9–2

Speci

¿ cations

Identi

¿ cation Numbers

Vehicle Information
Labels

Vehicle Identi

¿ cation Number

(South Africa)

The vehicle identi

¿ cation number legally

identi

¿ es your vehicle. The number is on

a plate attached to the cowl panel located
on the left corner of the instrument panel.
This plate can easily be seen through the
windscreen.

Model Plate

Chassis Number/Vehicle

Identi

¿ cation Number

(Ireland, Russia, U.K.)

Chassis Number
Open the cover shown in the

¿ gure to

check the chassis number.

Vehicle Identi

¿ cation Number

Vehicle Emission Control

Information Label (Thailand)

9–4

Speci

¿ cations

Speci

¿ cations

Speci

¿ cations

Engine

Petrol engine

Item

Speci

¿ cation

SKYACTIV-G 1.3

SKYACTIV-G 1.5

Type

DOHC-16V in-line, 4-cylinder

Bore × Stroke

71 × 82 mm (2.80 × 3.23 in)

74.5 × 85.8 mm (2.93 × 3.38 in)

Displacement

1,299 ml (1,299 cc)

1,496 ml (1,496 cc)

Compression ratio

12.0

12.0/13.0/14.0

Diesel engine

Item

Speci

¿ cation

SKYACTIV-D 1.5

Type

DOHC-16V in-line, 4-cylinder

Bore × Stroke

76 × 82.6 mm (2.99 × 3.25 in)

Displacement

1,499 ml (1,499 cc)

Compression ratio

14.8

9–5

Speci

¿ cations

Speci

¿ cations

Electrical System

Battery

Classi

¿ cation

Speci

¿ cation

SKYACTIV-G 1.3

Q-85

SKYACTIV-G 1.5

N-55 (S)

or Q-85

12V-60Ah/20HR

SKYACTIV-D 1.5

S-95

or Q-85

*1 N-55 (S), Q-85 or S-95 is designed for i-stop system (FOR STOP & START)/i-ELOOP system. Only N-55 (S),

Q-85 or S-95 should be used to ensure correct operation of i-stop system (FOR STOP & START)/i-ELOOP
system. Consult an expert repairer, we recommend an Authorised Mazda Repairer for details.

*2 Not for i-stop system/i-ELOOP system.

Spark-plug

Classi

¿ cation

Speci

¿ cation

SKYACTIV-G 1.3,
SKYACTIV-G 1.5 LP

Mazda Genuine spark plug

P51R-18-110

SKYACTIV-G 1.5 MP

SKYACTIV-G 1.5 HP

Mazda Genuine spark plug

PE5R-18-110 or PE5S-18-110

*1 The alphabetical letters at the end of the engine types are short for the following:

LP: Low-Power

MP: Medium-Power

HP: High-Power

*2 The spark plugs provide the SKYACTIV-G its optimum performance. Consult an expert repairer, we

recommend an Authorised Mazda Repairer for details.

CAUTION

When cleaning the iridium plugs, do not use a wire brush. The

¿ ne particulate coating on

the iridium alloy and platinum tips could be damaged.

9–6

Speci

¿ cations

Speci

¿ cations

Lubricant Quality

Engine oil

Europe

Except Europe

SKYACTIV-G 1.3,
SKYACTIV-G 1.5

Recommended Oils

Oil Quality

Mazda Original Oil Supra 0W-20

API SG/SH/SJ/SL/SM/SN or

ILSAC GF-II/GF-III/GF-IV/GF-V

Mazda Original Oil Ultra 5W-30

Alternative Oil Quality

API SL/SM/SN or

ACEA A3/A5

0W-20

5W-30

SKYACTIV-D 1.5

Recommended Oils

Oil Quality

Mazda Original Oil Supra DPF 0W-30

ACEA C3

0W-30 / 5W-30

Mazda Original Oil Ultra DPF 5W-30

Alternative Oil Quality

ACEA C3

0W-30

5W-30

*1 Refer to the recommended SAE viscosity numbers on page 6-23 .
*2 Mazda Original Oils are specially designed/tested for the respective engine. For optimum performance we

recommend to use Mazda Original Oils at all times.

*3 If you are unable to

¿ nd a Mazda Original Oil, alternative oils meeting the listed speci¿ cation may also be used.

Do not use oils which do not meet the above speci

¿ cation or requirements. Use of

unsuitable oil may lead to engine damage which is not covered by the Mazda Warranty.

