Mazda CX-9 (2019 year). Instruction

Specifications

▼ Engine

Item

Specification

Type

DOHC-16V in-line, 4-cylinder

Bore × Stroke

89.0 × 100 mm (3.50 × 3.94 in)

Displacement

2,488.5 ml (2,488.5 cc)

Compression ratio

10.5

▼ Electrical System

Item

Classification

Battery

12V-60Ah/20HR or 12V-65Ah/20HR

Spark-plug number

Mazda Genuine spark plug

PY8V-18-110

1 The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer

for details.

CAUTION

When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.

▼ Lubricant Quality

Lubricant

Classification

Engine oil

Refer to Recommended Oil on page 6-23.

Coolant

FL-22 type

Automatic transaxle fluid

Mazda Genuine ATF FZ

Transfer case oil

Mazda Long Life Hypoid Gear Oil SG1

Rear differential oil

Mazda Long Life Hypoid Gear Oil SG1

Brake fluid

SAE J1703 or FMVSS116 DOT-3

NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.

▼ Capacities

(Approximate Quantities)

Item

Capacity

Engine oil

With oil filter replacement

4.8 L (5.1 US qt, 4.2 Imp qt)

Without oil filter replacement

4.6 L (4.9 US qt, 4.0 Imp qt)

Specifications

9-4

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Capacity

Coolant

U.S.A. and Canada

9.9 L (10.5 US qt, 8.7 Imp qt)

Mexico

9.8 L (10.4 US qt, 8.6 Imp qt)

Automatic transaxle fluid

8.0 L (8.5 US qt, 7.0 Imp qt)

Transfer case oil

0.45 L (0.48 US qt, 0.40 Imp qt)

Rear differential oil

0.35 L (0.37 US qt, 0.31 Imp qt)

Fuel tank

2WD

72.0 L (19.0 US gal, 15.8 Imp gal)

AWD

74.0 L (19.5 US gal, 16.3 Imp gal)

Check oil and fluid levels with dipsticks or reservoir gauges.

▼ Dimensions

U.S.A. and Canada

Item

Vehicle specification

Overall length

5,075 mm (199.8 in)

Overall width

1,969 mm (77.5 in)

Overall height

1,752 mm (69.0 in)

Front tread

1,659 mm (65.3 in)

Rear tread

1,656 mm (65.2 in)

Wheelbase

2,928 mm (115.3 in)

Mexico

Item

Vehicle specification

Overall length

5,075 mm (199.8 in)

Overall width

1,969 mm (77.5 in)

Overall height

1,747 mm (68.8 in)

Front tread

1,659 mm (65.3 in)

Rear tread

1,656 mm (65.2 in)

Wheelbase

2,928 mm (115.3 in)

▼ Weights

U.S.A. and Canada

Item

Weight

2WD

AWD

GVWR (Gross Vehicle Weight Rating)

2,572 kg (5,670 lbs)

2,638 kg (5,816 lbs)

GAWR (Gross Axle Weight Rating)

Front

1,225 kg (2,701 lbs)

1,241 kg (2,736 lbs)

Rear

1,386 kg (3,056 lbs)

1,433 kg (3,159 lbs)

Specifications

9-5

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Mexico

Item

Weight

2WD

AWD

GVW (Gross Vehicle Weight)

Total

2,495 kg (5,500 lbs)

2,565 kg (5,655 lbs)

Front

1,180 kg (2,601 lbs)

1,205 kg (2,657 lbs)

Rear

1,315 kg (2,899 lbs)

1,360 kg (2,998 lbs)

GAW (Permissible axle load)

Front

1,200 kg (2,646 lbs)

1,225 kg (2,701 lbs)

Rear

1,370 kg (3,020 lbs)

1,420 kg (3,131 lbs)

▼ Air Conditioner

The type of refrigerant used is indicated on a label attached to the inside of the engine com‐
partment. Check the label before recharging the refrigerant. Refer to Climate Control Sys‐
tem on page 5-4.

