WARNING

●

Do not attach anything to areas such as the doors,
windshield, side windows, front or rear pillars, roof
side rails and assist grips.

●

Do not hang coat hangers or other hard objects on the coat hooks. These items could
become projectiles if the SRS curtain shield airbags deploy, possibly leading to death
or serious injury.

●

If a vinyl cover is attached to the area where the SRS knee airbag deploys, be sure to
remove it.

●

Do not use seat accessories which cover the parts from which the SRS airbags deploy,
as they may interfere with inflation of the SRS airbags. Such accessories may prevent
the SRS airbags from deploying correctly, may disable the system or cause the SRS
airbags to inflate unintentionally, possibly resulting in death or serious injury.

●

Do not strike or apply significant force to the SRS airbag system components, front
doors or their surrounding area. Doing so may cause the SRS airbags to malfunction.

●

Do not touch any components of the SRS airbags immediately after the SRS airbags
have deployed (inflated) as they may be hot.

●

If breathing becomes difficult after the SRS airbags have deployed, open a door or
window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any
residue as soon as possible to prevent skin irritation.

●

If a part where an SRS airbag is stored is damaged or cracked, have it replaced by
your Lexus dealer.

●

Do not place anything, such as a cushion, on the front passenger's seat. Doing so
will disperse the passenger’s weight, which prevents the sensor from detecting the
passenger’s weight properly. As a result, the SRS front airbags for the front passenger’s
seat may not deploy in the event of a collision.

■

Modification and disposal of SRS airbag system components

Do not dispose of your vehicle or perform any of the following modifications without
consulting your Lexus dealer.
The SRS airbags may malfunction or deploy unintentionally, possibly leading to death or
serious injury.

●

Removal, installation, disassembly or repair of the SRS airbags

●

Repair, removal or modification of the following parts or their surrounding

•

Steering wheel

6-3. Reducing impact to the occupants in a collision

542

WARNING

•

Instrument panel

•

Dashboard

•

Seats

•

Seat upholstery

•

Front pillars

•

Side pillars

•

Rear pillars

•

Roof side rails

•

Front door panels

•

Front door trim

•

Front door speakers

●

Modifications to the front door panels (such as making holes in them)

●

Repair or modification of the following parts or their surrounding

•

Front fender

•

Front bumper

•

Sides of the vehicle interior

●

Installation of the following parts or accessories

•

Bull bars or kangaroo bars

•

Snow plows

•

Winches

●

Modifications to the vehicle's suspension

●

Installation of electronic devices such as mobile two-way radios (RF-transmitter) and
CD players

●

Modifications to your vehicle for a persons with a physical disability

 Related Links

Operation of emergency shut off system(P. 635)
Locking/unlocking the doors using smart access system with push-button start(P. 119)
Driving assist systems(P. 379)
Location of the interior lights(P. 296)
Using the emergency flashers to warn other drivers(P. 633)
Safety Connect(P. 550)

6-3. Reducing impact to the occupants in a collision

543

6

Driving suppor

t s

ystem

Front passenger occupant classification system

Your vehicle is equipped with a front passenger occupant classification system.
This system detects the conditions of the front passenger seat and activates or
deactivates the following airbags.

●

SRS front passenger airbag

●

SRS front passenger knee airbag

●

Front passenger's seat SRS seat cushion airbag

A

SRS warning light

B

Front passenger’s seat belt reminder light

C

"AIR BAG OFF" indicator light

D

"AIR BAG ON" indicator light

WARNING

■

Front passenger occupant classification system precautions

Observe the following precautions regarding the front passenger occupant classification
system. Failure to do so may cause death or serious injury.

●

Wear the seat belt properly.

●

Make sure the front passenger’s seat belt plate has not been left inserted into the
buckle before someone sits in the front passenger seat.

●

Make sure the "AIR BAG OFF" indicator light is not illuminated when using the seat
belt extender for the front passenger seat. If the "AIR BAG OFF" indicator light is
illuminated, disconnect the extender tongue from the seat belt buckle, and reconnect
the seat belt. Reconnect the seat belt extender after making sure the "AIR BAG ON"
indicator light is illuminated. If you use the seat belt extender while the "AIR BAG

6-3. Reducing impact to the occupants in a collision

545

6

Driving suppor

t s

ystem

WARNING

OFF" indicator light is illuminated, the SRS airbags for the front passenger will not
activate, which could cause death or serious injury in the event of a collision.

●

Do not apply a heavy load to the front passenger seat or equipment (e.g. seatback
pocket or armrest).

