Lexus ES300h (2023 year). Manual in english - page 16

266

5-2. Using the air conditioning system

fan speed.

Press the off switch to turn the fan off.

■

Changing the air flow mode

Press the airflow mode control switch.
The mode changes as follows each
time the switch is pressed. (



P.268)

■

Switching between outside air and
recirculated air modes

Press the outside/recirculated air
mode switch.
The mode changes as follows each
time the switch is pressed.

(recirculated air mode)



automatic mode



(outside

air mode)



(recirculated air

mode)

When the system is switched to automatic
mode, the air conditioning system oper-
ates automatically.

: This item cannot be selected when the

air conditioning is off.

■

Defogging the windshield

Defoggers are used to defog the wind-
shield and front side windows.
Press the windshield defogger switch.

Set the outside/recirculated air mode
switch to outside air mode if the recircu-
lated air mode is used. (It may switch auto-
matically.)
To defog the windshield and the side win-
dows early, turn the air flow and tempera-
ture up.
To return to the previous mode, press the
windshield defogger switch again when the
windshield is defogged.

■

Defogging the rear window and
outside rear view mirrors

Defoggers are used to defog the rear
window, and to remove raindrops, dew
and frost from the outside rear view
mirrors.
Press the rear window and outside
rear view mirror defoggers switch.

The defoggers will automatically turn off
after 15 minutes.

■

When the outside temperature exceeds

75°F (24°C) and the air conditioning

system is on

●

In order to reduce the air conditioning

power consumption, the air conditioning

system may switch to recirculated air

mode automatically. This may also

reduce fuel consumption.

●

Recirculated air mode is selected as a

default mode when the power switch is

turned to ON mode.

●

It is possible to switch to outside air mode

at any time by pressing the outside/recir-

culated air mode switch.

■

Fogging up of the windows

The windows will easily fog up when the

humidity in the vehicle is high. Turning

“A/C” on will dehumidify the air from the

outlets and defog the windshield effectively.

●

If you turn “A/C” off, the windows may

fog up more easily.

●

The windows may fog up if the recircu-

lated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up by the

vehicle is still drawn into the vehicle after

closing the windows, it is recommended

that the air intake mode be set to outside air

mode and the fan speed to any setting

except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode tem-

porarily is recommended in preventing

267

5-2. Using the air conditioning system

Interio

r fe

atures

dirty air from entering the vehicle interior

and helping to cool the vehicle when the

outside air temperature is high.

●

Outside/recirculated air mode may

automatically switch regardless of the air

conditioning setting depending on the

temperature setting or inside tempera-

ture.

■

Registering air conditioning settings to

electronic keys

●

Unlocking the vehicle using an electronic

key and turning the power switch to ON

mode will recall that key’s registered air

conditioning settings.

●

When the power switch is turned off, the

current air conditioning settings will auto-

matically be registered to the electronic

key that was used to unlock the vehicle.

●

The system may not operate correctly if

more than one electronic key is in the

vicinity or if the smart access system with

push-button start is used to unlock the

passenger door.

●

Vehicles with the driving position mem-

ory: The doors that can recall the air con-

ditioning setting

when unlocked using

the smart access system with push-but-

ton start can be changed. For details,

contact your Lexus dealer.

: The doors that can recall the driving posi-

tion memory are changed at the same
time.

■

Operation of the air conditioning sys-

tem in Eco drive mode

In Eco drive mode, the air conditioning sys-

tem is controlled as follows to prioritize fuel

efficiency:

●

Engine speed and compressor operation

controlled to restrict heating/cooling

capacity

●

Fan speed restricted when automatic

mode is selected

To improve air conditioning performance,

perform the following operations:

●

Turn off eco air conditioning mode

(



P.269)

●

Adjust the fan speed

●

Turn off Eco drive mode (



P.218)

■

When the outside temperature falls to

nearly 32°F (0°C)

The dehumidification function may not

operate even when “A/C” is selected.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning

system to the outside air mode.

●

During use, various odors from inside

and outside the vehicle may enter into

and accumulate in the air conditioning

system. This may then cause odor to be

emitted from the vents.

●

To reduce potential odors from occur-

ring, the start timing of the blower may be

delayed for a short period of time imme-

diately after the air conditioning system is

started in automatic mode.

