Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda

specifications for complete refill of Traction-Lok axles. If submerged in
water, the rear axle lubricant should be changed.

Ensure the correct automatic transmission fluid is used. Transmission

fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCON

t and MERCONt V are not interchangeable. DO NOT

mix MERCON

t and MERCONt V. Refer to your service maintenance

section to determine the correct service interval.

ENGINE SPECIFICATIONS

Engine

2.3L I4 engine 3.0L V6 engine

4.0L V6 engine

Cubic inches

138

182

245

Required fuel

87 octane

Firing order

1-3-4-2

1-4-2-5-3-6

Spark plug gap

1.04-1.19mm
(0.041-0.047
inch)

1.07-1.17mm
(0.042-0.046
inch)

1.3-1.4 mm
(0.052-0.056
inch)

Ignition system

EDIS

Compression
ratio

9.7:1

9.14:1

9.0:1

VEHICLE DIMENSIONS

Vehicle dimensions

Regular Cab

mm (in)

SuperCab mm

(in)

(1) Overall length

4 763 (187.5)

5 153 (202.9)

(2) Overall width

1 785 (70.3)

(3) Overall height 4x2/4x4

1 575 (62.0) /

1 655 (65.2)

1 585 (62.4) /

1 684 (66.3)

(4) Wheelbase

2 831 (111.4)

3 192 (125.7)

(5) Track - Front

1 486 (58.5)

1 485 (58.5)

(5) Track - Rear

1 455 (57.3)

Maintenance and Specifications

276

Maintenance and Specifications

277

IDENTIFYING YOUR VEHICLE

Certification label

The National Highway Traffic Safety Administration Regulations require
that a Certification Label be affixed to a vehicle and prescribe where the
Certification Label may be located. The Certification Label is located on
the front door latch pillar on the driver’s side.

Vehicle identification number (VIN)

The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel. (Please note that
in the graphic XXXX is
representative of your vehicle
identification number.)

Engine number

The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if equipped).

XXXXXXXXXXXXXXXXX

Maintenance and Specifications

278

CELL PHONES

Use of cell phones and other devices by driver:

WARNING: Although not Mazda products, use of any electrical
devices such as cell phones, computers, portable radios, vehicle
navigation or other devices by the driver while the vehicle is
moving is dangerous. Dialing a number on a cell phone while
driving also ties-up the driver’s hands. Use of these devices will
cause the driver to be distracted and could lead to a serious
accident. If a passenger is unable to use the device, pull off the
right-of-way to a safe area before use. If use of a cell phone is
necessary despite this warning, use a hands-free system to at
least allow the hands free to drive the vehicle. Never use a cell
phone or other electrical device while the vehicle is moving and,
instead, concentrate on the full-time job of driving.

Accessories
