INFORMATION

Observe the following precautions when installing, removing, and handling tire chains:

●

Install and remove tire chains in a safe location.

●

Install tire chains to the front tires only.
Do not install tire chains to the rear tires.

●

Install tire chains following the instructions provided with the tire chains.

●

Install tire chains to the front tires as tightly as possible. Retighten the chains after
driving 1/4 - 1/2 mile (0.5 - 1.0 km).

WARNING

Observe the following precautions when tire chains are installed to the vehicle.
Failure to do so may lead to the vehicle not being able to be driven safely.

●

Do not drive in excess of the speed limit specified for the tire chains being used, or 30
mph (50 km/h), whichever is lower.

●

Avoid driving on bumpy road surfaces or over potholes.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations
that cause sudden engine braking.

●

Slow down sufficiently before entering a curve to ensure that vehicle control is
maintained.

●

Do not use LTA (Lane Tracing Assist).

●

Do not use LDA (Lane Departure Alert).

NOTICE

■

Fitting tire chains

The tire pressure warning valves and transmitters may not function correctly when tire
chains are fitted.

■

Selecting tire chains

Use the correct tire chain size when mounting the tire chains. Chain size is
regulated for each tire size.

●

Vehicles with 235/60R18 tires

3-5. Driving when it is cold

251

Driving accor

ding to the conditions

Side chain (0.12 in. [3 mm] in diameter)

Side chain (0.39 in. [10 mm] in width)

Side chain (0.98 in. [25 mm] in length)

Cross chain (0.16 in. [4 mm] in diameter)

Cross chain (0.55 in. [14 mm] in width)

Cross chain (0.98 in. [25 mm] in length)

●

Vehicles with 235/50R20 tires
Tire chains cannot be mounted on the 235/50R20 tires.
Snow tires should be used instead.

■

Regulations on the use of tire chains

Regulations regarding the use of tire chains vary depending on location and type of
road. Always check local regulations before installing chains.

3-5. Driving when it is cold

252

Cold weather driving tips

Things to check before driving in cold weather

Perform the following according to the driving conditions:

●

Do not try to forcibly open a window or move a wiper that is frozen. Pour warm
water over the frozen area to melt the ice. Wipe away the water immediately to
prevent it from freezing.

●

To ensure proper operation of the climate control system fan, remove any snow
that has accumulated on the air inlet vents in front of the windshield.

●

Check for and remove any excess ice or snow that may have accumulated on
the exterior lights, vehicle’s roof, chassis, around the tires or on the brakes.

●

Remove any snow or mud from the bottom of your shoes before getting in the
vehicle.

Precautions for driving in cold weather

Accelerate the vehicle slowly, keep a safe distance between you and the vehicle
ahead, and drive at a reduced speed suitable to road conditions.

Precautions for parking in cold weather

●

Turn automatic mode of the parking brake off. Otherwise, the parking brake
may freeze and not be able to be released automatically.
Also, avoid using the following as the parking brake may operate automatically,
even if automatic mode is off.

•

Brake hold system

•

Advanced Park (Remote Controlled)

●

Park the vehicle and shift the shift position to P without setting the parking
brake. The parking brake may freeze up, preventing it from being released. If
the vehicle is parked without setting the parking brake, make sure to block the
wheels.

Failure to do so may be dangerous because it may cause the vehicle to move unexpect-
edly, possibly leading to an accident.

●

When the parking brake is in automatic mode, release the parking brake after
change the shift position to P.

●

If the vehicle is parked without setting the parking brake, confirm that the shift
lever cannot be moved out of P.

* :

If equipped

3-5. Driving when it is cold

253

Driving accor

ding to the conditions

●

Park the vehicle and change the shift podition to P without setting the parking
brake.
If the vehicle is parked without setting the parking brake, make sure to block the
wheels. Failure to do so may be dangerous because it may cause the vehicle to
move unexpectedly, possibly leading to an accident.

●

If the vehicle is left parked with the brakes damp in cold temperatures, there is a
possibility of the brakes freezing.

INFORMATION

■

Linked mirror function when reversing

When used in cold weather during reverse driving, the door mirror could be frozen and
may not automatically point the mirror surface downward. In this event, remove any ice
and snow from the mirror surface.

Warming the windshield to allow frozen wipers to be moved

Use the windshield wiper de-icer to help prevent the windshield wiper blades from
freezing to the windshield.
Select the [Deicer] switch on the option screen.

The windshield wiper de-icer will automatically turn off after a period of time.

WARNING

Do not touch the lower part of the windshield or parts along the front pillars when the
windshield wiper de-icer is on, as they will be hot and may cause burns.

* :

If equipped

3-5. Driving when it is cold

254

Driving when in the fog or on a mountain road and visibility is poor

Fog light illumination

When driving in inclement weather, such as in rain and fog, turn on the front fog
lights to ensure forward visibility.

