed.
6.
To close the fuel-filler cap, turn it
Refer to the Settings section in
clockwise until a click is heard.
the Mazda Connect Owner's
Manual.
3-33
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Fuel and Emission
7. To close, press the fuel-filler lid
until a click sound is heard.
8. Make sure to lock all the doors
when leaving the vehicle.
NOTE
Lock the doors after closing the
fuel-filler lid.
If the fuel-filler lid is closed after
locking the doors, the fuel-filler lid
cannot be locked.
CAUTION
(U.S.A. and Canada)
If the check fuel cap warning light
illuminates, the fuel-filler cap may not
be properly installed. If the warning
light illuminates, park your vehicle
safely off the right-of-way, remove the
fuel-filler cap and reinstall it correctly.
After the cap has been correctly
installed, the fuel cap warning light
may continue to illuminate until a
number of driving cycles have been
completed. A drive cycle consists of
starting the engine (after four or more
hours with the engine off) and driving
the vehicle on city and highway roads.
Continuing to drive with the check fuel
cap warning light illuminated could
cause the check engine light to
illuminate as well.
3-34
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Mirrors
2.
Press the adjustment switch to
Mirrors
adjust the angle of the outside
mirror.
Mirrors
Before driving, adjust the inside and
outside mirrors.
Outside Mirrors
WARNING
Be sure to look over your shoulder
before changing lanes:
Changing lanes without taking into
account the actual distance of the
vehicle in the convex mirror is
dangerous. You could have a serious
accident. What you see in the convex
mirror is closer than it appears.
Mirror type
Flat type (driver's side)
1.
Indicator light
Flat surface mirror.
2.
Select switch
Convex type (front passenger side)
3.
Adjustment switch
The mirror has single curvature on its
surface.
After adjusting the angle of the outside
mirror, press the select switch for the
Power mirror adjustment
outside mirror to be adjusted to turn
The ignition must be switched to ACC
off the indicator light.
or ON position.
NOTE
To adjust:
(With driving position memory
1. Press the select switch for the
function)
outside mirror to be adjusted to
The on-road outside mirror position
turn on the indicator light.
can be programmed in conjunction
with the driving position memory
function.
Refer to Driving Position Memory on
page 2-10.
Power mirrors with reverse tilt down
function*
The outside mirrors tilt downward to
facilitate the view of the lower area on
each side of the vehicle.
1. Switch the ignition ON.
*Some models.
3-35
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Mirrors
2. Press the select switch for the
Engine-off outside mirror operation
outside mirror to be tilted
The outside mirrors can be operated
downward to turn on the indicator
for about 40 seconds after the ignition
light of the select switch.
is switched from ON to off.
3. Shift the shift lever/selector lever to
the R position to tilt the outer
Driver's side auto-dimming outside
mirror on the side where the select
mirror*
button was pressed downward.
The movement of the auto-dimming
NOTE
outside mirror is interlocked with the
When any of the following condition is
auto-dimming rearview mirror in the
met, the outer mirrors return to their
interior to automatically reduce glare
normal positions.
from rear on-coming vehicles.
Refer to Rearview Mirror on page
The ignition is switched to a position
3-37.
other than ON.
The shift lever/selector lever is
NOTE
shifted to a position other than R.
The front passenger-side outside
The select switch is pressed again.
mirror does not have the
auto-dimming feature.
Folding outside mirror
WARNING
Always return the outside mirrors to
the driving position before you start
driving:
Driving with the outside mirrors folded
in is dangerous. Your rear view will be
restricted, and you could have an
accident.
Manually fold the outside mirror
rearward until it is flush with the
vehicle.
3-36
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Mirrors
Rearview Mirror
Reducing glare from headlights
Manual day/night mirror
WARNING
Push the day/night lever forward for
day driving. Pull it back to reduce glare
Do not stack cargo or objects higher
of headlights from vehicles at the rear.
than the seatbacks:
Cargo stacked higher than the
seatbacks is dangerous. It can block
your view in the rearview mirror, which
might cause you to hit another car
when changing lanes.
Rearview mirror adjustment
Before driving, adjust the rearview
mirror to center on the scene through
the rear window.