●

Do not put weight on the front passenger seat by putting your hands or feet on the
front passenger seat seatback from the rear passenger seat.

●

Do not let a rear passenger lift the front passenger seat with their feet or press on the
seatback with their legs.

●

Do not put objects under the front passenger seat.

●

Do not recline the front passenger seatback so far that it touches a rear seat. This may
cause the "AIR BAG OFF" indicator light to be illuminated, which indicates that the
SRS airbags for the front passenger will not activate in the event of a severe accident. If
the seatback touches the rear seat, return the seatback to a position where it does not
touch the rear seat. Keep the front passenger seatback as upright as possible when the
vehicle is moving. Reclining the seatback excessively may lessen the effectiveness of
the seat belt system.

●

If an adult sits in the front passenger seat, the "AIR BAG ON" indicator light is
illuminated. If the "AIR BAG OFF" indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn correctly.
If the "AIR BAG OFF" indicator still remains illuminated, either ask the passenger to
move to the rear seat, or if that is not possible, move the front passenger seat fully
rearward.

●

When it is unavoidable to install a forward-facing child restraint system on the front
passenger seat, install the child restraint system on the front passenger seat in the
proper order.

●

Do not modify or remove the front seats.

●

Do not kick the front passenger seat or subject it to severe impact. Otherwise, the SRS
warning light may come on to indicate a malfunction of the front passenger occupant
classification system.
In this case, contact your Lexus dealer immediately.

●

Child restraint systems installed on the rear seat should not contact the front seat-
backs.

●

Do not use a seat accessory, such as a cushion and seat cover, that covers the seat
cushion surface.

●

Do not modify or replace the upholstery of the front seat.

6-3. Reducing impact to the occupants in a collision

546

 Related Links

Child restraint system(P. 92)
Child restraint system installation method(P. 94)

Front passenger occupant classification system conditions and opera-
tion

▶

Adult

(1)

Indicators / warning
lights

"AIR BAG ON" and "AIR BAG OFF"
indicator lights

"AIR BAG ON"

SRS warning light

Off

Front passenger’s seat belt reminder
light

Off

(2)

 or flashing

(3)

Devices

Front passenger airbag

Activated

Seat cushion airbag in the front pas-
senger side

Activated

(2)

 or deacti-

vated

(3)

(1)

The system judges a person of adult size as an adult. When a smaller adult sits in the

front passenger seat, the system may not recognize him/her as an adult depending on

his/her physique and posture.

(2)

In the event the front passenger is wearing a seat belt.

(3)

In the event the front passenger does not wear a seat belt.



▶

Child

(3)

Indicators / warning
lights

"AIR BAG ON" and "AIR BAG
OFF" indicator lights

"AIR BAG OFF" or "AIR
BAG ON"

(3)

SRS warning light

Off

Front passenger’s seat belt re-
minder light

Off

(1)

 or flashing

(2)

Devices

Front passenger airbag

Deactivated or activated

(3)

Seat cushion airbag in the front
passenger side

Deactivated or activated

(3)

(1)

(1)

In the event the front passenger is wearing a seat belt.

(2)

In the event the front passenger does not wear a seat belt.

(3)

For some children, child in seat, child in booster seat or child in convertible seat, the

system may not recognize him/her as a child. Factors which may affect this can be the

physique or posture.



6-3. Reducing impact to the occupants in a collision

547

6

Driving suppor

t s

ystem

▶

Child restraint system with infant

(3)

Indicators / warning
lights

"AIR BAG ON" and "AIR BAG OFF"
indicator lights

"AIR BAG OFF"

(4)

SRS warning light

Off

Front passenger’s seat belt reminder
light

Off

(1)

 or flashing

(2)

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passen-
ger side

(1)

In the event the front passenger is wearing a seat belt.

(2)

In the event the front passenger does not wear a seat belt.

(3)

Never install a rear-facing child restraint system on the front passenger seat. A

forward-facing child restraint system should only be installed on the front passenger

seat when it is unavoidable.

(4)

In case the indicator light is not illuminated, consult this manual on how to install the

child restraint system properly.



▶

Unoccupied

Indicators / warning lights

"AIR BAG ON" and "AIR BAG OFF" indi-
cator lights

"AIR BAG OFF"

SRS warning light

Off

Front passenger’s seat belt reminder light

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger
side

▶

System malfunction

Indicators / warning lights

"AIR BAG ON" and "AIR BAG OFF" indi-
cator lights

"AIR BAG OFF"

SRS warning light

On

Front passenger’s seat belt reminder light

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger
side

6-3. Reducing impact to the occupants in a collision

548

7

Wireless communication

7-1. Connected Services

Safety Connect .......................

