Lexus RX350h (2024 year). Manual in english - page 13

410

5-2. Using the air conditioning system and defogger

■

Adjusting the position of and open-
ing and closing the air outlets

To adjust the position of and opening
and closing the air outlets, perform the
following operations:



Front center

1

Direct air flow to the left or right, up
or down

2

Turn the knob to open or close the
vent

WARNING

■

To prevent the windshield defogger

from operating improperly

●

Do not use the windshield defogger in

extremely humid areas when the air

conditioning system is set to a low tem-

perature. The difference between the

temperature of the outside air and that

of the windshield can cause the outer

surface of the windshield to fog up,

blocking your vision.

●

Do not place anything on the instru-

ment panel which may cover the air

outlets. Otherwise, air flow may be

obstructed, preventing the windshield

defoggers from defogging.

■

When the outside rear view mirror

defoggers are operating

Do not touch the surface of the outside

rear view mirrors when the rear window

defogger and outside rear view mirror

defoggers are operating, as the surface

of the mirrors will become extremely hot

and may cause burns.

■

To prevent the windshield from fog-

ging up

Do not touch the lower part of the wind-

shield or parts along the front pillars

when the windshield wiper de-icer is on,

as they will be hot and may cause burns.

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the

hybrid system is off.

■

When repairing/replacing parts of

the air conditioning system

Have repair/replacement performed by

your Lexus dealer.

When a part of the air conditioning sys-

tem, such as the evaporator, is to be

replaced, it must be replaced with a new

one.

Air outlet layout and operations

411

5-2. Using the air conditioning system and defogger

5

Interio

r fe

atures



Front side

1

Direct air flow to the left or right, up
or down

2

Turn the knob to open or close the
vent



Rear

1

Direct air flow to the left or right, up
or down

2

Turn the knob to open or close the
vent

412

5-2. Using the air conditioning system and defogger

■

Center display



14-inch center display model

Rear seats temperature control switch

Turn temperature control dial clockwise to increases the temperature and turn the dial
counterclockwise to decreases the temperature.

Close the rear air conditioning control screen



9.8-inch center display model

Rear seats temperature control switch

Turn temperature control dial clockwise to increases the temperature and turn the dial
counterclockwise to decreases the temperature.

Close the rear air conditioning control screen

Rear air conditioning system

The rear air conditioning system can be operated selecting “Rear” switch on
the center display and rear air conditioning system control panel.

Rear air conditioning control operation

A

B

A

B

413

5-2. Using the air conditioning system and defogger

5

In

te

rio

r f

ea

tu

re

s

■

Rear air conditioning system con-
trol panel

Adjust the rear seats temperature set-
ting

Press

 to increase the temperature

and

 to decrease the temperature.

The temperature setting of the rear
seats can be adjusted using the follow-
ing methods:



When the “Sync” indicator is on:
Adjust the driver’s seat temperature.

Adjust the temperature setting of each
rear seat using the center display or rear
air conditioning system control panel.



Adjust the temperature setting of
rear seats using the center display
(rear air conditioning control
screen) or rear air conditioning sys-
tem control panel.



P.410

Adjusting the temperature set-
ting of the rear seats

Air outlets

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the

hybrid system is off.

414

5-2. Using the air conditioning system and defogger

*

: If equipped

Select

 on the center display.

Each time the switch is selected, the opera-
tion condition changes as follows.
AUTO



Hi (2 segments lit)



Lo (1 seg-

ment lit)



Off

The level indicator (red) lights up during
operation. “AUTO” indicator lights up
during automatic operation.

■

Operation condition

The power switch is in ON.

■

Customization

The temperature setting of the heated

steering wheel can be set through “Vehicle

customize” on the center display.

(



P.585)

■

Front seats

Select

 or

 on the center display.

Each time the switch is selected, the opera-
tion condition changes as follows.
AUTO



Hi (3 segments lit)



Mid (2 seg-

ments lit)



Lo (1 segment lit)



Off



Vehicles without seat ventilators

The level indicator (red) lights up
during operation. “AUTO” indicator
lights up during automatic operation.



Vehicles with seat ventilators

The level indicator (yellow) lights up
during operation.

■

Rear seats

*

Press the switch.

Each time the switch is selected, the opera-
tion condition changes as follows.

Heated steering wheel

*

/seat

heaters/seat ventilators

*



Heated steering wheel

Warms up the grip of the steering
wheel



Seat heaters

Warm up the seat upholstery



Seat ventilators

Maintain good ventilation using a fan
built into the seat

WARNING

■

To prevent minor burn injuries

Care should be taken if anyone in the fol-

lowing categories comes in contact with

the steering wheel or seats when the

heater is on:

●

Babies, small children, the elderly, the

sick and the physically challenged

●

Persons with sensitive skin

●

Persons who are fatigued

●

Persons who have taken alcohol or

drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

NOTICE

■

To prevent damage to the seat heat-

ers

Do not put heavy objects that have an

uneven surface on the seat and do not

stick sharp objects (needles, nails, etc.)

into the seat.

■

To prevent 12-volt battery discharge

Do not use the functions when the hybrid

system is off.

Heated steering wheel

Seat heaters

415

5-2. Using the air conditioning system and defogger

5

In

te

rio

r f

ea

tu

re

s

Hi (3 segments lit)



Mid (2 segments

lit)



Lo (1 segment lit)



Off

The level indicators (yellow) light up during
operation.