Lubricant

Classi

¿ cation

Coolant

FL-22 type

Manual transaxle oil

API Service

GL-4

SAE

75W-80

Automatic transaxle
À uid

Mazda Original Oil ATF-FZ

Brake/Clutch

À uid

SAE J1703 or FMVSS116 DOT-3 or DOT-4

*1 (Except European models)

Use FMVSS116 DOT-4 brake

À uid for vehicles equipped with the SKYACTIV-D 1.5 engine and drum type rear

brakes.

9–7

Speci

¿ cations

Speci

¿ cations

Capacities

(Approximate Quantities)

Item

Capacity

Engine oil

SKYACTIV-G 1.3,
SKYACTIV-G 1.5

With oil

¿ lter replacement

4.2 L (4.4 US qt, 3.7 Imp qt)

Without oil

¿ lter replacement

3.9 L (4.1 US qt, 3.4 Imp qt)

SKYACTIV-D 1.5

With oil

¿ lter replacement

5.1 L (5.4 US qt, 4.5 Imp qt)

Without oil

¿ lter replacement

4.7 L (5.0 US qt, 4.1 Imp qt)

Coolant

SKYACTIV-G 1.3

5.2 L (5.5 US qt, 4.6 Imp qt)

SKYACTIV-G 1.5

Manual
transaxle

Europe

Left-hand drive model

5.4 L (5.7 US qt, 4.8 Imp qt)

Right-hand drive model

5.0 L (5.3 US qt, 4.4 Imp qt)

Russia

5.4 L (5.7 US qt, 4.8 Imp qt)

Israel

5.0 L (5.3 US qt, 4.4 Imp qt)

Except
above

Left-hand drive model

5.0 L (5.3 US qt, 4.4 Imp qt)/

5.4 L (5.7 US qt, 4.8 Imp qt)

Right-
hand
drive
model

With heater

5.0 L (5.3 US qt, 4.4 Imp qt)

Without
heater

4.5 L (4.8 US qt, 4.0 Imp qt)

Automatic
transaxle

Europe

Left-hand drive model

5.6 L (5.9 US qt, 4.9 Imp qt)

Right-hand drive model

5.2 L (5.5 US qt, 4.6 Imp qt)

Russia

5.6 L (5.9 US qt, 4.9 Imp qt)

Israel, Saudi Arabia

5.2 L (5.5 US qt, 4.6 Imp qt)

Except
above

Left-hand drive model

5.2 L (5.5 US qt, 4.6 Imp qt)/

5.6 L (5.9 US qt, 4.9 Imp qt)

Right-
hand
drive
model

With heater

5.2 L (5.5 US qt, 4.6 Imp qt)

Without
heater

4.7 L (5.0 US qt, 4.1 Imp qt)

SKYACTIV-D 1.5

For engine

Europe

6.6 L (7.0 US qt, 5.8 Imp qt)

Except
above

Left-hand drive model

6.7 L (7.1 US qt, 5.9 Imp qt)

Right-hand drive model

6.8 L (7.2 US qt, 6.0 Imp qt)

For water-cooled charge air cooler

2.0 L (2.1 US qt, 1.8 Imp qt)

Manual
transaxle
oil

SKYACTIV-G 1.5

1.59 L (1.68 US qt, 1.40 Imp qt)

SKYACTIV-D 1.5

1.64 L (1.73 US qt, 1.44 Imp qt)

Automatic
transaxle
À uid

SKYACTIV-G 1.3, SKYACTIV-G 1.5

7.2 L (7.6 US qt, 6.3 Imp qt)

SKYACTIV-D 1.5

7.8 L (8.2 US qt, 6.9 Imp qt)

Fuel tank

44.0 L (11.6 US gal, 9.68 Imp gal)

Check oil and

À uid levels with dipsticks or reservoir gauges.

*1 The engine coolant amount varies depending on the speci

¿ cation.

9–8

Speci

¿ cations

Speci

¿ cations

Dimensions

Saloon

Item

Vehicle speci

¿ cation

Overall length

4,320 mm (170.1 in)

Overall width

1,695 mm (66.7 in)

Overall height

1,470 mm (57.9 in)

Front tread

1,495 mm (58.9 in)

Rear tread

1,485 mm (58.5 in)

Wheelbase

2,570 mm (101.2 in)

Hatchback

Item

Vehicle speci

¿ cation

Overall length

4,060 mm (159.8 in)

Overall width

1,695 mm (66.7 in)

Overall height

Except Colombia

1,495 mm (58.9 in)

Colombia

1,505 mm (59.3 in)

Front tread

Except Colombia

1,495 mm (58.9 in)

Colombia

1,490 mm (58.7 in)

Rear tread

1,485 mm (58.5 in)

Wheelbase

2,570 mm (101.2 in)

9–9

Speci

¿ cations

Speci

¿ cations

*Some models.