1. Day/Night lever
2. Night
3. Day
Auto-dimming mirror
The auto-dimming mirror
automatically reduces the glare of
headlights from vehicles at the rear
when the ignition is switched ON.
(With ON/OFF button)
Press the ON/OFF button ( ) to cancel
the auto-dimming function. The
indicator light will turn off.
NOTE
To reactivate the auto-dimming
For the manual day/night mirror,
function, press the ON/OFF button
perform the adjustment with the day/
(
). The indicator light will illuminate.
night lever in the day position.
1. ON/OFF button
2. Indicator light
3-37
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Mirrors
NOTE
Do not use glass cleaner or suspend
objects on or around the light
sensor. Otherwise, light sensor
sensitivity will be affected and may
not operate normally.
1. Light sensor
(With Homelink wireless control
system)
For information regarding the 3
buttons ( ,
,
) on the
auto-dimming mirror.
Refer to HomeLink Wireless Control
System on page 4-57.
The auto-dimming function is
canceled when the ignition is
switched ON and the shift lever/
selector lever is in the R position.
3-38
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Windows
Do not let a child put a hand or head
Power Windows
out of the window while driving the
vehicle:
Power Windows
If the person's hand or head hits
The windows can be opened/closed
something outside the vehicle, or
by operating the power window
sudden braking is applied, it could
switches.
result in serious injury or death.
WARNING
NOTE
When driving with only 1 of the rear
Make sure the opening is clear before
windows open, your ears might
closing a window:
experience a resonating sound.
Closing a power window is dangerous.
However, this does not indicate a
A person's hands, head, or even neck
problem. The sound can be reduced
could be caught by the window and
by slightly opening a front window or
result in serious injury or even death.
by changing the size of the rear
This warning applies especially to
window opening.
children.
Never allow children to play with
power window switches:
Power window switches that are not
locked with the power window lock
switch would allow children to operate
power windows unintentionally, which
could result in serious injury if a child's
hands, head or neck becomes caught
by the window.
Make sure nothing blocks the window
just before it reaches the fully closed
position or while fully holding up the
power window switch:
Blocking the power window just before
it reaches the fully closed position or
while fully holding up the power
window switch is dangerous.
In this case, the jam-safe function may
not prevent the window from closing
all the way. If fingers are caught,
serious injuries could occur.
3-39
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Windows
Opening/Closing Windows
9. Unlocked position
The window opens while the switch is
Front passenger's window switch/
pressed and it closes while the switch
Rear window switches
is pulled up with the ignition switched
ON. Do not open or close 3 or more
windows at the same time.
The front passenger's window and rear
windows can be opened/closed when
the power window lock switch on the
driver's door is in the unlocked
position. Keep this switch in the locked
1. Close
position while children are in the
2. Open
vehicle.
NOTE
Master control switches
A power window may no longer
open/close if you continue to press
the switch for a long time. If the
power window does not open/
close, wait for a while and then
operate the switch again.
The passenger windows may be
opened or closed using the master
control switches on the driver's door.
The power window can be operated
for about 40 seconds after the
ignition is switched from ON to ACC
or off with all doors closed. If any
door is opened, the power window
will stop operating.
Auto-opening/Closing
To fully open the window
automatically, press the switch
completely down, then release. The
window will fully open automatically.
To fully close the window
1.
Close
automatically, pull the switch
2.
Open
completely up, then release. The
3.
Front passenger's window
window will fully close automatically.
4.
Right rear window
5.
Power window lock switch
To stop the window partway, pull or
6.
Left rear window
press the switch in the opposite
7.
Driver's window
direction and then release it.
8.
Locked position
3-40
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Windows
NOTE
(A window cannot be closed)
Power window system initialization
If the jam-safe function has operated
procedure
and the window cannot be closed,
If you operate the switch any number
check around the window frame for
of times with the power window not
a foreign object.
fully closed, the window may no longer
If there is no foreign object around
fully open/close automatically.
the window frame, forcibly close a
The power window auto function will
window using the following
only resume on a power window that
procedure.
has been reset.
1.
After switching the ignition OFF,
1. Switch the ignition ON.
wait for 45 seconds or longer.
