Mazda 2 (2017 year). Instruction - part 2

2–6

Essential Safety Equipment

Seats

*Some models.

           Seat  Warmer

*



            The  front  seats  are  electrically  heated.  The
ignition must be switched ON.
  Press the seat warmer switch while the
ignition is switched ON to operate the seat
warmer. The indicator lights turn on to
indicate that the seat warmer is operating.
The mode changes as follows each time
the seat warmer switch is pressed.



OFF

High

Mid

Low



 WARNING

 Be careful when using the seat
warmer:
 The heat from the seat warmer may be
too hot for some people, as indicated
as follows, and could cause a low-
temperature burn.





  Infants, small children, elderly

people, and physically challenged
people



  People with delicate skin



  People who are excessively fatigued



  People who are intoxicated



  People who have taken sleep-

inducing medicine such as sleeping
pills or cold medicine


 Do not use the seat warmer with
anything having high moisture-
retention ability such as a blanket or
cushion on the seat:
 The seat may be heated excessively and
cause a low-temperature burn.

 Do not use the seat warmer even when
taking a short nap in the vehicle:
 The seat may be heated excessively and
cause a low-temperature burn.

 Do not place heavy objects with sharp
projections on the seat, or insert
needles or pins into it:
 This could cause the seat to become
excessively heated and result in injury
from a minor burn.

2–7

Essential Safety Equipment

Seats

 CAUTION

 Do not use organic solvents to clean the
seat. It may damage the seat surface and
the heater.

 NOTE



  If the ignition is switched off while

the seat warmer is operating (High,
Mid or Low) and then switched
ON again, the seat warmer will
automatically operate at the
temperature set before switching off
the ignition.



  Use the seat warmer when the engine

is running. Leaving the seat warmer
on for long periods with the engine
not running could cause the battery
power to be depleted.



  The temperature of the seat warmer

cannot be adjusted beyond High, Mid
and Low because the seat warmer is
controlled by a thermostat.

 Rear  Seat

                  Split/One-piece Folding the

Seatback

    By lowering the rear seatback(s) the
luggage compartment space can be
expanded.

2–8

Essential Safety Equipment

Seats

 WARNING

 Do not drive the vehicle with occupants
on folded down seatback(s) or in the
luggage compartment.
 Putting occupants in the luggage
compartment is dangerous because seat
belts cannot be fastened which could
lead to serious injury or death during
sudden braking or a collision.

 Do not allow children to play inside the
vehicle with the seatback(s) lowered.
 Allowing children to play in the vehicle
with the seatback(s) folded down is
dangerous. If a child enters the luggage
compartment and the seatback(s) were
raised back up, the child may become
trapped in the luggage compartment
which could lead to an accident.

 Tightly secure cargo in the luggage
compartment when it is transported
with the seatback(s) folded down.
 Driving without tightly securing cargo
and luggage is dangerous as it could
move and become an obstruction to
driving during emergency braking or
a collision resulting in an unexpected
accident.

 When transporting cargo, do not allow
the cargo to exceed the height of the
seatback(s).
 Transporting cargo stacked higher
than the seatback(s) is dangerous
as visibility to the rear and sides of
the vehicle is reduced which could
interfere with driving operations and
lead to an accident.

  Lowering  the  seatback(s)

 CAUTION



   (Hatchback)



  When folding the seatback forward,

always support the seatback with
your hand. If it is not supported by a
hand,

¿ ngers or the hand pressing the

push knob could be injured.



  Check the position of a front seat

before folding a rear seatback.



  Depending on the position of a front

seat, it may not be possible to fold
a rear seatback all the way down
because it may hit the seatback of
the front seat which could scratch or
damage the front seat or its pocket.
Remove the head restraint on the rear
outboard seat if necessary.

2–9

Essential Safety Equipment

Seats

   (Saloon)
   1.   If your vehicle is equipped with the

head restraint, lower it all the way
down.