Using the fog lights

NOTICE

To prevent 12-volt battery discharge, do not leave the lights on longer than necessary
when the hybrid system is off.

Turns the front fog lights off

Turns the front fog lights on

INFORMATION

■

Fog lights can be used when

The low beam headlights are on.

3-6. Driving when in the fog or on a mountain road and visibility is poor

255

Driving accor

ding to the conditions

Utility vehicle precautions

This vehicle belongs to the utility vehicle class, which has higher ground clearance
and narrower tread in relation to the height of its center of gravity.

Utility vehicle feature

●

Specific design characteristics give it a higher center of gravity than ordinary
passenger cars. This vehicle design feature causes this type of vehicle to be
more likely to rollover. Utility vehicles have a significantly higher rollover rate
than other types of vehicles.

●

An advantage of the higher ground clearance is a better view of the road
allowing you to anticipate problems.

●

It is not designed for cornering at the same speeds as ordinary passenger
cars any more than low-slung sports cars designed to perform satisfactorily
under off-road conditions. Therefore, sharp turns at excessive speeds may cause
rollover.

WARNING

■

Utility vehicle precautions

Always observe the following precautions to minimize the risk of death or serious injury
or damage to your vehicle:

●

In a rollover crash, an unbelted person is significantly more likely to die than a person
wearing a seat belt. Therefore, the driver and all passengers should always fasten their
seat belts.

●

Avoid sharp turns or abrupt maneuvers, if at all possible. Failure to operate this vehicle
correctly may result in loss of control or vehicle rollover causing death or serious
injury.

●

Loading cargo on the roof luggage carrier (if equipped) will make the center of the
vehicle gravity higher. Avoid high speeds, sudden starts, sharp turns, sudden braking
or abrupt maneuvers, otherwise it may result in loss of control or vehicle rollover due
to failure to operate this vehicle correctly.

●

Always slow down in gusty crosswinds. Because of its profile and higher center of
gravity, your vehicle is more sensitive to side winds than an ordinary passenger car.
Slowing down will allow you to have better control.

●

Do not drive horizontally across steep slopes. Driving straight up or straight down is
preferred. Your vehicle (or any similar off-road vehicle) can tip over sideways much
more easily than forward or backward.

3-7. Utility vehicle precautions

257

Driving accor

ding to the conditions

Off-road driving

Your vehicle is not designed to be driven off-road. However, in the event that
off-road driving cannot be avoided, please observe the following precautions to
help avoid the areas prohibited to vehicles.

●

Drive your vehicle only in areas where off-road vehicles are permitted to travel.

●

Respect private property. Get owner’s permission before entering private prop-
erty.

●

Do not enter areas that are closed. Honor gates, barriers and signs that restrict
travel.

●

Stay on established roads. When conditions are wet, driving techniques should
be changed or travel delayed to prevent damage to roads.

●

Avoid driving on very steep, slippery roads and other surfaces, such as sand,
where the tires are liable to lose traction. Your vehicle may not perform as well
as conventional AWD on-road vehicles on these surfaces.

INFORMATION

■

Additional information for off-road driving

For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertaining to driving your vehicle off-road, consult the
following organizations.

●

State and Local Parks and Recreation Departments

●

State Motor Vehicle Bureau

●

Recreational Vehicle Clubs

●

U.S. Forest Service and Bureau of Land Management

WARNING

■

Off-road driving precautions

Always observe the following precautions to minimize the risk of death or serious injury
or damage to your vehicle:

●

Drive carefully when off the road. Do not take unnecessary risks by driving in danger-
ous places.

●

Do not grip the steering wheel spokes when driving off-road. A bad bump could jerk
the wheel and injure your hands. Keep both hands and especially your thumbs on the
outside of the rim.

●

Always check your brakes for effectiveness immediately after driving in sand, mud,
water or snow.

3-7. Utility vehicle precautions

258

WARNING

●

After driving through tall grass, mud, rock, sand, water, etc., check that there is no
grass, bush, paper, rags, stone, sand, etc. adhering or trapped to the underbody. Clear
off any such matter from the underbody. If the vehicle is used with these materials
trapped or adhering to the underbody, a breakdown or fire could occur.

●

When driving off-road or in rugged terrain, do not drive at excessive speeds, jump,
make sharp turns, strike objects, etc. This may cause loss of control or vehicle rollover
causing death or serious injury. You are also risking expensive damage to your
vehicle’s suspension and chassis.

NOTICE

■

To prevent water damage

Take all necessary safety measures to ensure that water damage to the hybrid battery
(traction battery), hybrid system or other components does not occur.

●

Water entering the engine compartment may cause severe damage to the hybrid
system. Water entering the interior may cause the hybrid battery stowed under the
rear seats to short circuit.

●

Water entering the hybrid transmission and rear electric motor (traction motor) will
cause deterioration in transmission quality. The malfunction indicator may come on,
and the vehicle may not be drivable.