*

: If equipped

■

Operating conditions of seat heaters

The power switch is in ON.

■

Customization

The temperature setting of the seat heaters

of the front seats can be set through “Vehi-

cle customize” on the center display.

(



P.585)

■

Front seats

Select

 or

 on the center dis-

play.

Each time the switch is pressed, the opera-
tion condition changes as follows.

AUTO



Hi (3 segments lit)



Mid (2 seg-

ments lit)



Lo (1 segment lit)



Off

The level indicator (blue) lights up during
operation. “AUTO” indicator lights up
during automatic operation.

■

Operation condition

The power switch is in ON.

■

Air conditioning system-linked control

mode

When a seat ventilator is set to Hi, the fan

speed of the seat ventilator may increase

according to the fan speed of the air condi-

tioning system.

■

Customization

The temperature setting of the seat ventila-

tors of the front seats can be set through

“Vehicle customize” on the center display.

(



P.585)

WARNING

■

To prevent overheating and minor

burn injuries

Observe the following precautions when

using the seat heaters.

●

Do not cover the seat with a blanket or

cushion when using the seat heater.

●

Do not use seat heater more than nec-

essary.

Seat ventilators (front seats)

416

5-3. Using the interior lights

5-3.Using the interior lights

Outer foot lights
Shift lever light
Interior lights (



P.417)

Front personal lights (



P.417)

Door trim ornament lights

*1, 2

Inside door handle lights

*1

Rear personal lights (



P.417)

Door courtesy lights
Footwell lights

Instrument panel ornament lights

*1

*1

: The illumination color can also be changed.

*2

Refer to the “MULTIMEDIA OWNER’S MANUAL” to change the settings.

*2

: If equipped

Interior lights list

Location of the interior lights

A
B
C
D

E
F

G

H

I

J

417

5-3. Using the interior lights

5

Interio

r fe

atures

■

Turning the interior lights on/off

Touch the light

■

Turning the door position on

Press the door-linked interior light
switch

The lights are turned on and off according
to whether the doors are opened/closed.
When the door position is on, the indicator

 illuminates.

■

Turning the front personal lights
on/off

Touch the light

■

Turning the rear personal lights
on/off

Touch the light

The rear interior lights turn on/off together
the front interior lights.
When a door is opened while the door
position is on, the lights turn on.

■

Illuminated entry system

The lights automatically turn on/off accord-

ing to the power switch mode, the presence

of the electronic key, whether the doors are

locked/unlocked, and whether the doors

are opened/closed. Also, the brightness of

the lights is automatically adjusted linked

with the shift operation.

■

To prevent the 12-volt battery from

being discharged

If the interior lights remain on when the

power switch is turned off, the lights will go

off automatically after 20 minutes.

■

When interior light or personal lights do

not respond as normal

In the following cases, the interior lights and

personal lights may not respond as normal.

Operating the interior lights

Operating the personal lights

A

418

5-3. Using the interior lights

●

When water, dirt, etc., have adhered to

the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

■

The interior lights may turn on automati-

cally when

If any of the SRS airbags deploy (inflate) or

in the event of a strong rear impact, the inte-

rior lights will turn on automatically.
The interior lights will turn off automatically

after approximately 20 minutes.
The interior lights can be turned off manu-

ally. However, in order to help prevent fur-

ther collisions, it is recommended that they

be left on until safety can be ensured.
(The interior lights may not turn on auto-

matically depending on the force of the

impact and conditions of the collision.)

■

Using the voice control system

*

*

: If equipped

The following operations can be performed

using the voice control system.

●

Turning interior light on/off

●

Changing color of each lights

*

For details, refer to the “MULTIMEDIA

OWNER’S MANUAL”.

*

: If equipped

■

Customization

Some functions can be customized.

(



P.585)

NOTICE

■

Removing light lenses

Never remove the lens for the interior

light and personal lights. Otherwise, the

lights will be damaged. If the lens need to

remove, contact your Lexus dealer.

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

419

5-4. Using the storage features

5

In

te

rio

r f

ea

tu

re

s

5-4.Using the storage features

Glove box (



P.420)

Auxiliary boxes (if equipped) (



P.422)

Bottle holders (



P.421)

Door pockets
Cup holders (



P.420)

Console box (



P.420)

Coin box (



P.422)

List of storage features

Location of the storage features

A
B
C
D

E
F

G

WARNING

■

Items that should not be left in the

storage spaces

Do not leave glasses, lighters or spray

cans in the storage spaces, as this may

cause the following when cabin tempera-

ture becomes high:

●

Glasses may be deformed by heat or

cracked if they come into contact with

other stored items.

●

Lighters or spray cans may explode. If

they come into contact with other

stored items, the lighter may catch fire

or the spray can may release gas,

causing a fire hazard.

420

5-4. Using the storage features

1

Open (pull the lever)

2

Lock with the mechanical key

3

Unlock with the mechanical key

■

Glove box light

The glove box light turns on when the tail

lights are on.



Type A

Push the lid.

To close, press in and release the lid.



Type B

Press the button, lift up and open the
lid.

The console box can be opened from
either side.

■

Console box light

The console box light turns on when the tail

lights are on.



Front



Rear

Pull down the armrest and then press

Glove box

WARNING

■

Caution while driving

Keep the glove box closed.

In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by the open

glove box or the items stored inside.

Console box

WARNING

■

Caution while driving

Keep the console box closed.

In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by the open

console box or the items stored inside.