Refer to Head Restraints on page
 2-11 .

   2.    (Split-folding type seat)


Open the boot lid and pull the lever of
the seatback you want to fold down.



 (One-piece folding type seat)



Open the boot lid and pull the lever of
the seatback.



*1: With split-folding

type seat only

*1



   3.   Open a rear door and fold the rear seat

forward.





   (Hatchback)



   1.   Lower the head restraint all the way

down.



Refer to Head Restraints on page
 2-11 .

   2.   Press the push knob to fold down the

seatback.





   3.   Secure the rear seat belt in the belt clip.



Belt clip



2–10

Essential Safety Equipment

Seats

    To return the seatback to its upright
position:

 WARNING

 When returning a seatback to its
upright position, make sure the 3-point
seat belt is not caught in the seatback
and the 3-point seat belt is not twisted.
 If the seat belt is used while it is twisted
and caught in the seatback, the seat
belt cannot function at its full capacity,
which could cause serious injury or
death.

 When returning a seatback to its
upright position, make sure that it is
¿ rmly locked and the red indication is
not visible (Hatchback).
 If the red indication is visible behind
the push knob, it means the seatback
is not locked. If the vehicle is driven
without the seatback locked, it could
fold down suddenly and cause an
accident.


Locked position

Unlocked position

Red indication



   (Saloon)



   1.   Make sure that the seat belt passes

through the seat belt guide correctly
and it is not twisted, then raise the
seatback while preventing the seat belt
from being caught in the seatback.



Seat belt guide



   2.   Press the seatback rearward and lock it

in place. After returning the seatback
to its upright position, make sure it is
securely locked.



   (Hatchback)



   1.   Verify that the seat belt is secured in

the belt clip.



Belt clip



   2.   Lift  the  seatback  upright.
   3.   Press the seatback rearward and lock it

in place. After returning the seatback
to its upright position, make sure it is
securely locked.

2–11

Essential Safety Equipment

Seats

   4.   Make sure that the seat belt is neither

stuck in the rear seat nor twisted, then
remove the seat belt from the belt clip.



 Head  Restraints

              Your  vehicle  is  equipped  with  head
restraints on all outboard seats and the
rear centre seat. The head restraints are
intended to help protect you and the
passengers from neck injury.

 WARNING

 Always drive with the head restraints
installed when seats are being used and
make sure they are properly adjusted.
In addition, always raise the head
restraints on all rear seat when they are
being used:
 Driving with the head restraints
adjusted too low or removed is
dangerous. With no support behind
your head, your neck could be seriously
injured in a collision.

          Height Adjustment

    Adjust the head restraint so that the centre
is even with the top of the passenger's ears.






  To raise a head restraint, pull it up to the
desired position.
  To lower the head restraint, press the stop-
catch release, then push the head restraint
down.

2–12

Essential Safety Equipment

Seats

  Front  outboard  seat







  Rear  outboard  seat







  Rear  centre  seat







           Removal/Installation

    To remove the head restraint, pull it up
while pressing the stop-catch.
  To install the head restraint, insert the legs
into the holes while pressing the stop-
catch.

 WARNING

 Always drive with the head restraints
installed when seats are being used and
make sure they are properly installed:
 Driving with the head restraints not
installed is dangerous. With no support
behind your head, your neck could be
seriously injured in a collision.

 After installing a head restraint, try
lifting it to make sure that it does not
pull out:
 Driving with an unsecured head
restraint is dangerous as the
effectiveness of the head restraint will
be compromised which could cause it to
unexpectedly detach from the seat.

2–13

Essential Safety Equipment

Seats

 CAUTION



  When installing a head restraint,

make sure that it is installed
correctly with the front of the head
restraint facing forward. If the head
restraint is installed incorrectly, it
could detach from the seat during a
collision and result in injury.



