T–72

AUDIO AND NAVIGATION SYSTEM

Map Screen Selection
Current position map

•

The location of the vehicle and surrounding area are shown.

•

By pressing the [POS] button, the display switches to guide mode. (Only while in route guidance.)

.

Scroll map mode

•

The scroll map is displayed when operating the joystick on the current position map.

•

This map can be scrolled with the crosshair cursor.

•

By moving the crosshair cursor to a road and pressing [ENTER] button, the road name is displayed on the
screen.

.

Guide mode

•

Displays an enlarged view of the road using an arrow to indicate destination, and also displays route and
destination guidance information. (While in route guidance)

•

By pressing the [POS] button, the display switches to the current position map.

.

A6E8126T063

1

Map orientation

2

Map scale

3

Clock

4

GPS reception indicator

•

Lights up when receiving signals from 3 or more
satellites.

5

Vehicle position

A6E8126T066

1

Crosshair cursor

A6E8126T064

1

Distance to the next turn

2

Distance to the turn after the next turn

3

Arrow guidance for the next turn

4

Distance to the next turn

5

Destination direction

6

Destination distance

AUDIO AND NAVIGATION SYSTEM

T–73

T

T

Intersection zoom map

•

An enlarged map is displayed when approaching a roundabout or intersection. (While in route guidance.)
Activated by selecting Zoom (On) in setup mode.

.

Pop Up Menu

•

Pop up menu appears when pressing [ENTER] button.

•

The following items are displayed on the pop-up menu. The actual displayed items vary according to the
selected map, guidance, and other factors.

Note

•

Pop up menu is not available on intersection zoom maps.

•

Pop up menu cannot be displayed when the intersection zoom map is displayed.

.

A6E8126T065

1

Distance to the next turn

2

Distance to the turn after the next turn

3

Current road name

A6E8126T079

No.

Contents

Description

1

Detour

Displays route change options. (See

T–76 Detour function

.)

2

Route Preview

Displays complete route preview.

3

Maneuver List

Displays a route list.

4

Marked Point

Registers a point indicated by the crosshair cursor.

5

North up/Head up

Selects either north up or head up map display direction.

6

Stop Calc

Cancels route search.

7

Reroute

Searches for another route to return to the original route when the vehicle has moved
away from it. (Appears only when the auto reroute function is inactivated. See

T–76 Setup

Function

.)

8

Calc Method

Changes route search settings. (See

T–75 Whole route search function

.)

9

Volume

Adjusts volume of voice guidance.

10

Guidance Off

Selects/cancels voice guidance.

11

Destination

Registers a point indicated by the crosshair cursor as a destination.

12

Nearest POI

Searches for POI’s close to current location of the vehicle.

T–74

AUDIO AND NAVIGATION SYSTEM

Destination Setting Function
Outline

•

The following instructions explain how destinations can be chosen and set.

Note

•

A destination can be set to where the crosshair cursor indicates by selecting the Destination option of the
scroll map mode pop-menu.

.

*

: Memory stores up to 10 cities visited recently, and city names can be selected.

A6E8126T069

No.

Contents

1

Changes area set from the previous destination.

2

Sets destination by selecting city name*, inputting street name and selecting house number.

3

Sets destination by inputting city name*, inputting street name and selecting house number.

4

Sets destination by inputting postal code and street name, and selecting house number.

5

Sets intersection as destination by inputting main street name

→

 cross street names.

6

Sets intersection as destination by inputting city name

→

 main street name

→

 cross street names.

7

Sets destination by selecting POI category, inputting city name and selecting POI.

8

Sets destination by selecting POI category, inputting target name and selecting POI.

9

Sets destination from a list of 20 POI destinations closest to the current position (within a radius of 50 km) by inputting
POI category and selecting POI.

10

Sets destination from a list of recent destinations. Up to 50 points including the latest starting point are in the system
memory.

11

Sets destination from a list of points stored by the user. Up to 100 points can be stored in the memory.

12

Sets destination by moving the crosshair cursor to the destination when in scroll map mode.

AUDIO AND NAVIGATION SYSTEM

T–75

T

T

POI categories

•

When setting POI destination, the following categories can be selected. Data for categories according to the
selected country will be displayed.

.

Route Search Function
Whole route search function

•

After setting a destination, the following route search methods can be used:

A6E8126T067

1

Auto services

2

Parking garage

3

Open parking area

4

Park & Ride

5

Petrol station

6

Rent a car facility

7

Rest area

8

Motoring organization office

9

Border crossing

10

Business facility

11

City center

12

Emergency

13

Hospital/Polyclinic

14

Hotel or motel

15

Leisure/Recreation

16

Amusement park

17

Bowling center

18

Casino

19

Cinema

20

Golf course

21

Historical monument

22

Ice skating rink

23

Marina

24

Museum

25

Night life

26

Recreation facility

27

Theater

28

Ski resort

29

Sports activity

30

Sports center

31

Tourist attraction

32

Tourist office

33

Winery

34

Public facility

35

City hall

36

Community center

37

Exhibition or conference center

38

University or college

39

Restaurant

40

Shopping

41

Shopping center

42

Transportation

43

Airport

44

Bus station

45

Commuter rail station

46

Ferry terminal

47

Rail way station

48

Public sport airport

No.

Items

Route search method

1

Shortest route setting

•

Selects a route according to the shortest distance.

2

Avoid motorway setting

•

Selects a route that reduces use of motorways.