Cup holders

421

5-4. Using the storage features

5

In

te

rio

r f

ea

tu

re

s

down the button.

■

The depth of the front cup holder can be

changed.

1

To store a water bottle, push down the

bottom of the cup holder.

2

To return the bottom to its original posi-

tion, press the button.



Front



Rear

■

Bottle holders

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending

on its size or shape.

WARNING

■

Items unsuitable for the cup holder

Do not place anything other than cups,

aluminum cans, or water bottles in the

cup holders. Other items may be thrown

out of the holders in the event of an acci-

dent or sudden braking, possibly causing

injury. If possible, cover hot drinks to pre-

vent burns.

■

When not in use (rear cup holder)

Keep the cup holders closed.

Injuries may result in the event of an acci-

dent or sudden braking.

NOTICE

■

To prevent damage to the rear cup

holder

Stow the rear cup holders before stowing

the rear armrest.

Bottle holders

422

5-4. Using the storage features

Press in the button.



Instrument panel



Overhead

Press in the lid.



Rear seat (if equipped)

Pull up the lever to release the lock,
and lift the lid.

NOTICE

■

Items unsuitable for the bottle hold-

ers

Do not place open bottle, glass or paper

cups containing liquid in the bottle hold-

ers. Otherwise, contained liquid may be

spilled. Glass cups may break if used in

the bottle holders.

Coin box

WARNING

■

Caution while driving

Keep the coin box closed.

In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by the open

coin box or the items stored inside.

Auxiliary boxes

WARNING

■

Items unsuitable for storing (Instru-

ment panel)

Do not store items in the box that can

easily shift or roll out.

In the event of sudden braking, etc.,

stowed items may fly out, possibly lead-

ing to an accident.

■

Items unsuitable for storing (over-

head)

Do not store items heavier than 0.44 lb.

(200 g).

Doing so may cause the auxiliary box to

open and the items inside may fall out,

resulting in an accident.

423

5-4. Using the storage features

5

In

te

rio

r f

ea

tu

re

s

Pull down the hook to use.

The cargo hooks are provided for securing
loose items.

To hang the cargo net, use the cargo
net hooks and rear cargo hooks.

WARNING

■

Caution while driving

Keep the auxiliary boxes closed.

In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by the open

auxiliary boxes or the items stored inside.

Luggage compartment fea-
tures

Cargo hooks

WARNING

■

When cargo hooks are not in use

To avoid injury, always return the hooks

to their stowed positions when not in use.

Cargo net hooks

WARNING

■

When the cargo net is not in use

To avoid injury, always return the hooks

to their stowed positions when not in use.

424

5-4. Using the storage features

To use the grocery bag hook, push it in.

■

Installing the luggage cover

1

Insert either end of the luggage
cover into the recess, then com-
press the other end of the luggage
cover and insert it into the recess.

2

Pull out the luggage cover and
hook it onto the anchors.

■

Removing the luggage cover

1

Lift the rear portion of the cover to
release the left and right anchors
and allow the cover to retract.

2

Compress the end of the luggage
cover and lift the luggage cover up.

After removing the luggage cover, place it

somewhere other than the passenger

compartment.

Grocery bag hooks

NOTICE

■

To prevent damage to the grocery

bag hooks

Do not hang any object heavier than 8.8

lb. (4 kg) on the grocery bag hooks.

Luggage cover

425

5-4. Using the storage features

5

In

te

rio

r f

ea

tu

re

s

■

Opening the deck board

1

Pull the lever up and fold the flap of
the deck board.

2

Lift the deck board and disengage
the hook on the underside of the
deck board.

3

Attach the hook to the upper edge
of the back door opening as shown.

When closing, reverse the steps listed.

WARNING

■

Luggage cover

●

Do not place anything on the luggage

cover. In the event of sudden braking

or turning, the item may go flying and

strike an occupant. This could lead to

an unexpected accident, resulting in

death or serious injury.

●

Do not allow children to climb on the

luggage cover. Climbing on the lug-

gage cover could result in damage to

the luggage cover, possibly causing

death or serious injury to the child.

Deck board

WARNING

■

If the deck board is folded or

removed

Return it to its original position before

driving. In the event of sudden braking,

an accident may occur due to an occu-

pant being struck by the deck board or

the items stored in the deck under tray.

NOTICE

■

When closing the back door

Do not leave the deck board hook

hooked on the edge of the back door

opening. The deck board hook may get

damaged.

426

5-5. Using the other interior features

5-5.Using the other interior features

The USB charging ports are used to
supply 3.0 A of electricity at 5 V to
external devices.
The USB charging ports are for
charging only. They are not designed
for data transfer or other purposes.
Depending on the external device, it
may not charge properly. Refer to the
manual included with the device
before using a USB charging port.

■

Using the USB charging ports



On the instrument panel



Inside the console box



On the rear console

■

The USB charging ports can be used

when

The power switch is in ACC or ON.

■

Situations in which the USB charging

ports may not operate correctly

●

If a device which consumes more than

3.0 A at 5 V is connected

●

If a device designed to communicate with

a personal computer, such as a USB

memory device, is connected

●

If the connected external device is turned

off (depending on device)

●

If the temperature inside the vehicle is

high, such as after the vehicle has been

parked in the sun

■

About connected external devices

Depending on the connected external

device, charging may occasionally be sus-

pended and then start again. This is not a

malfunction.

