Mazda CX-3 (2019 year). Instruction - part 32





Overheating

If the high engine coolant temperature
warning light turns on, the vehicle loses
power, or you hear a loud knocking or
pinging noise, the engine is probably too
hot.

WARNING

Pull over to a safe location, then switch

the ignition off and make sure the fan is
not running before attempting to work
near the cooling fan:
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if the
engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.

Do not remove either cooling

system cap when the engine and radiator
are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot out
under pressure and cause serious injury.

Open the hood ONLY after steam is no
longer escaping from the engine:
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.

If the high engine coolant temperature
warning light turns on:

1. Drive safely to the side of the road and

park off the right-of-way.

2. Put a vehicle with an automatic

transaxle in park (P), a manual
transaxle in neutral.

3. Apply the parking brake.
4. Turn off the air conditioner.
5. Check whether coolant or steam is

escaping from the engine
compartment.

If steam is coming from the engine
compartment:
Do not go near the front of the vehicle.
Stop the engine.
Wait until the steam dissipates, then
open the hood and start the engine.

If neither coolant nor steam is
escaping:
Open the hood and idle the engine
until it cools.

CAUTION

If the cooling fan does not operate
while the engine is running, the engine
temperature will increase. Stop the
engine and call an Authorized Mazda
Dealer.

6. Make sure the cooling fan is operating,

then turn off the engine after the
temperature has decreased.

7. When cool, check the coolant level.

If Trouble Arises

Overheating

7-22

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

If it is low, look for coolant leaks from
the radiator and hoses.


If you find a leak or other damage, or if
coolant is still leaking:
Stop the engine and call an Authorized
Mazda Dealer.

Cooling system cap

Coolant reservoir

Cooling fan

If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required (page
6-25).

CAUTION

If the engine continues to overheat or
frequently overheats, have the cooling
system inspected. The engine could be
seriously damaged unless repairs are
made. Consult an Authorized Mazda
Dealer.

If Trouble Arises

Overheating

7-23

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Towing Description

We recommend that towing be done only
by an Authorized Mazda Dealer or a
commercial tow-truck service.

Proper lifting and towing are necessary to
prevent damage to the vehicle. Particularly
when towing an AWD vehicle, where all
the wheels are connected to the drive train,
proper transporting of the vehicle is
absolutely essential to avoid damaging the
drive system. Government and local laws
must be followed.

Wheel dollies


A towed 2WD vehicle should have its
drive wheels (front wheels) off the ground.
If excessive damage or other conditions
prevent this, use wheel dollies.

When towing a 2WD vehicle with the rear
wheels on the ground, release the parking
brake.
Refer to Electric Parking Brake (EPB) on
page 4-57.

A towed AWD vehicle must have all its
wheels off the ground.

WARNING

Always tow an AWD vehicle with all four
wheels off the ground:
Towing an AWD vehicle with either the
front or rear wheels on the ground is
dangerous as the drive train could be
damaged, or the vehicle could trail away
from the tow truck and cause an accident.
If the drive train has been damaged,
transport the vehicle on a flatbed truck.

CAUTION

Do not tow the vehicle pointed backward

with driving wheels on the ground. This
may cause internal damage to the
transaxle.

If Trouble Arises

Emergency Towing

7-24

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Do not tow with sling-type equipment.

This could damage your vehicle. Use
wheel-lift or flatbed equipment.

If the parking brake cannot be released

when towing the vehicle, transport the
vehicle with all front and rear wheels
raised off the ground as shown in the
figure. If the vehicle is towed without
raising the wheels off the ground, the
brake system could be damaged.

Wheel dollies

Tiedown Hooks

*

CAUTION

Do not use the front tiedown eyelet for
towing the vehicle.
They have been designed only for securing
the vehicle to a transport vessel during
shipping.
Using the eyelet for any other purpose
could result in the vehicle being damaged.