2. Make sure that the power window
2.
Switch the ignition ON.
lock switch located on the driver's
3.
Operate the switch in the
door is not depressed.
direction to close the window
3. Press the switch and fully open the
until the jam-safe function
window.
operates and the window stops.
4. Pull up the switch to fully close the
Repeat this operation a total of 5
window and continue holding the
times.
switch for about 2 seconds after the
4.
Continue pulling up the switch to
window fully closed.
fully close the window.
5. Make sure that the power windows
operate correctly using the door
switches.
Jam-safe Window
When the window is closing and a
foreign object is detected between the
window and the window frame, the
window stops closing and
automatically opens partway.
NOTE
The jam-safe function may operate
under the following conditions:
A strong impact is detected while
the window is closing.
The window is closing in very low
temperatures.
3-41
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Windows
Make sure nothing blocks the
Moonroof*
moonroof just before it reaches the
fully closed position:
Moonroof
Blocking the moonroof just before it
The moonroof can be opened or
reaches the closed position is
closed when operating the overhead
dangerous.
tilt/slide switch at the front seats.
In this case, the jam-safe function
cannot prevent the moonroof from
WARNING
closing. If fingers are caught, serious
injuries could occur.
Do not let passengers stand up or
extend part of the body through the
CAUTION
open moonroof while the vehicle is
moving:
¾ Do not sit on or put heavy items on
Extending the head, arms, or other
the area where the moonroof opens
parts of the body through the
and closes. Otherwise, the
moonroof is dangerous. The head or
moonroof could be damaged.
arms could hit something while the
¾ Do not open or close the moonroof
vehicle is moving. This could cause
forcefully during freezing
serious injury or death.
temperatures or snowfall. Otherwise,
the moonroof could be damaged.
Never allow children to play with the
¾ The sunshade does not tilt. To avoid
tilt/slide switch:
damaging the sunshade, do not push
The tilt/slide switch would allow
it up.
children to operate the moonroof
¾ Do not close the sunshade while the
unintentionally, which could result in
moonroof is opening. Trying to force
serious injury if a child's hands, head
the sunshade closed could damage
or neck becomes caught by the
it.
moonroof.
Make sure the opening is clear before
closing the moonroof:
A closing moonroof is dangerous. The
hands, head, or even neck of a person,
especially a child, could be caught in it
as it closes, causing serious injury or
even death.
3-42
*Some models.
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Windows
Tilt/Slide Operation
Tilt Operation
The moonroof can be opened or
The rear of the moonroof can be tilted
closed electrically only when the
open to provide more ventilation.
ignition is switched ON.
To fully tilt automatically, momentarily
Before leaving the vehicle or washing
press the tilt/slide switch.
your Mazda, make sure the
To fully close automatically,
moonroof is completely closed so
momentarily press the tilt/slide switch
that water does not get inside the
in the forward direction.
cabin area.
To stop tilting partway, press the tilt/
After washing your Mazda or after it
slide switch.
rains, wipe the water off the
When the moonroof is already slid
moonroof before operating it to
open and you want to tilt it open, first
avoid water penetration which could
close the moonroof and then do a tilt
cause rust and water damage to your
operation.
headliner.
1. Tilt up
2. Close (Tilt down)
1. Tilt/Slide switch
3-43
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Windows
Slide Operation
Jam-safe Moonroof
To fully open automatically,
If a person's hands, head or an object
momentarily press the tilt/slide switch
blocks the moonroof while it is closing,
in the backward direction.
the moonroof will stop and move in
To fully close automatically,
the open direction.
momentarily press the tilt/slide switch
NOTE
in the forward direction.
To stop sliding partway, press the tilt/
The jam-safe function may operate
slide switch.
under the following conditions:
When the moonroof is already tilted
A strong impact is detected while
open and you want to slide it open,
the moonroof is closing
first close the moonroof and then do a
automatically.
slide operation.
The moonroof is closing
automatically during very low
temperatures.
In the event the jam-safe function
activates and the moonroof cannot
be closed automatically, press the
tilt/slide switch and the moonroof
will close.
The jam-safe moonroof function
does not operate until the system has
1. Open
been reset.
