Mazda 3 (2018 year). Instruction

Inside Trunk Release

Lever (4-Door)

Your vehicle is equipped with an inside
trunk release lever that provides a means
of escape for children and adults in the
event they become locked inside the trunk.

No matter how careful adults might be
with keys and locking their cars, parents
should be aware that children may be
tempted to play around vehicles and use
the trunk as a hiding place.

Adults are advised to familiarize
themselves with the operation and location
of the inside trunk release lever so that all
children can be told about it in an
appropriate way, keeping in mind that
most vehicles do not have such levers.

WARNING

Close the trunk lid, be sure the seat backs
are latched and do not allow children to
play inside the vehicle:
Leaving the trunk lid open or leaving
children in the vehicle with the keys is
dangerous. Children could open the trunk
lid and climb inside resulting in possible
injury or death from heat exposure.

Always keep the car from being a tempting
place to play by latching the rear seats,
doors and the trunk, and keeping the keys
where children can not play with them:
Leaving children or animals unattended in
a parked vehicle is dangerous. Babies left
sleeping and children who lock themselves
in cars or trunks can die very quickly from
heat prostration. Do not leave your
children or pets alone in a car at any time.
Do not leave the car, the rear folding seats
or the trunk unlocked.

▼ Opening the Trunk Lid from the

Inside

Slide the inside trunk release lever in the
direction of the arrow. The lever is made
of material that will glow for hours in the
darkness of the trunk following a brief
exposure to ambient light.

The inside trunk release lever is located on
the inside of the trunk lid.

Before Driving

Doors and Locks

3-24

*Some models.

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Fuel and Engine Exhaust Precautions

▼ Fuel Requirements

Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.

This vehicle will perform best with fuel listed in the table.

Fuel

Octane Rating

(Anti-knock index)

Regular unleaded fuel

87 [(R M)/2 method] or above (91 RON or above)

 U.S. federal law requires that octane ratings be posted on gasoline station pumps.

Fuel with a rating lower than 87 octane (91 RON) will negatively affect the emission control
system performance and could also cause engine knocking and serious engine damage.

CAUTION

USE ONLY UNLEADED FUEL.

Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead to
deterioration of the emission control system and or failures.

This vehicle can only use oxygenated fuels containing no more than 10 % ethanol by

volume. Damage to the vehicle may occur when ethanol exceeds this recommendation, or
if the gasoline contains any methanol. Stop using gasohol of any kind if your vehicle engine
is performing poorly.

Never add fuel system additives, otherwise the emission control system could be damaged.

Consult an Authorized Mazda Dealer for details.

Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".

Vehicle damage and drivability problems resulting from the use of the following may not be
covered by the warranty.



Gasohol containing more than 10 % ethanol.



Gasoline or gasohol containing methanol.



Leaded fuel or leaded gasohol.

Before Driving

Fuel and Emission

3-25

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Emission Control System

This vehicle is equipped with an emission control system (the catalytic converter is part of
this system) that enables the vehicle to comply with existing exhaust emissions
requirements.

WARNING

Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.

CAUTION

Ignoring the following precautions could cause lead to accumulate on the catalyst inside the
converter or cause the converter to get very hot. Either condition will damage the converter
and cause poor performance.

USE ONLY UNLEADED FUEL.
Do not drive your Mazda with any sign of engine malfunction.
Do not coast with the ignition switched off.
Do not descend steep grades in gear with the ignition switched off.
Do not operate the engine at high idle for more than 2 minutes.
Do not tamper with the emission control system. All inspections and adjustments must be

made by a qualified technician.

Do not push-start or pull-start this vehicle.

NOTE



Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.



While the engine is off, the sound of a valve opening and closing can be heard at the rear
of the vehicle, however this does not indicate an abnormality. The vehicle has a
self-checking device and it operates while the engine is off.

Before Driving

Fuel and Emission

3-26

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Engine Exhaust (Carbon monoxide)

WARNING

Do not drive your vehicle if you smell exhaust gas inside the vehicle:
Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is colorless,
odorless, and poisonous. When inhaled, it can cause loss of consciousness and death. If you
smell exhaust gas inside the vehicle, keep all windows fully open and contact an Authorized
Mazda Dealer immediately.

Do not run the engine when inside an enclosed area:
Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust gas,
which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur.

Open the windows or adjust the heating or cooling system to draw fresh air when idling the
engine:
Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and the
engine running for a long time even in an open area, exhaust gas, which contains poisonous
carbon monoxide, could enter the cabin. Loss of consciousness or even death could occur.