●

Water can wash the grease from wheel bearings, causing rusting and premature
failure, and may also enter the hybrid transmission case, reducing the gear oil’s
lubricating qualities.

■

When you drive through water

If driving through water, such as when crossing shallow streams, first check the depth of
the water and the bottom of the riverbed for firmness. Drive slowly and avoid deep water.

■

Inspection after off-road driving

●

Sand and mud that has accumulated around brake discs may affect braking efficiency
and may damage brake system components.

●

3-7. Utility vehicle precautions

259

Driving accor

ding to the conditions

Changing the driving characteristics

Driving modes

The following driving modes can be used according to the driving/usage condi-
tions.

Characteristics of each driving mode

Vehicles without Adaptive Variable Suspension System:

■

Normal mode

Suitable when driving in the city, for good fuel consumption efficiency, silence, and
drive-ability.

■

Eco mode

In contrast with Normal mode, torque generation is slower when stepping on the
accelerator pedal, air conditioning operations (heating/cooling) are restrained,
and driving becomes suited for improved fuel consumption.

■

Sport mode

Helps to ensure steering feel and accelerator response by controlling the hybrid
system and transmission. Suitable for sporty, fun driving, such as when driving on
mountain roads.
Vehicles with Adaptive Variable Suspension System:

■

Normal/Custom mode

●

Normal mode
Suitable when driving in the city, for good fuel consumption efficiency, silence,
and drive-ability.

●

Custom mode
Driving is possible by setting the desired function for power train control, chassis
control or air conditioning operations. Custom mode settings can only be
changed on the drive mode customization display of the center display.

■

Eco mode

In contrast to Normal mode when stepping on the accelerator pedal, torque
generation becomes slower, air conditioning operations (heating/cooling) are
restrained, and driving is suited for improved fuel consumption.

■

Sport mode

●

Sport S mode

3-8. Changing the driving characteristics

260

Through control of the hybrid system and transmission, the generated torque
when the accelerator pedal is depressed is increased. Making this mode suitable
for when powerful acceleration is desired.

●

Sport S+ mode
Through control of the hybrid system and transmission, the generated torque
when the accelerator pedal is depressed is further increased, and excellent sta-
bility is provided through comprehensive control of the steering and suspension.
Making this mode suitable for sporty driving.

INFORMATION

■

Operation of the air conditioning system in Eco mode

●

In the Eco mode, the air conditioning system is controlled as follows to prioritize fuel
efficiency.

•

Engine speed and compressor operation controlled to restrict heating/cooling
capacity

•

Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations.

•

Adjust the fan speed

•

Adjust the temperature setting

•

Turn off Eco mode

●

When the driving mode is set to Eco mode, the air conditioning system may automati-
cally change to Eco mode. To cancel eco mode, press [Eco heat/cool].

3-8. Changing the driving characteristics

261

Driving accor

ding to the conditions

Changing the driving mode

▶

Vehicles without Adaptive Variable Suspension System

Eco mode
When not in Eco mode, turn the driving
mode select switch to the left to change
the driving mode to Eco mode. The Eco
drive mode indicator will be displayed on
the multi-information display.

Sport mode
When not in Sport mode, turn the driving
mode select switch to the right to change
the driving mode to Sport mode. The Sport
mode indicator will be displayed on the
multi-information display.

Normal mode
Press the driving mode select switch to
change the driving mode to Normal mode
when Eco mode or Sport mode is selected.

▶

Vehicles with Adaptive Variable Suspension System

Eco mode
When not in Eco mode, turn the driving
mode select switch to the left to change
the driving mode to Eco mode. The Eco
drive mode indicator will be displayed on
the multi-information display.

Sport mode

●

Sport S mode
When not in Sport S mode, turn the
driving mode select switch to the right
to change the driving mode to Sport S
mode. The Sport S mode indicator will
be displayed on the multi-information
display.

●

Sport S+ mode
When Sport S mode, turn the driving
mode select switch to the right to change
the driving mode to Sport S+ mode.

3-8. Changing the driving characteristics

262

The Sport S+ mode indicator will be dis-
played on the multi-information display.

Normal/Custom mode
Press the switch to select Normal mode
or Custom mode. Each time the switch is
pressed, the system changes between Nor-
mal mode and Custom mode.
When Custom mode is selected, the Cus-
tom mode indicator will be displayed on the
multi-information display.
If the switch is pressed when in Eco mode
or Sport mode, the system will return to
Normal mode.

INFORMATION

■

Canceling Sport/Custom mode

●

Select another driving mode. Sport mode and Custom mode will be canceled auto-
matically when the power switch is turned off.

●

Normal mode and Eco mode will not be canceled automatically until another driving
mode is selected, even if the power switch is turned off.

■

Display of the multi-information display according to selected driving mode

According to the driving mode selected, the gauges displayed on the multi-information
display may change.

Lexus NX450H+ (2022 year). Manual in english - page 15