2. Close
Sunshade
NOTE
If the moonroof does not operate
The sunshade can be opened and
normally, do the following procedure:
closed by hand.
1. Switch the ignition ON.
2. Press the tilt switch, to partially tilt
The sunshade opens at the same time
open the rear of the moonroof.
as the moonroof slides open, but it
3. Repeat Step 2. The rear of the
must be closed by hand.
moonroof tilts open to the fully
open position, then closes a little.
If the reset procedure is performed
while the moonroof is in the slide
position (partially open) it will close
before the rear tilt opens.
1. Sunshade
3-44
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Security System
Modification and
Immobilizer System
Add-On Equipment
Immobilizer System
Modification and Add-On
The immobilizer system allows the
Equipment
engine to start only with a key the
system recognizes.
Mazda cannot guarantee the
immobilizer and the theft-deterrent
If someone attempts to start the
system's operation if the system has
engine with an unrecognized key, the
been modified or if any add-on
engine will not start, thereby helping to
equipment has been installed.
prevent vehicle theft.
If you have a problem with the
CAUTION
immobilizer system or the key, consult
To avoid damage to the vehicle, do not
an Authorized Mazda Dealer.
modify the system or install any add-on
equipment to the immobilizer and the
CAUTION
theft-deterrent systems or the vehicle.
¾ Radio equipment like this is
governed by laws in the United
States.
Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user's authority to operate
the equipment.
¾ To avoid damage to the key, do not:
¾ Drop the key.
¾ Get the key wet.
¾ Expose the key to any kind of
magnetic field.
¾ Expose the key to high
temperatures on places such as the
dashboard, under direct sunlight.
¾ If the engine does not start with the
correct key, and the security indicator
light keeps illuminating or flashing,
the system may have a malfunction.
Consult an Authorized Mazda
Dealer.
3-45
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Security System
NOTE
Arming
The keys carry a unique electronic
The system is armed when the ignition
code. For this reason, and to assure
is switched from ON to off.
your safety, obtaining a replacement
The security indicator light in the
key requires some waiting time. They
instrument cluster flashes every 2
are only available through an
seconds until the system is disarmed.
Authorized Mazda Dealer.
Always keep a spare key in case one
is lost. If a key is lost, consult an
Authorized Mazda Dealer as soon as
possible.
If you lose a key, an Authorized
Mazda Dealer will reset the
Disarming
electronic codes of your remaining
The system is disarmed when the
keys and immobilizer system. Bring
ignition is switched ON with the
all the remaining keys to an
correct programmed key. The security
Authorized Mazda Dealer to reset.
indicator light illuminates for about 3
Starting the vehicle with a key that
seconds and then turns off.
has not been reset is not possible.
If the engine does not start with the
Operation
correct key, and the security indicator
light remains illuminated or flashing,
NOTE
try the following:
Make sure the key is within the
The engine may not start and security
operational range for signal
indicator light may illuminate or flash
transmission. Switch the ignition off,
if the key is placed in an area where
and then restart the engine. If the
it is difficult for the system to detect
engine does not start after 3 or more
the signal, such as on the dashboard
tries, contact an Authorized Mazda
or in the glove compartment. Move
Dealer.
the key to a location within the signal
range, switch the ignition off, and
then restart the engine.
Signals from a TV or radio station, or
from a transceiver or mobile
telephone could interfere with your
immobilizer system. If you are using
the proper key and the engine fails to
start, check the security indicator
light.
3-46
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Security System
NOTE
Theft-Deterrent System*
If the battery goes dead while the
Theft-Deterrent System
theft-deterrent system is armed, the
horn will activate and the hazard
If the theft-deterrent system detects an
warning lights will flash when the
inappropriate entry into the vehicle,
battery is charged or replaced.
which could result in the vehicle or its
contents being stolen, the alarm alerts
How to Arm the System
the surrounding area of an abnormality
1.
Close the windows and the
by sounding the horn and flashing the
hazard warning lights.
moonroof* securely.
2.
Switch the ignition OFF.
The system will not function unless it's
3.
Make sure the hood, the doors,
properly armed. So when you leave the
and the liftgate are closed.
vehicle, follow the arming procedure
4.