Other interior features

USB charging ports

NOTICE

■

To prevent damage to the USB

charging ports

●

Do not insert foreign objects into the

ports.

●

Do not spill water or other liquids into

the ports.

●

Do not apply excessive force to or

impact the USB charging ports.

●

Do not disassemble or modify the USB

charging ports.

427

5-5. Using the other interior features

5

In

te

rio

r f

ea

tu

re

s

A portable device, such as a smart-
phone or mobile battery, can be
charged by just placing it on the
charging area, provided the device is
compatible with the Qi wireless
charging standard created by the
Wireless Power Consortium. The com-
patible portable devices can be found
on the following Wireless Power Con-
sortium website. https://
www.wirelesspowerconsortium.com/
The wireless charger cannot be used
with a portable device that is larger
than the charging tray. Additionally,
depending on the portable device, the
wireless charger may not operate
properly. Refer to the operation man-
ual of the portable device.

■

The “Qi” logo

The “Qi” logo is a trademark of the
Wireless Power Consortium.

■

Name for all parts

Operation indicator light

Charge area

*

Charging tray
Approximately 3.9 in. (10 cm)
Approximately 1.0 in. (2.5 cm)

*

: The charging coil in the wireless charger

can be moved within the charge area up
to the position of the charging coil inside
a portable device. Charging is possible if
the center of the coil of the portable
device is placed within the charge area.

Additionally, if 2 or more portable devices

are placed on the charging tray at the
same time, each charging coil may not
be detected correctly and charging may
not be possible.

■

Using the wireless charger

Place the portable device on the wire-
less charger.

Place the charging side of the portable
device down with the center of the device
in the center of the charge area.
When charging, the operation indicator
light (orange) on the wireless charger
comes on.

NOTICE

■

To prevent damage to external

devices

●

Do not leave external devices in the

vehicle. The temperature inside the

vehicle may become high, resulting in

damage to an external device.

●

Do not push down on or apply unnec-

essary force to an external device or

the cable of an external device while it

is connected.

■

To prevent 12-volt battery discharge

Do not use the USB charging ports for a

long period of time with the hybrid sys-

tem stopped.

Wireless charger (if equipped)

A
B
C
D

E

428

5-5. Using the other interior features

Refer to “Situations in which the function
may not operate normally” (



P.431) when

charging is not performed.
When charging is complete, the operation
indicator light (green) on the wireless char-
ger comes on.

■

Recharging function



If a certain amount of time has
elapsed since charging completed
and the portable device has not
been moved, the wireless charger
will restart charging.



If a portable device is moved signifi-
cantly within the charging area, the
charging coil may disconnect and

charging may temporarily be
stopped. However, if a charging coil
is detected within the charging area,
the charging coil inside the wireless
charger will move near the other
coil and charging will resume.

■

Rapid charging function

The following portable devices support
rapid charging.



Portable devices compliant with
WPC Ver1.3.2 and compatible with
rapid charging



iPhone’s with an iOS version that
supports 7.5 W charging (iPhone 8
and later models)



Portable devices compatible with
Galaxy original rapid charging stan-
dard.

When a portable device that supports
rapid charging is charged, charging
automatically switches to the rapid
charging function.

■

Operation indicator light status

*1

: Charging power will not be output during standby. A metallic object will not be heated, if

it is placed on the wireless charger in this state.

*2

: Depending on the portable device, there are cases where the operation indicator light

will continue being lit up orange even after the charging is complete.

Operation indicator light

Conditions

Charging tray

Center display

Turning off

Disappear

When power for Multimedia is off or the power
switch is off

Green (comes

on)

Gray

On Standby (charging possible state)

*1

When charging is complete

*2

Orange (comes

on)

Blue

Charging

429

5-5. Using the other interior features

5

Interio

r fe

atures

■

When the wireless charger does not operate properly

When the wireless charger does not operate properly, handle the probable cause
based on the following tables.

Operation indicator light

Suspected causes/Handling method

Charging tray

Center display

Green (Flashing
repeatedly once

every second)

Disappear

Wireless charger and multimedia system communi-
cation failure



If the hybrid system is operating, stop and then
restart the hybrid system.

If the power switch is in ACC, start the hybrid sys-
tem. (



P.200)

Orange (Flashing

repeatedly once

every second)

Gray

Vehicle to wireless charger communication failure



If the hybrid system is operating, stop and then
restart the hybrid system.

If the power switch is in ACC, start the hybrid sys-
tem. (



P.200)

Green (comes

on)

Blue

AM radio stations are being automatically selected



Wait until the system has completed the auto-
matic selection of AM radio stations. In the
case that automatic selection cannot be com-
pleted, stop automatic selection.

The smart access system with pushbutton start is
detecting the key.



Wait until electronic key detection has com-
pleted.

430

5-5. Using the other interior features

■

The wireless charger can be operated

when

The power switch is in ACC or ON.

■

Portable devices that can be charged

●

Portable devices compatible with the Qi

wireless charging standard can be

charged by the wireless charger. How-

Green (comes

on)

Gray

Foreign substance detection:
A metallic foreign substance is in the charge area,
and so the abnormal heating prevention function of
the metallic foreign object operated



Remove the foreign substance from the charge
area.

Portable device misaligned / distanced from
charging surface:
The charging coil in the portable device moved out-
side of the charging area, or lens convex is large, or
case is thick so the abnormal heating prevention
function operated



Remove the portable device from the wireless
charger, after 5 seconds, then place the porta-
ble device so that it is near the center of the
wireless charger. Also, if a case or cover is
installed to the portable device, remove it.