▼ Tiedown Hook-Front

1. Remove the tiedown eyelet and the lug

wrench from the luggage compartment
(page 7-3).

2. Wrap a jack lever or similar tool with a

soft cloth to prevent damage to a
painted bumper, and open the cap
located on the front bumper.


CAUTION

Do not use excessive force as it may
damage the cap or scratch the painted
bumper surface.

If Trouble Arises

Emergency Towing

*Some models.

7-25

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

NOTE
Remove the cap completely and store it
so as not to lose it.

3. Securely install the tiedown eyelet

using the lug wrench.


Lug wrench

Tiedown eyelet

4. Hook the tying rope to the tiedown

eyelet.

CAUTION

If the tiedown eyelet is not securely
tightened, it may loosen or disengage
from the bumper when tying the
vehicle. Make sure that the tiedown
eyelet is securely tightened to the
bumper.

▼ Tiedown Hook-Rear

The hook positioned under the rear
bumper on the right side is for tying down
the vehicle during transport, and it cannot
be used for towing other vehicles.
It can be used as a towing hook only when
the vehicle must be towed by another
vehicle in an emergency case such as
when the vehicle is stuck in snow,
however, it may damage the bumper.

Tiedown hook

CAUTION

When using the hook in such emergency
cases, observe the following so as not to
damage the tiedown hook or the vehicle
body.

The vehicle must be pulled straight to the

rear so that no load is applied to the
vehicle in the lateral direction.

The bumper may be damaged if the tie

down hook is used as a towing hook.

When using a metal chain or wire cable,

wrap a cloth around the attachment
area. If the metal chain or wire cable
contacts the bumper directly, the
bumper could be scratched or damaged.

If Trouble Arises

Emergency Towing

7-26

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

If a Warning Light Turns On or Flashes

If any warning light turns on/flashes, take appropriate action for each light. There is no
problem if the light turns off, however if the light does not turn off or turns on/flashes again,
consult an Authorized Mazda Dealer.
(Vehicles with type B audio)
The details for some warnings can be viewed on the center display.
1. If the warning light is turned on, select   icon on the home screen to display the

application screen.

2. Select “Vehicle Status Monitor”.
3. Select “Warning Guidance” to display the current warnings.
4. Select the applicable warning to view the warning details.

▼ Stop Vehicle in Safe Place Immediately

If any of the following warning lights turns on, the system may have a malfunction. Stop the
vehicle in a safe place immediately and contact an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-27

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Brake System Warning

Light

This warning has the following functions:
Parking brake warning/Warning light inspection
The light illuminates when the parking brake is applied with the ignition switched to
START or ON. It turns off when the parking brake is released.
When the light turns on
If the brake system warning light remains turned on even though the parking brake is
released, the brake fluid may be low or there could be a problem with the brake sys-
tem. Park the vehicle in a safe place immediately and contact an Authorized Mazda
Dealer.
When the light is flashing
The light flashes if the Electric Parking Brake (EPB) has a malfunction.
If the light remains flashing even if the Electric Parking Brake (EPB) switch is oper-
ated, consult an Authorized Mazda Dealer as soon as possible.

WARNING

Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.

CAUTION

In addition, the effectiveness of the braking may diminish so you may need to depress
the brake pedal more strongly than normal to stop the vehicle.

Electronic Brake Force

Distribution System

Warning

If the electronic brake force distribution control unit determines that some compo-
nents are operating incorrectly, the control unit may illuminate the brake system
warning light and the ABS warning light simultaneously. The problem is likely to be
the electronic brake force distribution system.

WARNING

Do not drive with both the ABS warning light and brake warning light illuminated.
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as
soon as possible:
Driving when the brake system warning light and ABS warning light are illuminated
simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an emer‐
gency stop than under normal circumstances.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-28

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Charging System Warn-

ing Light

If the warning light illuminates while driving, it indicates a malfunction of the alter-
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Consult an Authorized
Mazda Dealer.