Item

Specification

Refrigerant Type

HFC134a (R-134a)

▼ Light Bulbs

Exterior light

With Adaptive Front Lighting System (AFS)

Light bulb

Category

Wattage

UN-R

(SAE)

Headlights

High beam

LED

― (―)

Low beam

LED

― (―)

Daytime running lights/Parking lights

LED

― (―)

Front side-marker lights

LED

― (―)

Front turn signal lights

LED

― (―)

Fog lights

LED

― (―)

Signature wing illumination

LED

― (―)

Side turn signal lights

LED

― (―)

High-mount brake light

LED

― (―)

Rear turn signal lights

WY21W (7443NA)

Rear side-marker lights

LED

― (―)

Brake lights/Taillights

LED

― (―)

Brake lights

LED

― (―)

Taillights

LED

― (―)

Reverse lights

W16W (921)

Specifications

9-6

*Some models.

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Light bulb

Category

Wattage

UN-R

(SAE)

License plate lights

LED

― (―)

1 UN-R stands for United Nations Regulation.

2 LED is the abbreviation for Light Emitting Diode.

Without Adaptive Front Lighting System (AFS)

Light bulb

Category

Wattage

UN-R

(SAE)

Headlights

High beam

LED

― (―)

Low beam

LED

― (―)

Daytime running lights

LED

― (―)

Parking lights/Front side-marker lights

WY5W (―)

Front turn signal lights

WY21W (7443NA)

Fog lights

LED

― (―)

Side turn signal lights

LED

― (―)

High-mount brake light

LED

― (―)

Rear turn signal lights

WY21W (7443NA)

Rear side-marker lights

LED

― (―)

Brake lights/Taillights

LED

― (―)

Brake lights

LED

― (―)

Reverse lights

W16W (921)

License plate lights

LED

― (―)

1 UN-R stands for United Nations Regulation.

2 LED is the abbreviation for Light Emitting Diode.

Interior light

Light bulb

Category

Wattage

UN-R

Overhead lights (Front)/Map lights
(Front)

Bulb type

―

LED type

LED

―

Overhead lights (Center)/Map lights
(Center)

Bulb type

―

LED type

LED

―

Overhead light (Rear)

Bulb type

―

LED type

LED

―

Ambient lights

LED

―

Specifications

*Some models.

9-7

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Light bulb

Category

Wattage

UN-R

Vanity mirror lights

Bulb type

―

LED type

LED

―

Luggage compartment light

―

1 UN-R stands for United Nations Regulation.

2 LED is the abbreviation for Light Emitting Diode.

▼ Tires

NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.

Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 6-38.

Standard tire

(U.S.A. and Canada)

Tire size

Inflation pressure

Front

Rear

P255/60R18 107H

230 kPa (34 psi)

P255/50R20 104V

230 kPa (34 psi)

(Mexico)

Tire size

Inflation pressure

Front

Rear

P255/50R20 104V

230 kPa (2.3 bar, 33 psi)

Temporary spare tire

(U.S.A. and Canada)

Tire size

Inflation pressure

T155/90D17 101M

420 kPa (60 psi)

(Mexico)

Tire size

Inflation pressure

185/80R17 99M

320 kPa (3.2 bar, 46 psi)

Specifications

9-8

*Some models.

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Personalization Features

The following personalization features can be set or changed by the customer or an Author‐
ized Mazda Dealer. Consult an Authorized Mazda Dealer for details.
Additionally, some of the personalization features can be changed by the customer depend‐
ing on the feature.
Personalization features and settings which can be changed differ depending on the market
and specification.

Settings Change Method

Settings can be changed by operating the center display screen.

A: Refer to Settings on page 5-77.
B: Refer to Fuel Economy Monitor on page 4-99.
C: Refer to Active Driving Display on page 4-56.

Settings can be changed by operating the vehicle switches.

D: Refer to Auto Lock/Unlock Function on page 3-16.
E: Refer to Transmitter on page 3-4.
F: Refer to Locking, Unlocking with Request Switch (With the advanced keyless function)
on page 3-13.

Settings can be changed by an Authorized Mazda Dealer.

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Safety
Advanced Smart
City Brake Sup‐
port (Advanced
SCBS) (page
4-158)
Smart City
Brake Support
(SCBS) (page
4-161)
Smart Brake
Support (SBS)
(page 4-164)

The system can be changed so that Advanced
Smart City Brake Support (Advanced SCBS)/
Smart City Brake Support (SCBS)/Smart Brake
Support (SBS) does not operate.

On/Off

A ―

The distance at which the collision warning ac‐
tivates can be changed.

Med.

Near/Med./Far

A ―

The volume of the collision warning can be
changed.

High

High/Low/Off

A ―

Specifications

Personalization Features

9-10

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Lane-keep As‐
sist System
(LAS) & Lane
Departure Warn‐
ing System
(LDWS) (page
4-147)

The system can be changed so that the steering
wheel assist does not operate.