Clear snow from underneath and around your vehicle, particularly the tail pipe, before
starting the engine:
Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust pipe
could be blocked by the snow, allowing exhaust gas to enter the cabin. Because exhaust gas
contains poisonous carbon monoxide, it could cause loss of consciousness or even death to
occupants in the cabin.

Before Driving

Fuel and Emission

3-27

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Fuel-Filler Lid and Cap

WARNING

When removing the fuel-filler cap, loosen
the cap slightly and wait for any hissing to
stop, then remove it:
Fuel spray is dangerous. Fuel can burn skin
and eyes and cause illness if ingested. Fuel
spray is released when there is pressure in
the fuel tank and the fuel-filler cap is
removed too quickly.

Before refueling, stop the engine, and
always keep sparks and flames away from
the filler neck:
Fuel vapor is dangerous. It could be ignited
by sparks or flames causing serious burns
and injuries.
Additionally, use of the incorrect fuel-filler
cap or not using a fuel-filler cap may result
in a fuel leak, which could result in serious
burns or death in an accident.

Do not continue refueling after the fuel
pump nozzle shuts off automatically:
Continuing to add fuel after the fuel pump
nozzle has shut off automatically is
dangerous because overfilling the fuel tank
may cause fuel overflow or leakage. Fuel
overflow and leakage could damage the
vehicle and if the fuel ignites it could cause
a fire and explosion resulting in serious
injury or death.

CAUTION

(U.S.A. and Canada)
Always use only a genuine Mazda fuel-filler
cap or an approved equivalent, available at
an Authorized Mazda Dealer. The wrong
cap can result in a serious malfunction of
the fuel and emission control systems. It
may also cause the check engine light in
the instrument cluster to illuminate.

▼ Fuel-Filler Lid

To open, pull the remote fuel-filler lid
release.
To close, press the fuel-filler lid until it
locks securely.

Remote fuel-filler
lid release

Before Driving

Fuel and Emission

3-28

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Fuel-Filler Cap

To remove the fuel-filler cap, turn it
counterclockwise.
Attach the removed cap to the inner side
of the fuel lid.

To close the fuel-filler cap, turn it
clockwise until a click is heard.

Open

CAUTION

(U.S.A. and Canada)
If the check fuel cap warning light
illuminates, the fuel-filler cap may not be
properly installed. If the warning light
illuminates, park your vehicle safely off the
right-of-way, remove the fuel-filler cap and
reinstall it correctly. After the cap has been
correctly installed, the fuel cap warning
light may continue to illuminate until a
number of driving cycles have been
completed. A drive cycle consists of starting
the engine (after four or more hours with
the engine off) and driving the vehicle on
city and highway roads.
Continuing to drive with the check fuel cap
warning light illuminated could cause the
check engine light to illuminate as well.

Before Driving

Fuel and Emission

3-29

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Steering Wheel

WARNING

Never adjust the steering wheel while the
vehicle is moving:
Adjusting the steering wheel while the
vehicle is moving is dangerous. Moving it
can very easily cause the driver to abruptly
turn to the left or right. This can lead to loss
of control or an accident.

▼ Steering Wheel Adjustment

To change the angle or length of the
steering wheel:
1. Stop the vehicle, and then pull down

the lock release lever under the
steering column.

Lock release lever

2. Tilt the steering wheel and/or adjust

the steering column length to the
desired positions, then push the lever
up to lock the column.

3. Attempt to push the steering wheel up

and down to make sure it's locked
before driving.

▼ Heated Steering Wheel

The grips on the left and right of the
steering wheel can be warmed up.

Heating area

Heated steering
wheel switch

The ignition must be switched ON.

Press the switch to turn on the heated
steering wheel. The heated steering wheel
operates for about 30 minutes and then
turns off automatically.
The indicator light illuminates when the
heater is operating.

To turn off the heated steering wheel
before the 30 minutes has elapsed, press
the switch again.

CAUTION

The following types of persons should be
careful not to touch the steering wheel.
Otherwise, it could cause a
low-temperature burn.

Infants, small children, elderly people,

and physically challenged people

People with delicate skin
People who are excessively fatigued
People who are intoxicated

Before Driving

Steering Wheel

3-30

*Some models.

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Mirrors

Before driving, adjust the inside and
outside mirrors.

▼ Outside Mirrors

WARNING

Be sure to look over your shoulder before
changing lanes:
Changing lanes without taking into
account the actual distance of the vehicle
in the convex mirror is dangerous. You
could have a serious accident. What you
see in the convex mirror is closer than it
appears.