Battery protection function of portable device:
Before full charging, battery protection function of
portable device operated



Confirm the setting of portable device.

Continued detection of an electronic key:
When a Multimedia function is used through vehi-
cle customization, the electronic key is continually
detected without being confirmed.



In this case, turn the power switch ACC or ON
to confirm the key.

Orange (Repeat-

edly flashes 4

times continu-

ously)

Gray

Safety shutdown resulting when the temperature
within the wireless charger exceeded the set value



Stop charging, remove the portable device
from the wireless charger, wait for the tem-
perature to drop, and then start charging
again.

Operation indicator light

Suspected causes/Handling method

Charging tray

Center display

431

5-5. Using the other interior features

5

Interio

r fe

atures

ever, compatibility with portable devices

that comply with Qi Ver. 1.0, 1.3.2 and

later versions is not guaranteed.

●

The wireless charger is designed to sup-

ply low power electricity (5 W or less) to

a cellular phone, smartphone, or other

portable device.

However, portable devices, such as the fol-

lowing, can be charged with more than 5

W.

• 7.5 W charging compatible iPhones can

be charged at 7.5 W or less.

• Devices that comply with independent

Galaxy charging standards support rapid

charging. Check the specifications of

each portable device for the charging

electricity.

• Portable devices compliant with EPP out-

put as defined by WPC standard

Ver1.3.2. can be charged at 15 W or less.

■

Using the smart access system with

push-button start

During charging, when the smart access

system with push-button start searches for

an electronic key, charging may be tempo-

rarily suspended.

■

If a cover or accessory is attached to the

portable device

Do not charge a portable device if a cover

or accessory which is not Qi compatible is

attached. Depending on the type of cover

(including the certain genuine manufacture

parts) and/or accessory attached, it may not

be possible to charge the portable device. If

the portable device is placed on the

charging area and does not charge, remove

the cover and/or accessories.

■

AM radio cooperation function during

charging

●

During charging, if noise occurs when lis-

tening to the AM radio, the charging fre-

quency is automatically changed to

reduce the noise.

●

When automatically seeking AM radio

stations, charging will be suspended to

prevent charging noise from being

detected as a radio station. Charging will

resume automatically when seek tuning is

stopped.

■

Charging precautions

●

If the electronic key cannot be detected

within the vehicle interior, charging can

not be done. When the door is opened

and closed, charging may be temporarily

suspended.

●

While charging, the wireless charger and

the portable device will become warm.

This is not a malfunction. If a portable

device becomes warm while charging

and charging stops due to the protection

function of the portable device, wait until

the portable device cools down and

charge it again. Also, to decrease the

temperature inside the wireless charger,

a fan may operate. This does not indicate

a malfunction.

■

Sound generated during operation

Operation sounds may be heard when the

power switch is pressed to change to ACC

or ON, or when a portable device is being

detected. This does not indicate a malfunc-

tion.

■

Cleaning the wireless charger



P.456

■

Situations in which the wireless charger

may not operate correctly

In the following situations, the wireless char-

ger may not operate correctly:

●

When a portable device is fully charged

●

When a portable device is being charged

by a wired connection

●

When there is a foreign object between

the charging area and portable device

●

When the temperature of a portable

device becomes high while charging

●

When the temperature near the charging

tray is 95°F (35°C) or more due to being

in direct sunlight, etc.

●

When a portable device is placed with its

charging surface facing up

●

The small portable device such as fold-

able type is placed in an area misaligned

from the charge area

●

When a portable device is larger than the

charging tray

●

When the vehicle is near a TV tower,

432

5-5. Using the other interior features

electric power plant, fuel station, radio

station, large display, airport, or other

facility that generates strong radio waves

or electrical noise

●

The electronic key is not inside the vehi-

cle

●

When the any of the following objects are

between the charging surface of a porta-

ble device and the charging area:

• Thick cases or covers

• A case or cover attached with an uneven

or tilted surface, so that the charging side

is not flat

• Thick decorations

• Accessories, such as finger rings, straps,

etc.

●

When there is a gap between the

charging side of the portable device and

the charge area due to a protrusion such

as a camera on the charging side of the

portable device.

●

When the portable device is in contact

with, or is covered by any of the following

metallic objects:

• Cards covered with metal, such as alumi-

num foil

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Heat packs

• Recorded media such as CDs and DVDs

• Metallic decorations

• Metallic cases or covers

• Casing which has magnet in it on the

charging side of the portable device

●

When wireless keys (that emit radio

waves) other than those of your vehicle

are being used nearby

●

When 2 or more portable devices are

placed on the charging tray at the same

time

●

If a portable device built in S-pen (Galaxy

“Note” series etc.) used, a portable

device that inserted S-pen is placed on

the tray

In situations other than above, if the wire-
less charger does not operate properly or
the operation indicator light blinks continu-
ously, the wireless charger may be mal-

functioning.
Contact your Lexus dealer.

■

If the smartphone OS has been updated

If the smartphone OS has been updated to

a newer version, its charging specifications

may have changed significantly. For details,

check the information on the manufac-

turer’s website.

■

Trademark information

iPhone is a trademark of Apple Inc., regis-

tered in the U.S. and other countries.
Galaxy is a trademark or registered trade-

mark of Samsung Electronics Co.,Ltd.