●

When parking, the system automatically

switches to fresh air intake mode to

encourage better air circulation through-

out the vehicle, helping to reduce odors

that occur when starting the vehicle.

■

Using the Intelligent Assistant

Air conditioning system can be operated

using voice commands. For details, refer to

the “MULTIMEDIA OWNER’S MAN-

UAL”.

■

Air conditioning filter



P.338

■

Air conditioning system refrigerant

●

A label regarding the refrigerant of the

air conditioning system is attached to the

hood at the location shown in the follow-

ing illustration.

268

5-2. Using the air conditioning system

●

The meaning of each symbol on the label

are as follows:

■

Customization

Settings (e.g. A/C Auto switch operation)

can be changed.

(Customizable features:



P.417)

■

Air conditioning control screen

Select

in the main menu on the

Center Display.

Select “Climate”.

Select “Front”.

Sub menu

Selecting the sub menu item to switch the
screen display.
“Front”: Display the air conditioning con-
trol screen
“Options”: Display the option screen

Select the air flow mode

Each time the switch is selected, the airflow
mode is changed.

: Air flows to the upper body

: Air flows to the upper body and feet

: Air flows to the feet

Caution

Air conditioning system

Air conditioning system lubri-
cant type

Requires registered techni-
cian to service air conditioning
system

Flammable refrigerant

WARNING

■

To prevent the windshield from fog-

ging up

Do not use the windshield defogger

switch during cool air operation in

extremely humid weather. The difference

between the temperature of the outside

air and that of the windshield can cause

the outer surface of the windshield to fog

up, blocking your vision.

■

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the

hybrid system is off.

■

When repairing/replacing parts of

the air conditioning system

Have repair/replacement performed by

your Lexus dealer. When a part of the air

conditioning system, such as the evapo-

rator, is to be replaced, it must be

replaced with a new one.

Air conditioning control screen

269

5-2. Using the air conditioning system

rio

r fe

atu

: Air flows to the feet and the wind-

shield defogger operates

Turn the function on/off

Each of the following functions can be
switched on and off.
When the function is on, the indicator illu-
minates on the control screen.
“A/C”: Set cooling and dehumidification
function
“Sync”: Adjust the temperature for driver
seat and front passenger seat simultane-
ously (“Sync” mode) (



P.271)

: Select front seat concentrated

air flow mode (S-FLOW) (



P.270)

“Climate concierge”: Set Lexus Climate
Concierge (



P.264)

Fan speed level display

The current fan speed level is displayed.

■

Option screen

Select “Options” on the air condition-
ing control screen (



P.268).

The functions can be switched

(on)

and

(off).

Set eco air conditioning mode

Air conditioning and heater output is lim-
ited to prioritize fuel economy.

Prevent ice from building up on the
windshield and wiper blades

(Windshield wiper de-icer) (if
equipped)

■

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from

building up on the windshield and wiper

blades.
The windshield wiper de-icer will automati-

cally turn off after approximately 15 min-

utes.

■

Eco air conditioning mode

When Eco drive mode is selected using the

Driving Mode Select switch, eco air condi-

tioning mode turns on.
When a drive mode other than Eco drive

mode is selected, eco air conditioning

mode may turn off.

Press the automatic mode switch.

Press the outside/recirculated air
mode switch to switch to automatic
air intake mode.

The air conditioning system automatically

switches between outside air and recircu-

lated air modes.

Adjust the temperature setting.

To stop the operation, press the off
switch.

If the fan speed setting or air flow
modes are operated, the automatic
mode indicator goes off. However,
automatic mode for functions other

WARNING

■

To prevent burns (vehicles with wind-

shield wiper de-icer)

Do not touch the glass at lower part of

the windshield or to the side of the front

pillars when the windshield wiper de-icer

is on.

Using automatic mode

270

5-2. Using the air conditioning system

than that operated is maintained.

■

Using automatic mode

Fan speed is adjusted automatically

according to the temperature setting and

the ambient conditions.
Therefore, the fan may stop for a while until

warm or cool air is ready to flow immedi-

ately after the automatic mode switch is

pressed.
Cool air may blow around the upper body

even when the heater is on due to sunlight.

■

Windshield fog detection function

When automatic mode is set, the humidity

sensor detects fog on the windshield and

controls the air conditioning system to pre-

vent fog.