Mirror type

Flat type (driver's side)
Flat surface mirror.
Convex type (front passenger side)
The mirror has single curvature on its
surface.

Power mirror adjustment

The ignition must be switched to ACC or
ON position.

To adjust:
1. Rotate the mirror switch to the left or

right to choose the left or right side
mirror.

2. Press the mirror switch in the

appropriate direction.

Center position

Mirror switch

After adjusting the mirror, lock the control
by rotating the switch in the center
position.

Folding mirror

WARNING

Always return the outside mirrors to the
driving position before you start driving:
Driving with the outside mirrors folded in is
dangerous. Your rear view will be restricted,
and you could have an accident.

Manually fold the outside mirror rearward
until it is flush with the vehicle.

Before Driving

Mirrors

3-32

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Rearview Mirror

WARNING

Do not stack cargo or objects higher than
the seatbacks:
Cargo stacked higher than the seatbacks is
dangerous. It can block your view in the
rearview mirror, which might cause you to
hit another car when changing lanes.

Rearview mirror adjustment

Before driving, adjust the rearview mirror
to center on the scene through the rear
window.

NOTE
For the manual day/night mirror, perform
the adjustment with the day/night lever in
the day position.

Reducing glare from headlights

Manual day/night mirror

Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Night

Day

Day/Night lever

Auto-dimming mirror

The auto-dimming mirror automatically
reduces the glare of headlights from
vehicles at the rear when the ignition is
switched ON.

(With Homelink wireless control
system)
Press the OFF button ( ) to cancel the
automatic dimming function. The
indicator light will turn off.
To reactivate the automatic dimming
function, press the ON button ( ). The
indicator light will illuminate.

Indicator light

OFF button

ON button

Before Driving

Mirrors

3-33

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

(Without Homelink wireless control
system)
Press the ON/OFF button to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto-dimming function,
press the ON/OFF button . The indicator
light will illuminate.

ON/OFF button

Indicator light

NOTE



Do not use glass cleaner or suspend
objects on or around the light sensor.
Otherwise, light sensor sensitivity will
be affected and may not operate
normally.
(With Homelink wireless control
system)

Light sensor

(Without Homelink wireless control
system)

Light sensor



(With Homelink wireless control
system)
For information regarding the 3 buttons
(

) on the auto-dimming

mirror.
Refer to HomeLink Wireless Control
System on page 4-56.



The auto-dimming function is canceled
when the ignition is switched ON and
the shift lever is in reverse (R).

Before Driving

Mirrors

3-34

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Power Windows

The windows can be opened/closed by
operating the power window switches.

WARNING

Make sure the opening is clear before
closing a window:
Closing a power window is dangerous. A
person's hands, head, or even neck could be
caught by the window and result in serious
injury or even death. This warning applies
especially to children.

Never allow children to play with power
window switches:
Power window switches that are not locked
with the power window lock switch would
allow children to operate power windows
unintentionally, which could result in
serious injury if a child's hands, head or
neck becomes caught by the window.

Make sure nothing blocks the window just
before it reaches the fully closed position or
while holding up the power window switch:
Blocking the power window just before it
reaches the fully closed position or while
holding up the power window switch is
dangerous.
In this case, the jam-safe function cannot
prevent the window from closing all the
way. If fingers are caught, serious injuries
could occur.

NOTE
When driving with only one of the rear
windows open, your ears might experience
a resonating sound. However, this does not
indicate a problem. The sound can be
reduced by slightly opening a front
window or by changing the size of the rear
window opening.

Before Driving

Windows

3-35

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Opening/Closing Windows

The window opens while the switch is pressed and it closes while the switch is pulled up
with the ignition switched ON. Do not open or close three or more windows at the same
time.
The front passenger's side and rear windows can be opened/closed when the power window
lock switch on the driver's door is in the unlock position. Keep this switch in the locked
position while children are in the vehicle.

Open

Driver's side

Front passenger's side
window/Rear windows

Left rear
window

Right rear window

Front
passenger's
window

Driver's
window

Open

Locked position

Unlocked position

NOTE



A power window may no longer open/close if you continue to press the switch after fully
opening/closing the power window. If the power window does not open/close, wait a
moment and then operate the switch again.



The passenger windows may be opened or closed using the master control switches on the
driver's door.



The power window can be operated for about 40 seconds after the ignition is switched
from ON to ACC or off with all doors closed. If any door is opened, the power window
will stop operating.
For engine-off operation of the power window, the switch must be held up firmly
throughout window closure because the auto-closing function will be inoperable.