WARNING

■

Caution while driving

When charging a portable device while

driving, for safety reasons, the driver

should not operate the portable device.

■

Precautions for when driving

Do not charge small, lightweight porta-

ble devices, such as wireless earbuds,

while driving. Lightweight devices may fly

off of the charging tray, possibly leading

to an accident.

■

Caution regarding interference with

electronic devices

People with implantable cardiac pace-

makers, cardiac resynchronization ther-

apy pacemakers or implantable

cardioverter defibrillators, as well as any

other electrical medical device, should

consult their physician about the usage of

the wireless charger.

Operations of the wireless charger may

have an affect on medical devices.

■

To prevent damage or burns

Observe the following precautions.

Failure to do so may result in the possibil-

ity of fire, equipment failure or damage,

or burns due to heat.

433

5-5. Using the other interior features

5

In

te

rio

r f

ea

tu

re

s

Pull the armrest down for use.

WARNING

●

Do not put any metallic objects

between the charging area and the

portable device while charging.

●

Do not attach metallic objects, such as

aluminum stickers, to the charging

area.

●

Do not charge portable devices with

aluminum stickers or other metallic

objects attached to the side which

touches the charging area.

●

Do not store items on the wireless

charger instead of in an auxiliary box.

●

Do not apply force or impact to the

wireless charger.

●

Do not disassemble, modify or remove

the wireless charger.

●

Do not attempt to charge portable

devices which are not compatible with

the Qi wireless charging standard.

●

Do not allow magnetic objects to

come near the wireless charger.

●

Do not perform charging if the

charging area is dirty.

●

When not using the wireless charger,

to prevent foreign matter or liquids

from contacting it, make sure to close

the lid.

●

Keep the lid open while charging is

taking place.

●

Do not cover the wireless charger with

a cloth or other object while charging.

NOTICE

■

To prevent failure or damage to data

●

Do not place magnetic cards, such as a

credit card, or magnetic recording

media, close to the wireless charger

while charging. Otherwise, data may

be erased due to the influence of mag-

netism. Additionally, do not bring pre-

cision instruments such as wrist

watches, close to the wireless charger,

as such objects may malfunction.

●

Do not perform charging with a con-

tactless smart card, such as a transpor-

tation system IC card, between the

charging surface of a portable device

and the charging area. The IC chip in

the card may become extremely hot,

possibly damaging the portable device

or smart card.

Be extra careful to not charge a porta-

ble device with a case or cover which a

contactless smart card can be

inserted.

●

Do not leave portable devices in the

cabin. The temperature inside the

cabin may become high when parked

in the sun, and cause damage to the

device.

■

To prevent 12-volt battery discharge

Do not use the wireless charger for a

long period of time with the hybrid sys-

tem stopped.

Armrest

434

5-5. Using the other interior features

An assist grip installed on the ceiling
can be used to support your body
while sitting on the seat.

The coat hooks are provided with the
rear assist grips.

Please use as a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).
When connecting multiple devices,
make sure that the total power con-
sumption of all the connected devices
is less than 120 W.



Inside the console box

Open the lid.

NOTICE

■

To prevent damage to the armrest

Do not apply too much load on the arm-

rest.

Assist grips

WARNING

■

Assist grip

Do not use the assist grip when getting in

or out of the vehicle or rising from your

seat.

NOTICE

■

To prevent damage to the assist grip

Do not hang any heavy object or put a

heavy load on the assist grip.

Coat hooks

WARNING

■

Items that must not be hung on the

hook

Do not hang coat hangers or other hard

or sharp objects on the hook. If the SRS

curtain shield airbags deploy, these items

may become projectiles, causing death

or serious injury.

Power outlets (12 VDC)

435

5-5. Using the other interior features

5

In

te

rio

r f

ea

tu

re

s



In the luggage compartment

Open the lid.

■

The power outlet can be used when

The power switch is in ACC or ON.

■

When stopping the hybrid system

Disconnect electrical devices with charging

functions, such as mobile battery packs.

If such devices are left connected, the

hybrid system may not stop normally.

1

To set the visor in the forward posi-
tion, flip it down.

2

To set the visor in the side position,
flip down, unhook, and swing it to
the side.

3

To use the side extender, place the
visor in the side position, then slide
it backward.

Slide the cover to open.

The light turns on when the cover is
opened.

■

To prevent 12-volt battery discharge

If the vanity lights remain on when the

power switch is turned off, the lights will go

off automatically after 20 minutes.

NOTICE

■

To avoid damaging the power outlet

Install the cap or close the lid when the

power outlets is not in use.

Foreign objects or liquids that enter the

power outlet may cause a short circuit.

■

To prevent 12-volt battery discharge

Do not use the power outlet longer than

necessary when the hybrid system is not

running.

Sun visors

Vanity mirrors

436

5-5. Using the other interior features

Pull the sunshade up using the tab and
hook the sunshade on to the anchors.

To lower the sunshade, pull it up slightly
using the tab, unhook it from the anchors,
and lower it slowly.

NOTICE

■

To prevent the 12-volt battery from

being discharged

Do not leave the vanity lights on for

extended periods while the hybrid sys-

tem is off.

Rear door sunshades (if
equipped)

WARNING

■

Closing the rear door sunshade

When a rear door sunshade is in use, do

not put fingers, etc. on the anchors or in

the groove of the rear door sunshade.

Otherwise, a finger, etc. may get caught,

possibly causing an injury.

