ON-BOARD DIAGNOSTIC [ENGINE CONTROL SYSTEM (FS)] 01–02B–8 Freeze Frame PID Data Access Procedure 1. Perform the necessary vehicle preparation and visual inspection. 16-pin connector located on the left side of the 3. Retrieve FREEZE FRAME PID DATA using WDS or equivalent. On-Board System Readiness Tests Access Procedure 1. Perform the necessary vehicle preparation and visual inspection. 16-pin connector located on the left side of the 3. Monitor the OBD-II system operating status using WDS or equivalent. PID/DATA Monitor and Record Procedure 1. Perform the necessary vehicle preparation and visual inspection. 16-pin connector located on the left side of the 3. Access and monitor PIDs using WDS or equivalent. Z3U0102W001 Z3U0102W001 Z3U0102W001 1712-1U-01G(01-02B).fm 8 ページ 2001年6月29日 金曜日 午後3時24分 |