  The head restraints on each of the

front and rear seats are specialized
to each seat. Do not switch around
the head restraint positions. If a head
restraint is not installed to its correct
seat position, the effectiveness of the
head restraint during a collision will
be compromised which could cause
injury.

2–14

Essential Safety Equipment

Seat Belt Systems

      Seat  Belt  Precautions

            Seat belts help to decrease the possibility of severe injury during accidents and sudden
stops. Mazda recommends that the driver and all passengers always wear seat belts.
  All the seats have lap/shoulder belts. These belts also have retractors with inertia locks that
keep them out of the way when not in use. The locks allow the belts to remain comfortable
on users, but they will lock in position during a collision.

 WARNING

 Always wear your seat belt and make sure all occupants are properly restrained:
 Not wearing a seat belt is extremely dangerous. During a collision, occupants not
wearing seat belts could hit someone or things inside the vehicle or even be thrown out
of the vehicle. They could be seriously injured or even killed. In the same collision,
occupants wearing seat belts would be much safer.

 Do not wear twisted seat belts:
 Twisted seat belts are dangerous. In a collision, the full width of the belt is not available
to absorb the impact. This puts more force on the bones beneath the belt, which could
cause serious injury or death. So, if your seat belt is twisted, you must straighten the
seat belt to remove any twists and to allow the full width of the belt to be used.

 Never use one seat belt on more than one person at a time:
 Using one seat belt for more than one person at a time is dangerous. A seat belt used
in this way cannot spread the impact forces properly and the two passengers could
be crushed together and seriously injured or even killed. Never use one belt for more
than one person at a time and always operate the vehicle with each occupant properly
restrained.

 Do not operate a vehicle with a damaged seat belt:
 Using a damaged seat belt is dangerous. An accident could damage the belt webbing
of the seat belt in use. A damaged seat belt cannot provide adequate protection in a
collision. Have an expert repairer, we recommend an Authorised Mazda Repairer
inspect all seat belt systems in use during an accident before they are used again.

 Have your seat belts changed immediately if the pretensioner or load limiter has been
expended:
 Always have an expert repairer, we recommend an Authorised Mazda Repairer
immediately inspect the seat belt pretensioners and air bags after any collision. Like the
air bags, the seat belt pretensioners and load limiters will only function once and must
be replaced after any collision that caused them to deploy. If the seat belt pretensioners
and load limiters are not replaced, the risk of injury in a collision will increase.



2–15

Essential Safety Equipment

Seat Belt Systems

 WARNING

 Positioning the Shoulder Portion of the Seat Belt:
 Improper positioning of the shoulder portion of the seat belt is dangerous. Always make
sure the shoulder portion of the seat belt is positioned across your shoulder and near
your neck, but never under your arm, on your neck, or on your upper arm.

 Positioning the Lap Portion of the Seat Belt:
 The lap portion of the seat belt worn too high is dangerous. In a collision, this would
concentrate the impact force directly on the abdominal area, causing serious injury.
Wear the lap portion of the belt snugly and as low as possible.

 Instructions for Use of Seat Belt Assemblies:
 Seatbelts are designed to bear upon the bony structure of the body, and should be worn
low across the front of the pelvis or the pelvis, chest and shoulders, as applicable;
wearing the lap section of the belt across the abdominal area must be avoided.
 Seatbelts should be adjusted as

¿ rmly as possible, consistent with comfort, to provide

the protection for which they have been designed. A slack belt will greatly reduce the
protection afforded to the wearer.
 Care should be taken to avoid contamination of the webbing with polishes, oils and
chemicals, and particularly battery acid. Cleaning may safely be carried out using mild
soap and water. The belt should be replaced if webbing becomes frayed, contaminated
or damaged.
 It is essential to replace the entire assembly after it has been worn in a severe impact
even if damage to the assembly is not obvious.
 Belts should not be worn with straps twisted.
 Each belt assembly must only be used by one occupant; it is dangerous to put a belt
around a child being carried on the occupant's lap.
 No  modi

¿ cations or additions should be made by the user which will either prevent

the seat belt adjusting devices from operating to remove slack, or prevent the seat belt
assembly from being adjusted to remove slack.

