MANUAL TRANSAXLE
J–3
J
TRANSAXLE OIL INSPECTION
A6E511227001W01
1. Park the vehicle on level ground.
2. Remove the oil level plug and washer.
3. Verify that the oil is near the brim of the plug port.
• If the oil level is lower than the low level, add
the specified amount and type of oil through
the oil level plug hole.
Specified oil grade
API Service GL-4 or GL-5
Specified oil viscosity
All-season: SAE 75W-90
Above 10
°C {50 °F}: SAE 80W-90
4. Install a new washer and the oil level plug.
Tightening torque
40—58 N·m {4.0—6.0 kgf·m, 29—43 ft·lbf}
End Of Sie
TRANSAXLE OIL REPLACEMENT
A6E511227001W02
1. Remove the drain plug with the washer.
2. Drain the oil into a suitable container.
3. Install a new washer and the drain plug.
Tightening torque
40—58 N·m {4.0—6.0 kgf·m, 29—43 ft·lbf}
4. Remove the oil level plug with washer and add
the specified amount and type of oil through the
oil level plug hole until the level reaches the
bottom of the oil level plug hole.
Specified oil viscosity
All-season: SAE 75W-90
Above 10
°C {50 °F}: SAE 80W-90
Capacity (approximate quantity)
2.87 L {3.03 US qt, 2.53 lmp qt}
5. Install a new washer and the oil level plug.
Tightening torque
40—58 N·m {4.0—6.0 kgf·m, 29—43 ft·lbf}
End Of Sie
MANUAL TRANSAXLE
A6E5112W007
A6E5112W008