Light Bulbs

Exterior light

Light bulb

Category

Wattage

UNECE

(SAE)

Headlights

Halogen bulb headlights

High/Low
beam

60/55

H4 (H4)

LED headlights

High beam

LED

— (—)

Low beam

LED

— (—)

Running lights

With halogen bulb headlights

21/5

W21/5W (7443)

With LED headlights

LED

— (—)

Position lights

With halogen bulb headlights

With running
lights

21/5

W21/5W (7443)

Without
running lights

W5W (—)

With LED headlights

LED

— (—)

Front direction indicator lights

WY21W (7443NA)

Front fog lights

LED

— (—)

Side direction indicator lights

LED

— (—)

High-mount brake light

LED

— (—)

Rear direction indicator lights

WY21W (7443NA)

Brake lights/Tail lights

Bulb type

21/5

W21/5W (7443)

LED type

LED

— (—)

Reverse lights

W16W (921)

Rear fog light

W21W (7440)

Number plate lights

W5W (—)

     *1   UNECE stands for United Nations Economic Commission for Europe.
   *2   LED is the abbreviation for Light Emitting Diode.
*3   Double-

¿ lament light bulb, however, only 21 W ¿ lament bulb is used in the running lights.

*4 Double-

¿ lament light bulb, however, only 5 W ¿ lament bulb is used in the position lights.

Interior light

Light bulb

Category

Wattage

UNECE

Boot light (Saloon)

—

Luggage compartment light (Hatchback)

—

Overhead light (Front)

With map lights

—

Without map lights

—

Overhead light (Rear)

—

*1 UNECE stands for United Nations Economic Commission for Europe.

9–10

Speci

¿ cations

Speci

¿ cations

Tyres

Sample tyre mark and its meaning

Nominal section width
Nominal aspect ratio in %
Construction code

Mud and snow

Speed symbol

Load index (not on ZR tyres)

Nominal rim diameter in inches

Tyre mark information

Choose the proper tyres for your vehicle using the following tyre mark information.

Speed symbol

Maximum permissible speed

Up to 160 km/h (99 mph)

Up to 170 km/h (105 mph)

Up to 180 km/h (111 mph)

Up to 190 km/h (118 mph)

Up to 200 km/h (124 mph)

Up to 210 km/h (130 mph)

Up to 240 km/h (149 mph)

Up to 270 km/h (167 mph)

Up to 300 km/h (186 mph)

Over 240 km/h (149 mph)

Tyre and in

À ation pressure

NOTE

The tyres have been optimally matched with the chassis of your vehicle.
When replacing tyres, Mazda recommends that you replace tyres of the same type
originally

¿ tted to your vehicle. For details, contact an expert repairer, we recommend an

Authorised Mazda Repairer.

Check the tyre pressure label for tyre size and in

À ation pressure (page 6-44 ).

  After adjusting the tyre pressure, initialization of the tyre pressure monitoring system is
necessary to make the system operates normally.
  Refer to Tyre Pressure Monitoring System Initialization on page 4-192 .

9–11

Speci

¿ cations

Speci

¿ cations

*Some models.

Standard tyre

Tyre size

À ation pressure

Up to 3 persons

—Full load

185/65R15 88T

Type A

Front

230 kPa (2.3 bar, 33 psi)

260 kPa (2.6 bar, 38 psi)

Rear

210 kPa (2.1 bar, 30 psi)

320 kPa (3.2 bar, 46 psi)

Type B

Front

250 kPa (2.5 bar, 36 psi)

270 kPa (2.7 bar, 39 psi)

Rear

230 kPa (2.3 bar, 33 psi)

320 kPa (3.2 bar, 46 psi)

Type C

Front

260 kPa (2.6 bar, 38 psi)

270 kPa (2.7 bar, 39 psi)

Rear

230 kPa (2.3 bar, 33 psi)

320 kPa (3.2 bar, 46 psi)

Type D

Front

240 kPa (2.4 bar, 35 psi)

260 kPa (2.6 bar, 38 psi)