CAUTION

Do not continue driving when the charging system warning light is illuminated be‐
cause the engine could stop unexpectedly.

Engine Oil Warning

Light

This warning light indicates low engine oil pressure.

CAUTION

Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.

If the light illuminates or the warning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way on level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
3. Inspect the engine oil level (page 6-25). If it's low, add the appropriate amount of

engine oil while being careful not to overfill.

CAUTION

Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.

4. Start the engine and check the warning light.

If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.

(Red)

High Engine Coolant

Temperature Warning

Light

The light flashes when the engine coolant temperature is extremely high, and illumi-
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine load until you can find a safe place to stop the vehicle
and wait for the engine to cool down.
Illuminated light
This indicates the possibility of overheating. Park the vehicle in a safe place immedi-
ately and stop the engine.
Refer to Overheating on page 7-22.

CAUTION

Do not drive the vehicle with the high engine coolant temperature warning light illumi‐
nated. Otherwise, it could result in damage to the engine.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-29

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Power Steering Mal-

function Indicator Light

The light illuminates/flashes if the electric power steering has a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the light turns off after a while. Contact an Au-
thorized Mazda Dealer if the light illuminates/flashes continuously.

NOTE

•

If the indicator light illuminates/flashes, the power steering will not operate normal-
ly. If this happens, the steering wheel can still be operated, however, the operation
may feel heavy compared to normal, or the steering wheel could vibrate when turn-
ing.

•

Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem. If
this occurs, park the vehicle safely and wait several minutes for the system to return
to normal.

▼ Contact Authorized Mazda Dealer and Have Vehicle Inspected

If any of the following warning lights or the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.

Signal

Warning

ABS Warning Light

If the ABS warning light stays on while you're driving, the ABS control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an Authorized Mazda Dealer as soon as possible.

NOTE

•

When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.

•

The brake assist system does not operate while the ABS warning light is illuminated.

Master Warning

Light

(Vehicles with type B audio)
The light turns on when the system has a malfunction.
Operate the center display and verify the content.
Refer to If a Warning Light Turns On or Flashes on page 7-27.
(Vehicles with type A audio)
The light illuminates continuously if any one of the following occurs. Consult an Author-
ized Mazda Dealer.

•

There is a malfunction in the battery management system.

•

There is a malfunction in the brake switch.

Electric Parking

Brake (EPB) Warn-

ing Light

The warning light illuminates when the system has a malfunction. Have your vehicle in-
spected at an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-30

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

(Red)

Brake Pedal Opera-
tion Demand Warn-

ing Light

When only flashing

Flashes if there is the possibility of the vehicle not being held in the stopped position by
the AUTOHOLD function, such as on steep slopes. Depress and hold your foot on the
brake pedal.

When flashing and beep sound is activated at the same time

The warning light flashes and the beep sound is activated for about five seconds if there is
a problem with the system. If the warning light flashes and the warning sound is activated,
immediately depress the brake pedal and stop using the AUTOHOLD function then con-
tact an Authorized Mazda Dealer.

WARNING

Immediately depress the brake pedal if the warning light flashes and the beep sound is acti‐
vated while using the AUTOHOLD function:
Because the AUTOHOLD function is canceled forcibly, the vehicle may move unexpectedly
and result in an accident.

Check Engine Light

If this light illuminates while driving, the vehicle may have a problem. It is important to
note the driving conditions when the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:

•

The fuel tank level being very low or approaching empty.

•

The engine's electrical system has a problem.

•

The emission control system has a problem.

•

The fuel-filler cap is missing or not tightened securely.

If the check engine light remains on, or it flashes continuously , do not drive at high
speeds and consult an Authorized Mazda Dealer as soon as possible.

Automatic Trans-

axle Warning Light

*

The light illuminates when the transaxle has a problem.

