ON-BOARD DIAGNOSTIC [ENGINE CONTROL SYSTEM (FS)] 01–02B–60 End Of Sie 15 VERIFY TROUBLESHOOTING OF DTC P0133 • Make sure to reconnect all disconnected • Turn ignition key to ON (Engine OFF). • Clear DTC from memory using WDS or • Start engine. • Run OBD-ll DRIVE MODE 1 and 3. • Stop vehicle and access ON BOARD SYSTEM • Verify RFC changes to YES for OXYGEN • Access DIAGNOSTIC MONITORING TEST • Verify following TEST # values: • Are they all below MAX value? Yes Go to next step. No Replace PCM, then go to next step. 16 VERIFY AFTER REPAIR PROCEDURE • Perform “After Repair Procedure”. • Is there any DTC present? Yes Go to applicable DTC inspection. (See 01–02B–15 DTC TABLE [FS].) No Troubleshooting completed. STEP INSPECTION ACTION 1712-1U-01G(01-02B).fm 60 ページ 2001年6月29日 金曜日 午後3時24分 |