On/Off

A ―

When the steering
wheel operation assis‐
tance is turned on

The sensitivity of the
steering assistance for
the Lane-keep Assist
System (LAS) & Lane
Departure Warning
System (LDWS) can
be changed.

High

High/Low

A ―

The system can be
changed so that the
lane departure warn‐
ing does not activate.

On/Off

A ―

When the steering
wheel operation assis‐
tance is turned off

The warning timing in
which the Lane-keep
Assist System (LAS)
& Lane Departure
Warning System
(LDWS) system deter‐
mines that the vehicle
may be deviating from
its lane can be
changed.

At/Before

A ―

The sensitivity of the
warning for the
Lane-keep Assist Sys‐
tem (LAS) & Lane
Departure Warning
System (LDWS) can
be changed.

Often

Often/Rare

A ―

The type of Lane-keep Assist System (LAS) &
Lane Departure Warning System (LDWS)
warning can be changed.

Vibration

Vibration/Beep/

Rumble.

A ―

The warning intensity/
volume of the
Lane-keep Assist Sys‐
tem (LAS) & Lane De‐
parture Warning Sys‐
tem (LDWS) system
can be changed.

Vibration

Low

High/Low

A ―

Rumble.

Low

High/Mid/Low

A ―

Beep

Low

High/Low

A ―

Specifications

Personalization Features

9-11

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Blind Spot Mon‐
itoring (BSM)
(page 4-114)

The system can be changed so that Blind Spot
Monitoring (BSM) does not operate.

On/Off

A ―

Warning beep volume

High

High/

Low/

Off

A ―

Distance Recog‐
nition Support
System (DRSS)
(page 4-126)

The system can be changed so that Distance
Recognition Support System (DRSS) does not
operate.

On/Off

A ―

The distance at which the vehicle ahead and
your vehicle indicated in the display flashes in
white can be changed.

Near

Far/Med./Near

A ―

Traffic Sign
Recognition
System (TSR)

(page 4-120)

The Traffic Sign Recognition System (TSR)
can be set to inoperable.

On/Off

A ―

The warning pattern of the excessive speed
warning can be changed.

Off

Off/

Visual/

Audio & Visual

A ―

The activation timing for the excessive speed
warning can be changed.

0/ 5/ 10

A ―

360° View Mon‐
itor (page 4-166)

Setting can be changed so that the 360° view
monitor is automatically displayed when the
ignition is switched to ON.

Off

On/Off

A ―

Setting can be changed so that the display of
the estimated forward line of progress is not
displayed.

On/Off

A ―

Setting can be changed so that the top view/
front view displayed while the vehicle is mov‐
ing in the forward direction after reversing is
not displayed.

On/Off

A ―

Parking sensor
system (page
4-225)

Display

/non-display

On/Off

A ―

Specifications

Personalization Features

9-12

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Vehicle

Door locks
(page 3-16)

Operation condition of auto lock/unlock func‐
tion

Lock: When
Driving Un‐

lock: IGN

Off

Lock: Out of

Park Unlock: In

Park/

Lock: Shifting

Out of Park/
Lock: When

Driving Unlock:

In Park/

Lock: When

Driving Unlock:

IGN Off/

Lock: When

Driving/

Off

A D

Keyless entry
system (page
3-3)

Method for unlocking door using transmitter

Driver's:

Once, All

Doors: Twice

All Doors:

Once/

Driver's: Once,

All Doors:

Twice

Time for locking door automatically

60 seconds

90 seconds/
60 seconds/

30 seconds

A ―

Advanced key‐
less entry system
(page 3-9)

Method for unlocking door using request
switch/transmitter

Driver's:

Once, All

Doors: Twice

All Doors:

Once/

Driver's: Once,

All Doors:

Twice

Time for locking door automatically

60 seconds

90 seconds/
60 seconds/

30 seconds

A ―

Auto-lock function operation/non-operational

Off

On/Off

A ―

Beep volume when locking/unlocking

Medium

High/

Medium/

Low/

Off

Specifications

Personalization Features

9-13

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Illuminated en‐
try system (page
5-96)

Time until interior lights turn off after closing
door

15 seconds

60 seconds/
30 seconds/
15 seconds/
7.5 seconds

A ―

Time until interior lights turn off automatically
when any door is not closed completely