NOTICE

■

To ensure normal operation of the

sunshade

●

Do not put anything in an area where it

may interfere with the operation of a

rear door sunshade.

●

To prevent damage to the rear door

sunshades, do not apply excessive

load or attach items to the rear door

sunshades.

437

5-5. Using the other interior features

5

Interio

r fe

atures

*

: If  equipped

Observe the following precautions
before starting the power supply:



As the engine may operate while
the system is operating, avoid areas
with poor ventilation, such as a
garage. Park the vehicle in a well
ventilated place.



Park the vehicle on a solid and level
place.



Check that the hood is closed.



Check that the parking brake is
engaged.



Check that the P shift position is
selected.



Check that the power switch is off.



Note that the alarm system cannot
be enabled during the Power supply.
For theft prevention, do not leave
valuable items, etc. in the cabin or
luggage compartment.

Power switch (



P.200)

In the luggage compartment

1

Check that the parking brake is
engaged. securely depress the
brake pedal, and press the power
switch. (



P.200)

2

Check that the “READY” indicator
is illuminated, and select the short-
cut switch on the center display.

3

Touch “Power outlet 1500W”.

The power outlets are turned on/off each

time “Power outlet 1500W” is touched.

4

Open the lid, and fully and securely
insert the plug of the device into the
power outlet.

1

Turn the connected device(s) off.

2

Select the shortcut switch on the
center display.

3

Touch “Power outlet 1500W” to
turn it off.

Using the power outlets
(1500 W)

*

The system allows the on-board use
of electric devices which operate
on 120 VAC and have a combined
power consumption of 1500 W or
less.

Precautions for using the power
outlets while parked

Names of parts

Using the power outlets (1500
W)

Stopping the use of the power
outlets (1500 W)

A
B

438

5-5. Using the other interior features

4

Disconnect each plug from the
power outlets.

5

Close the lid of each power outlet.

■

When connecting a device

Make sure to read the instruction man-
ual which came with a device and
observe warnings on the device.
Before connecting a device to the
power outlet, make sure that the device
is turned off.

1

Open the lid, and fully and securely
insert the plug of the device into the
power outlet.

Do not leave the plug halfway inserted.
In the following situations, use cable
extension, etc. and connect the plug
securely to the power outlet:



When the plug of a device is too
large to allow it to be inserted fully
and securely into the power outlet.



When the plug of a device is heavy,
possibly causing it to come off the
power outlet.

If the device to be used has a ground
wire, use a conversion adapter avail-
able on the market and connect the
ground wire to the ground terminal of
the conversion adapter.

■

Power outlets

●

With these power outlets, use devices

which operate on 120 VAC and have a

combined maximum power consumption

of 1500 W or less. If a device is con-

nected and the power consumption is

exceeded, a protection circuit may be

activated and the power supply function

may be stopped.

●

Some of the devices that consume a large

amount of power, such as an electric

grille, may require the exclusive use of the

power outlets. When such a device is

connected, do not connect other

device(s) to the power outlets.

●

When multiple devices are connected,

depending on the device, a connected

device may not operate properly. For

such a device, use exclusively the power

outlets.

●

When a power outlet is being used,

depending on the device to be used, the

current flow may be high and the initial

peak wattage may exceed 1500 W.

●

When a power outlet is being used,

depending on the device to be used, it

may cause interference with TV and

radio broadcasts.

●

While a power outlet is being used, a

cooling fan sound may be heard from

near a luggage compartment. This does

not indicate a malfunction.

■

Devices which may not operate cor-

rectly

The following devices may not operate

properly even if the combined power con-

sumption is 1500 W or less:

●

Devices with high initial peak wattage

Connecting a device

439

5-5. Using the other interior features

5

In

te

rio

r f

ea

tu

re

s

●

Devices requiring larger amount of

power supply than the power consump-

tion specified in its instruction manual

●

Measuring devices that process precise

data

●

Devices that require an extremely stable

power supply

●

Devices that require a constant power

supply from the power outlet, such as a

device with a timer.

■

When the power outlets are used while

the vehicle is parked or stopped

●

The doors cannot be locked/unlocked

using the smart access system with

push-button start.

●

The doors cannot be locked/unlocked

using an electronic key. The doors can

only be locked/unlocked using a

mechanical key. (



P.544)

●

When a door is opened/closed, a buzzer

may sound or “Key not detected Check

key location” may be displayed on the

multi-information display. Check that an

electronic key is carried with you.

●

When the surrounding area becomes

dark while the power supply is being per-

formed, the headlights, etc. will come on

automatically.

To turn the lights off:



P.224

WARNING

■

For safe use

Observe the following precautions. Fail-

ure to do so may lead to an accident,

resulting in death or serious injury.

●

Do not allow children or other people

not used to the operation to perform

the power supply by themselves.

●

Do not disconnect the plug of a device

while your hands are wet or insert a pin

or other object into the power outlet.

Also, if a liquid or snow is on the power

outlet, dry the outlet before using it.

●

Do not attempt to modify, disassemble,

or repair a Power outlet. For informa-

tion on repairs, contact your Lexus

dealer.

●

Keep the power outlets free of dust

and foreign matter. Also, make sure to

clean the power outlets periodically.

●

Hold the plug body to plug in/out of a

power outlet. Do not touch the plug

blades. Do not pull on a cord for

unplugging, as otherwise the plug or

cord may be damaged.