Before Driving

Windows

3-36

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Auto-opening/Closing

To fully open the window automatically,
press the switch completely down, then
release. The window will fully open
automatically.
To fully close the window automatically,
pull the switch completely up, then
release. The window will fully close
automatically.

To stop the window partway, pull or press
the switch in the opposite direction and
then release it.
This function is only equipped on the
driver's side.

NOTE
Power window system initialization
procedure
If the battery was disconnected during
vehicle maintenance, or for other reasons
(such as a switch continues to be operated
after the window is fully open/closed), the
window will not fully open and close
automatically.
The power window auto function will only
resume on a power window that has been
reset.
1. Switch the ignition ON.
2. Make sure that the power window lock

switch located on the driver's door is
not depressed.

3. Press the switch and fully open the

window.

4. Pull up the switch to fully close the

window and continue holding the
switch for about 2 seconds after the
window fully closed.

5. Make sure that the power windows

operate correctly using the door
switches.

▼ Jam-safe Window

If foreign matter is detected between the
window and the window frame while the
window is closing automatically (refer to
Auto-opening/Closing on page 3-37), the
window stops closing and automatically
opens partway.

NOTE



The jam-safe function may operate
under the following conditions:



A strong impact is detected while the
window is closing automatically.



Window is closing automatically in
very low temperatures.



In the event the jam-safe function
activates and the power window cannot
be closed automatically, pull and hold
the switch and the window will close.



The jam-safe window function does not
operate until the system has been reset.

Before Driving

Windows

3-37

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Moonroof

The moonroof can be opened or closed
when operating the overhead tilt/slide
switch at the front seats.

WARNING

Do not let passengers stand up or extend
part of the body through the open
moonroof while the vehicle is moving:
Extending the head, arms, or other parts of
the body through the moonroof is
dangerous. The head or arms could hit
something while the vehicle is moving. This
could cause serious injury or death.

Never allow children to play with the tilt/
slide switch:
The tilt/slide switch would allow children to
operate the moonroof unintentionally,
which could result in serious injury if a
child's hands, head or neck becomes
caught by the moonroof.

Make sure the opening is clear before
closing the moonroof:
A closing moonroof is dangerous. The
hands, head, or even neck of a person,
especially a child, could be caught in it as it
closes, causing serious injury or even death.

CAUTION

Do not sit on or put heavy items on the

area where the moonroof opens and
closes. Otherwise, the moonroof could be
damaged.

Do not open or close the moonroof

forcefully during freezing temperatures
or snowfall. Otherwise, the moonroof
could be damaged.

The sunshade does not tilt. To avoid

damaging the sunshade, do not push it
up.

Do not close the sunshade while the

moonroof is opening. Trying to force the
sunshade closed could damage it.

▼ Tilt/Slide Operation

The moonroof can be opened or closed
electrically only when the ignition is
switched ON.



Before leaving the vehicle or washing
your Mazda, make sure the moonroof is
completely closed so that water does not
get inside the cabin area.



After washing your Mazda or after it
rains, wipe the water off the moonroof
before operating it to avoid water
penetration which could cause rust and
water damage to your headliner.

Tilt/Slide switch

Before Driving

Windows

3-38

*Some models.

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Tilt Operation

The rear of the moonroof can be tilted
open to provide more ventilation.

To fully tilt automatically, momentarily
press the tilt/slide switch.
To stop tilting partway, press the tilt/slide
switch.
To close to the desired position, press the
tilt/slide switch in the forward direction.
When the moonroof is already slid open
and you want to tilt it open, first close the
moonroof and then do a tilt operation.

Close (Tilt down)

Tilt up

Slide Operation

To fully open automatically, momentarily
press the tilt/slide switch in the backward
direction.
To stop sliding partway, press the tilt/slide
switch.
To close to the desired position, press the
tilt/slide switch in the forward direction.
When the moonroof is already tilted open
and you want to slide it open, first close
the moonroof and then do a slide
operation.

Open

NOTE
If the moonroof does not operate normally,
do the following procedure:
1. Switch the ignition ON.
2. Press the tilt switch, to partially tilt

open the rear of the moonroof.

3. Repeat Step 2. The rear of the

moonroof tilts open to the fully open
position, then closes a little.

If the reset procedure is performed while
the moonroof is in the slide position
(partially open) it will close before the
rear tilt opens.

Before Driving

Windows

3-39

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Mazda 3 (2018 year). Instruction - part 7