■

Automatic mode for air intake control

In automatic mode, the system detects

exhaust gas and other pollutants and auto-

matically switches between outside air and

recirculated air modes.
When the dehumidification function is off,

and the fan is operating, turning automatic

mode on will activate the dehumidification

function. The next time the dehumidification

function is turned off, the automatic mode

for switching between outside air and recir-

culated air modes is canceled.

This function automatically controls the
air conditioning airflow so that priority
is given to the front seats. When the
front passenger seat is not occupied,
airflow may switch to only the driver’s
seat. Unnecessary air conditioning is
suppressed, contributing to increased
fuel efficiency.
Front seat concentrated airflow mode
operates in the following situations.



No passengers are detected in the
rear seats



The windshield defogger is not
operating

While operating, the indicator on the
switch will turn on.

■

Manually turning front seat con-
centrated airflow mode on/off

In front seat concentrated airflow
mode, directing airflow to the front
seats only and to all seats can be
switched via switch operation. When
the mode has been switched manually,
automatic airflow control stops operat-
ing.

Select

on the air conditioning

NOTICE

■

Humidity sensor

In order to detect fog on the windshield,

a sensor which monitors the temperature

of the windshield, the surround humidity,

etc. is installed.
Follow these points to avoid damaging

the sensor:

●

Do not disassemble the sensor

●

Do not spray the glass cleaner on the

sensor or subject it to strong impacts

●

Do not stick anything on the sensor

Front seat concentrated airflow
mode (S-FLOW)

271

5-2. Using the air conditioning system

Interio

r fe

atures

control screen and switch the airflow.



Indicator illuminated: Airflow to the
front seats only



Indicator off: Airflow to all the seats

■

Operation of automatic airflow control

●

In order to maintain a comfortable inte-

rior, airflow may be directed to seats

without passengers immediately after the

hybrid system is started and at other

times depending on the outside tempera-

ture.

●

After the hybrid system is started, if pas-

sengers move around inside or enter/exit

the vehicle, the system cannot accurately

detect the presence of passengers and

automatic airflow control will not oper-

ate.

■

Operation of manual airflow control

Even if the function is manually switched to

directing airflow to only the front seats,

when a rear seat is occupied, it may auto-

matically direct airflow to all seats.

■

To return to automatic airflow control

With the indicator off, turn the power

switch off.

After 60 minutes or more elapse, turn

the power switch to ON mode.

To turn on the “Sync” mode, select the
“Sync” on the air conditioning control
screen.

The driver’s side temperature control
switches can be used to adjust the tem-
perature for the driver’s seat and passen-
ger’s seat side. To enter individual mode,
operate the passenger’s side temperature
control switches or select the “Sync” again.

The indicator on the air conditioning con-
trol screen comes on when the “Sync”
mode is on.

■

Location of air outlets

The air outlets and air volume changes
according to the selected air flow
mode.

■

Adjusting the air flow direction and
opening/closing the air outlets



Front center/front side

Direct air flow to the left or right, up
or down

Turn the knob to open or close the
vent

Adjusting the temperature for
driver seat and front passenger
seat simultaneously (“Sync”
mode)

Air outlet layout and operations

272

5-2. Using the air conditioning system



Rear

Direct air flow to the left or right, up
or down

Turn the knob to open or close the
vent

: If equipped

WARNING

■

To prevent the windshield defogger

from operating improperly

Do not place anything on the instrument

panel which may cover the air outlets.

Otherwise, air flow may be obstructed,

preventing the windshield defoggers

from defogging.

Heated steering wheel

/seat

heaters

/seat ventilators



Heated steering wheel

Warms up the grip of the steering wheel



Seat heaters

Warm up the seat upholstery



Seat ventilators

Maintain good air flow by sucking air
into the seats

The heated steering wheel/seat
heaters/seat ventilators can be
operated using the switches and
control screen on the Center Dis-
play (



P.274).

WARNING

■

To prevent minor burn injuries

Care should be taken if anyone in the fol-

lowing categories comes in contact with

the steering wheel or seats when the

heater is on:

●

Babies, small children, the elderly, the

sick and the physically challenged

●

Persons with sensitive skin

●

Persons who are fatigued

●

Persons who have taken alcohol or

drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

NOTICE

■

To prevent damage to the seat heat-

ers and seat ventilators

Do not put heavy objects that have an

uneven surface on the seat and do not

stick sharp objects (needles, nails, etc.)

into the seat.