30 minutes

60 minutes/
30 minutes/

10 minutes

A ―

Auto-wiper con‐
trol (page 4-74)

Operational/non-operational

On or Off

On/Off

A ―

Daytime running
lights (page
4-72)

Operational/non-operational

On/Off

― ―

Auto headlight
off

(page 4-68)

Time until headlights turn off

30 seconds

120 seconds/

90 seconds/
60 seconds/
30 seconds/
0 seconds

A ―

Auto-light con‐
trol (page 4-68)

Timing by which lights turn on

Medium

High/

Med. High/

Medium/

Med. Low/

Low

A ―

High Beam Con‐
trol System
(HBC) (page
4-111)

Operational/non-operational

On/Off

A ―

Adaptive Front
Lighting System
(AFS) (page
4-110)

Operational/non-operational

On/Off

A ―

Lights-on re‐
minder

(page

7-46)

Warning beep volume

High

High/Low/Off

A ―

Coming home
light (page 4-71)

Time until headlights turn off

30 seconds

120 seconds/

90 seconds/
60 seconds/
30 seconds/

Off

A ―

Leaving home
light (page 4-71)

Operational/non-operational

On/Off

A ―

Turn indicator
(page 4-73)

Beep volume

High

High/Low

A ―

Specifications

Personalization Features

9-14

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Three-flash turn
signal (page
4-74)

Operational/non-operational

On/Off

A ―

Ambient Light‐
ing (page 5-93)

Ambient lights brightness

Medium

Bright/

Medium/

Dim/

Off

*10

A ―

Rear window
defogger (page
4-78)

The operation time for the rear window defog‐
ger can be changed.

15 minutes

15 minutes/

Continuous

*11

― ―

System

Language

Language indicated in display

US English

Depends on

market

*12

A ―

Temperature

Temperature unit indicated in display

°F or °C

°F/°C

A ―

Distance

Distance unit indicated in display

mi or km

mi/km

A ―

Fuel Economy Monitor (page 4-99)

Ending display

On/off

Off

On/Off

B ―

Fuel economy
resetting proce‐
dure

Linkage/non-linkage with fuel economy reset
and trip meter reset

Off

On/Off

B ―

Specifications

Personalization Features

9-15

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Item

Feature

Factory Set‐

ting

Available Set‐

tings

Settings

Change
Method

Active driving display (page 4-56)

Display

Setting can be changed so that the Active Driv‐
ing Display is not displayed.

On/Off

C ―

The display height (up/down position) can be
changed.

13 steps up/

down from ini‐

tial setting (total:

27 steps)

C ―

The method for adjusting the display bright‐
ness (automatically/manually) can be changed.

Auto

Auto/Man.

C ―

The standard brightness with the automatic
brightness adjustment can be changed.

2 steps up/down

from initial set‐

ting (total: 5

steps)

C ―

The standard brightness with the manual
brightness adjustment can be changed.

20 steps up/

down from ini‐

tial setting (total:

41 steps)

C ―

The display angle can be changed.

3steps up/down
from initial set‐

ting (total:

7steps)

C ―

Navigation guid‐
ance

Display/non-display

On/Off

C ―

1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda

recommends that these systems remain On.

2 Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation can be changed. The

volume of the warning beep during Rear Cross Traffic Alert (RCTA) operation cannot be changed.

3 This system functions only when the navigation system is functioning.

4 When the ultrasonic sensors detect an obstruction, the contents indicated on the center display switches to the

360°View Monitor. (Vehicles with 360°View Monitor)

5 If the auto-wiper control is set to Off, the wiper lever

position is set to intermittent operation.

6 If the setting is changed to Off, the following operation is performed according to the headlight switch

position:



position: Headlights turn off immediately after the ignition is switched off.



At any position other than

: Headlights on/off conditions vary according to the headlight switch

position. Refer to Headlights on page 4-68.

7 When set to 0 seconds, the lights-on reminder is operable.

8 The lights-on reminder settings can be changed at anytime, however, the lights-on reminder only operates

when the auto headlight function is set to Off. Refer to Lights-On Reminder on page 7-46.

9 Change the ambient light illumination level with the parking lights or headlights turned on.

10 When set to OFF, the ambient lights remain turned off regardless of whether or not the parking lights or

headlights are on or off. However, they will turn on or off in conjunction with the illuminated entry system.

Specifications

Personalization Features

9-16

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Mazda CX-9 (2019 year). Instruction - part 42
