ON-BOARD DIAGNOSTIC 08-02–51 08-02 Diagnostic procedure STEP INSPECTION ACTION 1 INSPECT SEAT TRACK POSITION SENSOR • Using the M-MDS, verify the following PID/ DATA monitor. • Is the seat track position sensor circuit normal? Yes [Present malfunction diagnosis] • Replace the SAS control module. (See 08-10-10 SAS CONTROL MODULE REMOVAL/ [Past malfunction diagnosis] • DTC troubleshooting completed. No Go to the next step. 2 INSPECT WIRING HARNESS BETWEEN Warning components improperly can • Turn the ignition switch to the LOCK position. • Disconnect the negative battery cable and wait for 1 min or more. • Remove the column cover. (See 09-17-8 COLUMN COVER REMOVAL/ • Disconnect the clock spring connector. • Remove the glove compartment.(See 09-17- 8 GLOVE COMPARTMENT REMOVAL/ • Disconnect the passenger-side air bag module connector. • Disconnect the driver and passenger-side seat connectors. • Remove the C-pillar trim. (See 09-17-17 C- PILLAR TRIM REMOVAL/INSTALLATION.) • Remove the D-pillar trim. (See 09-17-18 D- PILLAR TRIM REMOVAL/INSTALLATION.) • Disconnect the driver and passenger-side curtain air bag module connector. • Remove the B-pillar lower trim. (See 09-17- 16 B-PILLAR LOWER TRIM REMOVAL/ • Disconnect the driver and passenger-side pre-tensioner seat belt connectors. • Remove the console. (See 09-17-13 CONSOLE REMOVAL/INSTALLATION.) • Disconnect the SAS control module connector. • Disconnect the seat track position sensor connector • Inspect the wiring harness between SAS control module terminal and seat track — 2X— A • Is the wiring harness normal? Yes Replace the seat track position sensor, then go to the next No Replace wiring harness, then go to the next step. 1871-1U-06B(08-02).fm 51 ページ 2006年3月15日 水曜日 午前11時33分 |