550

Remote Connect.....................

554

Service Connect......................

555

549

7

W

ireles
s communication

Connected Services

Safety Connect

*

Safety Connect is a subscription-based telematics service that uses Global Posi-
tioning System (GPS) data and embedded cellular technology to provide safety
and security features to subscribers. Safety Connect is supported by Lexus’ desig-
nated response center, which operates 24 hours per day, 7 days per week.Safety
Connect service is available by subscription on select, telematics hardware-equip-
ped vehicles.By using the Safety Connect service, you are agreeing to be bound
by the Telematics Subscription Service Agreement and its Terms and Conditions,
as in effect and amended from time to time, a current copy of which is available at
Lexus.com. All use of the Safety Connect service is subject to such then-applicable
Terms and Conditions.

System components



A

Microphone

B

[SOS] button

C

LED light indicators

Services

Subscribers have the following Safety Connect services available:

●

Automatic Collision Notification

*1

Helps drivers receive necessary response from emergency service provid-
ers.

→

 P.552

●

Stolen Vehicle Location
Helps drivers in the event of vehicle theft.

→

 P.552

●

Emergency Assistance Button ([SOS])
Connects drivers to response-center support.

→

 P.552

●

Enhanced Roadside Assistance
Provides drivers various on-road assistance.

→

 P.552

* :

If equipped

*1 :

U.S. Patent No. 7,508,298 B2

7-1. Connected Services

550

Subscription

After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus
dealer, call the following or push the [SOS] button in your vehicle for further
subscription details.

●

The United States
1-800-25-LEXUS (1-800-255-3987)

●

Canada
1-800-26-LEXUS (1-800-265-3987)

●

Puerto Rico
1-877-539-8777

NOTICE

■

Safety Connect Services Information

●

Phone calls using the vehicles Bluetooth

®

 technology will not be possible during

Safety Connect.

●

Safety Connect is available beginning Fall 2009 on select Lexus models (in the
contiguous United States only). Contact with the Safety Connect response center
is dependent upon the telematics device being in operative condition, cellular connec-
tion availability, and GPS satellite signal reception, which can limit the ability to reach
the response center or receive emergency service support. Enrollment and Telematics
Subscription Service Agreement required. A variety of subscription terms is available;
charges vary by subscription term selected and location.

●

Automatic Collision Notification, Emergency Assistance and Stolen Vehicle Location
will function in the United States, including Hawaii and Alaska, Puerto Rico and in
Canada, and Enhanced Roadside Assistance will function in the United States, Puerto
Rico and in Canada.

●

Automatic Collision Notification, Emergency Assistance, Stolen Vehicle and En-
hanced Road Assistance will not function in the United States Virgin Islands. For
vehicles first sold in the USVI, no Safety Connect services will function in and outside
the United States Virgin Islands.

●

Safety Connect services are not subject to section 255 of the Telecommunications
Act and the device is not TTY compatible.

7-1. Connected Services

551

7

W

ireles
s communication

NOTICE

■

Languages

The Safety Connect response center will offer support in multiple languages. The Safety
Connect system will offer voice prompts in English, Spanish, and French. Please indicate
your language of choice when enrolling.

■

When contacting the response center

You may be unable to contact the response center if the network is busy.

Safety Connect LED light Indicators

When the power switch is turned to ON, the red indicator light comes on for 2
seconds then turns off. Afterward, the green indicator light comes on, indicating
that the service is active.The following indicator light patterns indicate specific
system usage conditions:

●

Green indicator light on = Active service

●

Green indicator light flashing = Safety Connect call in process

●

Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)

●

No indicator light (off) = Safety Connect service not active

Safety Connect services

■

Automatic Collision Notification

In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent receives
the vehicle’s location and attempts to speak with the vehicle occupants to assess
the level of emergency. If the occupants are unable to communicate, the agent
automatically treats the call as an emergency, contacts the nearest emergency
services provider to describe the situation, and requests that assistance be sent to
the location.

■

Stolen Vehicle Location

If your vehicle is stolen, Safety Connect can work with local authorities to assist
them in locating and recovering the vehicle. After filing a police report, call the
Safety Connect response center at 1-800-25-LEXUS (1-800-255-3987) in the
United States, 1-877-539-8777 in Puerto Rico or 1-800-265-3987 in Canada,
and follow the prompts for Safety Connect to initiate this service.
In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-
Connect-equipped vehicle location data may, under certain circumstances, be

7-1. Connected Services

552

shared with third parties to locate your vehicle. Further information is available at
Lexus.com.