CAUTION

If the automatic transaxle warning light illuminates, the transaxle has an electrical prob‐
lem. Continuing to drive your Mazda in this condition could cause damage to your trans‐
axle. Consult an Authorized Mazda Dealer as soon as possible.

(Turns on)

TCS/DSC Indicator

Light

If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-31

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Air Bag/Front Seat

Belt Pretensioner

System Warning

Light

A system malfunction is indicated if the warning light constantly flashes, constantly illu-
minates or does not illuminate at all when the ignition is switched ON. If any of these oc-
cur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate
in an accident.

WARNING

Never tamper with the air bag/pretensioner systems and always have an Authorized Mazda
Dealer perform all servicing and repairs:
Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner could
accidentally activate or become disabled causing serious injury or death.

AWD Warning

Light

*

When the light is turned on

The light turns on under the following conditions. The system may have a malfunction.
Have the vehicle checked at an Authorized Mazda Dealer.

•

When there is a malfunction in the AWD system.

•

When there is a large difference between the tire size of the front and rear wheels.

When the light is flashing

Park the vehicle in a safe place. After a few moments, if the warning light stops flashing,
you can resume driving. If the light does not stop flashing, contact an Authorized Mazda
Dealer.

•

When the differential oil temperature is excessively high.

•

When there is a large difference between the front and rear wheel rotation, such as when
trying to remove the vehicle from mud.

(Flashing)

Tire Pressure Moni-

toring System

Warning Light

*

If the tire pressure monitoring system has a malfunction, the tire pressure warning light
flashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.

WARNING

If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, decrease vehicle speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, it is dangerous to drive the vehicle at high speeds, or
perform sudden maneuvering or braking. Vehicle drivability could worsen and result in an
accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed to a
place where air may be added and the system monitored again by an Authorized Mazda
Dealer or a tire repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have
the problem taken care of as soon as possible before it develops into a more serious situa‐
tion that could lead to tire failure and a dangerous accident.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-32

*Some models.

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

(Red)

(Turns on)

KEY Warning Light

If any malfunction occurs in the keyless entry system, it illuminates continuously.

CAUTION

If the key warning indicator light illuminates or the push button start indicator light (amber)
flashes, the engine may not start. If the engine cannot be started, try starting it using the
emergency operation for starting the engine, and have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.

Refer to Emergency Operation for Starting the Engine on page 4-9.

Security Indicator

Light

If the engine does not start with the correct key, and the security indicator light remains
illuminated or flashing, try the following:
Make sure the key is within the operational range for signal transmission. Switch the igni-
tion off, and then restart the engine. If the engine does not start after 3 or more tries, con-
tact an Authorized Mazda Dealer.

(Amber)

High Beam Control

System (HBC)

Warning Light

*

The light remains turned on if there is a problem with the system. Have your vehicle in-
spected at an Authorized Mazda Dealer.

NOTE

If the Forward Sensing Camera (FSC) field of view is impaired during bad weather condi-
tions (such as rain, fog, and snow) and when the windshield is dirty, the warning indica-
tion/warning light for the High Beam Control System (HBC) may display/turn on. Howev-
er, this does not indicate a problem.

(Turns on)

Lane Departure

Warning System

(LDWS) Warning

Light

*

•

The warning light remains turned on if there is a problem with the system. Have your
vehicle inspected at an Authorized Mazda Dealer.

•

The LDWS does not operate when the warning light illuminates.

CAUTION

 A problem in the system may be indicated under the following conditions. Have your ve‐

hicle inspected at an Authorized Mazda Dealer.

 When the light remains turned on while driving the vehicle.

When the system is canceled automatically, the light turns on. Normally, the system re‐
stores automatically and the light turns off, however, if the light remains turned on,
there may be a problem with the system.

 The light does not illuminate when the ignition is switched ON.

 Always use tires for all wheels that are of the specified size, and the same manufacture,

brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the LDWS may not operate
normally.

 When an emergency spare tire is used, the system may not operate normally.