2–16

Essential Safety Equipment

Seat Belt Systems

 CAUTION

 Belt retraction may become dif

¿ cult if the belts and rings are soiled, so try to keep them

clean. For more details about cleaning the seat belts, refer to "Seat Belt Maintenance"
(page   6-73 ).


Ring



          Pregnant Women and Persons with Serious Medical Conditions

            Pregnant  women  should  always  wear  seat  belts.  Ask  your  doctor  for  speci

¿ c

recommendations.
  The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS.
  The shoulder belt should be worn across your shoulder properly, but never across the
stomach area.
  Persons with serious medical conditions also should wear seat belts. Check with your doctor
for any special instructions regarding speci

¿ c medical conditions.





           Emergency Locking Mode

            When the seat belt is fastened, it will always be in the emergency locking mode.
  In the emergency locking mode, the belt remains comfortable on the occupant and the
retractor will lock in position during a collision.
  If the belt is locked and cannot be pulled out, retract the belt once, and then try pulling it out
slowly. If this fails, pull the belt strongly one time and loosen, then pull it out again slowly.

2–17

Essential Safety Equipment

Seat Belt Systems

 Seat  Belt

                    Fastening the Seat Belt



Seat belt
buckle

Seat belt tongue



  Position the lap belt as low as possible,
not on the abdominal area, then adjust the
shoulder belt so that it

¿ ts snugly against

your body.



Keep low on
hip bone

Too high

Take up slack



           Unfastening the Seat Belt

    Depress the button on the seat belt buckle.
If the belt does not fully retract, pull it out
and check for kinks or twists. Then make
sure it remains untwisted as it retracts.



Button



 NOTE

 If a belt does not fully retract, inspect
it for kinks and twists. If it is still not
retracting properly, have it inspected at
an expert repairer, we recommend an
Authorised Mazda Repairer.

           Front Shoulder Belt Adjuster



To raise

To lower



  Make sure the adjuster is locked.

2–18

Essential Safety Equipment

Seat Belt Systems

*Some models.

 Seat  Belt  Warning
Systems

    If it detects that the occupant seat belt
is unfastened, the warning light or beep
alerts the occupant.
  Refer to Taking Action on page  7-43 .
  Refer to Seat Belt Warning Beep on page
 7-50 .


  Seat belt indicator light (rear seat)
(green)

*







  The light turns on when the ignition
is switched ON and a rear seat belt is
fastened, and then it turns off after about
30 seconds.

 Seat Belt Pretensioner
and Load Limiting
Systems

    For optimum protection, the front seat
belts and rear outboard seat belts

*

   are

equipped with pretensioner and load
limiting systems. For both these systems to
work properly you must wear the seat belt
properly.

   Pretensioners:
  When a collision is detected, the
pretensioners deploy simultaneously with
the air bags.
  For deployment details, refer to the SRS
Air Bag Deployment Criteria (page
 2-56 ).
  The seat belt retractors remove slack
quickly as the air bags are expanding.
Any time the air bags and seat belt
pretensioners have

¿ red they must be

replaced.
  A system malfunction or operation
conditions are indicated by a warning.
  Refer to Warning/Indicator Lights on page
 4-38 .
  Refer to Air Bag/Seat Belt Pretensioner
System Warning Beep on page  7-50 .
   (With front passenger air bag
deactivation switch)
  In addition, the pretensioner system for
the front passenger, like the front and side
passenger air bag, is designed to only
deploy when the front passenger air bag
deactivation switch is turned to the ON
position.
  For details, refer to front passenger air bag
deactivation switch (page  2-47 ).