■

Emergency Assistance Button ([SOS])

In the event of an emergency on the road, push the [SOS] button to reach the
Safety Connect response center. The answering agent will determine your vehicle’s
location, assess the emergency, and dispatch the necessary assistance required.
If you accidentally press the [SOS] button, tell the response-center agent that you
are not experiencing an emergency.

■

Enhanced Roadside Assistance

Enhanced Roadside Assistance adds GPS data to the already included warranty-
based Lexus roadside service.
Subscribers can press the [SOS] button to reach a Safety Connect response-cen-
ter agent, who can help with a wide range of needs, such as: towing, flat tire, fuel
delivery, etc. For a description of the Roadside Assistance services and their limita-
tions, please see the Safety Connect Terms and Conditions, which are available at
Lexus.com.

Safety information for Safety Connect

Important! Read this information about exposure to radio frequency signals before
using Safety Connect;The Safety Connect system installed in your vehicle is a
low-power radio transmitter and receiver. It receives and also sends out radio
frequency (RF) signals.In August 1996, the Federal Communications Commission
(FCC) adopted RF exposure guidelines with safety levels for mobile wireless
phones. Those guidelines are consistent with the safety standards previously set by
the following U.S. and international standards bodies.

●

ANSI (American National Standards Institute) C95.1 [1992]

●

NCRP (National Council on Radiation Protection and Measurement) Report
86 [1986]

●

ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]

Those standards were based on comprehensive and periodic evaluations of the
relevant scientific literature. Over 120 scientists, engineers, and physicians from
universities, and government health agencies and industries reviewed the available
body of research to develop the ANSI Standard (C95.1).
The design of Safety Connect complies with the FCC guidelines in addition to
those standards.

7-1. Connected Services

553

7

W

ireles
s communication

Remote Connect

Remote Connect is a smartphone application that lets you view and remotely
control certain aspects of your vehicle.For details about the functions and services
of this application, refer to

http://www.lexus.com/enform/

.Function of the Remote

Connect is achieved by using an embedded cellular device in the vehicle (DCM:
Data Communication Module).

Remote Connect subscription

After you sign the Telematics Subscription Service Agreement, download the
Lexus App from your smartphone’s app store, and register within the app (or enroll
and complete registration at the dealer), you can begin using these services.A
variety of subscription terms are available. Contact your Lexus dealer,or call
1-800-25-LEXUS (1-800-255-3987) for further subscription details.

INFORMATION

■

Availability of service

Remote Connect is not available in some countries or areas.

■

Remote Connect Information

●

Remote Connect should only be used by authorized users.

●

Laws in some communities may require that the vehicle be within view of the user
when operating Remote Connect. In some states, use of Remote Connect may violate
state or local laws. Before using Remote Connect, check your state and local laws.

●

Any malfunction of the Lexus should be repaired by your Lexus dealer.

●

Remote Connect is designed to work at temperatures above -22°F (-30°C). This
specification is related to the Remote Connect operation, but is dependent on the
vehicle’s operating temperature range which may be different.

●

Content is subject to change without notice.

●

Some features of the Remote Connect may not be available on some models.

●

Additional information can be found at

https://www.lexus.com/enform/

.

●

Availability of functions of the Remote Connect service is dependent on network
reception level.

■

Safety information for Remote Connect

Refer to the safety information for Safety Connect:

→

 P.553

7-1. Connected Services

554

Service Connect

Service Connect uses embedded telematics hardware to collect and transmit
vehicle data that allows Lexus to provide:

●

Vehicle Health Report (VHR) (Safety Recalls, Service Campaigns, Current
Vehicle Alerts, Required Maintenance, and Vehicle Condition Status)

●

Maintenance Notifications

●

Vehicle Alert Notifications

For details about this service and how to register, refer to

http://www.lexus.com/

enform/

. The Service Connect is achieved by using a Data Communication Mod-

ule (DCM) built in the vehicle.

INFORMATION

■

Availability of service

Service Connect is not available in some countries or areas.

■

Service Connect Information

Availability of functions of the Service Connect is dependent on network reception level.

■

Safety information for Service Connect

Refer to the safety information for Safety Connect:

→

 P.553

7-1. Connected Services

555

7

W

ireles
s communication

8

Maintenance and care

8-1. Exterior maintenance and care

Washing the vehicle ..............