Rear

210 kPa (2.1 bar, 30 psi)

320 kPa (3.2 bar, 46 psi)

185/60R16 86H

Type A

Front

250 kPa (2.5 bar, 36 psi)

260 kPa (2.6 bar, 38 psi)

Rear

230 kPa (2.3 bar, 33 psi)

330 kPa (3.3 bar, 48 psi)

Type B

Front

250 kPa (2.5 bar, 36 psi)

270 kPa (2.7 bar, 39 psi)

Rear

230 kPa (2.3 bar, 33 psi)

330 kPa (3.3 bar, 48 psi)

Type C

Front

260 kPa (2.6 bar, 38 psi)

270 kPa (2.7 bar, 39 psi)

Rear

230 kPa (2.3 bar, 33 psi)

330 kPa (3.3 bar, 48 psi)

1 person's weight: About 75 kg

*1 Check the tyre in

À ation pressure label (driver's door frame ) for the correct tyre inÀ ation pressure. Refer to Tyre

Pressure Label on page 9-3 .

Temporary spare tyre

Tyre size

À ation pressure

T125/90R15 96M

420 kPa (60 psi)

T125/70D15 95M

420 kPa (60 psi)

165/65R14 79M

250 kPa (2.5 bar, 36 psi)

9–12

Speci

¿ cations

Speci

¿ cations

Winter tyre

Tyre size

À ation pressure

Up to 3 persons

—Full load

185/65R15

Front

230 kPa (2.3 bar, 33 psi)

240 kPa (2.4 bar, 35 psi)

260 kPa (2.6 bar, 38 psi)

Rear

230 kPa (2.3 bar, 33 psi)

320 kPa (3.2 bar, 46 psi)

185/60R16

Front

250 kPa (2.5 bar, 36 psi)

260 kPa (2.6 bar, 38 psi)

270 kPa (2.7 bar, 39 psi)

Rear

250 kPa (2.5 bar, 36 psi)

320 kPa (3.2 bar, 46 psi)

350 kPa (3.5 bar, 50 psi)

1 person's weight: About 75 kg

   *1   Load index and Speed Symbol: 88Q/88S/88T
   *2   Load index and Speed Symbol: 86Q/86S/86T/86H
*3   SKYACTIV-G  1.5
*4   SKYACTIV-D  1.5
   *5   Load index and Speed Symbol: 86Q/86S/86T
   *6   Load index and Speed Symbol: 86H

Wheel nut tightening torque

When installing a tyre, tighten the wheel nut to the following torque.
108—147 N·m (12—14 kgf·m, 80—108 ft·lbf)

Fuses

Refer to Fuses on page 6-61 .

Brakes

If you require information regarding the wear limit speci

¿ cation for the brake disc plates

and drums, or the measurement method, please contact an expert repairer, we recommend an
Authorised Mazda Repairer. The information is made freely available.

9–13

Speci

¿ cations

Personalisation Features

The  following  personalisation  features  can  be  set  or  changed  by  the  customer  or  an
Authorised Mazda Repairer. Consult an Authorised Mazda Repairer for details.
  Additionally, some of the personalisation features can be changed by the customer
depending on the feature.
  Personalisation features and settings which can be changed differ depending on the market
and speci

¿ cation.

Settings Change Method

         Settings can be changed by operating the centre display screen.
  A: Refer to Settings on page 5-137 .
  B: Refer to Fuel Economy Monitor on page 4-93 .
  C: Refer to Active Driving Display on page 4-35 .

       Settings can be changed by operating the vehicle switches.
  D: Refer to Auto Lock/Unlock Function on page 3-17 .
  E: Refer to Transmitter on page 3-4 .
  F: Refer to Locking, Unlocking with Request Switch (With the advanced keyless function)

on page 3-14 .

Settings can be changed by an Authorised Mazda Repairer.

Item

Feature

Factory Setting

Available

Settings

Settings Change

Method

Safety

Smart City Brake
Support Forward
(SCBS F)
(page   4-155 )
Smart  City  Brake
Support Reverse
(SCBS R)
(page   4-161 )

Operational/non-operational

On/Off

—

Smart Brake Support
(SBS)
(page 4-167 )

The system can be changed
so that Smart Brake Support
(SBS) does not operate.

On/Off

—

The distance at which the
collision warning activates
can be changed.

Near

Near/Far

—

The volume of the collision
warning can be changed.

High

High/Low/Off

—

Mazda 2 (2017 year). Instruction - part 43