2–19

Essential Safety Equipment

Seat Belt Systems

   Load limiter:
  The load limiting system releases belt
webbing in a controlled manner to reduce
belt force on the occupant's chest. While
the most severe load on a seat belt occurs
in frontal collisions, the load limiter has
an automatic mechanical function and
can activate in any accident mode with
suf

¿ cient occupant movement.

  Even if the pretensioners have not

¿ red,

the load limiting function must be checked
by an expert repairer, we recommend an
Authorised Mazda Repairer.

 WARNING

 Wear seat belts only as recommended
in this owner's manual:
 Incorrect positioning of the seat belts is
dangerous. Without proper positioning,
the pretensioner and load limiting
systems cannot provide adequate
protection in an accident and this
could result in serious injury. For more
details about wearing seat belts, refer
to "Fastening the seat belts" (page
 2-17 ).

 Have your seat belts changed
immediately if the pretensioner or load
limiter has been expended:
 Always have an expert repairer, we
recommend an Authorised Mazda
Repairer immediately inspect the
seat belt pretensioners and air bags
after any collision. Like the air bags,
the seat belt pretensioners and load
limiters will only function once and
must be replaced after any collision
that caused them to deploy. If the seat
belt pretensioners and load limiters
are not replaced, the risk of injury in a
collision will increase.



 WARNING

 Do not modify the components or
wiring, or use electronic testing devices
on the pretensioner system:
 Modifying the components or wiring
of the pretensioner system, including
the use of electronic testing devices
is dangerous. You could accidentally
activate it or make it inoperable which
would prevent it from activating in an
accident. The occupants or repairers
could be seriously injured.

 Properly dispose of the pretensioner
system:
 Improper disposal of the pretensioner
system or a vehicle with non-
deactivated pretensioners is dangerous.
Unless all safety procedures are
followed, injury could result. Have
an expert repairer, we recommend an
Authorised Mazda Repairer safely
dispose of the pretensioner system or
scrap a pretensioner system equipped
vehicle.

2–20

Essential Safety Equipment

Seat Belt Systems

 NOTE



  The pretensioner system may not

operate depending on the type of
the collision. For details, refer to the
SRS Air Bag Deployment Criteria
(page   2-56 ).



  Some smoke (non-toxic gas) will

be released when the air bags and
pretensioners deploy. This does not
indicate a

¿ re. This gas normally has

no effect on occupants, however,
those with sensitive skin may
experience light skin irritation. If
residue from the deployment of the
air bags or the pretensioner system
gets on the skin or in the eyes, wash
it off as soon as possible.

2–21

Essential Safety Equipment

Child Restraint

      Child-Restraint  Precautions

            Mazda strongly urges the use of child-restraint systems for children small enough to use
them.
  Mazda recommends use of a Mazda genuine child-restraint system or one that complies with
the   UNECE

*1

  44 regulation. If you would like to purchase a Mazda genuine child-restraint

system, please contact an Authorised Mazda Dealer.
  Check your local and state or provincial laws for speci

¿ c requirements regarding the safety

of children riding in your vehicle.



   *1  UNECE stands for United Nations Economic Commission for Europe.




  Whatever child-restraint system you consider, please pick the appropriate one for the age
and size of the child, obey the law and follow the instructions that come with the individual
child-restraint system.

  A child who has outgrown child-restraint systems should sit in the rear and use seat belts.

  The child-restraint system should be installed on the rear seat.
  Statistics  con

¿ rm that the rear seat is the best place for all children up to 12 years of age-the

more so with a supplementary restraint system (air bags).

  A rear-facing child-restraint system should  NEVER  be used in the front passenger seat with
the air bag system activated. The front passenger's seat is also the least preferred seat for
other child-restraint systems.

  For some models, we have provided a deactivation switch that will disable front passenger
air bag in

À ation. Do not switch off the front passenger air bag without reading the “Front

Passenger Air Bag Deactivation Switch” (page  2-47 ).