273

5-2. Using the air conditioning system

rio

r fe

atu

Each time the switch is pressed, the
operation condition changes as fol-
lows.
AUTO (lit)



Hi (2 segments lit)



Lo (1 segment lit)



Off

The AUTO indicator

and/or level

indicator

illuminates during opera-

tion.

■

Operation condition

The power switch is in ON mode.

■

When AUTO mode is selected

The heated steering wheel function may

turn off according to the air conditioning set

temperature, outside temperature, etc.

■

Stored settings

When the power switch is turned to ON

mode, the stored settings are recalled.

■

Seat heaters

Each time the switch is pressed, the
operation condition changes as fol-

lows.
AUTO (lit)



Hi (3 segments lit)



Mid (2 segments lit)



Lo (1 segment

lit)



Off

The AUTO indicator

and/or level

indicator

illuminates during opera-

tion.

When in the AUTO mode, the seat heat-
ers or seat ventilators automatically oper-
ate according to circumstances.

■

Seat ventilators

Each time the switch is pressed, the
operation condition changes as fol-
lows.
AUTO (lit)



Hi (3 segments lit)



Mid (2 segments lit)



Lo (1 segment

lit)



Off

The AUTO indicator

and/or level indi-

cator

illuminates during operation.

When in the AUTO mode, the seat
heaters or seat ventilators automati-
cally operate according to circum-
stances.

NOTICE

■

To prevent 12-volt battery discharge

Do not use the functions when the hybrid

system is off.

Heated steering wheel

Seat heaters and ventilators

274

5-2. Using the air conditioning system

■

Operation condition

The power switch is in ON mode.

■

Air conditioning system-linked control

mode

When the seat ventilator fan speed level is

Hi (when “AUTO” is selected), the seat

ventilator fan speed may become higher

according to the fan speed of the air condi-

tioning system.

■

When AUTO mode is selected

The following functions may turn off

according to the air conditioning set tem-

perature, outside temperature, etc.

●

Seat heaters

●

Seat ventilators

■

Stored settings

When the power switch is turned to ON

mode, the stored settings of the following

functions are recalled.

●

Seat heaters

●

Seat ventilators

Select

in the main menu on the

Center Display.

Select “Comfort”.

Adjust the seat ventilator fan speed
level

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO



Hi (3 segments lit)



Mid (2

segments lit)



Lo (1 segment lit)



Off

When in the AUTO mode, the seat heat-
ers or seat ventilators automatically oper-
ate according to circumstances.

Adjust the seat heater temperature
level

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO



Hi (3 segments lit)



Mid (2

segments lit)



Lo (1 segment lit)



Off

When in the AUTO mode, the seat heat-
ers or seat ventilators automatically oper-
ate according to circumstances.

Adjust the heated steering wheel
temperature level

Each time the switch is pressed, the opera-
tion condition changes as follows.
AUTO



Hi (2 segments lit)



Lo (1 seg-

ment lit)



Off

WARNING

■

To prevent overheating and minor

burn injuries

Observe the following precautions when

using the seat heaters.

●

Do not cover the seat with a blanket or

cushion when using the seat heater.

●

Do not use seat heater more than nec-

essary.

Control screen

275

5-2. Using the air conditioning system

Interio

r fe

atures

Set the automatic mode

The following functions can be set to auto-
matic mode respectively.
When the automatic mode is on, the switch
on the screen illuminates.
• Left-hand side seat heater/seat ventila-

tor

• Right-hand side seat heater/seat ventila-

tor

• Heated steering wheel

■

Customization

Steering wheel heating preference in auto-

matic mode and the automatic mode set-

tings for the seat heaters and ventilators can

be changed. (Customizable features:



P.417)

276

5-3. Using the interior lights

5-3.Using the interior lights

Rear personal lights (



P.277)

Inside door handle lights (if equipped)

Instrument panel ornament lights (if equipped)

Shift lever light

Front personal lights (



P.277)

Interior lights (



P.277)

Clock light

Footwell lights

Power switch illumination

Door trim ornament lights (if equipped)

Door courtesy lights

Outer foot lights (front/front and rear)

Interior lights list

Location of the interior lights

A
B
C
D

E
F

277

5-3. Using the interior lights

Interio

r fe

atures

■

Turning the door position on

Press the door-linked interior light
switch

The lights are turned on and off according
to whether the doors are opened/closed.