558

8-2. Cleaning and protecting the ve-

hicle interior

Cleaning the vehicle interi-

or ................................................

564

Cleaning the areas with sat-

in-finish metal accents........

566

Cleaning the leather areas..

567

Cleaning the synthetic

leather areas..........................

568

Cleaning DC/DC convert-

er air intake vent....................

569

8-3. Maintenance

Maintenance requirements

......................................................

573

Scheduled maintenance

outline........................................

574

Do-it-yourself maintenance

......................................................

575

General maintenance ...........

576

Engine compartment main-

tenance items list ..................

577

Luggage compartment

maintenance item list ..........

578

Vehicle interior mainte-

nance items list ......................

579

Vehicle exterior mainte-

nance items list .....................

580

Emission inspection and

maintenance (I/M) pro-
grams.........................................

581

8-4. Inspection of consumables

Do-it-yourself service pre-

cautions ...................................

582

Opening the hood .................

584

Engine compartment............

585

Adding washer fluid ...............

592

12-volt battery...........................

593

Air conditioning filter main-

tenance.....................................

596

8-5. Tire maintenance

Tire maintenance ....................

598

Tire inspection items...............

599

Run-flat tire features...............

602

Operation of the tire pres-

sure warning system...........

603

Checking tire inflation pres-

sure..............................................

614

Lifting the vehicle with a

floor jack....................................

616

Rotating the tires.......................

617

Wheels..........................................

618

Replacing the tire ....................

620

Headlight aim............................

629

557

8

Maintenance and car

e

Exterior maintenance and care

Washing the vehicle

WARNING

●

When washing the vehicle, do not apply water to the inside of the engine compart-
ment.
If water contacts electrical components, it may cause the vehicle to catch fire.

●

Exhaust gasses cause the exhaust pipes to become quite hot.
When washing the vehicle, be careful not to touch the exhaust pipes until they have
cooled sufficiently. Touching a hot exhaust pipe can cause burns.

NOTICE

■

To prevent paint deterioration and corrosion of the body and components (wheels,
etc.)

●

Wash the vehicle immediately in the following cases:

•

After driving near the sea coast

•

After driving on salted roads

•

If coal tar or tree sap is present on the paint surface

•

If dead insects, insect droppings or bird droppings are present on the paint surface

•

After driving in an area contaminated with soot, oily smoke, mine dust, iron powder
or chemical substances

•

If the vehicle becomes heavily soiled with dust or mud

•

If liquids such as benzine or gasoline are spilled on the paint surface

●

If the paint is chipped or scratched, have it repaired immediately.

●

To prevent the wheels from corroding, remove any dirt and store in a place with low
humidity when storing the wheels.

■

To prevent damage to the windshield wiper arms

When lifting the wiper arms away from the windshield, pull the driver side wiper arm
upward first, and repeat for the passenger side. When returning the wipers to their
original position, do so from the passenger side first.

Perform cleaning in a manner appropriate to each component and its material.

●

Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly with water.

●

Wipe away any water.

8-1. Exterior maintenance and care

558

INFORMATION

■

Self-restoring coat

The vehicle body has a self-restoring coating that is resistant to small surface scratches
caused by a car wash, etc.

●

The coating lasts for 5 to 8 years from when the vehicle is delivered from the plant.

●

The restoration time differs depending on the depth of the scratch and outside
temperature.
The restoration time may become shorter when the coating is warmed by applying
warm water.

●

Deep scratches caused by keys, coins, etc., cannot be restored.

●

Do not use waxes that contain abrasives.

■

When using a car wash

If the door handle becomes wet while the electronic key is within the effective range,
the door may lock and unlock repeatedly. In that case, follow the following correction
procedures to wash the vehicle:

●

Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the
vehicle is being washed.
Take care to ensure that the key is not stolen.

●

Set the electronic key to battery-saving mode to disable the smart access system with
push-button start.

■

Brake pads and calipers

Rust may form if the vehicle is parked with wet brake pads or disc rotors, causing them
to stick. Before parking the vehicle after it is washed, drive slowly and apply the brakes
several times to dry the parts.

Using an automatic car wash

NOTICE

When using an automatic car wash, move the wiper lever to the off position.
If the wiper lever is in the AUTO position, the wipers may operate unintentionally and the
wiper blades may be damaged.

●

Perform the following before washing your vehicle:

•

Fold the mirrors.

•

Vehicles with power back door:
Turn off the power back door.

Start washing from the front of the vehicle.

8-1. Exterior maintenance and care

559

8

Maintenance and car

e