●

Stop the use immediately if abnormal

heat is observed on a cord or power

outlet. To prevent the cord or power

outlet from becoming hot, observe the

following precautions:

• Do not connect 2 or more multi-point

outlet adapters, such as dual adapters.

• When an extension cord reel is used,

make sure to draw the whole cord out

of the reel.

●

If the device to be used has a ground

wire, use a conversion adapter avail-

able on the market and connect the

ground wire to the ground terminal of

the conversion adapter.

●

If the plug of a device fits loosely in a

power outlet, even though it is fully

inserted, replace the power outlet. For

information on replacement, contact

your Lexus dealer.

■

Devices to be connected

●

Make sure to read any instruction

manual which came with a device and

observe any warnings on the device.

440

5-5. Using the other interior features

WARNING

●

Do not connect a device to a power

outlet if the device is malfunctioning or

its plug is damaged.

●

Otherwise, the device may be further

malfunctioning, especially when the

outside temperature is high or low.

●

Devices requiring to be installed on a

level place may not operate properly.

●

Do not use devices, other than water-

proof devices, in a place where water,

such as rain, is splashed over or where

it is humid.

●

Do not use a device that has been or

likely to have been merged in water or

absorbed water within.

●

Depending on the vehicle condition,

the power supply function may be tem-

porarily stopped.

■

When the power outlets are used

while the vehicle is parked or stopped

●

The power outlets are designed to be

connected to electric devices, such as

lighting devices. Do not use them as a

generator that supplies power to a

house, etc. Also, when they are to be

used on an emergency power supply

device for homes, such as an exclusive

device having connection to an exter-

nal power source, or a device whose

power supply circuit for external

power source is separate from electric

wiring of power companies, consult

with the manufacturer or a retailer of

the device.

●

When using a power outlet, make sure

to securely engage the parking brake

and shift the shift position to P. Other-

wise, the vehicle may move, possibly

leading to an accident.

●

When using a power outlet, do not

move away from the vehicle.

●

Do not perform rapid charging during

weather when lightning may occur.

Stop supplying power if lightning is

observed during power supply.

●

Do not use the power outlets if the

vehicle has a vehicle cover installed.

●

Take due care when you sleep in the

vehicle while using devices such as an

electric heater. The power supply sys-

tem may stop automatically, possibly

resulting in unintended stoppage of

the connected device.

●

Do not use a power outlet when the

vehicle is parked on a slanted place or

a slope. When a power outlet is being

used, do not move the vehicle or cause

it to be inclined.

●

Observe the following precautions

when a connected cord is to be

brought outside the vehicle:

• Take due care for not allowing rain to

enter.

If the power outlet are wet with rain-

drops, dry them before use.

• Do not have cords pinched in a win-

dow or door.

• Allow slack in a connected cord. Do

not cause it to be extraordinary tense.

• Do not start off the vehicle by mistake.

●

Do not refuel or wash the vehicle when

using a power outlet.

441

5-5. Using the other interior features

5

In

te

rio

r f

ea

tu

re

s

WARNING

●

Make sure that the hood is closed. As

the engine will start automatically

depending on the condition of the

vehicle, make sure that nothing is left

near or contacting the exhaust pipes.

Also, do not put your head or hands

anywhere inside the engine compart-

ment. The cooling fans may operate

suddenly. Keep hands and clothing

(especially a tie, scarf, muffler, etc.)

away from the fans as they may get

caught in a fan, resulting in serious

injury.

●

Do not stop the vehicle near objects

which burn easily. If the exhaust system

is extremely hot, it may cause a fire.

●

If the charge level of the hybrid battery

(traction battery) becomes low, the

gasoline engine will operate automati-

cally. When using a power outlet in an

area with poor ventilation, such as a

garage, or an enclosed area (covered

with snow), to prevent the exhaust gas-

ses from accumulating and causing a

lack of oxygen, make sure to properly

install and use an air supply/exhaust

device. Do not use the power outlets if

such a device cannot be installed.

■

Use of a power outlet while driving

●

In situations such as the following, do

not use an electric device while driv-

ing. Also, do not use a device if it can-

not be secured within the vehicle.

• When a device is likely to distract the

driver and be a hindrance to safe driv-

ing, such as a TV, video/DVD player,

etc.

• When an inadequately secured device

is likely to fall over in case of sudden

braking or an accident

• When a device is likely to cause fire if it

falls or generates heat

• When a device is likely to cause burns,

such as a toaster, microwave, electric

heater, electric kettle, coffee maker,

etc.

• When a device is likely to fall under the

pedals and prevent the brake pedal

from being depressed, such as a hair

dryer, AC adapter, mouse, etc.

●

Do not use devices which produce

steam while the windows are closed.

Doing so may cause the windows to

fog up, reducing visibility and making it

difficult to drive safely. Also, the steam

may damage or negatively affect other

devices. If the device must be used,

stop the vehicle and open the windows

before use.

NOTICE

■

To avoid short circuit or malfunction

Observe the following precautions. Fail-

ure to do so may lead to the power out-

lets not operating correctly or damage to

the vehicle or a connected device.

●

Do not set a toaster or other device

which generates heat near the interior

components or on a seat. Heat may

cause these parts to melt or burn.

●

Do not use devices which are sensitive

to vibration or heat in the vehicle.

These devices may malfunction due to

vibration while driving or heat while

the vehicle is parked in the sun.

●

When not using a power outlet, make

sure to close the lid. If foreign matter or

a liquid enters the power outlet, it may

cause a malfunction or short circuit.