■

Turning the lights on/off

Turns the lights on/off (touch the light)
The rear interior light turns on/off
together with the front interior light.

When a door is opened while the door
position is on, the lights turn on.

■

Turning the lights on/off



Front

Turns the lights on/off (touch the light)



Rear

Turns the lights on/off

■

Illuminated entry system

The lights automatically turn on/off accord-

ing to the power switch mode, the presence

of the electronic key, whether the doors are

locked/unlocked, and whether the doors

are open/closed.

■

To prevent the 12-volt battery from

being discharged

If the interior lights remain on when the

power switch is turned off, the lights will go

off automatically after 20 minutes.

■

When front interior light or front per-

sonal lights do not respond as normal

●

When water, dirt, etc., have adhered to

the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

■

The interior lights will turn on automati-

cally when

If any of the SRS airbags deploy (inflate) or

in the event of a strong rear impact, the

interior lights will turn on automatically.

Operating the interior lights

Operating the personal lights

278

5-3. Using the interior lights

The interior lights will turn off automatically

after approximately 20 minutes. The inte-

rior lights can be turned off manually. How-

ever, in order to help prevent further

collisions, it is recommended that they be

left on until safety can be ensured. (The inte-

rior lights may not turn on automatically

depending on the force of the impact and

conditions of the collision.)

■

Customization

Some functions can be customized. (Cus-

tomizable features:



P.417)

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

■

Removing light lenses

Never remove the lens for the front inte-

rior light and front personal lights. Other-

wise, the lights will be damaged. If a lens

needs to be removed, contact your

Lexus dealer.

279

5-4. Using the storage features

rio

r fe

atu

5-4.Using the storage features

Auxiliary boxes (



P.281)

Cup holders (



P.280)

Open tray (if equipped) (



P.281)/Wireless charger (if equipped) (

Console box (

Glove box (



P.280)

List of storage features

Location of the storage features

WARNING

■

Items that should not be left in the

vehicle

Do not leave glasses, lighters or spray

cans in the storage spaces, as this may

cause the following when cabin tempera-

ture becomes high:

●

Glasses may be deformed by heat or

cracked if they come into contact with

other stored items.

●

Lighters or spray cans may explode. If

they come into contact with other

stored items, the lighter may catch fire

or the spray can may release gas,

causing a fire hazard.

■

When storage compartments are not

in use

When driving or when the storage com-

partments are not in use, keep the lids

closed.

In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by an open lid

or the items stored inside.

280

5-4. Using the storage features

Open (press the glove box opener)

Unlock with the mechanical key

Lock with the mechanical key

■

Glove box light

The glove box light turns on when the tail

lights are on.

■

Trunk opener main switch



P.114

Press a button to open the console
box.

The console box can be opened from
either side.

■

Console box light

The console box light turns on when the tail

lights are on.



Front



Rear

To open, pull down the armrest and
open the lid.

Glove box

Console box

WARNING

■

Caution while driving

Keep the console box closed.

Injuries may result in the event of an acci-

dent or sudden braking.

NOTICE

■

To prevent damage to the console

box

When the console box is open, do not

apply excessive force in the direction

that it was opened.

Cup holders

281

5-4. Using the storage features

rio

r fe

atu



Instrument panel

Press in the button.



Front

■

Auxiliary box (front)

The insole for the auxiliary box can be

removed for cleaning.

WARNING

■

Items unsuitable for the cup holder

Do not place anything other than cups or

beverage cans in the cup holders. Even

when the lid is closed, items must not be

stored in the cup holders.

Other items may be thrown out of the

holder in the event of an accident or sud-

den braking, causing injury. If possible,

cover hot drinks to prevent burns.

NOTICE

■

To prevent damage to the cup holder

Stow the rear cup holder before stowing

the armrest.

Auxiliary boxes

Open tray (if equipped)

WARNING

■

Items unsuitable for the open tray

Observe the following precautions when

putting items in the open tray. Failure to

do so may cause items to be thrown out

of the tray in the event of sudden braking

or steering. In these cases, the items may

interfere with pedal operation or cause

driver distraction, resulting in an acci-

dent.

●

Do not store items in the tray that can

easily shift or roll out.

●

Do not stack items in the tray higher

than the tray’s edge.

●

Do not put items in the tray that may

protrude over the tray’s edge.

Content .. 14 15 16 17 ..