Press the lock button on the
correctly.
transmitter.
The hazard warning lights will flash
Operation
once.
The following method will also arm
System triggering conditions
the theft-deterrent system:
The horn sounds intermittently and the
Press the door-lock switch “
hazard warning lights flash for about
while any door is open and then
30 seconds when the system is
close all of the doors.
triggered by any one of the following:
(With the advanced keyless
Unlocking a door with the auxiliary
function)
key, door lock switch, or an inside
Touch the sensing area of the door
door-lock knob.
lock touch sensor.
Forcing open a door, the hood or the
liftgate.
The security indicator light in the
Opening the hood by operating the
instrument cluster flashes twice per
hood release handle.
second for 20 seconds.
Switching the ignition ON without
using the push button start.
If the system is triggered again, the
lights and horn will activate until the
driver's door or the liftgate is unlocked
5.
After 20 seconds, the system is fully
with the transmitter.
armed.
(With the advanced keyless function)
The lights and horn can also be
deactivated by touching the sensing
area of the door release touch sensor.
*Some models.
3-47
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Security System
NOTE
NOTE
When the doors are unlocked by
The theft-deterrent system can also
pressing the unlock button on the
be armed by activating the auto
transmitter while the theft-deterrent
relock function with all the doors,
system is turned off, the hazard
the liftgate and the hood closed.
warning lights will flash twice to
Refer to Transmitter on page 3-5.
indicate that the system is turned off.
The system will disarm if one of the
following operations takes place
To Stop the Alarm
within 20 seconds after pressing the
A triggered alarm can be turned off
lock button:
using any one of the following
Unlocking any door.
methods:
Opening any door.
Pressing the unlock button on the
Opening the hood.
transmitter.
Switching the ignition ON.
Starting the engine with the push
To rearm the system, do the arming
button start.
procedure again.
(With the advanced keyless
When the doors are locked by
function)
pressing the lock button on the
Touching the sensing area of the
transmitter while the theft-deterrent
door release touch sensor.
system is armed, the hazard warning
Pressing the electric liftgate opener
lights will flash once to indicate that
while the key is being carried.
the system is armed.
The hazard warning lights will flash
To Turn Off an Armed System
twice.
An armed system can be turned off
using any one of the following
methods:
Pressing the unlock button on the
transmitter.
Starting the engine with the push
button start.
(With the advanced keyless
function)
Touching the sensing area of the
door release touch sensor.
The hazard warning lights will flash
twice.
3-48
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09
Before Driving
Driving Tips
Break-In Period
Saving Fuel and
Protection of the
Break-In Period
Environment
No special break-in is necessary, but a
few precautions in the first 1,000 km
Saving Fuel and Protection of the
(600 miles) may add to the
Environment
performance, economy, and life of the
vehicle.
How you operate your Mazda
determines how far it will travel on a
Do not race the engine.
tank of fuel. Use these suggestions to
Do not maintain one constant
help save fuel and reduce CO2.
speed, either slow or fast, for a long
period of time.
Avoid long warm-ups. Once the
Do not drive constantly at
engine runs smoothly, begin driving.
full-throttle or high engine rpm for
Avoid fast starts.
extended periods of time.
Drive at lower speeds.
Avoid unnecessary hard stops.
Anticipate when to apply the brakes
Avoid full-throttle starts.
(avoid sudden braking).
Follow the maintenance schedule
and have an Authorized Mazda
Dealer perform inspections and
servicing.
Refer to Scheduled Maintenance
(U.S.A. and Puerto Rico) on page
6-4.
Refer to Scheduled Maintenance
(Canada) on page 6-6.
Refer to Scheduled Maintenance
(Mexico) on page 6-9.
Use the air conditioner only when
necessary.
Slow down on rough roads.
Keep the tires properly inflated.
Do not carry unnecessary weight.
Do not rest your foot on the brake
pedal while driving.
Keep the wheels in correct
alignment.
Keep windows closed at high
speeds.
Slow down when driving in
crosswinds and headwinds.
3-49
CX-30_8JP5-EA-20K_Edition1_new
2020-7-22 15:50:09















Content      ..     2      3      4      5     ..