NOTE

If the windshield area in front of the Forward Sensing Camera (FSC) is fogged or ob-
structed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-33

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

(Amber)

Mazda Radar Cruise
Control with Stop &

Go function

(MRCC with Stop

& Go function)

Warning Light

*

The warning light turns on if there is a malfunction in the system while the Mazda Radar
Cruise Control with Stop & Go function (MRCC with Stop & Go function) system is on.
Have your vehicle inspected at an Authorized Mazda Dealer.

Blind Spot Monitor-

ing (BSM) OFF In-

dicator Light

*

A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.

•

The light does not turn on when the ignition is switched ON.

•

The light remains on even when the Blind Spot Monitoring (BSM) system can be operat-
ed.

•

The light turns on while driving the vehicle.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator light
in the instrument cluster illuminates). However, it does not indicate a malfunction.

LED Headlight

Warning Light

*

This light illuminates if there is a malfunction in the LED headlight. Have your vehicle
inspected by an Authorized Mazda Dealer.

▼ Taking Action

Take the appropriate action and verify that the warning light turns off.

Signal

Warning

Action to be taken

Low Fuel Warning

Light

The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).

NOTE

The light illumination timing may vary be-
cause fuel inside the fuel tank moves around
according to the driving conditions and the
vehicle posture.

Add fuel.

Check Fuel Cap Warn-

ing Light

If the check fuel cap warning light illumi-
nates while driving, the fuel-filler cap may
not be installed properly.

Stop the engine and reinstall the fuel-filler
cap.
Refer to Refueling on page 3-27.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-34

*Some models.

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Action to be taken

Seat Belt Warning

Light

Except Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig-
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re-
mains illuminated.

NOTE

•

The warning light flashes for about 6 sec-
onds if the driver's seat belt is not fastened
when the ignition is switched ON.

•

To allow the front passenger occupant
classification sensor to function properly,
do not place and sit on an additional seat
cushion on the front passenger's seat. The
sensor may not function properly because
the additional seat cushion could cause
sensor interference.

•

If a small child is seated on the front pas-
senger's seat, the warning light may not
operate.

Fasten the seat belts.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-35

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Action to be taken

Seat Belt Warning

Light

Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig-
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re-
mains illuminated. If a seat belt remains un-
fastened, the warning light flashes again for
a given period of time.

NOTE

•

Placing heavy items on the front passeng-
er's seat may cause the front passenger's
seat belt warning function to operate de-
pending on the weight of the item.

•

To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor may
not function properly because the addi-
tional seat cushion could cause sensor in-
terference.

•

If a small child is seated on the front pas-
senger's seat, the warning light may not
operate.

Fasten the seat belts.

Door-Ajar Warning

Light

The light turns on if any door/liftgate is not
closed securely.

Close the door/liftgate securely.

Low Washer Fluid

Level Warning Light

*

This warning light indicates that little wash-
er fluid remains.

Add washer fluid (page 6-27).

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-36

*Some models.

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Signal

Warning

Action to be taken

(Amber)

Smart Brake Support/

Smart City Brake Sup-

port (SBS/SCBS)

Warning Light

*

The light turns on if the windshield or the
radar sensor are dirty, or there is a malfunc-
tion in the system.

(Vehicles with type B audio)
Verify the reason why the warning light is
illuminated on the center display (page
7-27).
If the reason why the warning light is illu-
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em-
blem.
For any other reasons, have the vehicle in-
spected at an Authorized Mazda Dealer.
(Vehicles without type B audio)
If the reason why the warning light is illu-
minated is due to a dirty windshield, clean
the windshield. For any other reasons,
have the vehicle inspected at an Author-
ized Mazda Dealer.



Tire Pressure Monitoring System Warning Light (Turns on)

*

Take the appropriate action and verify that the warning light turns off.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-37

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14















Content   ..  30  31  32  33   ..
